2007 Pontiac G5 Owner Manual

Seats and Restraint Systems ........................ 7

.............................................. 8

............................................. 15

............................................ 16

Child Restraints

........................................ 64

Restraint System Check

Features and Controls ................................. 83

....................................................... 85

Doors and Locks

............................................... 100

Theft-Deterrent Systems

Starting and Operating Your Vehicle

.................................................. 125

®

...................................... 131

................................................ 132

...................................... 39

......................... 80

.................................... 94

....................... 102

..... 106

................................... 127

Instrument Panel ........................................ 133

Instrument Panel Overview

Climate Controls

Warning Lights, Gages, and Indicators

Driver Information Center (DIC)

Audio System(s)

Driving Your Vehicle .................................. 217

Your Driving, the Road, and

..................................... 218

................................................. 254

Service and Appearance Care ................... 265

................................................. 268

...................................................... 270

Checking Things Under the Hood

Headlamp Aiming

Bulb Replacement

Windshield Wiper Blade Replacement

M

................... 136

................................... 152

.... 157

............ 174

................................... 185

......... 276

................................. 309

................................ 312

.... 319

1

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 2007 G5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pontiac 2007 G5

Page 1: Table Of Contents
2007 Pontiac G5 Owner Manual Seats and Restraint Systems ... 7 Front Seats ... 8 Rear Seats ... 15 Safety Belts ... 16 Child Restraints ... 39 Airbag System ... 64 Restraint System Check Features and Controls ... 83 Keys ...
Page 2 Tires ... 320 Appearance Care ... 353 Vehicle Identiﬁcation ... 361 Electrical System ... 362 Capacities and Speciﬁcations Maintenance Schedule ... 371 Maintenance Schedule Customer Assistance Information ... 393 Customer Assistance and Information ... 369 Reporting Safety Defects Index ... 413 ...
Page 3: Canadian Owners
For vehicles ﬁrst sold in Canada, substitute the name “General Motors of Canada Limited” for Pontiac Division whenever it appears in this manual. Litho in U.S.A. Part No. 15864460 A First Printing...
Page 4: How To Use This Manual
How to Use This Manual Many people read the owner manual from beginning to end when they ﬁrst receive their new vehicle. If this is done, it can help you learn about the features and controls for the vehicle. Pictures and words work together in the owner manual to explain things.
Page 5: Vehicle Damage Warnings
Vehicle Damage Warnings Also, in this manual you will ﬁnd these notices: Notice: These mean there is something that could damage your vehicle. A notice tells about something that can damage the vehicle. Many times, this damage would not be covered by your vehicle’s warranty, and it could be costly.
Page 6 These are some examples of symbols that may be found on the vehicle:...
Page 7: Seats And Restraint Systems
Section 1 Front Seats ... 8 Manual Seats ... 8 Driver Seat Height Adjuster ... 9 Manual Lumbar ... 9 Heated Seats ... 10 Reclining Seatbacks ... 10 Head Restraints ... 13 Easy Entry Seat (Coupe) ... 14 Rear Seats ... 15 Split Folding Rear Seat ...
Page 8: Front Seats
Front Seats Manual Seats CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to.
Page 9: Driver Seat Height Adjuster
Driver Seat Height Adjuster The driver’s seat height adjuster is located on the outboard side of the seat. To raise the seat, move the lever upward repeatedly until the seat is at the desired height. To lower the seat, move the lever downward repeatedly until the seat is at the desired height.
Page 10: Heated Seats
Heated Seats Your vehicle may have heated front seats. The switches are located on the instrument panel above the climate control system. Press the side of the switch with the double indicator lights to turn on the heated seat at the highest setting.
Page 11 Your seats have manual reclining seatbacks. The lever used to operate them is located on the outboard side of the seats. To recline the seatback, do the following: 1. Lift the recline lever. 2. Move the seatback to the desired position, then release the lever to lock the seatback in place.
Page 12 CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts cannot do their job when you are reclined like this. The shoulder belt cannot do its job because it will not be against your body.
Page 13: Head Restraints
Head Restraints Adjust the head restraint so that the top of the restraint is at the same height as the top of the occupant’s head. This position reduces the chance of a neck injury in a crash. Pull the head restraint up to raise it.
Page 14: Easy Entry Seat (Coupe)
Easy Entry Seat (Coupe) CAUTION: If the easy entry right front seat is not locked, it can move. In a sudden stop or crash, the person sitting there could be injured. After you have used it, be sure to push rearward on an easy entry seat to be sure it is locked.
Page 15: Rear Seats
Rear Seats Split Folding Rear Seat You can fold either side of the rear seatback down for more cargo space. To lower the rear seatback, follow these steps: 1. Open the trunk and pull one or both of the small handles located in the center of the trunk.
Page 16: Safety Belts
To raise the rear seatback, lift it up and push rearward until you hear a click. Push and pull on the seatback to be sure it is locked into place. CAUTION: If the seatback is not locked, it could move forward in a sudden stop or crash. That could cause injury to the person sitting there.
Page 17 CAUTION: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 18: Why Safety Belts Work
Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. Put someone on it. Take the simplest vehicle. Suppose it is just a seat on wheels.
Page 19 Get it up to speed. Then stop the vehicle. The rider does not stop. The person keeps going until stopped by something. In a real vehicle, it could be the windshield...
Page 20 or the instrument panel... or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense.
Page 21: Questions And Answers About Safety Belts
Questions and Answers About Safety Belts Will I be trapped in the vehicle after an accident if I am wearing a safety belt? You could be — whether you are wearing a safety belt or not. But you can unbuckle a safety belt, even if you are upside down.
Page 22: How To Wear Safety Belts Properly
How to Wear Safety Belts Properly This part is only for people of adult size. Be aware that there are special things to know about safety belts and children. And there are different rules for smaller children and babies. If a child will be riding in your vehicle, see Older Children on page 39 or Infants and Young Children on page 42.
Page 23 4. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. If the belt is not long enough, see Safety Belt Extender on page 38. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 24 The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you would be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 25 What is wrong with this? The shoulder belt is too loose. It will not give nearly as much protection this way. CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury.
Page 26 What is wrong with this? The lap belt is too loose. It will not give nearly as much protection this way. CAUTION: You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force at your abdomen.
Page 27 What is wrong with this? The belt is buckled in the wrong place. CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen.
Page 28 What is wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
Page 29 What is wrong with this? The belt is twisted across the body. CAUTION: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to ﬁx it.
Page 30: Shoulder Belt Height Adjustment
To unlatch the belt, push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.
Page 31: Safety Belt Use During Pregnancy
Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they do not wear safety belts. A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy.
Page 32: Rear Seat Passengers
Rear Seat Passengers It is very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who are not safety belted can be thrown out of the vehicle in a crash.
Page 33 2. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. When the shoulder belt is pulled out all the way, it will lock. If it does, let it go back all the way and start again.
Page 34 The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you would be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 35: Rear Safety Belt Comfort Guides
To unlatch the belt, push the button on the buckle. Rear Safety Belt Comfort Guides Rear shoulder belt comfort guides may provide added safety belt comfort for older children who have outgrown booster seats and for some adults. When installed on a shoulder belt, the comfort guide positions the belt away from the neck and head.
Page 36 2. Slide the guide under and past the belt. The elastic cord must be under the belt. Then, place the guide over the belt and insert the two edges of the belt into the slots of the guide. 3. Be sure that the belt is not twisted and it lies ﬂat.
Page 37 CAUTION: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.
Page 38: Safety Belt Pretensioners
Safety Belt Pretensioners Your vehicle has safety belt pretensioners for the driver and right front passenger. Although you cannot see them, they are part of the safety belt assembly. They help tighten the safety belts during the early stages of a moderate to severe frontal and near frontal crash if the threshold conditions for pretensioner activation are met.
Page 39: Child Restraints
Child Restraints Older Children Older children who have outgrown booster seats should wear the vehicle’s safety belts. What is the proper way to wear safety belts? An older child should wear a lap-shoulder belt and get the additional restraint a shoulder belt can provide.
Page 40 CAUTION: Never do this. Here two children are wearing the same belt. The belt can not properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time.
Page 41 CAUTION: Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt.
Page 42: Infants And Young Children
Infants and Young Children Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 43 CAUTION: Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer protection for adults and older children, but not for young children and infants. CAUTION: (Continued) CAUTION: (Continued) Neither the vehicle’s safety belt system nor its airbag system is designed for...
Page 44 What are the different types of add-on child restraints? Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic types. Selection of a particular restraint should take into consideration not only the child’s weight, height, and age but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.
Page 45: Child Restraint Systems
CAUTION: The body structure of a young child is quite unlike that of an adult or older child, for whom the safety belts are designed. A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should.
Page 46 A rear-facing infant seat (B) provides restraint with the seating surface against the back of the infant. The harness system holds the infant in place and, in a crash, acts to keep the infant positioned in the restraint. A forward-facing child seat (C-E) provides restraint for the child’s body with the harness and also sometimes with surfaces such as T-shaped or shelf-like shields.
Page 47 A booster seat (F-G) is a child restraint designed to improve the ﬁt of the vehicle’s safety belt system. Some booster seats have a shoulder belt positioner, and some high-back booster seats have a ﬁve-point harness. A booster seat can also help a child to see out the window.
Page 48 Securing an Add-on Child Restraint in the Vehicle CAUTION: A child can be seriously injured or killed in a crash if the child restraint is not properly secured in the vehicle. Make sure the child restraint is properly installed in the vehicle using the vehicle’s safety belt or LATCH system, following the instructions that came with that restraint, and also the instructions in...
Page 49: Securing The Child Within The Child Restraint
Securing the Child Within the Child Restraint There are several systems for securing the child within the child restraint. One system, the three-point harness, has straps that come down over each of the infant’s shoulders and buckle together at the crotch. The ﬁve-point harness system has two shoulder straps, two hip straps, and a crotch strap.
