Bluetooth Module Removal
Prerequisite:
Upper Cover Removal
1. Disconnect Bluetooth cable (B) from mainboard connector.
2. Remove module (A).
Figure 3-19. Bluetooth Module
Bluetooth Module Installation
1. Connect Bluetooth cable (B) to mainboard connector (Figure 3-19).
2. Install module (A).
3. Install upper cover.
3-24
0
B
A
Machine Maintenance Procedures
