DIMENSIONS unit: mm (inch)
21.5 (.85)
10 (.39)
TERMINAL ASSIGNMENTS unit: mm (inch)
INPUT RESISTOR
(model: REM2)
4
1
8
5
12
9
14 13
Input shunt resistor attached
for current input.
SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM
+
SIGNAL SOURCE
–
The M2VF, by its fast-response feature, is not designed to eliminate noise present in the input signal.
Use a shielded twisted-pair cable for preventing noise entering through the input wiring.
Specifications are subject to change without notice.
SEN TRONIC
AG
Produkte, Support und Service
84 (3.31)
114 (4.49)
• When mounting, no extra space is needed between units.
Isolation
Low Drift
1
*
Amplifier
R
4
5
8
Base Socket
*Input shunt resistor attached for current input.
Rugghölzli 2
CH - 5453 Busslingen
6 (.23)
DIN RAIL
4
1
35mm wide
8
5
2–4.2x5
(.17x.20)
MTG HOLE
6 (.24) deep
12
9
8–M3
SCREW
14 13
15 (.59)
[4 (.16)]
23 (.91)
Z
S
Output
+
9
Driver
OUTPUT
–
12
13
U(+)
POWER
14
V(–)
Tel. +41 (0)56 222 38 18
Fax +41 (0)56 222 10 12
MODEL: M2VF
