Attach The Acrylic Shield - VersaTables AMHS Assembly Instructions

Adjustable Mobile Hygiene Shield
3
Pull back pullpin and insert to desired height.
Pullpin will lock into slot and align itself.
Roller Base
Qty: 1
Upright
Extension
Qty: 1
4
Attach the Acrylic Shield to the Shield Brackets by inserting the Phillips Bolts
through the Acrylic Shield and Upright extension Shield Brackets. Once in
place, insert the Phillips Bolts from the other side and tighten the Acrylic
Shield in place.
Cap Nut
Qty: 4
Carrige Bolt
Qty: 4
Acrylic Sheild
Qty: 1