Page 50 Your vehicle has a rear seat that will accommodate a rear-facing child restraint. A label on your sun visor says, “Never put a rear-facing child seat in the front.” This is because the risk to the rear-facing child is so great, if the airbag deploys. CAUTION: A child in a rear-facing child restraint can be seriously injured or killed if the right...
Page 51: Lower Anchors And Tethers For Children (Latch)
Lower Anchors and Tethers for Children (LATCH) The LATCH system holds a child restraint during driving or in a crash. This system is designed to make installation of a child restraint easier. The LATCH system uses anchors in the vehicle and attachments on the child restraint that are made for use with the LATCH system Make sure that a LATCH-compatible child restraint...
Page 52 Top Tether Anchor A top tether (A, C) anchors the top of the child restraint to the vehicle. A top tether anchor is built into the vehicle. The top tether attachment (B) on the child restraint connects to the top tether anchor in the vehicle in order to reduce the forward movement and rotation of the child restraint during driving or in a crash.
Page 53 Lower Anchor and Top Tether Anchor Locations Seating positions with top tether anchors. (Lower Anchor): Seating positions with two lower anchors. Rear Seat Each rear seating position has two exposed metal lower anchors in the crease between the seatback and the seat cushion. To assist you in locating the top tether anchors, the top tether anchor...
Page 54 Securing a Child Restraint Designed for the LATCH System CAUTION: If a LATCH-type child restraint is not attached to anchors, the restraint will not be able to protect the child correctly. In a crash, the child could be seriously injured or killed.
Page 55 CAUTION: Children can be seriously injured or strangled if a shoulder belt is wrapped around their neck and the safety belt continues to tighten. Secure any unused safety belts behind the child restraint so children cannot reach them. Pull the shoulder belt all the way out of the retractor to set the lock, if your vehicle has one, after the child restraint has...
Page 56 2. If the child restraint manufacturer recommends that the top tether be attached, attach and tighten the top tether to the top tether anchor, if equipped. Refer to the child restraint instructions and the following steps: 2.1. Find the top tether anchor. 2.2.
Page 57: Securing A Child Restraint In A Rear Seat Position
If the position you are using has a ﬁxed or adjustable head restraint and you are using a dual tether, route the tether around the head restraint. 3. Push and pull the child restraint in different directions to be sure it is secure. Securing a Child Restraint in a Rear Seat Position If your child restraint has the LATCH system,...
Page 58 3. Buckle the belt. Make sure the release button 4. Pull the rest of the shoulder belt all the way is positioned so you would be able to unbuckle out of the retractor to set the lock. the safety belt quickly if you ever had to.
Page 59 5. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt, and feed the shoulder belt back into the retractor. If you are using a forward-facing child restraint, you may ﬁnd it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 60: Securing A Child Restraint In The Right Front Seat Position
Securing a Child Restraint in the Right Front Seat Position Your vehicle has a right front passenger’s airbag. A rear seat is a safer place to secure a forward-facing child restraint. See Where to Put the Restraint on page 49. In addition, your vehicle may have the passenger sensing system.
Page 61 CAUTION: (Continued) If you need to secure a forward-facing child restraint in the right front seat, always move the front passenger seat as far back as it will go. It is better to secure the child restraint in a rear seat. If you need to secure a forward-facing child restraint in the right front seat position, move the seat as far back as it will go before securing the...
Page 62 2. Put the child restraint on the seat. 3. Pick up the latch plate, and run the lap and shoulder portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how. 4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 63 6. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt, and feed the shoulder belt back into the retractor. If you are using a forward-facing child restraint, you may ﬁnd it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 64: Airbag System
Airbag System Your vehicle has a frontal airbag for the driver and a frontal airbag for the right front passenger. Your vehicle may also have roof-mounted side impact airbags. Roof-mounted side impact airbags are available for the driver and the passenger seated directly behind the driver and for the right front passenger and the passenger seated directly behind that passenger.
Page 65 CAUTION: (Continued) Frontal airbags for the driver and right front passenger are designed to deploy in moderate to severe frontal and near frontal crashes. They are not designed to inﬂate in rollover, rear crashes, or in many side crashes. And, for some unrestrained occupants, frontal airbags may provide less protection in frontal crashes than more forceful airbags have provided in...
Page 66 CAUTION: Anyone who is up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer the best protection for adults, but not for young children and infants. Neither the vehicle’s safety belt system nor its airbag system is designed for them.
Page 67: Where Are The Airbags
Where Are the Airbags? The driver’s frontal airbag is in the middle of the steering wheel. The right front passenger’s frontal airbag is in the instrument panel on the passenger’s side.
Page 68 If your vehicle has a roof-mounted side impact airbag for the driver and the person seated directly behind the driver, it is located in the ceiling above the side windows. If your vehicle has a roof-mounted side impact airbag for the right front passenger and the person directly behind that passenger, it is located in the ceiling above the side windows.
Page 69: When Should An Airbag Inﬂate
CAUTION: If something is between an occupant and an airbag, the bag might not inﬂate properly or it might force the object into that person causing severe injury or even death. The path of an inﬂating airbag must be kept clear. Do not put anything between an occupant and an airbag, and do not attach or put anything on the steering wheel hub or on or near any...
Page 70 If the front of your vehicle goes straight into a wall that does not move or deform, the threshold level for the reduced deployment is about 12 to 16 mph (19 to 26 km/h), and the threshold level for a full deployment is about 18 to 24 mph (29 to 38.5 km/h).
Page 71: What Makes An Airbag Inﬂate
What Makes an Airbag Inﬂate? In an impact of sufficient severity, the airbag sensing system detects that the vehicle is in a crash. The sensing system triggers a release of gas from the inﬂator, which inﬂates the airbag. The inﬂator, airbag, and related hardware are all part of the airbag modules inside the steering wheel and in the instrument panel in front of the right front passenger.
Page 72: What Will You See After An Airbag Inﬂates
What Will You See After an Airbag Inﬂates? After a frontal airbag inﬂates, it quickly deﬂates, so quickly that some people may not even realize the airbag inﬂated. Roof-mounted side impact airbags may still be at least partially inﬂated minutes after the vehicle comes to rest. Some components of the airbag module —...
Page 73: Passenger Sensing System
In many crashes severe enough to inﬂate an airbag, windshields are broken by vehicle deformation. Additional windshield breakage may also occur from the right front passenger airbag. • Airbags are designed to inﬂate only once. After an airbag inﬂates, you will need some new parts for the airbag system.
Page 74 The passenger sensing system will turn off the right front passenger’s frontal airbag under certain conditions. The driver’s airbags are not part of the passenger sensing system. The passenger sensing system works with sensors that are part of the right front passenger’s seat and safety belt.
Page 75 CAUTION: (Continued) If you need to secure a forward-facing child restraint in the right front seat, always move the front passenger seat as far back as it will go. It is better to secure the child restraint in a rear seat. The passenger sensing system is designed to turn off the right front passenger’s frontal airbag if: •...
Page 76 The passenger sensing system is designed to enable (may inﬂate) the right front passenger’s frontal airbag anytime the system senses that a person of adult size is sitting properly in the right front passenger’s seat. When the passenger sensing system has allowed the airbag to be enabled, the on indicator will light and stay lit to remind you that the airbag is active.
Page 77 CAUTION: If the airbag readiness light in the instrument panel cluster ever comes on and stays on, it means that something may be wrong with the airbag system. If this ever happens, have the vehicle serviced promptly, because an adult-size person sitting in the right front passenger’s seat may not have the protection of the frontal airbag.
Page 78: Servicing Your Airbag-Equipped Vehicle
Servicing Your Airbag-Equipped Vehicle Airbags affect how your vehicle should be serviced. There are parts of the airbag system in several places around your vehicle. You do not want the system to inﬂate while someone is working on your vehicle. Your dealer and the service manual have information about servicing your vehicle and the airbag system.
Page 79: Adding Equipment To Your Airbag-Equipped Vehicle
Adding Equipment to Your Airbag-Equipped Vehicle Is there anything I might add to the front or sides of the vehicle that could keep the airbags from working properly? Yes. If you add things that change your vehicle’s frame, bumper system, height, front end or side sheet metal, they may keep the airbag system from working properly.
Page 80: Restraint System Check
Restraint System Check Checking the Restraint Systems Now and then, make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired.
Page 81: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts After a Crash CAUTION: A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary replacements made as...
Page 82 NOTES...
Page 83 Section 2 Keys ... 85 Remote Keyless Entry (RKE) System ... 86 Remote Keyless Entry (RKE) System Operation ... 87 Doors and Locks ... 94 Door Locks ... 94 Power Door Locks ... 95 Delayed Locking ... 95 Automatic Door Lock ... 96 Programmable Automatic Door Unlock ...
Page 84: Features And Controls
Section 2 ® OnStar System ... 127 Storage Areas ... 131 Glove Box ... 131 Cupholder(s) ... 131 Features and Controls Center Console Storage Area ... 131 Driver’s Storage Compartment ... 131 Convenience Net ... 131 Sunroof ... 132...
Page 85: Keys
Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons. They could operate the power windows or other controls or even make the vehicle move. The children or others could be badly injured or even killed. Do not leave the keys in a vehicle with children.
Page 86: Remote Keyless Entry (Rke) System
One key is used for the ignition, the doors and all other locks. When a new vehicle is delivered, the dealer removes the key tag from the key and gives it to the ﬁrst owner. Each tag has a code on it that tells your dealer or a qualiﬁed locksmith how to make extra keys.
Page 87: Remote Keyless Entry (Rke) System Operation
At times you may notice a decrease in range. This is normal for any RKE system. If the transmitter does not work or if you have to stand closer to your vehicle for the transmitter to work, try this: • Check the distance.
Page 88 (Remote Vehicle Start): If your vehicle has this feature, the engine may be started from outside the vehicle using the RKE transmitter. See “Remote Vehicle Start” later in this section for more detailed information. (Lock): Press the lock button to lock all the doors.
Page 89: Matching Transmitter(S) To Your Vehicle
(Remote Trunk Release): The trunk will open when this button on the transmitter is pressed and held for about one second. You can open the trunk with the transmitter when the vehicle speed is less than 2 mph (3 km/h), when the ignition is off, or when the vehicle shift lever is in PARK (P), if your vehicle has an automatic transaxle.
Page 90: Battery Replacement
Battery Replacement Under normal use, the battery in your RKE transmitter should last about four years. The battery is weak if the transmitter will not work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it is probably time to change the battery.
Page 91: Remote Vehicle Start
Remote Vehicle Start Your vehicle may have a remote start feature. This feature allows you to start the engine from outside the vehicle. It may also start the vehicle’s heating or air conditioning systems. When you start your vehicle using the remote start feature, the climate control system will come on and adjust the interior to the temperature settings that you left it set to when you turned the...
Page 92 (Remote Start): If your vehicle has the remote start feature, the RKE transmitter will have a button with this symbol on it. To start the vehicle using the remote start feature, do the following: 1. Aim the transmitter at the vehicle. 2.
