- Page 1 USER MANUAL VMAX VX4 Art. No. 110.52604 With road permission Age 14+...
- Page 2 Mail: service@vmaxglobal.net Website: www.vmax-escooter.ch Die Marke VMAX VMAX was founded in 2015 and is a Swiss brand with various mobility solutions. The compay‘s vision „your mobility solution“ is underpin- ned with diverse products groups in the field of mobility. VMAX wants to develop the best e-scooter, pedelec or hoverboard for each the best e-scooter, the best pedelec or the best hoverboard.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Road approval Switzerland/Germany Disclaimer Symbols used Safety instructions 8–9 Safety instructions lithium ion battery Charging process Maintenance and care Storage Parts description Assembly Display Display functions Adjustments Before the first ride Technical data Legal notice Warranty Service VX4 User manual... -
Page 4: Introduction
Dear Customer We congratulate you on the purchase of your new VMAX e-scooter and welcome you to the VMAX family. To ensure that you have a good knowledge of the device and can experience the greatest possible driving pleasure with the highest level of safety, it is important that you read this user manual carefully before using it for the first time and keep it for any questions that may arise later. -
Page 5: Road Approval Switzerland/Germany
ROAD APPROVAL An e-scooter is a means of locomotion with an electric motor and the- refore falls into the category of light motor vehicles or, in Germany, into the category of „miniature electric vehicles“. Your device meets all the requirements and conditions for the category of light motor vehicles and „very small electric vehicles“... -
Page 6: Disclaimer
Since its not possible for us control the handling fo the e-scoo- ter, the compilance with operating instructions, as well as the charging/discharging and the maintenance of battery, VMAX Global AG cannot assume any liability for losses, damages or cost. Any claim fo damages that may arise from, or in any way be related to, the opera- tion, failure or malfunction is denied. -
Page 7: Symbols Used
SYMBOLS USED In the manual WARNING: Warning of possible risks, personal injury and danger of injury. ATTENTION: Indication of need for action or adjustment work by the user. On the packaging CE mark (Conformity Europe) this product is cons- tructed in conformity with designated european standards. -
Page 8: Safety Instructions
SAFETY INSTRUCTIONS WARNING: RIDING AN E-SCOOTER CAN RESULT IN SERIOUS INJURY OR DEATH Please note that the instructions and hazard warnings described in the operating instructions can reduce risk, but not all risks are excluded. We ask you to handle your e-scooter carefully and responsibly. ATTENTION: Read user manual before commissioning •... - Page 9 • The e-scooter is designed for use by a single person. Any in- fringement will be regarded as improper use. The user bears all risks. • All interventions to increase the power or speed, as well as general changes to the characteristics of the e-scooter are punishable by law and will be prosecuted, furthermore any warranty claims are void.
-
Page 10: Safety Instructions Lithium Ion Battery
SAFETY INSTRUCTIONS LITHIUM ION BATTERY WARNING: • The lithium ion battery may only be charged under supervision and not overnight. • The li-ion battery must not be charged when your device or the device or the charging cable are wet or damp. •... -
Page 11: Charging Process
CHARGING PROCESS ATTENTION: Your device requires regular charging. Proceed as follows: • Fully charge the li-ion battery before initial operation and do not interrupt the charging process. Also do not switch on or operate your device during the charging process. •... -
Page 12: Maintenance And Care
MAINTENANCE AND CARE ATTENTION: Your device requires regular and careful maintenance. Proceed as follows: • Your e-scooter is not waterproof. The device is protected against dust in harmful quantities and protected against splas- hing water on all sides in accordance with the IP 54 standard. •... -
Page 13: Storage
STORAGE ATTENTION: Your device requires some rules during storage, proceed as follows: • Charge the li-ion battery to approx. 60% before storage. • Repeat the procedure at least every four weeks during storage and when not in use to avoid deep discharge. •... -
Page 14: Parts Description
PARTS DESCRIPTION 1. Handles 2. Accelerator 3. Display 4. Front light 5. Front reflectors 6. Hook 7. Handlebar 8. Safety lock 9. Folding lever 10. Front fender 11. Front wheel 12. Drum break 13. Stand 14. Footboard 15. Fixing piece 16. -
Page 15: Assembly
ASSEMBLY Step 1 Remove the e-scooter from the packaging and check whether all parts of the scope of delivery (page 4) are included. Now adjust the stand so that the e-scooter stands on its own. Step 2 Now insert the brake cable into the opening of the brake lever before placing the steering head on the handlebar. -
Page 16: Display
DISPLAY 1. Gear 2. Bluetooth 3. Light 4. Mph 5. Km/h 6. Battery display 7. Cruise control 8. Speed 9. Mileage 10. Throttle 11. On / Off button 12. Light button VX4 User manual... -
Page 17: Display Functions
DISPLAY FUNCTIONS On/off gear shifting Press the on / off button (11) for 2 seconds to switch on the device. Briefly press the on / off button again, to switch between gears: „S“ = ECO mode, less performance „Red S“ = SPORT mode, more performance Press the on / off button (11) again for 4 seconds to switch the device off. If the e-scooter is not used, the device switches off automatically after 5 minutes. -
Page 18: Adjustments
ADJUSTMENTS Brake adjustment dum brake If the brake lever has too much „play“ for your needs, you can turn the nut on the drum brake clockwise. Fine adjustment handlebar and folding mechanism If you feel that the handlebars are wobbling a bit, first tighten the four bolts that secure the steering head with a 2.5 mm allen wrench. -
Page 19: Before The First Ride
BEFORE THE FIRST RIDE Make sure that the device is in perfect and undamaged condition. • Place the e-scooter on a flat surface and check the charging status of your device. • Press the on/off button on the handlebar, the display with the battery indicator lights up. -
Page 20: Technical Data
TECHNICAL DATA Product description: VMAX VX2 Art. No.: 110.52604 Battery: 48 V / 13‘000 mAh Engine power: 500 W Range: max. 40 km Max. speed: approx. 20 km/h Max. load: 120 kg Net. weight: 17.7 kg Protection class: IP54 Operating temperature: -10 - 50°C... -
Page 21: Legal Notice
LEGAL NOTICE All descriptions and instructions for the functions or details were checked at the time of production. Individual details may vary slightly. The manufacturer reserves the right to change design and functionality without prior notice. VX4 User manual... -
Page 22: Warranty
WARRANTY If you need technical assistance, please contact your dealer. Keep the original packaging in case your device needs to be retur- ned. The general and statutory warranty conditions apply. The warranty is not granted on: • Damage caused by improper use. •... -
Page 23: Service
SERVICE 1. Disposal of electrical and electronic equipment The crossed-out waste garbage can means that you are legally obli- ged to dispose of these devices separately from unsorted municipal CH/DE waste. Disposal via the residual waste garbage can or the yellow gar- bage can is prohibited. - Page 24 VMAX Global AG Industrieweg 32 CH-4852 Rothrist Mail: service@vmaxglobal.net Phone: +41 79 586 90 98 Hammer International GmbH Hagenring 57 DE-72119 Ammerbuch-Altingen Mail: marius@hammer-international.de Phone: 07032-9185103...
