- Page 1 Operating Manual pMDDL2450 2X2 MIMO 2.4 GHz OEM DDL Module (1W) Revision 0.26 March 10, 2018 Microhard www.microhardcorp.com...
-
Page 2: Warranty
Warranty Microhard Systems Inc. warrants that each product will be free of defects in material and workmanship for a period of one (1) year for its products. The warranty commences on the date the product is shipped by Microhard Systems Inc. Microhard Systems Inc.’s sole liability and responsibility under this warranty is to repair or replace any product which is returned to it by the Buyer... - Page 3 WARNING: Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment. This device has been tested with UFL to Reverse Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM products, fixed antennas require installation preventing end-users from replacing them with non-approved antennas.
-
Page 4: Pmddl2450 Exigences Réglementaires
. WARNING: Les changements ou modifications non expressément approuvés par Microhard Systems Inc. pourraient annuler l'autorité de l'utilisateur à utiliser l'équipement . Ce dispositif a été testé avec MCX et connecteurs SMA à polarité inverse sur les antennes répertoriées à... - Page 5 Co-Location with Cellular Modems The maximum calculated MPE ratio for the EUT with 2.5 dBi dipole antenna is 0.379, this configuration can be co- located with other antennas provided the sum of the MPE ratios for all the other simultaneous transmitting antennas incorporated in a host device is <...
-
Page 6: Table Of Contents
Contents Warranty ..................................ii Proprietary Rights ................................. ii pMDDL2450 Regulatory Requirements ........................iii pMDDL2450 Exigences Réglementaires ........................iv Co-Location Instructions ............................... v GENERAL ................................1 ................................ 1 RODUCT VERVIEW ..............................2 UTPUT OWER EVEL INSTALLATION ..............................3 ... -
Page 7: General
ease of installation and use – the pMDDL2450 module uses a subset of standard AT style commands, very similar to those used by traditional telephone line modems. -
Page 8: Output Power Level
While the typical application for the pMDDL2450 is to provide a short- to mid-range wireless communications link between DTEs, it can be adapted to almost any situation where an asynchronous serial interface is used and data intercommunication is required. -
Page 9: Installation
3. Installation 3.0 Overview The pMDDL2450 complies with FCC part 15 at the modular level for operation in the license-free 2400-2483.5 MHz ISM band. This chapter provides guidelines for installing and deploying equipment which incorporates the pMDDL2450 module. 3.1 Estimating the Gain Margin... - Page 10 Figure 1 Gain Calculation The power level has been set to 30dBm (1W) on the transmitter, and the receiver sensitivity for the pMDDL2450 is -108dBm. System gain would be calculated to be: 30 - 2 + 6 + 3 - 2 + 108 = 143 dB.
-
Page 11: Antennas And Cabling
-95dBm. 3.2 Antennas and Cabling This section describes the recommended procedure for installing cabling and antennas for use with the pMDDL2450 module. 3.2.1 Internal Cabling The most common method for installing the module is to run a cable from the module’s UFL connector to a reverse TNC bulkhead connector on the chassis... -
Page 12: Installing External Cables, Antennas And Lightning Arrestors
N-female. External Filter Although the pMDDL2450 is capable of filtering out RF noise in most environments, there are circumstances that require external filtering. WARNING: Paging towers and cellular base stations in close proximity to the Direct human contact with the pMDDL2450 antenna can desensitize the receiver. - Page 13 Appendix A. antenna with appropriate gain. See appendix A for a list of approved antennas that can be used with the pMDDL2450 radio modem. If you require another type of antenna WARNING: please contact Microhard Systems Inc. The pMDDL2450 CANNOT be Be careful with dBi vs dBd gains used with any antenna that does not appear in Appendix A.
- Page 14 36dBm with respect to the isotropic radiator. Example 1) What is the maximum power the pMDDL2450 can be set to comply with FCC and IC given the following equipment given a Rubber Ducky Ant Gain 2dBi and no cable or connectors in the system? Max EIRP 36dBm Max TX power = EIRP –...
- Page 15 WARNING: Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment. This device has been tested with UFL connectors with the antennas listed in Appendix A When integrated in OEM products, fixed antennas require installation preventing end-users from replacing them with non-approved antennas.