Page 93 The remote vehicle start feature will not operate if any of the follow occur: • The remote start system is disabled through the DIC. • The vehicle’s key is in the ignition. • The vehicle’s hood is open. • The hazard warning ﬂashers are on. •...
Page 94: Doors And Locks
Doors and Locks Door Locks CAUTION: Unlocked doors can be dangerous. • Passengers, especially children, can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle will not open it. You increase the chance of being thrown out of the vehicle in a crash if the doors are not locked.
Page 95: Power Door Locks
Power Door Locks Your vehicle may have power door locks. The locks are located on the driver’s and front passenger’s door armrest. Driver’s Switch shown, Front Passenger’s Switch similar Press the side of the switch with the lock symbol to lock the doors. This is the right side for the driver’s switch and the left side for the front passenger’s switch.
Page 96: Automatic Door Lock
Automatic Door Lock If your vehicle has power door locks, the doors will automatically lock when the shift lever is moved out of PARK (P) for a vehicle with an automatic transaxle. For a vehicle with a manual transaxle, the speed must be greater than 5 mph (8 km/h). The automatic door locking feature cannot be disabled.
Page 97: Lockout Protection
To set the locks, do the following: 1. Insert the key into the security lock slot and turn it so the slot is in the horizontal position. 2. Close the door. When you want to open a rear door when the security lock is on, do the following: 1.
Page 98: Trunk
Trunk To release the trunk lid from the outside, use the key or the remote keyless entry transmitter, if equipped. CAUTION: It can be dangerous to drive with the trunk lid open because carbon monoxide (CO) gas can come into your vehicle. You cannot see or smell CO.
Page 99: Remote Trunk Release
Remote Trunk Release To open the trunk from inside the vehicle, press the remote trunk release button located inside the driver’s storage compartment located on the lower left side of the instrument panel. See Instrument Panel Overview on page 136 or Driver’s Storage Compartment on page 131.
Page 100: Windows
Windows CAUTION: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 101: Power Windows
Power Windows If your vehicle has power windows, the switches on the driver’s door armrest control each of the windows. Sedan Shown, Coupe Similar In addition, each passenger’s door has a window switch that controls that door’s window. Press the front of the switch to open the window. Pull the front of the switch up to close it.
Page 102: Theft-Deterrent Systems
Sun Visors To block out glare, swing down the visor(s). The visors can also be detached from the center mount and swung to the side to cover the windows. Visor Vanity Mirror Your vehicle may have a driver’s side vanity mirror.
Page 103: Disarming The System
The security light, located on the instrument panel cluster, will turn on to indicate that arming has been initiated. Once the system is armed, the security light will ﬂash once every three seconds. If the security light is ﬂashing twice per second, this means that a door is open.
Page 104: How To Detect A Tamper Condition
How to Detect a Tamper Condition If you hear three chirps when you press the unlock, lock, or trunk release buttons on the remote keyless transmitter, it means that the content theft security system alarm was previously activated. ® PASS-Key III+ ®...
Page 105 ® When the PASS-Key III+ system senses that someone is using the wrong key, it prevents the vehicle from starting. Anyone using a trial-and-error method to start the vehicle will be discouraged because of the high number of electrical key codes. When trying to start the vehicle if the engine does not start and the security light comes on, the key may have a damaged transponder.
Page 106: Starting And Operating Your Vehicle
If you are ever driving and the security light comes on and stays on, you may be able to restart your engine if you turn it off. Your PASS-Key system, however, is not working properly and must be serviced by your dealer. Your vehicle is not ®...
Page 107: Ignition Positions
Ignition Positions With the key in the ignition switch, you can turn it to four different positions. Notice: Using a tool to force the key from the ignition switch could cause damage or break the key. Use the correct key and turn the key only with your hand.
Page 108: Key In The Ignition
(RUN): This is the position the switch returns to after you start your engine and release the switch. The switch stays in the RUN position when the engine is running. But even when the ignition is not running, you can use RUN to operate your electrical accessories and to display some warning and indicator lights.
Page 109 Column Lock Release For vehicles with an automatic transaxle, The following procedure allows the ignition to be turned to LOCK and for ignition key removal in case of a dead battery or low voltage battery. 1. Make sure the shift lever is in PARK (P). 2.
Page 110: Retained Accessory Power (Rap)
Retained Accessory Power (RAP) Your vehicle has a Retained Accessory Power (RAP) feature which allow’s the radio, power windows, and sunroof to continue to work up to 10 minutes after the ignition is turned off. Your vehicle’s radio will work when the ignition key is in RUN or ACC.
Page 111 Your vehicle has a Computer-Controlled Cranking System. This feature assists in starting the engine and protects components. If the ignition key is turned to the START position, and then released when the engine begins cranking, the engine will continue cranking for a few seconds or until the vehicle starts.
Page 112: To Use The Engine Coolant Heater
Engine Coolant Heater Your vehicle may be equipped with an engine coolant heater. In very cold weather, 0°F ( 18°C) or colder, the engine coolant heater can help. You will get easier starting and better fuel economy during engine warm-up. Usually, the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle.
Page 113: Automatic Transaxle Operation
Automatic Transaxle Operation If your vehicle has an automatic transaxle, the shift lever is located on the console between the seats. There are several different positions for the automatic transaxle. PARK (P): This position locks your front wheels. It is the best position to use when you start your engine because your vehicle cannot move easily.
Page 114 You have to fully apply your regular brakes ﬁrst and then press the shift lever button before you can shift from PARK (P) when the ignition key is in RUN. If you cannot shift out of PARK (P), ease pressure on the shift lever and push the shift lever all the way into PARK (P) as you maintain brake application.
Page 115 DRIVE (D): This position is for normal driving with the automatic transaxle. It provides the best fuel economy for your vehicle. If you need more power for passing, and you are: • Going less than about 35 mph (55 km/h), push your accelerator pedal about halfway down.
Page 116: Manual Transaxle Operation
Manual Transaxle Operation This is your shift pattern. Here is how to operate your manual transaxle: FIRST (1): Press the clutch pedal and shift into FIRST (1). Then, slowly let up on the clutch pedal as you press the accelerator pedal. You can shift into FIRST (1) when you are going less than 20 mph (32 km/h).
Page 117: Shift Speeds
Shift Speeds CAUTION: If you skip a gear when you downshift, you could lose control of your vehicle. You could injure yourself or others. Do not shift down more than one gear at a time when you downshift. Up-Shift Light If you have a manual transaxle, you may have an up-shift light.
Page 118: Parking Brake
Parking Brake The parking brake lever is located between the front seats. For vehicles equipped with an armrest, lift the console armrest in order to access the parking brake lever. To set the parking brake, hold the brake pedal down and pull up on the parking brake lever. If the ignition is on, the brake system warning light will come on.
Page 119: Shifting Into Park (P) (Automatic Transaxle)
Shifting Into Park (P) (Automatic Transaxle) CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 120: Leaving Your Vehicle With The Engine Running
Leaving Your Vehicle With the Engine Running CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch ﬁre.
Page 121: Shifting Out Of Park (P) (Automatic Transaxle)
Shifting Out of Park (P) (Automatic Transaxle) This vehicle is equipped with an electronic shift lock release system. The shift lock release is designed to: • Prevent ignition key removal unless the shift lever is in PARK (P) with the shift lever button fully released, and •...
Page 122: Parking Over Things That Burn
Parking Over Things That Burn CAUTION: Things that can burn could touch hot exhaust parts under your vehicle and ignite. Do not park over papers, leaves, dry grass, or other things that can burn.
Page 123: Engine Exhaust
Engine Exhaust CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you cannot see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: • Your exhaust system sounds strange or different. •...
Page 124: Running The Engine While Parked
Running the Engine While Parked It is better not to park with the engine running. But if you ever have to, here are some things to know. CAUTION: Idling the engine with the climate control system off could allow dangerous exhaust into your vehicle.
Page 125: Mirrors
Mirrors Manual Rearview Mirror While sitting in a comfortable driving position, adjust the mirror so you can see clearly behind your vehicle. Grip the mirror in the center to move it up or down and side to side. The control at the bottom of the mirror is the day/night feature that allows adjustment to the mirror so that the glare of headlamps from behind is reduced.
Page 126: Outside Power Mirrors
Outside Power Mirrors The controls for the outside power mirrors are located on the driver’s door armrest. Move the selector switch located below the four-way control pad to the left or right to choose either the driver’s side or passenger’s side mirror.
Page 127: Onstar ® System
® OnStar System ® OnStar uses several innovative technologies and live advisors to provide you with a wide range of safety, security, information, and convenience services. If your airbags deploy, the system is designed to make an automatic call to OnStar Emergency advisors who can request emergency services be sent to your location.
Page 128 ® OnStar Services For new vehicles equipped with OnStar & Sound Plan, or the Directions & Connections Plan is included for one year from the date of purchase. You can extend this plan beyond the ﬁrst year, or upgrade to the Directions & ®...
Page 129 ® OnStar Virtual Advisor ® OnStar Virtual Advisor is a feature of OnStar Hands-Free Calling that uses your minutes to access location-based weather, local traffic reports, and stock quotes. By pressing the phone button and giving a few simple voice commands, you can browse through the various topics.
Page 130 ® OnStar service cannot work unless your vehicle ® is in a place where OnStar has an agreement with a wireless service provider for service in that ® area. OnStar service also cannot work unless you are in a place where the wireless service ®...
Page 131: Storage Areas
Storage Areas Glove Box Open the glove box by lifting up on the lever. Close the glove box with a ﬁrm push. Cupholder(s) There are two cupholders located at the front of the center console, in front of the shift lever. There are also cupholders for the rear seat passengers located at the rear of the center console.
Page 132: Sunroof
Sunroof If the vehicle has a sunroof, the switch that operates it is located on the headliner between the map lamps. The sunroof will only operate while the ignition is on, or turned to ACC, or if Retained Accessory Power (RAP) is active. See Retained Accessory Power (RAP) on page 110.
Page 133: Instrument Panel
Section 3 Instrument Panel Overview ... 136 Hazard Warning Flashers ... 138 Other Warning Devices ... 138 Horn ... 138 Tilt Wheel ... 139 Turn Signal/Multifunction Lever ... 139 Turn and Lane-Change Signals ... 140 Headlamp High/Low-Beam Changer ... 140 Flash-to-Pass ...
Page 134 Section 3 Anti-Lock Brake System Warning Light ... 166 Enhanced Traction System Warning Light ... 166 Engine Coolant Temperature Warning Light ... 167 Malfunction Indicator Lamp ... 168 Oil Pressure Light ... 171 Security Light ... 172 Fog Lamp Light ... 172 Highbeam On Light ...
Page 135 NOTES...
Page 136: Instrument Panel Overview
Instrument Panel Overview...
Page 137 The main components of your instrument panel are the following: A. Side Window Outlets. See Climate Control System on page 152. B. Air Outlets. See Outlet Adjustment on page 155. C. Turn Signal/Multifunction Lever. See Turn Signal/Multifunction Lever on page 139. D.
Page 138: Hazard Warning Flashers
Hazard Warning Flashers Your hazard warning ﬂashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will ﬂash on and off. The hazard warning ﬂasher button is located in the center of the instrument panel.
