Summary of Contents for Dyaco Sole Fitness SB900

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Registration Important Safety Instructions Important Operation Instructions SB900 Assembly Instructions Operation of Your New Indoor Cycle Exploded View Drawing Parts list Manufacturer's Limited Warranty ATTENTION THIS FITNESS BIKE IS INTENDED FOR RESIDENTIAL USE ONLY AND IS WARRANTED FOR THE APPLICATION.

  • Page 3: Product Registration

    CONGRATULATIONS ON YOUR NEW INDOOR CYCLE TRAINOR AND WELCOME TO THE SOLE FAMILY! Thank you for your purchase of this quality Sole indoor cycle from Dyaco Canada Inc. Your new indoor cycle has been manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.

  • Page 4: Important Safety Instructions

    5. Proper installation and regular maintenance are required to ensure user's safety. Maintenance is the sole responsibility of the owner. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 5 #88. M8 × P1.25 × 25L Button Head Socket Bolt Head Socket Bolt (4 pcs) Flat Washer (4 pcs) (4 pcs) #146. Ø8 × 1.5T_ #144. 5/16" × 7T Split Washer (4 pcs) Nylon Nut (4 pcs) Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 6 HARDWARE STEP 6 #101. 4 × 16mm_ Sheet Metal Screw (3 pcs) ASSEMBLY TOOLS #85.14/15m/m_Wrench #86. M5_Combination M5 Allen Wrench & Phillips Head Screwdriver #145.13/14m/m_Wrench Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...

  • Page 7: Sb900 Assembly Instructions

    Install the front and rear stabilizers with four Carriage Bolts (81), four Curved Washers (83) and four Nuts (82). The front and rear stabilizer are different. Be sure to assemble the stabilizer with the wheels onto the front of the bike. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 8 #91. M5 x 10mm Phillips Head Screw (2 pcs) 1. Install the rear stabilizer cover with two Phillips Head Screws (91). CONSOLE 1 – Console 2 – Clamp mounting screw 3 –Mounting Clamp Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 9 Install the Drink Bottle Holder(L) (141)and Drink Bottle Holder(R) (142) with four 5/16" × 15L_Button Head Socket Bolt (143) and four 5/16" × 7T_Nylon Nut (144)by using the M5_Combination M5 Allen Wrench & Phillips Head Screw Driver (86)and 13/14m/m_Wrench(145). Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 10 The pedals are identified by either an R or L stamped into the end of the bolt. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 11 When new batteries are installed in the transmitter or console, you must perform the synchronizing procedure below for the console to work properly After synchronizing, make sure the wire from transmitter is wrapped around the plastic as in the above image. Reinstall left cover. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 12 2. Install and slightly tighten the thumbscrew (4), then adjust the console angle for optimal visibility. Once the console is adjusted, continue to tighten the screw until it is securely attached to the handlebar. ＊See P.11 for replacing transmitter battery. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...

  • Page 13: Operation Of Your New Indoor Cycle

    This is measured by RPM. CALORIES (KCAL) Kcal is the approximation of calories burned during workout. Calories are calculated by measuring rider's instantaneous heart rate, age, and weight. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 14 If user presets the COUNT DOWN TIME, the TIME will count down to zero with flashing display, then start counting up the Timer. Under DIST or KCAL, user can go into TIMER setting by holding 'PAGE' key for 3 seconds. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 15 Please download Kinomap / Zwift from Google Play/App Store After open, the APP, press the phone icon on bike console. After APP search for bike console, the bike console will display the pairing interface. Video of pairing process Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 16 Log in to Zwift Select power source and cadence, system will prompt you to select machine Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 17 Select ride to start Enjoy the ride! Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 18 Select "More" on the bottom right corner Select equipment management Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 19 Select "+" on the top right corner Select exercise bike Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 20 Select "sensor" at the very bottom Select "FTMS" Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 21 Select machine you wish to connect Successfully paired machine will show up on this page Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 22 Go to browse to select a video you would like to play Select start Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 23 10. Press start on the console when kinomap ask you to start pedalling 11. Enjoy the ride! This console is compatible with most virtual active apps available Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 24 A suitable forward/aft position should allow the rider to comfortably grasp the handlebar with a slight bend at the elbow. Tighten the quick release to secure the handlebar assembly. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 25 Binding tension is adjustable and should be set, so that cleat and shoe do not disengage when pedalling. Use an Allen key to turn tension adjusting screws, clockwise to increase binding tension, counterclockwise to decrease binding tension. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 26 1. Do not service internal parts of pedals. If they are found to be worn internally, we recommend replacing the pedal. 2. Use of lubricants or cleaning solutions other than those so specified will result in diminished performance and a shorter life span for that part. Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...

  • Page 27: Exploded View Drawing

    EXPLODED VIEW DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...

  • Page 28: Parts List

    C140005-Z3 Crank Axle J210056-Y3 Ø8.5 × Ø16 × 1.5T_Flat Washer J210021-Z1 Ø8 × Ø16 × 1T_Flat Washer J260007-Z1 Ø8 × 1.5T_Split Washer P050032-A1 Transportation Wheel J023001-ZJ M8 × P1.25 × 10L_Button Head Socket Bolt Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 29 K134003-ZA Magent Base P060608-A1 Magnet Separator J034014F-YL M3 × P0.5 × 6L_Socket Head Cap Bolt J210015-ZJ Ø4 × Ø14 × 1T_Flat Washer J094515-Z1 M4 × P0.7 × 8L_Phillips Head Screw PP100188-I1 Adjustment Cover (L) Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 30 PP240031A-KQ Tablet Holder (Front) B130472-Q2 Fixing Plate CC060191-Q2-A Drink Bottle Holder(L) CC060192-Q2-A Drink Bottle Holder(R) J020520-Y3 5/16" × 15L_Button Head Socket Bolt J139062-Y3 5/16" × 7T_Nylon Nut J330027 13/14m/m_Wrench J260007-Y3 Ø8 × 1.5T_Split Washer Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...

  • Page 31: Manufacturer's Limited Warranty

    MANUFACTURER'S LIMITED WARRANTY Dyaco Canada Inc. warrants all its fitness bike parts for a period of time listed below from the date of retail sale, as determined by sale receipt. Dyaco Canada Inc.'s responsibilities include providing new or remanufactured parts at Dyaco Canada Inc.'s option and technical support to our independent dealers and servicing organizations.
  • Page 32 Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
  • Page 33 Customer Service 1-888-707-1880 Dyaco Canada Inc. Email: customerservice@dyaco.ca...
