Majestic JASPER30IN Owner's Manual

Hide thumbs Also See for JASPER30IN:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
JASPER30IN
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Owner's Manual
Care and Operation
Majestic • JASPER30IN Owner's Manual • 2546-981 Rev. C • 7/19
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JASPER30IN and is the answer not in the manual?

Questions and answers

Related Manuals for Majestic JASPER30IN

Summary of Contents for Majestic JASPER30IN

  • Page 1 See appliance installation manual for additional gases, unless a certified kit is used. Commonwealth of Massachusetts requirements. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 2: Welcome

    BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 3: Table Of Contents

    C. Contact Information ......27  = Contains updated information. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 4: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 6: Product Specific Information

    HHT Factory Trained or NFI certified professionals. B. Glass Specifications This appliance is equipped with 5 mm ceramic glass. Re- place glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 7: Important Safety And Operating Information

    Figure 3.1 Clear Space Requirement - All Models protection lockout feature. • Keep remote controls out of reach of children. • Never leave children alone near a hot fireplace, whether operating or cooling down. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 8: General Operating Parts

    Use appropriate finishing materials that are able to withstand these conditions. For APPLIANCE SURROUND additional finishing guidelines, see Section 8 Installation Manual. Figure 3.3 Good Faith Wall Surface Temperatures Above Appliance Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 9 Sugges ons on how to further reduce TV temperatures: Increase “A” dimension. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 3.4 Good Faith TV Guidelines Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 10: Before Lighting Appliance

    • Verify collar slide plate screw is attached see Figure 3.5. BE SURE SLIDE PLATE SCREW IS FULLY TIGHTENED. Figure 3.5 Collar slide Plate Screw Detail Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 11: Lighting Instructions (Ipi)

    For more information go to: www. Propane Installation code, CSA B149.1. P65Warnings.ca.gov. For additional information on operating your Keep burner and control compartment clean. See installation and operating instructions accompanying appliance. refer to www.hearthnhome.com. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 12: Appliance Break-In

    NOTICE! Open windows for air circulation during fire- place break-in. • Some people may be sensitive to smoke and odors. • Smoke detectors may activate. GLASS SEAL PLATE INSTALLED Figure 3.6 Glass Seal Plate Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 13: Heat Management

    NOTICE: Some functionality will be lost when using battery backup including remote control or fan that require household 110-120 VAC power. Figure 3.7 Control Cavity Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 14: Detailed Component Operating Instructions - Intellifire

    If desired, a fan kit may be added. Contact your dealer to order the correct fan kit. Detailed instructions are includ- ed with the fan kit and in appliance installation manual. ON/OFF SWITCH 3.9 Surround ON/OFF Switch Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 15: Maintenance And Service

    CAUTION! Risk of Burns! The fireplace should be turned off and cooled before servicing. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 16 Figure 4.3 Glass Seal Plate Verify top latches are fully engaged and then fasten the two bottom latches using the supplied multi-purpose tool. • Reinstall door or decorative front. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 17 GLASS SEAL PLATE COMPONENT TRAY WITH HEAT SHIELD Figure 4.4 Component Tray Access CAUTION: Be sure to reinstall the component heat shield before firing the appliance. Components will overheat. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 18: Maintenance Tasks - Qualified Service Technician

    • Verify that the collar slide plate screw is installed. See Figure 3.5. • Remove all foreign objects. • Verify unobstructed air circulation. • Ensure no wire connections become disengaged. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 19 Polish with fine steel wool or replace as required. • Verify that there is not a short in flame sense circuit by checking continuity between pilot hood and flame sensing rod. Replace pilot as necessary. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 20: Frequently Asked Questions And Troubleshooting

    (two D cell batteries required). Refer to Section 3.I for more details. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.majesticproducts.com to locate a dealer. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 21: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. D. Module voltage output /Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 22 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fine. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 23: Reference Materials

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative front. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 24: Service Parts

    Pilot Shield 2532-153 Burner Assembly 2546-007 Base Pan 2546-130 Seal, Glass Frame 2532-122 Glass Door Assembly GLA-2532 Power Cord 2201-017 Additional service part numbers appear on following page. 7/19 Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 25 19.3 Wire Assembly SRV593-590 19.4 3V Transformer SRV593-593 19.5 Remote Wire Assembly 2103-013 19.6 Wire Tray 2534-171 19.7 2534-170 Tray, Component Additional service part numbers appear on following page. Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
  • Page 26 Pilot Orifice NG SRV593-528 Pilot Orifice Propane 593-526 Regulator NG SRVNGK-DXV Regulator Propane: Compatible only with field converted to SRVLPK-DXV LP 750-500. Valvle must be Replaced if using 2155-501 Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...

  • Page 27: Contact Information

    6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7074035, 7098269, 7258116, 7322819, 7470729, 7726300, 8147240, 9625149 or other U.S. and foreign patents pending. 2000-945D Printed in U.S.A. - Copyright 2019 Majestic • JASPER30IN Owner’s Manual • 2546-981 Rev. C • 7/19...