Page 139: Tilt Wheel
Tilt Wheel A tilt wheel allows you to adjust the steering wheel before you drive. You can raise the steering wheel to the highest level to give your legs more room when you enter and exit the vehicle. The lever that allows you to tilt the steering wheel is located on the left side of the steering column.
Page 140: Turn And Lane-Change Signals
Turn and Lane-Change Signals The turn signal has two upward (for right) and two downward (for left) positions. These positions allow you to signal a turn or a lane change. To signal a turn, move the lever all the way up or down.
Page 141: Flash-To-Pass
Flash-to-Pass This feature lets you use your high-beam headlamps to signal a driver in front of you that you want to pass. To use it, pull the turn signal/multifunction lever toward you until the high-beam headlamps come on, then release the lever to turn them off. Windshield Wipers Use this lever, located on the right side of the steering wheel, to operate the windshield wipers.
Page 142: Windshield Washer
(Mist): Move the lever all the way down to this position for a single wiping cycle. Hold it there until the windshield wipers start; then let go. The windshield wipers will stop after one wiping cycle. If you want additional wiping cycles, hold the lever down longer.
Page 143: Cruise Control
Cruise Control With cruise control, you can maintain a speed of about 25 mph (40 km/h) or more without keeping your foot on the accelerator. This can really help on long trips. Cruise control does not work at speeds below 25 mph (40 km/h). CAUTION: Cruise control can be dangerous where you cannot drive safely at a steady speed.
Page 144 (On/Off): Press this button to turn the cruise control system on and off. RES+ (Resume): Press this button to resume a set speed and to accelerate the speed. SET– (Set): Press this button to set a speed and to decrease the speed. To set a speed do the following: 1.
Page 145 Reducing Speed While Using Cruise Control If the cruise control system is already engaged, • Push and hold the SET– part of the button until you reach the lower speed you want, then release it. • To slow down in very small amounts, push the SET–...
Page 146: Headlamps
Headlamps The lever on the left side of the steering column operates the exterior lamps. The exterior lamp switch has the following four positions: (Headlamps): Turn the switch to this position to turn on the headlamps, parking lamps, and taillamps. (Parking Lamps): Turn the switch to this position to turn on the parking lamps and taillamps only.
Page 147: Wiper Activated Headlamps
Wiper Activated Headlamps This feature activates the headlamps and parking lamps after the windshield wipers are turned on. For this feature to work, automatic lighting must be enabled. See Headlamps on page 146 for additional information. When the ignition is turned off, the wiper-activated headlamps will immediately turn off.
Page 148: Fog Lamps
The DRL system will be off any time your vehicle is in PARK (P). The DRL system on U.S. vehicles can also be turned off by using the off/on switch for one ignition cycle. As with any vehicle, you should turn on the regular headlamp system when you need it.
Page 149: Dome Lamp
Dome Lamp Your vehicle may have a dome lamp. (Off): Move the lever to this position to turn the lamp off, even when a door is opened. (Door): Move the lever to this position to turn the lamp on whenever a door is opened. (On): Move the lever to this position to turn the dome lamp on.
Page 150: Battery Run-Down Protection
The battery can be discharged at idle if the electrical loads are very high. This is true for all vehicles. This is because the generator (alternator) may not be spinning fast enough at idle to produce all the power that is needed for very high electrical loads.
Page 151: Ashtray(S) And Cigarette Lighter
Certain electrical accessories may not be compatible with the accessory power outlet and could result in blown vehicle or adapter fuses. If you experience a problem, see your dealer for additional information on the accessory power outlet. Notice: Adding any electrical equipment to your vehicle may damage it or keep other components from working as they should.
Page 152: Climate Controls
Climate Controls Climate Control System With this system you can control the heating, cooling, and ventilation for the vehicle. Vehicles with Air Conditioning shown, without Air Conditioning similar Operation To change the current mode, select one of the following: (Vent): This mode directs air to the instrument panel outlets.
Page 153 (Recirculate): Press this button to prevent outside air and odors from entering the vehicle or to help heat or cool the air inside the vehicle more quickly. An indicator light above the button will come on in this mode. The air conditioning compressor also comes on.
Page 154: Defogging And Defrosting
Defogging and Defrosting Fog on the inside of windows is a result of high humidity (moisture) condensing on the cool window glass. This can be minimized if the climate control system is used properly. There are two modes to clear fog or frost from the windshield and side windows.
Page 155: Outlet Adjustment
Outlet Adjustment Use the thumbwheels located next to and below the air outlets to change the direction of the airﬂow and to open and close the outlets. Operation Tips • Clear away any ice, snow or leaves from the air inlets at the base of the windshield that may block the ﬂow of air into your vehicle.
Page 156 3. Open the passenger compartment air ﬁlter door by reaching through the opening in the back of the glove box and raising the tab until the door can be opened downward. 4. Remove the ﬁlter by sliding it out of the housing.
Page 157: Warning Lights, Gages, And Indicators
Warning Lights, Gages, and Indicators This part describes the warning lights and gages that may be on your vehicle. The pictures will help you locate them. Warning lights and gages can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement.
Page 158: Instrument Panel Cluster
Instrument Panel Cluster Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You will know how fast you are going, about how much fuel is left in the tank, and many other things you will need to drive safely and economically.
Page 159: Speedometer And Odometer
Speedometer and Odometer Your speedometer lets you see your speed in both miles per hour (mph) and kilometers per hour (km/h). Your vehicle’s odometer works together with the driver information center. You can set a Trip A and Trip B odometer. See “Trip Information” under DIC Operation and Displays on page 174.
Page 160: Safety Belt Reminder Light
Safety Belt Reminder Light When the key is turned to RUN or START, a chime will sound for several seconds to remind you and your passengers to buckle your safety belts. The driver safety belt light will also come on and stay on for several seconds, then it will ﬂash for several more.
Page 161: Airbag Readiness Light
Airbag Readiness Light There is an airbag readiness light on the instrument panel cluster, which shows the airbag symbol. The system checks the airbag’s electrical system for malfunctions. The light tells you if there is an electrical problem. The system check includes the airbag sensor, the airbag modules, the wiring and the crash sensing and diagnostic module.
Page 162: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator If your vehicle has the passenger sensing system, then your instrument panel has a passenger airbag status indicator. See Passenger Sensing System on page 73. United States When the ignition key is turned to RUN or START, the passenger airbag status indicator will light ON and OFF, or the symbol for on and off, for several seconds as a system check.
Page 163 CAUTION: Even though the passenger sensing system is designed to turn off the passenger’s frontal airbag if the system detects a rear-facing child restraint, no system is failsafe, and no one can guarantee that an airbag will not deploy under some unusual circumstance, even though it is turned off.
Page 164: Charging System Light
Charging System Light The charging system light will come on brieﬂy when you turn on the ignition, and the engine is not running, as a check to show you it is working. Then it should go out when the engine is started. If it stays on, or comes on while you are driving, you may have a problem with the electrical charging system.
Page 165: Brake System Warning Light
Brake System Warning Light Your vehicle’s hydraulic brake system is divided into two parts. If one part is not working, the other part can still work and stop you. For good braking, though, you need both parts working well. If the warning light comes on, there is a brake problem.
Page 166: Anti-Lock Brake System Warning Light
Anti-Lock Brake System Warning Light Your vehicle may have an Anti-Lock Brake System (ABS) warning light. The ABS warning light will come on brieﬂy when you turn the ignition key to LOCK. This is normal. If the light does not come on then, have it ﬁxed so it will be ready to warn you if there is a problem.
Page 167: Engine Coolant Temperature Warning Light
The Enhanced Traction System warning light may come on for the following reasons: • If you turn the system off by moving the shift lever to LOW (L), the warning light will come on and stay on. To turn the system back on, move the shift lever back to a position other than LOW (L).
Page 168: Malfunction Indicator Lamp
Malfunction Indicator Lamp Check Engine Light Your vehicle has a computer which monitors operation of the fuel, ignition, and emission control systems. This system is called OBD II (On-Board Diagnostics-Second Generation) and is intended to assure that emissions are at acceptable levels for the life of the vehicle, helping to produce a cleaner environment.
Page 169: If The Light Is Flashing
This light should come on, as a check to show you it is working, when the ignition is on and the engine is not running. If the light does not come on, have it repaired. This light will also come on during a malfunction in one of two ways: •...
Page 170: If The Light Is On Steady
If the Light Is On Steady You may be able to correct the emission system malfunction by considering the following: Did you recently put fuel into your vehicle? If so, reinstall the fuel cap, making sure to fully install the cap. See Filling the Tank on page 274. The diagnostic system can determine if the fuel cap has been left off or improperly installed.
Page 171: Emissions Inspection And Maintenance Programs
Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or may begin programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. Here are some things you need to know to help your vehicle pass an inspection: Your vehicle will not pass this inspection if the check engine light is on or not working properly.
Page 172: Security Light
• If you are idling at a stop sign, the light may blink on and then off. • If you make a hard stop, the light may come on for a moment. This is normal. CAUTION: Do not keep driving if the oil pressure is low.
Page 173: Highbeam On Light
Highbeam On Light This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 140. Fuel Gage Your fuel gage tells you about how much fuel you have left. Here are four things that some owners ask about. None of these show a problem with your fuel gage: •...
Page 174: Driver Information Center (Dic)
Driver Information Center (DIC) Your vehicle has a Driver Information Center (DIC). The DIC display gives you the status of many of your vehicle’s systems. The DIC is also used to display driver personalization menu modes and warning/status messages. All messages will appear in the DIC display, located at the bottom of the instrument panel cluster.
Page 175: Information Modes
Information Modes (Information): Press this button to scroll through the following vehicle information modes: Outside Air Temperature and Odometer Press the information button until the outside air temperature and the odometer are displayed. This mode shows the temperature outside of the vehicle in either degrees Fahrenheit (°F) or degrees Celsius (°C) and the total distance the vehicle has been driven in either miles (mi) or kilometers (km).
Page 176 ECON (Economy) Press the information button until ECON is displayed. This mode shows how many miles per gallon (mpg) or liters per 100 kilometers (L/100 km) your vehicle is getting based on current and past driving conditions. Press and hold the reset button while ECON is displayed to reset the average fuel economy.
Page 177: Dic Warnings And Messages
DIC Warnings and Messages These messages appear if there is a problem detected in one of your vehicle’s systems. A message will clear when the vehicle’s condition is no longer present. To acknowledge a message and clear it from the display, press and hold any of the DIC buttons.
Page 178 COOLING MODE ON This message may display on some vehicles. Under severe conditions, hot ambient temperatures, steep grades, and towing, your vehicle may experience more transaxle shifting. This is temporary and normal under these conditions. This does not require engine or transaxle service.
