  • Page 1 INSTRUCTION FOR USE ELBUR Nursing Beds: PB 636 IV, PB 636 IV with axional brake...
  • Page 3 Due to designing and manufacturing in accordance to the latest technological development at the time of delivery, PB 636 IV nursing bed is very durable and ensure essential performance. It is used to alleviate and compensate injuries and disabilities for older, frail and handicapped people.

  • Page 4: Table Of Contents

    Table of contents 1.0. Product description ..............6 1.1. Purpose and range of application ..........6 1.2. Technical specification .............. 7 1.3. Labelling of nursing beds ............8 1.3.1. Name plates ..............8 1.3.2. Information labelling ............8 1.3.3. Explanation of symbols used on name plate ......9 2.0.
  • Page 5 6.5. Assembly of mattress support platform drive unit – adjustment of foot rest section ................19 6.6. Assembly of mattress support platform drive unit – adjustment of head rest section ................19 6.7. Connecting electric components ..........20 6.8. Cable routing ................. 20 6.9.

  • Page 6: Product Description

    PB 636 IV 1.0. Product description 1.1. Purpose and range of application PB 636 IV adjustable nursing bed is used to alleviate and compensate injury, disability disease. ensures comfortable and contribute necessary care of infirm, frail people, thus enhancing conditions of work for nursing staff. Electric regulation simplifies getting in/out to bed, comfortable setting in chosen position and access to patient during hygienic actions given by care assistant.

  • Page 7: Technical Specification

    0,3 / 0,5 Side rails (set) 11,2 Lifting pole Temperature [ +10 ÷ +40 Conditions operating Humidity [%] 30 ÷ 75 +5 ÷ +45 Temperature [ Conditions storage Humidity [%] 30 ÷ 75 Elbur sp. z o.o. sp.k. 7 of 36...

  • Page 8: Labelling Of Nursing Beds

    146 cm, a mass equal to or more than 40 kg and a body max index (BMI) equal to or more than 17. Elbur sp. z o.o. sp.k. 8 of 36...

  • Page 9: Explanation Of Symbols Used On Name Plate

    Patient – person undergoing a medical procedure or disabled person. Responsible organization – entity accountable for the use and maintenance of the PB 636 IV nursing bed, for example, a hospital, and individual clinician or a layperson. In home use applications, the patient, operator and responsible organization can be one and the same person.

  • Page 10: Marking And Safety Signs

    Due to the design, PB 636 IV nursing bed is only approved for use by patients having a physical size equal to or more than 146 cm, a mass equal to or more than 40 kg and a body max index (BMI) equal to or more than 17.

  • Page 11: Electrical Components Information

    Do not open any electric components. For reasons of safety and electromagnetic compatibility, use only original electric components from Elbur that have been released for the nursing bed model in order. Otherwise it can caused danger for patients and loss of bed functionality.

  • Page 12: Information For Care Personnel

    There must be a minimum height of 22 cm without compression measured from the top of the mattress to the top edge of the top side rail. This is illustrated on the picture on the next page. Elbur sp. z o.o. sp.k. 12 of 36...

  • Page 13: Assembly Information

    Use the test protocol draft on pages 28 – 31 during maintenance (you can find it also on website www.elbur.eu) – the subsequent technical safety check has to be documented. It has to be done at least once a year and every re-use at the new place.

  • Page 14: Scope Of Delivery

    (items described below may not be included in your model). Please contact your distributor or Elbur customer service, if you miss any component or get something in bad condition. End board type (code B4): ✓...

  • Page 15: Electric Components

    4.2. Back rest / foot rest drive units PB 636 IV has got one drive unit used to adjust back rest section and one drive unit used to adjust upper and lower leg sections. Both of them are fitted under the bed - in that case assembly is necessary –...

  • Page 16: Hand Switch

    Accessories and spare parts can be ordered from distributor or Elbur company. For reasons of safety, it is allowed to use only original spare parts or accessories from Elbur sp. z o.o. sp.k. Otherwise, our company will assume no liability for any accidents, damage, injury and risks that come about through the use of other spare parts or accessories.

  • Page 17: Assembly

    Before commencing assembly of the nursing bed, please read carefully instruction manual and verify the shipment contents with your order (chapter 3.0). Please contact your distributor or Elbur customer service, if you miss any items or get something in bad condition.

  • Page 18: Location Of Drive Units And Control Box For Mattress Support Platform

    These must not be interchanged. Otherwise it can cause damage of electric components. On the following page you will find the scheme, which clearly indicates how to correctly assembly drive units of PB 636 IV nursing bed. Elbur sp. z o.o. sp.k. 18 of 36...

