VQ Radio Control Model VQA098 Instruction Manual

Dornier do-27

Hide thumbs

page of 10

/ 10
Bookmarks

Quick Links

Download this manual

Radio control model

R/C Flugmodell

INSTRUCTION MANUAL

MONTAGEANLEITUNG

Designed for brushless electric motors

Entwickelt für Brushless Elektro Motoren

TECHNISCHE DATEN

Spannweite

Lange

Elektroantrieb

(siehe nächste Seite)

Fernsteuerung

WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and

cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.

Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.

ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,

die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann

hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um

professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist

durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.

SPECIFICATIONS

Wingspan

1210mm

Length

940mm

Electric Motor

Radio

4 Kanal / 4 Servos

DORNIER

DO-27

VQ No: VQA090

VQ No: VQA098

VQ No: VQA099

1210mm.

940mm.

(See next page)

4 Channel / 4 Servos

Need help?

Do you have a question about the VQA098 and is the answer not in the manual?

Questions and answers

Summary of Contents for VQ Radio Control Model VQA098

Page 1 Radio control model DORNIER R/C Flugmodell INSTRUCTION MANUAL DO-27 MONTAGEANLEITUNG Designed for brushless electric motors Entwickelt für Brushless Elektro Motoren VQ No: VQA090 VQ No: VQA098 VQ No: VQA099 SPECIFICATIONS TECHNISCHE DATEN Wingspan 1210mm. Spannweite 1210mm Length 940mm. Lange 940mm...
Page 2: Recommended Accessories
RECOMMENDED ACCESSORIES Empfohlenes Zubehör 4 x Servo S2112 Antrieb Tuning (Kraftvoller Kunstflug): mit 500mm Servokabel BOOST 25 Brushless Combo Set, No. C2981 LiPo Akku RED POWER 2200-3S, No. C2158 Propeller 10*5, No. C5749 4 - channel radio 4 - Kanal Fernsteuerung MASTER, No.
Page 3 Full the elevator out of the horizontal stabilizer. Cut away only the film both side Aluminum wing joiner B=B’ B’ Stabilizer Stabilizer A=A’ A’ When you are satisfied with the alignment, use a pencil to trace around the top and bottom of the stabilizer where it meets the fuselage.
Page 4 Apply thin CA to each of the four joints and use a generous Thin CA glue amount to ensure to strong bond. WARNING! Securely glue together. If coming off during flights, you lose control of your airplane which leads to accidents ! Vergewissern Sie sich, sauber geklebt zu haben.
Page 5 When you are satisfied with the alignment, use a pencil to trace around the right and left of the stabilizer where it meets the fuselage. Cut away only the covering both side WARNING! Securely glue together. If coming off during flights, you lose control Apply thin CA to each of the of your airplane which leads to accidents ! joints and use a generous...
Page 6 Note: The slots for the control horn installation pre- cut at factory. Control horn WARNING! Securely glue together. If coming off during flights, you lose control of your airplane which leads to accidents ! ...1 Vergewissern Sie sich, sauber geklebt zu haben. Andernfalls konnen Probleme mit der Flugeigenschaft auftreten! 4X20mm screw ....4...
Page 7 Pull the magnetic battery hatch out of the fuselage ! Engine thrust on balk head is already adjust at factory Sturz und Zug beachten! Sperrholztrager Platten zusammenkleben, wie gezeigt ausrichten und Locher bohren. For maximum performance, we recommended Motor nach untenstehendem Schema einbauen. the following: Fur optimale Leistung empfehlen wir folgende Komponenten: -Brushless-Motor PICHLER BOOST 60...
Page 8 Elevator linkage The holes for the elevator servo FUSELAGE - BOTTOM VIEW are Pre-cut at factory.. Cut away only the covering FUSELAGE - BOTTOM VIEW Rudder linkage FUSELAGE - BOTTOM VIEW 1.5mm 1.5mm...
Page 9 Aileron extension cord Aileron & flap pushrod 1.2mm O Alenk-Gestange Note: The slots for the control horn installation are pre- cut at factory. BOTTOM - VIEW / Unteransicht Plastic control horn WARNING! Securely glue together......2 If coming off during flights, you lose control of your airplane which leads to accidents ! Linkage Stopper set Vergewissern Sie sich, sauber geklebt zu haben.
Page 10 Uberprufen Sie vor dem Flug den Schwerpunkt. Do not try to fly an out-of balance model! Querruderausschlag Aileron / 15mm Rudder Hohenruderausschlag Elevator / 10mm Seitenruderausschlag 15mm 10mm 55~58 mm IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner to clean on surface of your model to keep the colour not fade.