Page 179: Dic Vehicle Personalization
LOW FUEL This message displays when your vehicle is low on fuel. Reﬁll the fuel tank as soon as possible. See Fuel Gage on page 173, Fuel on page 270, and Filling the Tank on page 274 for more information. LOW TRACTION This message displays when the Enhanced Traction System (ETS) is actively limiting wheel...
Page 180: Entering Personalization Menu
To change feature settings, use the following procedure: Entering Personalization Menu 1. Turn the ignition on while the vehicle is stopped. To avoid excessive drain on the battery, it is recommended that the headlamps are turned off. 2. Press and hold the information and reset buttons at the same time for one second, then release to enter the personalization menu.
Page 181 Choose one of the available settings and press the information button to select it and move on to the next feature. LOCK HORN If your vehicle has Remote Keyless Entry (RKE), this feature, which allows the vehicle’s horn to chirp every time the lock button on the RKE transmitter is pressed, can be enabled or disabled.
Page 182 LIGHT FLASH If your vehicle has Remote Keyless Entry (RKE), this feature, which allows the vehicle’s exterior hazard/turn signal lighting to ﬂash every time the lock, unlock, or trunk release buttons on the RKE transmitter are pressed, can be enabled or disabled.
Page 183 AUTO UNLK (Unlock) This feature, which allows the vehicle to automatically unlock certain doors, can be enabled or disabled. When AUTO UNLK appears on the display, press and hold the reset button for at least one second to scroll through the available settings: ALL (default): All of the doors will automatically unlock.
Page 184 EXT (Exterior) LIGHTS If your vehicle has Remote Keyless Entry (RKE), this feature, which allows the vehicle’s exterior perimeter lighting to turn on each time the unlock button on the RKE transmitter is pressed, can be enabled or disabled. When EXT LIGHTS appears on the display, press and hold the reset button for at least one second to scroll through the available settings:...
Page 185: Exiting Personalization Menu
Exiting Personalization Menu The personalization menu will be exited when any of the following conditions occur: • A ten second time period has elapsed. • The ignition is turned off. • The end of the personalization menu list is reached. Audio System(s) Determine which radio your vehicle has and then read the pages following to familiarize yourself...
Page 186: Setting The Time (Without Date Display)
While your vehicle is parked: • Familiarize yourself with all of its controls. • Familiarize yourself with its operation. • Set up your audio system by presetting your favorite radio stations, setting the tone, and adjusting the speakers. Then, when driving conditions permit, you can tune to your favorite radio stations using the presets and steering wheel controls if the vehicle has them.
Page 187: Setting The Time (With Date Display)
3. Press the clock button again until the clock display stops ﬂashing to set the currently displayed time; otherwise, the ﬂashing will stop after ﬁve seconds and the current time displayed will be automatically set. To change the time default setting from 12 hour to 24 hour, press the clock button and then the pushbutton located under the forward arrow label.
Page 188 To set the time and date, follow these instructions: 1. Turn the radio on. 2. Press the MENU button. Once the clock option is displayed. 3. Press the pushbutton located under that label. The HR, MIN, MM, DD, YYYY displays. 4.
Page 189: Radio With Cd (Base)
Radio with CD (Base) Playing the Radio (Power/Volume): Press this knob to turn the system on and off. Turn this knob clockwise or counterclockwise to increase or decrease the volume. The radio goes to the previous volume setting whenever the radio is turned on. The volume can still be adjusted by using the volume knob.
Page 190 Setting Preset Stations Up to 18 stations (six FM1, six FM2, and six AM), can be programmed on the six numbered pushbuttons, by performing the following steps: 1. Turn the radio on. 2. Press BAND to select FM1, FM2, or AM. 3.
Page 191: Playing A Cd (Single Cd Player)
Playing a CD (Single CD Player) Insert a CD partway into the slot, label side up. The player pulls it in and the CD should begin playing. If the ignition or radio is turned off with a CD in the player, it stays in the player.
Page 192 © ¨ SEEK : Press the left SEEK arrow to go to the start of the current track, if more than ten seconds have played. Press the right SEEK arrow to go to the next track. If either SEEK arrow is held or pressed multiple times, the player continues moving backward or forward through the CD.
Page 193: Using The Auxiliary Input Jack
CD Messages CHECK DISC: If an error message displays and/or the CD comes out, it could be for one of the following reasons: • It is very hot. When the temperature returns to normal, the CD should play. • You are driving on a very rough road. When the road becomes smoother, the CD should play.
Page 194: Radio With Cd (Mp3)
Radio with CD (MP3) BAND: Press this button to listen to the radio while a portable audio device is playing. The portable audio device continues playing, so you might want to stop it or turn it off. CD/AUX (CD/Auxiliary): Press this button to play a CD while a portable audio device is playing.
Page 195: Radio Data System (Rds)
Radio Data System (RDS) The audio system has a Radio Data System (RDS). The RDS feature is available for use only on FM stations that broadcast RDS information. This system relies upon receiving speciﬁc information from these stations and only works when the information is available.
Page 196 Finding a Station BAND: Press this button to switch between AM, FM, or XM™ (if equipped). The selection displays. (Tune): Turn this knob to select radio stations. © ¨ SEEK : Press the right or left SEEK arrow to go to the next or to the previous station and stay there.
Page 197 FAV (Favorites): A maximum of 36 stations can be programmed as favorites using the six pushbuttons positioned below the radio station frequency labels and by using the radio favorites page button (FAV button). Press the FAV button to go through up to six pages of favorites, each having six favorite stations available per page.
Page 198 Setting the Tone (Bass/Midrange/Treble) BASS/MID/TREB (Bass, Midrange, or Treble): To adjust bass, midrange, or treble, press the tune knob until the tone control labels display. Continue pressing to highlight the desired label, or press the pushbutton positioned under the desired label. Turn the tune knob clockwise or counterclockwise to adjust the highlighted setting.
Page 199: Finding A Category (Cat) Station
Finding a Category (CAT) Station CAT (Category): The CAT button is used to ﬁnd XM™ stations while the radio is in the XM™ mode. To ﬁnd XM™ channels within a desired category, perform the following: 1. Press the BAND button until the XM™ frequency is displayed.
Page 200: Playing A Cd(S) (Six-Disc Cd Player)
Radio Messages Calibration Error: The audio system has been calibrated for your vehicle from the factory. If Calibration Error displays, it means that the radio has not been conﬁgured properly for your vehicle and it must be returned to your dealer for service. Locked: This message displays when the ®...
Page 201 When a CD is inserted, the CD symbol displays on the CD. As each new track starts to play, the track number displays. The CD player can play the smaller 3 inch (8 cm) single CDs with an adapter ring. Full-size CDs and the smaller CDs are loaded in the same manner.
Page 202 EJECT: Press the CD eject button to eject CD(s). To eject the CD that is currently playing, press and release this button. A beep sounds and Ejecting Disc displays. Once the disc is ejected, Remove Disc displays. The CD can be removed. If the CD is not removed after several seconds, the CD automatically pulls back into the player and begins playing.
Page 203: Playing An Mp3 Cd-R Or Cd-Rw Disc
• Press the CD/AUX button, or for a six-disc CD player, press and hold the LOAD button. A beep sounds and Load All Discs displays. Insert one or more discs partway into the slot of the CD player. To play tracks from all CDs loaded in a six-disc CD player in random order, press the pushbutton positioned under the RDM label until Randomize All Discs displays.
Page 204 If the CD is not playing correctly, for any other reason, try a known good CD. If any error occurs repeatedly or if an error cannot be corrected, contact your dealer. If the radio displays an error message, write it down and provide it to your dealer while reporting the problem.
Page 205: Using An Mp3
Using an MP3 MP3 CD-R or CD-RW Disc The radio plays MP3 ﬁles that were recorded on a CD-R or CD-RW disc. The ﬁles can be recorded with the following ﬁxed bit rates: 32 kbps, 40 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 160 kbps, 192 kbps, 224 kbps, 256 kbps, and 320 kbps or a variable bit rate.
Page 206 • Minimize the length of the ﬁle, folder, or playlist names. Long ﬁle, folder, or playlist names, or a combination of a large number of ﬁles and folders, or playlists can cause the player to be unable to play up to the maximum number of ﬁles, folders, playlists, or sessions.
Page 207 When the CD-R contains only playlists and compressed audio ﬁles, but no folders, all ﬁles are located under the root folder. The folder down and the folder up buttons search playlists (Px) ﬁrst and then goes to the root folder. When the radio displays the name of the folder, the radio displays ROOT.
Page 208 Playing an MP3 Insert a CD-R partway into the slot (Single CD Player), or press the load button and wait for the message to insert disc (Six-Disc CD Player), label side up. The player pulls it in, and the CD-R should begin playing. If the ignition or radio is turned off with a CD-R in the player, it stays in the player.
Page 209 EJECT: Press the CD eject button to eject CD-R(s). To eject the CD-R that is currently playing, press and release this button. A beep will sound and Ejecting Disc displays. Once the disc is ejected, Remove Disc displays. The CD-R can be removed.
Page 210 RDM (Random): With the random setting, MP3 ﬁles on the CD-R can be played in random, rather than sequential order, on one CD-R or all discs in a six-disc CD player. To use random, do one of the following: 1. To play MP3 ﬁles in random order from the CD-R that is currently playing, press the pushbutton positioned under the RDM label until Random Current Disc displays.
Page 211 To change from playback by artist to playback by album, press the pushbutton located below the Sort By label. From the sort screen, push one of the buttons below the album button. Press the pushbutton below the back label to return to the main music navigator screen.
Page 212: Xm Radio Messages
XM Radio Messages Radio Display Message XL (Explicit Language XL on the radio display, Channels) after the channel name, indicates content with explicit language. XM Updating Updating encryption code The encryption code in the receiver is being updated, and No XM Signal Loss of signal Loading XM Acquiring channel audio...
Page 213 Radio Display Message No CAT Info Category Name not available No Information No Text/Informational message available CAT Not Found No channel available for the chosen category XM Theft Locked Theftlock XM Radio ID Radio ID label (channel 0) If tuned to channel 0, this message alternates with the Unknown Radio ID not known (should only be if...
Page 214: Theft-Deterrent Feature
Theft-Deterrent Feature ® THEFTLOCK is designed to discourage theft of your vehicle’s radio. The feature works automatically by learning a portion of the Vehicle Identiﬁcation Number (VIN). If the radio is moved to a different vehicle, it will not operate and LOCK or LOCKED will appear on the display.
Page 215: Radio Reception
(Volume): Press the plus or minus button to increase or to decrease the volume. (Mute/Voice Activation): Press this button to silence the system. Press this button again to turn the sound on. If your vehicle is equipped with ® OnStar , press and hold this button for two seconds to activate voice on the OnStar system.
Page 216: Care Of Your Cds
Care of Your CDs Handle CDs carefully. Store them in their original cases or other protective cases and away from direct sunlight and dust. The CD player scans the bottom surface of the disc. If the surface of a CD is damaged, such as cracked, broken, or scratched, the CD will not play properly or not at all.
Page 217: Driving Your Vehicle
Section 4 Your Driving, the Road, and Your Vehicle ... 218 Defensive Driving ... 218 Drunken Driving ... 219 Control of a Vehicle ... 222 Braking ... 222 Anti-Lock Brake System (ABS) ... 223 Braking in Emergencies ... 225 Enhanced Traction System (ETS) ... 226 Steering ...
Page 218: Your Driving, The Road, And Your Vehicle
Your Driving, the Road, and Your Vehicle Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. See Safety Belts: They Are for Everyone on page 16. CAUTION: Defensive driving really means “Be ready for anything.”...
Page 219: Drunken Driving
