- Page 1 RADIO CONTROL MODEL / RC FLUGMODELL ARF BY INSTRUCTION MANUAL / MONTAGEANLEITUNG SPECIFICATION TECHNISCHE DATEN Spannweite :910mm Wing span approx : 35.8 in. Lange : 635mm Length approx : 25.0 in. Antriebsset Propulsion Set Brushless für Brushless for Swallow Swallow # 5542 # C5542...
-
Page 2: Top View
1- Horizontal Tail / Hohenruder SIDE-VIEW Seitenansicht Horizontal stabilizer Elevator Fuselage TOP VIEW Draufsicht Cut away only the covering 1-Trial fit the horizontal stabilizer in place . Check the alignment of the horizontal stabilizer. When you are satisfied with the alignment, use a pencil to trace around the bottom of the stabilizer where it meets the fuselage. - Page 3 2- Vertical Tail / Seitenruder Cut away only the covering Cut 31/64”(12mm) long slots along the centerline for the rudder hinge. TOP VIEW Draufsicht Cut away only the covering on both side. Securely glue together. If coming off during flight, you lose control of your air plane.
- Page 4 3- Linkage / Ruderanlenkung Securely glue together. If coming off during flight, you lose control of your BOTTOM - VIEW air plane. Unteransicht 1- Push the elevator pushrod into the white nylon pushrod guider. 2- Insert the elevator pushrod into the elevator control horn. 3- Place the elevator control horn onto the elevator and carefully cut away the covering where the elevator control horn meets the elevator.
-
Page 5: Radio Installation
4- Wooden parts installation BOTTOM - VIEW Unteransicht 4mm O dowel. 5- Radio installation Elevator servo Höhenruderservo LITHIUM POLYMER BATTERY RED POWER 800 - 7.4V TOP VIEW Draufsicht Rudder servo 3mm set Screw Seitenruderservo Madenschraube M3 Pushrod Rudergestänge 2 mm... -
Page 6: Motor Installation
Draufsicht secure the Motor mount with fuselage using CA glue. LITHIUM POLYMER BATTERY RED POWER 800 - 7.4V Propulsion Set Antriebsset Brushless for Brushless für Swallow Swallow # C5542 # 5542 7- Canopy / Kabinenhaube Rubber band... - Page 7 8- Wooden part installation 9- Balance / Schwerpunkt Do not try to fly an out-of balance model! Uberprufen Sie vor dem Flug den Schwerpunkt. 38mm WARNING ! Securely install the receiver and power pack, ensuring they will not come loose or rattle during flight. Never fly before checking the Cg’s required position.
