Franklin 11835S10 Assembly

Figure #3 NET ASSEMBLY
RED TAB
2
11
8
9
6
4
BLUE TAB
Step Net Assembly Instructions
1. The net has been designed with red tabs to identify the top corners
and blue tabs to identify the bottom corners. Follow the numbered
sequence to attach the net.
2. Using the self-stick closure strips, tie the top corners first which are
identified by the two red tabs. Refer to 1 & 2 .
3. Using the self-stick closure strips, tie the front bottom corners which
are identified by the two blue tabs. Refer to 3 & 4 .
4. Stretch the net and using the self-stick closure strips, tie the back
bottom corners. Refer to 5 & 6 .
5. Fill in the top front section 7 with 4 self-stick strips,
6. Fill in each of the two side sections 8 with 4 self-stick strips,
7. Fill in each of the two base sections 9 with 3 self-stick strips,
8. Fill in the bottom back section
9. Fill in each of the two reinforcement sections
NOTE: Following goal assembly 6 ground stakes will secure goal.
Refer to sketch for recommended locations
For replacements parts call
1-781-341-5178 or 1-800-225-8649
OR visit www.franklinsports.com
7
RED TAB
1
8
10
3
BLUE TAB
with 4 self-stick strips.
10
with 3 self-stick strips.
11
Franklin Sports Inc.
Stoughton, MA. 02072
Made in China
www.franklinsports.com
SIZE: 12Ft.Wide x 6Ft.High x 5Ft.Deep
11
Work on a smooth, flat surface.
5
Lay out all components so they are in easy reach.
Read assembly instructions completely to familiarize
yourself with the components.
9
This goal is designed to provide many hours of enjoyment
if properly assembled and used only for the purpose
intended.
ALWAYS ANCHOR GOAL
Unsecured Goal Can Fall Over
Causing Serious Injury or Death
CAUTION:
Adult assembly required
Adult supervision is recommended when the goal is used
by children.
11835S10
SOCCER GOAL
(3.66 m x 1.83 m x 1.52 m)
BEFORE ASSEMBLY:
NEVER CLIMB ON GOAL
Goal Can Fall Over Causing
Serious Injury or Death