Drunken Driving Death and injury associated with drinking and driving is a national tragedy. It is the number one contributor to the highway death toll, claiming thousands of victims every year. Alcohol affects four things that anyone needs to drive a vehicle: •...
Page 220 According to the American Medical Association, a 180 lb (82 kg) person who drinks three 12 ounce (355 ml) bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4 ounce (120 ml) glasses of wine or three mixed drinks if each had 1-1/2 ounces (45 ml) of liquors like whiskey, gin, or vodka.
Page 221 But the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night. All drivers are impaired at BAC levels above 0.05 percent.
Page 222: Control Of A Vehicle
Control of a Vehicle You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering, and the accelerator. All three systems have to do their work at the places where the tires meet the road. Sometimes, as when you are driving on snow or ice, it is easy to ask more of those control systems than the tires and road can provide.
Page 223: Anti-Lock Brake System (Abs)
Avoid needless heavy braking. Some people drive in spurts — heavy acceleration followed by heavy braking — rather than keeping pace with traffic. This is a mistake. The brakes may not have time to cool between hard stops. The brakes will wear out much faster if you do a lot of heavy braking.
Page 224 Let us say the road is wet and you are driving safely. Suddenly, an animal jumps out in front of you. You slam on the brakes and continue braking. Here is what happens with ABS: A computer senses that wheels are slowing down. If one of the wheels is about to stop rolling, the computer will separately work the brakes at each wheel.
Page 225: Braking In Emergencies
Remember: ABS does not change the time you need to get your foot up to the brake pedal or always decrease stopping distance. If you get too close to the vehicle in front of you, you will not have time to apply your brakes if that vehicle suddenly slows or stops.
Page 226: Enhanced Traction System (Ets)
Enhanced Traction System (ETS) Your vehicle may have an Enhanced Traction System (ETS) that limits wheel spin. This is especially useful in slippery road conditions. The system operates only if it senses that one or both of the front wheels are spinning or beginning to lose traction.
Page 227: Steering
• The warning light will come on when you set your parking brake with the engine running, and it will stay on if your parking brake does not release fully. If the transaxle shift lever is in any position other than LOW (L) and the warning light stays on after your parking brake is fully released, it means there is a problem with the system.
Page 228: Steering Tips
Steering Tips It is important to take curves at a reasonable speed. A lot of the “driver lost control” accidents mentioned on the news happen on curves. Here is why: Experienced driver or beginner, each of us is subject to the same laws of physics when driving on curves.
Page 229: Steering In Emergencies
Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and ﬁnd a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 230: Off-Road Recovery
Off-Road Recovery You may ﬁnd that your right wheels have dropped off the edge of a road onto the shoulder while you are driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that your vehicle straddles the edge of the pavement.
Page 231 So here are some tips for passing: • Drive ahead. Look down the road, to the sides, and to crossroads for situations that might affect your passing patterns. If you have any doubt whatsoever about making a successful pass, wait for a better time. •...
Page 232: Loss Of Control
• Check your vehicle’s mirrors, glance over your shoulder, and start your left lane change signal before moving out of the right lane to pass. When you are far enough ahead of the passed vehicle to see its front in your vehicle’s inside mirror, activate the right lane change signal and move back into the right lane.
Page 233 A cornering skid is best handled by easing your foot off the accelerator pedal. If you have the Enhanced Traction System (ETS), remember: It helps to avoid only the acceleration skid. See Enhanced Traction System (ETS) on page 226. If you do not have the Enhanced Traction System, or if the system is off, then an acceleration skid is also best handled by easing your foot off the accelerator pedal.
Page 234: Driving At Night
Driving at Night Night driving is more dangerous than day driving. One reason is that some drivers are likely to be impaired — by alcohol or drugs, with night vision problems, or by fatigue. Here are some tips on night driving. •...
Page 235: Driving In Rain And On Wet Roads
Keep the windshield and all the glass on your vehicle clean — inside and out. Glare at night is made much worse by dirt on the glass. Even the inside of the glass can build up a ﬁlm caused by dust. Dirty glass makes lights dazzle and ﬂash more than clean glass would, making the pupils of your eyes contract repeatedly.
Page 236 The heavier the rain, the harder it is to see. Even if your windshield wiper blades are in good shape, a heavy rain can make it harder to see road signs and traffic signals, pavement markings, the edge of the road, and even people walking. It is wise to keep your windshield wiping equipment in good shape and keep your windshield washer ﬂuid reservoir ﬁlled with washer ﬂuid.
Page 237: Driving Through Deep Standing Water
Driving Through Deep Standing Water Notice: If you drive too quickly through deep puddles or standing water, water can come in through your engine’s air intake and badly damage your engine. Never drive through water that is slightly lower than the underbody of your vehicle.
Page 238: City Driving
City Driving One of the biggest problems with city streets is the amount of traffic on them. You will want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving: •...
Page 239: Freeway Driving
Freeway Driving Mile for mile, freeways — also called thruways, parkways, expressways, turnpikes, or superhighways — are the safest of all roads. But they have their own special rules. The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving.
Page 240: Before Leaving On A Long Trip
Once you are moving on the freeway, make certain you allow a reasonable following distance. Expect to move slightly slower at night. When you want to leave the freeway, move to the proper lane well in advance. If you miss your exit, do not, under any circumstances, stop and back up.
Page 241: Highway Hypnosis
Highway Hypnosis Is there actually such a condition as highway hypnosis? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy.
Page 242 If you drive regularly in steep country, or if you are planning to visit there, here are some tips that can make your trips safer and more enjoyable. • Keep your vehicle in good shape. Check all ﬂuid levels and also the brakes, tires, cooling system, and transaxle.
Page 243: Winter Driving
• Stay in your own lane when driving on two-lane roads in hills or mountains. Do not swing wide or cut across the center of the road. Drive at speeds that let you stay in your own lane. • As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident.
Page 244: Driving On Snow Or Ice
Include an ice scraper, a small brush or broom, a supply of windshield washer ﬂuid, a rag, some winter outer clothing, a small shovel, a ﬂashlight, a red cloth, and a couple of reﬂective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet, or a couple of burlap bags to help provide traction.
Page 245 What is the worst time for this? Wet ice. Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get wet ice when it is about freezing, 32°F (0°C), and freezing rain begins to fall.
Page 246: If You Are Caught In A Blizzard
If You Are Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow.
Page 247 CAUTION: Snow can trap exhaust gases under your vehicle. This can cause deadly CO (carbon monoxide) gas to get inside. CO could overcome you and kill you. You cannot see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that is blocking your exhaust pipe.
Page 248: If Your Vehicle Is Stuck In Sand, Mud
If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you do not want to spin your wheels too fast. The method known as rocking can help you get out when you are stuck, but you must use caution.
Page 249: Loading Your Vehicle
Loading Your Vehicle It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo and all nonfactory-installed options. Two labels on your vehicle show how much weight it may properly carry, the Tire and Loading Information label and the Certiﬁcation label.
Page 250 The Tire and Loading Information label also shows the tire size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D). For more information on tires and inﬂation see Tires on page 320 and Inﬂation - Tire Pressure on page 327.
Page 251 Example 1 Item Description Vehicle Capacity Weight for Example 1 Subtract Occupant Weight 150 lbs (68 kg) Available Occupant and Cargo Weight Total Item 1,000 lbs (453 kg) 300 lbs (136 kg) 700 lbs (317 kg) Example 2 Description Vehicle Capacity 1,000 lbs (453 kg) Weight for Example 2 Subtract...
Page 252 Example 3 Item Description Vehicle Capacity Weight for Example 3 Subtract Occupant Weight 200 lbs (91 kg) Available Cargo Weight Refer to your vehicle’s Tire and Loading Information label for speciﬁc information about your vehicle’s capacity weight and seating positions. The combined weight of the driver, passengers, and cargo should never exceed your vehicle’s capacity weight.
Page 253 CAUTION: Do not load your vehicle any heavier than the Gross Vehicle Weight Rating (GVWR), or either the maximum front or rear Gross Axle Weight Rating (GAWR). If you do, parts on your vehicle can break, and it can change the way your vehicle handles. These could cause you to lose control and crash.
Page 254: Towing
Towing Towing Your Vehicle Consult your dealer or a professional towing service if you need to have your disabled vehicle towed. See Roadside Assistance Program on page 399. If you want to tow your vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see “Recreational Vehicle Towing”...
Page 255: Dinghy Towing
Dinghy Towing You may dinghy tow your vehicle from the front following these steps: 1. Set the parking brake. 2. Turn the ignition key to ACC to unlock the steering wheel. 3. Shift an automatic transaxle to NEUTRAL (N) or a manual transaxle to NEUTRAL. 4.
Page 256: Dolly Towing
Notice: Towing your vehicle from the rear could damage it. Also, repairs would not be covered by the warranty. Never have your vehicle towed from the rear. Dolly Towing Your vehicle cannot be dolly towed, but can be dinghy towed. See “Dinghy Towing” earlier in this section.
Page 257: Towing A Trailer (Automatic Transaxle)
Towing a Trailer (Automatic Transaxle) CAUTION: If you do not use the correct equipment and drive properly, you can lose control when you pull a trailer. For example, if the trailer is too heavy, the brakes may not work well — or even at all. You and your passengers could be seriously injured.
Page 258: If You Do Decide To Pull A Trailer
If You Do Decide To Pull A Trailer If you do, here are some important points: • There are many different laws, including speed limit restrictions, having to do with trailering. Make sure your rig will be legal, not only where you live but also where you will be driving.
Page 259: Weight Of The Trailer Tongue
Maximum trailer weight is calculated assuming only the driver is in the tow vehicle and it has all the required trailering equipment. The weight of additional optional equipment, passengers and cargo in the tow vehicle must be subtracted from the maximum trailer weight. You can ask your dealer for our trailering information or advice.
Page 260: Total Weight On Your Vehicle's Tires
Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inﬂated to the upper limit for cold tires. You will ﬁnd these numbers on the Tire-Loading Information label. See Loading Your Vehicle on page 249. Then be sure you do not go over the GVW limit for your vehicle, including the weight of the trailer tongue.
Page 261: Driving With A Trailer
Driving with a Trailer Towing a trailer requires a certain amount of experience. Before setting out for the open road, you will want to get to know your rig. Acquaint yourself with the feel of handling and braking with the added weight of the trailer. And always keep in mind that the vehicle you are driving is now a good deal longer and not nearly as responsive as your vehicle is by itself.
Page 262: Making Turns
Making Turns Notice: Making very sharp turns while trailering could cause the trailer to come in contact with the vehicle. Your vehicle could be damaged. Avoid making very sharp turns while trailering. When you are turning with a trailer, make wider turns than normal.
Page 263: Parking On Hills
When towing under severe conditions such as hot ambient temperatures or steep grades, your vehicle may experience more transaxle shifting. A COOLING MODE ON message may also appear in the DIC. This alerts the driver that the shifting mode is in progress and is aiding engine cooling. See DIC Warnings and Messages on page 177 DIC Warnings and Messages for more information.
