Leader in Electrics & Automation
Compact & Powerful Inverter
STARVERT
iG5A
0.4~7.5kW 3Phase 200~230Volts
0.4~7.5kW 3Phase 380~480Volts
Automation Equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STARVERT iG5A and is the answer not in the manual?

Questions and answers

Related Manuals for LS Industrial Systems STARVERT iG5A

Summary of Contents for LS Industrial Systems STARVERT iG5A

  • Page 1 Leader in Electrics & Automation Compact & Powerful Inverter STARVERT iG5A 0.4~7.5kW 3Phase 200~230Volts 0.4~7.5kW 3Phase 380~480Volts Automation Equipment...
  • Page 2 Inverter STARVERT iG5A LS Starvert iG5A is very competitive in its price and shows an upgraded functional strength compared to iG5. User-friendly interface, extended inverter ranges up to 7.5kW, superb torque competence and small size of iG5A provides an optimum use environment.
  • Page 3 Compact & Powerful Inverter iG5A C o n t e n t s Overview Model & Type Standard Specifications Wiring Terminal Configurations Keypad Features Parameter Setting Trial Run Dimensions Braking Resistors and Peripheral Devices Function List Protective Functions Fault Remedy...
  • Page 4 iG5A Powerful & Upgraded Performance iG5A provides sensorless vector control, PID control, and ground-fault protection through powerful built-in functions. Sensorless vector control S S p p e e e e d d v v s s T T o o r r q q u u e e C C h h a a r r a a c c t t e e r r i i s s t t i i c c s s The built-in sensorless vector control provides the superb speed control and powerful high torque.
  • Page 5 Compact & Powerful Inverter iG5A RS-485 communication Connected to PC RS-485 - 232C converter Monitoring Checking operation status (Voltage, Current, Frequency, etc) Checking modified parameters Windows support Remote Control Convenient remote control to modify operation status (Forward/Reverse operation, Frequency, etc) Easy parameter setting Available to control up to 31 Inverters RS-485, Modbus communication...
  • Page 6 iG5A User-friendly Interface & Easy Maintenance The parameter setting becomes easier by adopting the 4 directions key. And iG5A supports easy maintenance via diagnosis and fan changeable structure. Diagnosis of output module Through easy parameter setting, iG5A can diagnose the status of output module.

  • Page 7: Compact Size

    Compact & Powerful Inverter iG5A Compact Size The compact size, improved by 46% smaller than iG5 achieves cost-efficiency and various applications. Same height from 0.4 to 4.0kW (128mm) Global standard compliance CE UL Global standard iG5A series complies with CE and UL (Type1) standards. PNP/NPN input Both PNP and NPN inputs become possible and these enable to use the outer power.

  • Page 8: Model & Type

    iG5A Model & Type Applicable motor ranges 200V Series 400V Series 0.4kW (0.5HP) SV004iG5A-4 SV004iG5A-2 0.75kW (1HP) SV008iG5A-2 SV008iG5A-4 1.5kW (2HP) SV015iG5A-2 SV015iG5A-4 2.2kW (3HP) SV022iG5A-2 SV022iG5A-4 3.7kW (5HP) SV037iG5A-2 SV037iG5A-4 4.0kW (5.4HP) SV040iG5A-2 SV040iG5A-4 5.5kW (7.5HP) SV055iG5A-2 SV055iG5A-4 7.5kW (10HP) SV075iG5A-2 SV075iG5A-4 iG5A...

  • Page 9: Standard Specifications

    Compact & Powerful Inverter iG5A Standard Specifications 200V Series SV� � � � � � iG5A-2 � � (HP) Max. capacity (kW) 0.75 Capacity (kVA) 0.95 12.2 Rated current (A) Output rating Max. output frequency (Hz) Max. output voltage (V) 3 phase 200~230 Voltage (V) 3 phase 200~230VAC (+10%, -15%)
  • Page 10 iG5A Standard Specifications Control method V/F, Sensorless vector control Digital command: 0.01Hz Frequency setting resolution Analog command: 0.06Hz (Max. freq.: 60Hz) Digital command: 0.01% of Max. output frequency Frequency accuracy Analog command: 0.1% of Max. output frequency Control V/F pattern Linear, Squared, User V/F Overload capacity 150% per 1 min.
  • Page 11 Compact & Powerful Inverter iG5A Wiring DB resistor (Optional) 3 phase AC input (Rated input voltage) Ground 24V output Multi-function analog output FX (Forward run) signal: 0~10V RX (Reverse run) Input signal common BX (Emergency stop) RST (Trip reset) A contact output JOG (Jog operation) Input signal common A/B contact common...

