Powercast Powercaster TX91501B User Manual

User's Manual
TX91501B – 915 MHz Powercaster Transmitter

PRODUCT DESCRIPTION

The Powercast TX91501B Powercaster
transmitter is specially designed to provide
both power and data to end devices
containing the Powercast P2110 or P1110
Powerharvester® receivers. The TX91501B is
housed in a durable plastic case with several
mounting options.
provided to either of the two DC power
connectors at 5V DC. The TX91501B includes
a status LED to provide feedback on
functional state. The TX91501B has a factory
set, fixed power output and no user-
adjustable settings. The label indicates the
effective power for which the device is
configured, with 3 watts EIRP being the
maximum. Once
transmission is initiated by applying power
to the TX91501B.

FEATURES

 FCC and IC approved
 Flexible wall mounting options
 Fully integrated system
 Transmits power and data
 Factory configurable for custom
applications
 Wide temperature range
 RoHS compliant

ORDERING OPTIONS

Model Firmware
TX91501B XX
Powercast®, Lifetime Power®, Powerharvester®, and Powercaster® are registered trademarks of Powercast Corporation.
Rev A-1 – 2018/10

Operational power is
properly mounted,
XX
Data
ID: Transmitter ID
Output Power
3W: 3 Watts
1W: 1 Watt
All other trademarks are the property of their respective owners.
User's Manual - TX91501B Transmitter
www.powercastco.com

POWERING APPLICATIONS

 Wireless battery charging
 Battery-free wireless sensors
- Industrial Monitoring
- Smart Grid
- Structural Health Monitoring
- Defense
- Building automation
- Agriculture
- Oil & Gas
- Location-aware services
 Wireless trigger
 Low power electronics

PRODUCT CONTENTS

The following items are included inside the
package:
Qty Description
1 915 MHz transmitter
1 Power supply
1 US plug for Power supply (must be
snapped in to the Power supply)
1 Quick Start instruction card
Page 1