Page 264: When You Are Ready To Leave After Parking On A Hill
When You Are Ready to Leave After Parking on a Hill 1. Apply your regular brakes and hold the pedal down while you: • Start your engine. • Shift into a gear. • Release the parking brake. 2. Let up on the brake pedal. 3.
Page 265: Service And Appearance Care
Section 5 Service ... 268 Accessories and Modiﬁcations ... 268 California Proposition 65 Warning ... 269 Doing Your Own Service Work ... 269 Adding Equipment to the Outside of Your Vehicle ... 270 Fuel ... 270 Gasoline Octane ... 270 Gasoline Speciﬁcations ...
Page 266 Section 5 Windshield Wiper Blade Replacement ... 319 Tires ... 320 Tire Sidewall Labeling ... 321 Tire Terminology and Deﬁnitions ... 324 Inﬂation - Tire Pressure ... 327 Tire Inspection and Rotation ... 328 When It Is Time for New Tires ... 330 Buying New Tires ...
Page 267 Section 5 Vehicle Identiﬁcation ... 361 Vehicle Identiﬁcation Number (VIN) ... 361 Service Parts Identiﬁcation Label ... 362 Electrical System ... 362 Add-On Electrical Equipment ... 362 Headlamp Wiring ... 363 Windshield Wiper Fuses ... 363 Service and Appearance Care Power Windows and Other Power Options ...
Page 268: Service
Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you will go to your dealer for all your service needs. You will get genuine GM parts and GM-trained and supported service people. We hope you will want to keep your GM vehicle all GM.
Page 269: California Proposition 65 Warning
California Proposition 65 Warning Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems (including some inside the vehicle), many ﬂuids, and some component wear by-products contain and/or emit these chemicals.
Page 270: Fuel
Adding Equipment to the Outside of Your Vehicle Things you might add to the outside of your vehicle can affect the airﬂow around it. This may cause wind noise and affect windshield washer performance. Check with your dealer before adding equipment to the outside of your vehicle. Fuel Use of the recommended fuel is an important part of the proper maintenance of your vehicle.
Page 271: Gasoline Speciﬁcations
Gasoline Speciﬁcations At a minimum, gasoline should meet ASTM speciﬁcation D 4814 in the United States or CAN/CGSB-3.5 in Canada. Some gasolines may contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT). General Motors recommends against the use of gasolines containing MMT. See Additives on page 272 for additional information.
Page 272: Additives
Additives To provide cleaner air, all gasolines in the United States are now required to contain additives that will help prevent engine and fuel system deposits from forming, allowing your emission control system to work properly. In most cases, you should not have to add anything to your fuel.
Page 273: Fuels In Foreign Countries
Some gasolines that are not reformulated for low emissions may contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT); ask the attendant where you buy gasoline whether the fuel contains MMT.General Motors recommends against the use of such gasolines. Fuels containing MMT can reduce the life of spark plugs and the performance of the emission control system may be affected.
Page 274: Filling The Tank
Filling the Tank CAUTION: Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the pump island. Turn off your engine when you are refueling.
Page 275 While refueling, hang the tethered fuel cap from the hook on the fuel door. CAUTION: If you spill fuel and then something ignites it, you could be badly burned. Fuel can spray out on you if you open the fuel cap too quickly.
Page 276: Checking Things Under The Hood
Filling a Portable Fuel Container CAUTION: Never ﬁll a portable fuel container while it is in your vehicle. Static electricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle damaged if this occurs. To help avoid injury to you and others: •...
Page 277: Hood Release
Hood Release To open the hood, do the following. 1. Pull the interior hood release lever with this symbol on it. It is located under the instrument panel on the driver’s side of the vehicle. 2. Then go to the front of the vehicle and push the secondary hood release lever to the left.
Page 278: Engine Compartment Overview
Engine Compartment Overview When you open the hood on the 2.2L L4 engine (2.4L L4 engine similar), here is what you will see:...
Page 279: Engine Oil
A. Engine Air Cleaner/Filter. See Engine Air Cleaner/Filter on page 284. B. Engine Oil Fill Cap. See “When to Add Engine Oil” under Engine Oil on page 279. C. Engine Oil Dipstick (Out of View). See “Checking Engine Oil” under Engine Oil on page 279.
Page 280: When To Add Engine Oil
When to Add Engine Oil If the oil is below the MIN (minimum) mark, you will need to add at least one quart/liter of oil. But you must use the right kind. This section explains what kind of oil to use. For engine oil crankcase capacity, see Capacities and Speciﬁcations on page 369.
Page 281: What Kind Of Engine Oil To Use
What Kind of Engine Oil to Use Look for two things: • GM6094M Your vehicle’s engine requires oil meeting GM Standard GM6094M. You should look for and use only an oil that meets GM Standard GM6094M. • SAE 5W-30 As shown in the viscosity chart, SAE 5W-30 is best for your vehicle.
Page 282: Engine Oil Additives
You should look for this information on the oil container, and use only those oils that are identiﬁed as meeting GM Standard GM6094M and have the starburst symbol on the front of the oil container. Notice: Use only engine oil identiﬁed as meeting GM Standard GM6094M and showing the American Petroleum Institute Certiﬁed For Gasoline Engines starburst symbol.
Page 283 If the system is ever reset accidentally, you must change your oil at 3,000 miles (5 000 km) since your last oil change. Remember to reset the oil life system whenever the oil is changed. How to Reset the Engine Oil Life System The Engine Oil Life System calculates when to change your engine oil and ﬁlter based on vehicle...
Page 284: What To Do With Used Oil
What to Do with Used Oil Used engine oil contains certain elements that may be unhealthy for your skin and could even cause cancer. Do not let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 285: When To Inspect The Engine Air Cleaner/Filter
When to Inspect the Engine Air Cleaner/Filter Inspect the air cleaner/ﬁlter at the Maintenance II intervals and replace it at the ﬁrst oil change after each 50,000 mile (85 000 km) interval. See Scheduled Maintenance on page 375 for more information.
Page 286: Automatic Transaxle Fluid
Automatic Transaxle Fluid It is not necessary to check the transaxle ﬂuid level. A transaxle ﬂuid leak is the only reason for ﬂuid loss. If a leak occurs, take your vehicle to the dealership service department and have it repaired as soon as possible. Change the ﬂuid and ﬁlter at the intervals listed in Additional Required Services on page 378, and be sure to use the transaxle ﬂuid listed in...
Page 287: Engine Coolant
Engine Coolant The cooling system in your vehicle is ﬁlled with ® DEX-COOL engine coolant. This coolant is designed to remain in your vehicle for ﬁve years or 150,000 miles (240 000 km), whichever occurs ﬁrst, ® if you add only DEX-COOL extended life coolant.
Page 288: What To Use
What to Use Use a mixture of one-half clean, drinkable water ® and one-half DEX-COOL coolant which will not damage aluminum parts. If you use this coolant mixture, you do not need to add anything else. CAUTION: Adding only plain water to your cooling system can be dangerous.
Page 289: Checking Coolant
Checking Coolant The coolant surge tank is located in the engine compartment on the driver’s side of the vehicle. See Engine Compartment Overview on page 278 for more information on location. CAUTION: Turning the surge tank pressure cap when the engine and radiator are hot can allow steam and scalding liquids to blow out and burn you badly.
Page 290: Coolant Surge Tank Pressure Cap
Adding Coolant If you need more coolant, add the proper ® DEX-COOL coolant mixture at the coolant surge tank, but only when the engine is cool. If the coolant surge tank is empty, a special ﬁll procedure is necessary. See Engine Overheating on page 290 for instructions on “How to Add Coolant to the Coolant Surge Tank.”...
Page 291: If No Steam Is Coming From Your Engine
If Steam Is Coming From Your Engine CAUTION: Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Just turn it off and get everyone away from the vehicle until it cools down.
Page 292: Cooling System
3. Turn on your heater to full hot at the highest fan speed and open the windows as necessary. If you no longer have the overheat warning, you can drive. Just to be safe, drive slower for about 10 minutes. If the warning does not come back on, you can drive normally.
Page 293 CAUTION: An electric engine cooling fan under the hood can start up even when the engine is not running and can injure you. Keep hands, clothing, and tools away from any underhood electric fan. If the coolant inside the coolant surge tank is boiling, do not do anything else until it cools down.
Page 294: How To Add Coolant To The Coolant Surge Tank
How to Add Coolant to the Coolant Surge Tank Notice: This vehicle has a speciﬁc coolant ﬁll procedure. Failure to follow this procedure could cause your engine to overheat and be severely damaged. If you have not found a problem yet, check to see if coolant is visible in the coolant surge tank.
Page 295 CAUTION: Adding only plain water to your cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can boil before the proper coolant mixture will. Your vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, your engine could get too hot but you would not get the overheat warning.
Page 296 2. Then keep turning the pressure cap slowly, and remove it. 3. Fill the coolant surge tank with the proper mixture, to the COLD FILL line. Wait about ﬁve minutes, then check to see if the level is below the COLD FILL line. If the level is below the line, add additional coolant to bring the level up to the line.
Page 297: Windshield Washer Fluid
4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose getting hot. Watch out for the engine cooling fan. By this time, the coolant level inside the coolant surge tank may be lower.
Page 298: Brake Fluid
Adding Washer Fluid Open the cap with the washer symbol on it. Add washer ﬂuid until the tank is full. See Engine Compartment Overview on page 278 for reservoir location. Notice: • When using concentrated washer ﬂuid, follow the manufacturer’s instructions for adding water.
Page 299 There are only two reasons why the brake ﬂuid level in the reservoir might go down. The ﬁrst is that the brake ﬂuid goes down to an acceptable level during normal brake lining wear. When new linings are put in, the ﬂuid level goes back up. The other reason is that ﬂuid is leaking out of the brake and/or clutch hydraulic system.
Page 300 What to Add When you do need brake ﬂuid, use only DOT-3 brake ﬂuid. Use new brake ﬂuid from a sealed container only. See Recommended Fluids and Lubricants on page 385. Always clean the brake ﬂuid reservoir cap and the area around the cap before removing it.
Page 301: Brake Wear
Brake Wear Your vehicle has front disc brakes and may have rear drum brakes or rear disc brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed. The sound may come and go or be heard all the time your vehicle is moving, except when you are pushing on the brake pedal ﬁrmly.
Page 302: Replacing Brake System Parts
Brake Pedal Travel See your dealer if the brake pedal does not return to normal height, or if there is a rapid increase in pedal travel. This could be a sign of brake trouble. Brake Adjustment Every time you make a moderate brake stop, the disc brakes adjust for wear.
Page 303: Battery
Battery Your vehicle has a maintenance free battery. When it is time for a new battery, get one that has the replacement number shown on the original battery’s label. We recommend an ACDelco replacement battery. Your vehicle’s battery is located in the trunk. You do not need to access the battery to jump start your vehicle.
Page 304: Jump Starting
Jump Starting If your vehicle’s battery has run down, you may want to use another vehicle and some jumper cables to start your vehicle. Be sure to use the following steps to do it safely. CAUTION: Batteries can hurt you. They can be dangerous because: •...
Page 305 Notice: If you leave your radio or other accessories on during the jump starting procedure, they could be damaged. The repairs would not be covered by your warranty. Always turn off your radio and other accessories when jump starting your vehicle. 3.
Page 306 The remote negative ( ) ground terminal, marked GND ( ), is located behind the engine coolant surge tank. See Engine Compartment Overview on page 278 for more information on the location of the positive (+) and negative ( ) terminals on your vehicle.
Page 307 CAUTION: Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running. 5. Check that the jumper cables do not have loose or missing insulation. If they do, you could get a shock.
