C1. Name of each part

Indicator LED
Connection method
Waiting for Wi-Fi connection
Wi-Fi
Upon Wi-Fi connection
Charge
When the program is connected
USB
6
Status
At boot
When booting up /
Blue/green flashing
Connecting to Wi-Fi Blinking green
Low battery Red/blue flashing
At power off
Charging
Fully charged
LED
Blinking blue
Green light
Blinking red
Red light
Red off
Blue light
Wi-Fi mode power button
UP button: LED Brightness button (0~3step)
DOWN button: Preview Rotation Button(90degrees)
Capture button
Long press: Start / stop movie recording
Short press: Take a picture
+DC 5V Input terminal
USB Input terminal
