Specifications; Switch 4400 (24-Port) - 3Com 3C17203 Getting Started Manual

C
Switch 4400
(24-port)
Physical Dimensions
Environmental Requirements
Operating Temperature
Storage Temperature
Operating Humidity
Standards
Safety
Agency Certifications
EMC
Emissions
Immunity
Heat Dissipation
Power Supply
AC Line Frequency
Input Voltage Options
Current Rating
(continued)
T
ECHNICAL
Height: 44 mm (1.7 in.) x Width: 440 mm (17.3 in.) x Depth: 274 mm (10.8 in.)
Weight: 2.8 kg (6.2 lbs)
0 ° to 40 °C (32 ° to 104 °F)
–40 ° to +70 °C (-40 ° to 158 °F)
10–95% relative humidity, non-condensing
EN60068 to 3Com schedule (Package testing: paras 2.1, 2.2, 2.30, and 2.32.
Operational testing: paras 2.1, 2.2, 2.30 and 2.13).
UL 1950, EN60950, CSA 22.2 No. 950, IEC 60950
CISPRR 22 Class A, EN55022 Class A, FCC Part 15 Subpart B Class A,
ICES-003 Class A, AS/NZS 3548 Class A, CNS 13438 Class A, EN61000-3-2,
EN61000-3-3
EN 55024
75 watts maximum (1300 BTU/hour maximum)
50/60 Hz
90–240 VAC
2.3 A (amps)(maximum)
S
PECIFICATIONS
