- Page 1 Flex2-L User Manual CAT.1 Revision 1.0...
-
Page 2: Table Of Contents
Index FLEX2-L USER MANUAL ............................1 INTRODUCTION .............................. 3 PHYSICAL AND ELECTRICAL SPECIFICATIONS .................. 3 WIRE HARNESS ............................... 4 DESCRIPTION ..............................5 LED INDICATORS ............................6 PROGRAMMING AND CONFIGURATION SUMMARY ................7 ... -
Page 3: Introduction
1 Introduction The Flex2-L is a remote start and security tracking device that uses a GPS satellite receiver to determine location information and an LTE transceiver to communicate information to and from a land based server. This document outlines the operation and configuration of the FLEX2-L product line using the supplied tracking application.This... -
Page 4: Description
TheFLEX2-LPCB devices. For PCB equipment, the PCB of this equipment is divided into two, one is the daughter board of FLEX2-L, and the other is the mother board. As shown below. Complete equipment of Flex2-L. For the complete equipment, as shown below. After installation, the device sometimes connects the harness, and some will not connect the harness. -
Page 5: Led Indicators
Connect the DC 12V cable to the connector of 12 PINon the device, the other side connect to DC 12V, you can use the DC 12v cable to supply power The other interfaces of theFLEX2-L device are shown in the following pictures.(The Modem USB PORT on device is for modem debug and update firmware) 5 LED Indicators There are 3 indicator LEDs on the device, which are used to indicate the status of cellular communications... -
Page 6: Tracking Behavior Summary
1) Power State Reporting The FLEX2-L can be configured to report power up and rebooting behavior in a variety of ways depending on what is desired. Cold Boot, Warm Boot, and first GPS Acquisition are reported if so configured following Power Up events, power cycling, commanded reboots, and configured periodic reboots. - Page 7 If the device is equipped with a backup battery, then it will also report Power Disconnected and Power Connected events when primary power is removed and restored. 2) Moving State A device enters Moving state either due to detection of a hardwired Ignition signal, an increase in the supply voltage, detection of movement by the GPS, or an “Absolute G”...
- Page 8 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 9 FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with FCC RF Exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for the transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co‐located or operating in conjunction with any other antenna or transmitter.