  • Page 12: Terminal Configuration

    iG5A Terminal Configuration Specifications for power terminal block wiring • 5.5~7.5kW (200V/400V) • 2.2~4.0kW (200V/400V) • 0.4~1.5kW (200V/400V) Description Terminal R, S, T AC Line voltage input B1, B2 Connection terminal for DB resistor (Optional) U, V, W Connection terminal for motor 200V Series 400V Series Inverter capacity...

  • Page 13: Keypad Features

    Compact & Powerful Inverter iG5A Keypad Features Display Term Description Run key Run command STOP Stop command during operation, STOP/RESET key STOP/RESET RESET Reset command when a fault occurs. ▲ ▲ Up key Used to scroll through codes or increase parameter value ▼...

  • Page 14: Moving To Other Groups

    iG5A Moving to Other Groups Parameter groups There are 4 different parameter groups in iG5A series as shown below. Parameter group Description Drive group Basic parameters necessary for the inverter to run. Parameters such as Target frequency, Accel/Decel time settable. Function group 1 Basic function parameters to adjust output frequency and voltage.
  • Page 15 Compact & Powerful Inverter iG5A When changing ACC time from 5.0 sec to 16.0 sec ∙In the first code “0.00” , press the Up (▲) key once to go to the second code. ∙ACC [Accel time] is displayed. ∙Press the Ent (●) key once. ∙Preset value is 5.0, and the cursor is in the digit 0.

  • Page 16: Trial Run

    iG5A Trial Run Multi-step operation + Run/Stop via FX/RX + Max. frequency change Operation condition Operation command: Frequency command: Max. frequency change: Run/Stop via FX/RX Multi-step operation [Low (20), Middle (30), High (80)] From 60Hz to 80Hz Wiring P1 (Forward) P2 (Reverse) 3 phase AC input...
  • Page 17 Compact & Powerful Inverter iG5A Potentiometer (Volume) + Run/Stop via FX/RX + Accel/Decel time change Operation condition Operation command: Frequency command: Accel/Decel time: Run/Stop via FX/RX 0~60Hz analog input via potentiometer Accel-10sec, Decel-20sec Wiring Potentiometer 1~5kohm, 1/2W Motor 3 phase AC input 0~60Hz P1 (FX) Forward...
  • Page 18 iG5A Dimensions SV004iG5A-2 / SV008iG5A-2, SV004iG5A-4 / SV008iG5A-4 ∅ mm (inches) Inverter model (kW) W (mm) W1 (mm) H (mm) H1 (mm) D (mm) ∅ A (mm) B (mm) (kg) SV004IG5A-2 65.5 0.76 SV008IG5A-2 0.75 65.5 0.77 SV004IG5A-4 65.5 0.76 SV008IG5A-4 0.75 65.5...
  • Page 19 Compact & Powerful Inverter iG5A SV022iG5A-2 / SV037iG5A-2 / SV040iG5A-2, SV022iG5A-4 / SV037iG5A-4 / SV040iG5A-4 ∅ mm (inches) Inverter model (kW) W (mm) W1 (mm) H (mm) H1 (mm) D (mm) ∅ A (mm) B (mm) (kg) 120.5 1.84 SV022IG5A-2 SV037IG5A-2 120.5 1.89...

  • Page 20: Braking Resistors

    iG5A Braking Resistors and Peripheral Devices Braking resistors 100% braking 150% braking Voltage Inverter Resistor [Ω] Watt [W] Resistor [Ω] Watt [W] 0.75 200V Series 1000 1200 1800 1200 0.75 400V Series 1000 1000 1200 1) The wattage is based on Enable Duty (%ED) with continuous braking time 15sec. Breakers Breaker Breaker...

