Summary of Contents for Vintec V40SGES3
- Page 1 User Manual V40SGES3 V40SGEBK AL-V40SGE vintec.com...
- Page 2 User Manual V40SGES3 V40SGEBK AL-V40SGE...
- Page 3 Vintec manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Vintec manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual.
- Page 4 Some models are available in dedicated countries only. VINTEC offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed. VINTEC cannot be held responsible for any error in this manual.
- Page 5 - have a surge protector fitted to the electrical outlet; - away from the microwave oven. Certain microwave ovens do not have wave interference shield. When placed within 1 meter vicinity of the wine cabinet, they may affect the operation of the wine cabinet. User Manual V40SGES3 V40SGEBK AL-V40SGE...
-
Page 6: Installing Your Wine Cellar
Leveling your wine cellar: Wine cellar must be leveled BEFORE loading your wines. Your Vintec wine cellar is equipped with 4 adjustable feet to facilitate easy leveling. VINTEC recommends that you tighten the back feet to the maximum and adjust the front feet to level the wine cellar. - Page 7 Fixing the Back spacer: Compressor run appliances require proper ventilation for proper and longer usage. Your Vintec wine cellar is supplied with a back spacer. Affix the back spacer at the back of the cellar for air circulation and heat evacuation.
- Page 8 3. Vintec “Built in” wine cellars draw air from the rear and expels through the metal grid under the door at the front. If a kick board is to be placed in front of the wine cellar’s grid another one must be fitted into the kick board with a minimum air flow allowance of 150cm2.
- Page 9 INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS: User Manual V40SGES3 V40SGEBK AL-V40SGE...
- Page 10 TOP VIEW access when installed flush-fit. For complete installation instructions, please refer to the user manual for this product. © 2018 Electrolux Home Products Pty Ltd ABN 51 004 762 341 VDIM_V40SGEBK_DimSheet vintec.com.au 1800 771 776 User Manual V40SGES3 V40SGEBK AL-V40SGE...
- Page 11 An individual’s perception of noise is directly linked to the environment in which the wine cellar is located, as well the specific type of models. VINTEC wine cellars are in line with international standards for such appliance. VINTEC will always do its utmost to satisfy its customers but will not retake possession of the goods due to complaints based on normal operating noise occurrences.
- Page 12 - Do not cover the wooden shelves with alloy foil or other materials, as it will obstruct air circulation. - Do not move your wine cellar while it is loaded with wines. This might distort the body of the wine cellar and cause back injury. User Manual V40SGES3 V40SGEBK AL-V40SGE...
-
Page 13: Types Of Regulation
12ºC. They can also be set to provide ideal serving temperature for full enjoyment of the wine’s qualities. Unless stated by the wine maker on the bottle, VINTEC recommends 7ºC for your champagne, 12ºC for whites and 18ºC for reds. (Refer to “Wine Service Temperature”... -
Page 14: Temperature Settings
1 degree Celsius. The temperature setting can be adjusted from 6 to 18 . To view the “set” temperature, press and hold the UP or DOWN buttons, the “set” temperature will temporarily “flash” in the LED display for 5 seconds. User Manual V40SGES3 V40SGEBK AL-V40SGE... -
Page 15: Wine Serving Temperature Chart
14ºC Red Pinot Noir, 16ºC Red Grenache, Syrah 16ºC Red Vintage Pinot Noir 18ºC Cabernet & Merlot: French, Australian, New Zealand, 20ºC Chilean, Italian, Spanish, Californian, Argentinean… Vintage Bordeaux … Room temperature not exceeding 20ºC User Manual V40SGES3 V40SGEBK AL-V40SGE... -
Page 16: Defrosting/Condensation/ Hygrometry/ Ventilation
IMPORTANT INFORMATION ABOUT TEMPERATURE Your VINTEC wine cellar has been designed to guarantee optimum conditions for storing and/or serving your wines. Fine wines require long and gentle developments and need specific conditions in which to reach their full potential. All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC. -
Page 17: Reversibility Of The Door
- Depending on the type of handle your wine cabinet is equipped with, the door may not be reversible or may require that a left or right opening door be ordered to change the opening side. User Manual V40SGES3 V40SGEBK AL-V40SGE... - Page 18 - Remove the 3 bolts and take out the right top hinge (2); (Fig. 3) - Fix the left top hinge and the bottom left hinge with the bolts as per Fig. 4, - Re-install the door the same way it was removed and fix back the door axis. User Manual V40SGES3 V40SGEBK AL-V40SGE...
- Page 19 (7) at left top of cabinet with 3 screws. (Fig. D) 5. Following the above procedure, install the spare lower hinge to the left (9). (Fig. E) 6. Install and aligned the door. 7. Insert the plastic caps to cover the holes(8). User Manual V40SGES3 V40SGEBK AL-V40SGE...
-
Page 20: Operation Anomalies
Check fuse, if any. Make sure that the door is closed properly. If your wine cellar appears to be malfunctioning, unplug it and contact your VINTEC’s after sales service. Any intervention on the cold circuit should be performed by a refrigeration technician who should carry out an inspection of the circuit sealing system. -
Page 21: Troubleshooting Guide
The door will not close properly. The Wine cellar is not level. The door was reversed and not properly installed. The gasket is faulty. ( magnet or rubber is spoiled) The shelves are out of position. User Manual V40SGES3 V40SGEBK AL-V40SGE... - Page 22 (c) ‘ASC’ means Electrolux’s authorised serviced centres; (viii) insect or vermin infestation; (d) ‘Vintec/Transtherm’ is the brand controlled by Electrolux Home Products (ix) failure to comply with any additional instructions supplied with Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 the Appliance;...
- Page 23 User Manual V40SGES3 V40SGEBK AL-V40SGE...
- Page 24 Service and support In the rare event that your Vintec cabinet does not perform to your satisfaction, contact our dedicated support team: 1800 771 776 concierge@vintecclub.com Vintec. We are part of the Electrolux Family. To add a touch of professional inspiration to your home, visit electrolux.com.au...
