Installation
Illustration 3
To install the cage:
Gently place the cage on top of the chassis. Ensure the sides of the cage are fully seated
on the top plate.
Slowly slide the cage forward until the two locating screws engage with the cap screws
behind the front panel.
See illustration 4. When the cage rear flange is flush with the rear edge of the chassis the
cage is fully installed. Note that you may have to slightly squeeze in the sides to allow
slots in the cage flange to align with the top plate cap screws.
Illustration 4
10