  • Page 21: Function List

    Compact & Powerful Inverter iG5A Function List Drive Group Parameter Factory Adj. during Description display name default During stop: Frequency command 0~400Hz 0.00 0.00 During run: Output frequency Accel time 0~6000sec Decel time 10.0 Drive mode 0 (Keypad), 1 (FX/RX-1), 2 (FX/RX-2), 3 (RS-485) 0 (Keypad-1), 1 (Keypad-2), 2 (V1S: -10~10V), 3 (V1: 0~10V) Frequency setting method 4 (I: 0~20mA), 5 (V1S+1), 6 (V1+I), 7 (RS-485)
  • Page 22 iG5A Function List Function group 1 Parameter Factory Adj. during Description display name default Torque Boost select 0 (Manual torque boost), 1 (Auto torque boost) Torque boost in forward direction 0~15% Torque boost in reverse direction V/F pattern 0 (Linear), 1 (Square), 2 (User V/F) User V/F frequency 1 0~400Hz 15.00...
  • Page 23 Compact & Powerful Inverter iG5A Function group 2 Parameter Factory Adj. during Description display name default Reset fault history 0 (No), 1 (Yes) 0 (NO) Dwell frequency 0~400Hz 5.00 Dwell time 0~10sec Skip frequency select 0 (No), 1 (Yes) 0 (NO) Skip frequency low limit 1 0~400Hz 10Hz...
  • Page 24 iG5A Function List Function group 2 Parameter Factory Adj. during Description display name default Rated slip frequency 0~10Hz – Motor rated current 1.0~50A – No load motor current 0.1~20A – Motor efficiency 50~100% – Load inertia rate Carrier frequency select 1~15kHz 3kHz 0 (Volts/frequency control), 1 (Slip compensation control),...

  • Page 25: Input/Output Group

    Compact & Powerful Inverter iG5A Function group 2 Parameter Factory Adj. during Description display name default Cooling fan control 0 (Always ON), 1 (Keep ON when its Temp. is higher than Inverter protection limit Temp.) Operating method select 0 (Run when cooling fan malfunctions), 1 (Stop when cooling fan malfunctions) when cooling fan malfunctions S/W version 0~10.0...
  • Page 26 iG5A Function List Input/output group Parameter Factory Adj. during Description display name default 0: Disabled Criteria for analog input signal loss 1: activated below half of set value. 2: activated below set value. 0: Forward run command Multi-function input terminal 1: Reverse run command P1 define 2: Emergency stop trip...
  • Page 27 Compact & Powerful Inverter iG5A Input/output group Parameter Factory Adj. during Description display name default Analog output level adjustment 10~200% Frequency detection level 0~400Hz 30.00 Frequency detection bandwidth 10.00 Multi-function output terminal select 0: FDT-1 1: FDT-2 2: FDT-3 3: FDT-4 4: FDT-5 5: Overload (OL) 6: Inverter overload (IOL)

  • Page 28: Protective Functions

    iG5A Protective Functions Keypad display Protective functions Descriptions The inverter turns off its output when the output current of the inverter flows more than 200% of the inverter Overcurrent rated current. The inverter turns off its output when a ground fault occurs and the ground fault current is more than the Ground fault current internal setting value of the inverter.

  • Page 29: Fault Remedy

    Compact & Powerful Inverter iG5A Fault Remedy Keypad display Cause Remedy Caution: When an overcurrent fault occurs, operation must be started after the cause is removed to avoid damage to IGBT inside the inverter. Accel/Decel time is too short compared to the GD →...
  • Page 30 iG5A Memo...
  • Page 31 Compact & Powerful Inverter iG5A...
  • Page 32 Vietnam Address: Room C21, 5Th Floor, Horison Hotel, 40 Cat Linh , Hanoi, Vietnam Tel: 84-4-736-6270/1 Fax: 84-4-736-6269 � � Dalian LS Industrial Systems Co., Ltd China Address: No. 15 Liaohexi 3 Road, economic and technical development zone, Dalian, China...