  • Page 19: Assembly Of Mattress Support Platform Drive Unit - Adjustment Of Foot Rest Section

    – adjustment of head rest section • drive unit has to be fixed under mattress support platform with the motor housing towards the foot end board (see label on the bed); Elbur sp. z o.o. sp.k. 19 of 36...

  • Page 20: Connecting Electric Components

    There are holders for hand switch cable on both sides of the mattress support platform (in the non-moving section). Please use one on the side, where hand switch is going to be hooked. Elbur sp. z o.o. sp.k. 20 of 36...

  • Page 21: Testing Of Adjustment Functions

    The side rails in the foot section end are assembled in the same way as in the head section. If the bed is equipped with wooden side rails on both sides of the nursing bed, assembly them in the same manner as the first. Elbur sp. z o.o. sp.k. 21 of 36...

  • Page 22: Assembly Of The Lifting Pole

    The electric adjustment range of height or angle of mattress support platform is possible only within a predetermined range. The electrical adjustments can be made using the hand switch, which functions are described on the following page. Elbur sp. z o.o. sp.k. 22 of 36...
  • Page 23 Also, the lower leg rest will be dragged down automatically if you lower the thigh rest. Warning Do not put your fingers between moving parts of the mattress support platform – it can caused their entrapment and injuries! Elbur sp. z o.o. sp.k. 23 of 36...

  • Page 24: Side Rails Operating

    There should be access to castors at all the time. They have to be placed along the bed before locking them, In standard version of PB 636 IV for the purpose of activating the brake push the foot lever down as far as it goes.

  • Page 25: Movements Of Nursing Beds

    PB 636 IV PB 636 IV with an axional brake - pressing the foot brake lever allows to activate castors locking system on one end of the nursing bed (at head end or foot end). Similarly – pressing the foot brake lever back allows to deactivate castor locking system in the same axis ( at head end or foot end).

  • Page 26: Maintenance

    Adhering to the described on the next page rules of the bed maintenance ensures its long life and keeps its nice appearance. Elbur sp. z o.o. sp.k. 26 of 36...

  • Page 27: Service

    Use the test protocol draft on pages 28 - 31 during maintenance (you can find it also on website www.elbur.eu) – the subsequent technical safety check has to be documented. It is obligated with every maintenance to perform regular inspections, to ensure the safe condition of the nursing bed.
  • Page 28 • Manufacturer’s final inspection □ Electrical appliance class: I □ II □ Manufacturer: Elbur sp. z o.o. sp.k. Bed type: PB _________________________________________________ Serial number: _______________________________________________ Inventory number: ____________________________________________ Location: ____________________________________________________ Testing equipment used (name / type / serial number): ____________________________________________________________...
  • Page 29 Is labelling on the hand switch readable? □ YES □ NO Description of defects (if applicable): _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ II. Electric measurements (according to EN 62353) Elbur sp. z o.o. sp.k. 29 of 36...
  • Page 30 Is the CPR function working properly with a load of the □ YES □ NO back rest (if applicable)? Description of defects (if applicable): _______________________________________________________ _______________________________________________________ _______________________________________________________ IV. Results of the inspection Elbur sp. z o.o. sp.k. 30 of 36...

  • Page 31: Troubleshooting

    Comments: ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ Next inspection date: __________________________________________ Inspected on: ________________________________________________ Inspected by: ________________________________________________ Signature: ___________________________________________________ Inspection protocol can be also downloaded from website: www.elbur.eu 9.1. Troubleshooting DEFECT POSSIBLE SOLUTION CAUSES Elbur sp. z o.o. sp.k. 31 of 36...
  • Page 32 Control box Safe working Let to cool it down, reduce the overheated load exceeded load, follow the instruction from Elbur sp. z o.o. sp.k. 32 of 36...

  • Page 33: Transport And Storage

    Technical specifications (subclause 1.2.) contain guidance of operating and storage conditions for ELBUR nursing beds. Nursing bed shall be protected from destruction under external influences before re-storage.
  • Page 34 ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ Elbur sp. z o.o. sp.k. 34 of 36...
  • Page 35 PB 636 IV Elbur sp. z o.o. sp.k. 35 of 36...
  • Page 36 Elbur sp. z o.o. sp.k. Działosza 34, 56-500 Syców, POLAND Tel.: + 48 62 786 97 80 Fax: + 48 62 786 97 81 e-mail: info@elbur.eu www.elbur.eu E.TF-3E.13-01 23.11.2020...
