Kohler DEVONSHIRE K-704516 Installation Manual

Features
• 3/4" (2 cm) adjustability per side
• Soft touch foam handle insert
• Corrosion proof
• Full length magnet provides secure door closure
• Tempered glass ensures maximum safety and
durability
• Right or left door swing
• CleanCoat
glass coating
TM
• 72" (182.9 cm) height
Codes/Standards Applicable
Specified model meets or exceeds the following:
• ANSI Z97.1 (tempered glass)
Specified Model
Model Description
K-704516 Shower enclosure - for use with K-1018 walls and
K-9455 receptor
K-704517 Shower enclosure - for use with K-9455 receptor
Recommended Accessories
K-1018 Shower walls
K-9132 Shower drain with grid strainer
K-9455 Shower receptor
Product Specification
The shower enclosure shall be 72" (182.9 cm) in height. The shower enclosure shall have right or left door swing with
CleanCoat glass coating. The shower enclosure shall be corrosion proof. The shower enclosure shall have a soft touch foam
TM
handle insert, full length magnet to provide secure door closure, and tempered glass to ensure maximum safety and durability.
The shower enclosure shall be Kohler Model K-_______-_______-_______.
Page 1 of 2
F
1024187-4-
NEO-ANGLE SHOWER
Colors/Finishes
•
BH: Bright Brass
•
SH: Bright Silver
•
MX: Matte Nickel
Glass Options
•
B1: Intrex
TM
•
L: Clear
Glass Options
❑ B1 ❑ L
❑ B1 ❑ L
DEVONSHIRE
ENCLOSURES
K-704516
ALSO K-704517
Frame Finishes/Colors
❑ SH ❑ BH ❑ MX
❑ SH ❑ BH ❑ MX
❑ 0 ❑ Other_______
❑ 0 ❑ Other_______
❑ CP ❑ Other_______
USA: 1-800-4-KOHLER
Canada: 1-800-964-5590
kohler.com
®
