- Page 1 Penn XL 165w Fanless LED Houselight User Manual Penn XL – GAMMA LED Vision Page 1 of 17...
-
Page 2: Table Of Contents
Dimmer Curve..............................9 Auto Test................................9 Temp...................................9 DMX Setup................................10 DMX Basics..............................10 DMX Wiring..............................10 DMX Modes and Configuration.........................12 Standalone Mode and Configuration......................14 3. Maintenance...............................15 Routine Maintenance............................15 Troubleshooting Problems...........................15 4. Technical Specifications..........................16 Photometric Reports............................17 Penn XL – GAMMA LED Vision Page 2 of 17... -
Page 3: Introduction And Setup
Introduction and Setup Unpacking and In the Box Thank you for choosing our Penn XL houselight. For your own safety, please read this manual before installing or using the device. This manual covers the important information on installation and applications. Please install and operate the fixture with following instructions. -
Page 4: Safety Precautions
∙Don’t try to modify the fixture without any instruction by the manufacturer. ∙Warranty is voided if there are any malfunctions from not following the user manual while operating or any hazardous operation, like shock short circuit, electronic shock, lamp broken, etc. Penn XL – GAMMA LED Vision Page 4 of 17... -
Page 5: Customer Support
Customer Support WARRANTY POLICY GAMMA LED Vision warrants its products for the periods set below from the date of purchase to be free of manufacturer and workmanship defects. Warranty does not cover normal wear and tear caused by force, negligence or misuse of products. GAMMA LED Vision is not responsible for any damages or injury caused by misuse or improper handling of the products and in accordance with instructions and specifications of manual. -
Page 6: Setup And Operation
After setting, press MENU button or wait for 1 minute to exit the power-off setting function automatically. There are also various status LED’s on the Penn to show if DMX is active, if the unit is in Master, Slave, or Sound-Active mode. Penn XL – GAMMA LED Vision Page 6 of 17... -
Page 7: Menu Operation
Color Mode Manual R (0-255) G (0-255) B (0-255) W (0-255) Color: 1-32 Sound Sens Sense 0-100 Dimmer Curve Curve Linear Sine 1 Sine 2 Auto Test Temp Fixture Time Firmware Penn XL – GAMMA LED Vision Page 7 of 17... -
Page 8: Dmx Address
Color Mode Select the Color Mode, press ENTER to confirm, and the current Color Mode will be displayed on the display. Use UP / DOWN button to select Manual（Manual Penn XL – GAMMA LED Vision Page 8 of 17... -
Page 9: Sound Sense (Sound-Active Mode)
Press the MENU button to return to main menu. Temp Select the Temp press ENTER to confirm Display temperature. Press the MENU ， ， button to return to the main menu. Penn XL – GAMMA LED Vision Page 9 of 17... -
Page 10: Dmx Setup
32 Fixture Rule – DMX only allows you to connect up to 32 fixtures in a single daisy chain for signal strength. Sometimes, depending on the fixtures and cable length, this number is less (or more). Penn XL – GAMMA LED Vision Page 10 of 17... - Page 11 XLR plug with a 120 Ω resistor connected between pins 2 and 3, which is then plugged into the output XLR socket of the last fixture in the chain. Please see illustrations below: Penn XL – GAMMA LED Vision Page 11 of 17...
-
Page 12: Dmx Modes And Configuration
DMX Modes and Configuration The Penn XL has multiple DMX modes, sometimes called “personalities”, “profiles”, or as we will use here “modes”. In general, modes with more DMX channels offer a greater level of control or options but take up more of your output channels on your lighting console or software. - Page 13 Use Menu Setting Reset Macros 0-110 No Function 111-160 Show1-Show5 161-210 Fade1-Fade5 211-255 No Function Macros 0-255 Macro Speed Speed Static Color 0-127 CCT (3200k-6500k) Macros 128-255 Color (9 Options) Penn XL – GAMMA LED Vision Page 13 of 17...
-
Page 14: Standalone Mode And Configuration
By linking the units with DMX cable in a Master/Slave connection, the first unit will control the other units to give an automatic, sound-activated, synchronized light show when the Penn XL is placed into Standalone mode by the on-board menu and keys.. Penn XL – GAMMA LED Vision... -
Page 15: Maintenance
Plug the light directly into the DMX controller with a cable that you know is good. • Unplug all other lights – does it work? Try to use another DMX controller. • Penn XL – GAMMA LED Vision Page 15 of 17... -
Page 16: Technical Specifications
◦ Shutter: Electronic Strobe ◦ Control Mode: Standard DMX512 ◦ Channel modes: 4,5,7, 9 CH ◦ Waterproof Grade: IP20 ◦ Work Environment Temperature:-20°C～40°C ◦ Dimension: 547x175x175mm ◦ Net Weight: 5.9kgs Penn XL – GAMMA LED Vision Page 16 of 17... -
Page 17: Photometric Reports
Photometric Reports 60 Degree Beam Angle, 110 Degree Field Angle Distance FC at Center 12.4 Penn XL – GAMMA LED Vision Page 17 of 17...