Page 308 11. Try to start the vehicle that had the dead battery. If it will not start after a few tries, it probably needs service. Notice: If the jumper cables are connected or removed in the wrong order, electrical shorting may occur and damage the vehicle. The repairs would not be covered by your warranty.
Page 309: Headlamp Aiming
To disconnect the jumper cables from both vehicles, do the following: 1. Disconnect the black negative ( ) cable from the vehicle that had the dead battery. 2. Disconnect the black negative ( ) cable from the vehicle with the good battery. 3.
Page 310 Headlamp aiming is done with the vehicle’s low-beam headlamps. The high-beam headlamps will be correctly aimed if the low-beam headlamps are aimed properly. The vertical headlamp aiming screws are located under the hood near the headlamps. The adjustment screw can be turned with a 6 mm socket wrench.
Page 311 4. At the wall measure from the ground upward (A) to the recorded distance from Step 3 and mark it. 5. Draw or tape a horizontal line (B) on the wall the width of the vehicle at the height of the mark in Step 4.
Page 312: Bulb Replacement
9. Make sure that the light from the headlamp is positioned at the bottom edge of the horizontal tape line. The lamp on the left (A) shows the correct headlamp aim. The lamp on the right (B) shows the incorrect headlamp aim. 10.
Page 313: Headlamps, Front Turn Signal, Sidemarker, And Parking Lamps
Headlamps, Front Turn Signal, Sidemarker, and Parking Lamps A. Front Turn Signal/Parking Lamp B. Sidemarker C. Headlamp To replace one of these bulbs, do the following: 1. Open the hood. See Hood Release on page 277 for more information. 2. Remove the two hex bolts from the headlamp assembly.
Page 314 3. Remove the two plastic fasteners from the fascia. 4. Pull the front fascia back. You may need someone else to assist you with Steps 3 and 4. 5. Pull the headlamp assembly up on an angle and towards the radiator to remove it. 6.
Page 315: Center High-Mounted Stoplamp (Chmsl)
Center High-Mounted Stoplamp (CHMSL) To replace a CHMSL bulb, do the following: 1. Open the trunk. See Trunk on page 98 for more information. 2. Locate the CHMSL bulb assembly in the trunk lid. 3. Press the plastic tabs to release the bulb assembly.
Page 316: Taillamps, Turn Signal, Stoplamps And Back-Up Lamps (Sedan)
Taillamps and Turn Signal Lamps (Coupe) To replace a taillamp or rear turn signal bulb, do the following: 1. Open the trunk. See Trunk on page 98 for more information. 2. Remove the screw retaining the taillamp assembly. 3. Disconnect the wiring harness by lifting up on the tab to release and pull it straight out.
Page 317: Back-Up Lamps (Coupe)
A. Sidemarker B. Stoplamp/Turn Signal/Taillamp C. Back-up 6. Locate the bulb you need to change. 7. Remove the taillamp bulb socket from the assembly by turning it counterclockwise. 8. Pull the old bulb out of the socket. 9. Install a new bulb. 10.
Page 318: License Plate Lamp
License Plate Lamp To replace one of these bulbs, do the following: 1. Remove the two screws holding each of the license plate lamps. 2. Turn and pull the license plate lamp toward you through the opening. 3. Turn the bulb socket counterclockwise and pull the bulb straight out of the socket.
Page 319: Windshield Wiper Blade Replacement
Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear or cracking. See Scheduled Maintenance on page 375 for more information on wiper blade inspection. Replacement blades come in different types and are removed in different ways. For proper type and length, see Normal Maintenance Replacement Parts on page 387.
Page 320: Tires
Tires Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your GM Warranty booklet for details. For additional information refer to the tire manufacturer’s booklet included with your vehicle.
Page 321: Tire Sidewall Labeling
Tire Sidewall Labeling Useful information about a tire is molded into its sidewall. The examples below show a typical passenger vehicle tire and a compact spare tire sidewall. Passenger (P-Metric) Tire Example (A) Tire Size: The tire size is a combination of letters and numbers used to deﬁne a particular tire’s width, height, aspect ratio, construction type and service description.
Page 322 (D) Tire Identiﬁcation Number (TIN): The letters and numbers following DOT (Department of Transportation) code is the Tire Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured. The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture.
Page 323 (B) Tire Ply Material: The type of cord and number of plies in the sidewall and under the tread. (C) Tire Identiﬁcation Number (TIN): The letters and numbers following the DOT (Department of Transportation) code is the Tire Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured.
Page 324: Tire Terminology And Deﬁnitions
(B) Tire Width: The three-digit number indicates the tire section width in millimeters from sidewall to sidewall. (C) Aspect Ratio: A two-digit number that indicates the tire height-to-width measurements. For example, if the tire size aspect ratio is 60, as shown in item C of the illustration, it would mean that the tire’s sidewall is 60 percent as high as it is wide.
Page 325 Cold Tire Pressure: The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has built up heat from driving. See Inﬂation - Tire Pressure on page 327. Curb Weight: This means the weight of a motor vehicle with standard and optional equipment including the maximum capacity of fuel, oil, and coolant, but without passengers and cargo.
Page 326 Occupant Distribution: Designated seating positions. Outward Facing Sidewall: The side of an asymmetrical tire that has a particular side that faces outward when mounted on a vehicle. The side of the tire that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same moldings on the other sidewall of the tire.
Page 327: Inﬂation - Tire Pressure
Vehicle Maximum Load on the Tire: Load on an individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. Vehicle Placard: A label permanently attached to a vehicle showing the vehicle’s capacity weight and the original equipment tire size and recommended inﬂation pressure.
Page 328: When To Check
When to Check Check your tires once a month or more. Do not forget to check the compact spare tire, it should be at 60 psi (420 kPa). For additional information regarding the compact spare tire, see Compact Spare Tire on page 352. How to Check Use a good quality pocket-type gage to check tire pressure.
Page 329 When rotating your tires, always use the correct rotation pattern shown here. Do not include the compact spare tire in your tire rotation. After the tires have been rotated, adjust the front and rear inﬂation pressures as shown on the Tire and Loading Information label.
Page 330: When It Is Time For New Tires
When It Is Time for New Tires One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining. You need a new tire if any of the following statements are true: •...
Page 331 CAUTION: Mixing tires could cause you to lose control while driving. If you mix tires of different sizes, brands, or types (radial and bias-belted tires), the vehicle may not handle properly, and you could have a crash. Using tires of different sizes, brands, or types may also cause damage to your vehicle.
Page 332: Different Size Tires And Wheels
Different Size Tires and Wheels If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, including its braking, ride and handling characteristics, stability, and resistance to rollover. Additionally, if your vehicle has electronic systems such as, anti-lock brakes, traction control, and electronic stability control, the performance of these systems...
Page 333: Uniform Tire Quality Grading
Uniform Tire Quality Grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by treadwear, traction, and temperature performance.
Page 334: Wheel Alignment And Tire Balance
Temperature – A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speciﬁed indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 335: Wheel Replacement
Wheel Replacement Replace any wheel that is bent, cracked, or badly rusted or corroded. If wheel nuts keep coming loose, the wheel, wheel bolts, and wheel nuts should be replaced. If the wheel leaks air, replace it (except some aluminum wheels, which can sometimes be repaired).
Page 336: Used Replacement Wheels
Used Replacement Wheels CAUTION: Putting a used wheel on your vehicle is dangerous. You cannot know how it has been used or how far it has been driven. It could fail suddenly and cause a crash. If you have to replace a wheel, use a new GM original equipment wheel.
Page 337: If A Tire Goes Flat
Notice: If your vehicle has a tire size other than P205/55R16 or P205/50R17, use tire chains only where legal and only when you must. Use only SAE Class S-type chains that are the proper size for your tires. Install them on the front tires and tighten them as tightly as possible with the ends securely fastened.
Page 338: Changing A Flat Tire
Changing a Flat Tire If a tire goes ﬂat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning ﬂashers. CAUTION: Changing a tire can be dangerous. The vehicle can slip off the jack and roll over or fall on you or other people.
Page 339: Removing The Spare Tire And Tools
The following information will tell you how to use the jack and change a tire. Removing the Spare Tire and Tools The equipment you will need is located in the trunk. Base Models 1. Open the trunk. See Trunk on page 98 for more information.
Page 340 A. Cover E. Jack and Wheel B. Retainer Wrench C. Spare Tire F. Bolt D. Wing Nut 3. Remove the retainer (B) that holds down the spare tire. See Compact Spare Tire on page 352 for more information.
Page 341 4. Remove the spare tire (C) by gently pulling it up and out of the trunk. 5. Remove the wing nut (D) that holds the jack and remove the jack and wheel wrench (E). Uplevel Models 1. Open the trunk. See Trunk on page 98 for more information.
Page 342 A. Retainer C. Spare Tire B. Jack and Wheel D. Foam Support Wrench E. Bolt 3. Remove the retainer (A) that holds down the jack, wheel wrench (B) and spare tire (C). 4. Remove the spare tire by gently pulling it up and out of the trunk.
Page 343 You will need to turn the plastic wheel nut counterclockwise to loosen the wheel wrench from the jack. Press the button and then pull on the end of the wheel wrench to extend the handle.
Page 344: Removing The Flat Tire And Installing
Removing the Flat Tire and Installing the Spare Tire 1. If your vehicle has plastic wheel covers, use the wheel wrench to loosen the plastic wheel nut caps. Once you have loosened the plastic wheel nut caps with the wheel wrench, you can ﬁnish loosening them with your ﬁngers.
Page 345 The rear location is about 4 inches (10 cm) in front of the rear wheel opening. 6. Raise the jack head until it ﬁts ﬁrmly in the vehicle’s frame, where the notch is located, nearest the ﬂat tire. 7. Put the compact spare tire near the ﬂat tire. CAUTION: Getting under a vehicle when it is jacked up is dangerous.
Page 346 9. Remove all of the wheel nuts. CAUTION: Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts become loose after time. The wheel could come off and cause an accident. When you change a wheel, remove any rust or dirt from the places where the wheel attaches to the vehicle.
Page 347 10. Remove any rust or 11. Place the compact spare tire on the wheel-mounting surface. dirt from the wheel bolts, mounting surfaces, and Never use oil or grease on studs or nuts. spare wheel. If you do, the nuts might come loose. Your wheel could fall off, causing a serious accident.
Page 348 CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to come loose and even come off. This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts.
Page 349: Storing A Flat Or Spare Tire And Tools
Notice: Wheel covers will not ﬁt on your compact spare. If you try to put a wheel cover on the compact spare, you could damage the cover or the spare. Do not try to put a wheel cover on your compact spare tire.
Page 350 Base Model A. Cover D. Stow Bolt B. Retainer Extension Rod C. Jack and Wheel E. Spare Tire Wrench F. Bolt...
Page 351 Uplevel Model A. Cover E. Spare Tire B. Retainer F. Foam Support C. Jack and Wheel G. Bolt Wrench D. Stow Bolt Extension Rod To store a ﬂat or spare tire and tools, do the following: 1. Remove the stow bolt extension rod and sleeve from the jack.
Page 352: Compact Spare Tire
7. Place the smaller jack hold-down nut (base models only) in a safe place for use when you put the compact spare tire back into the trunk. 8. Remove the plastic sleeve from the stow bolt extension rod. Secure the jack and road wheel using the larger plastic retainer.
Page 353: Appearance Care
Appearance Care Cleaning the Inside of Your Vehicle Your vehicle’s interior will continue to look its best if it is cleaned often. Although not always visible, dust and dirt can accumulate on your upholstery. Dirt can damage carpet, fabric, leather, and plastic surfaces.
Page 354: Fabric/Carpet
Do not clean your vehicle using the following cleaners or techniques: • Never use a knife or any other sharp object to remove a soil from any interior surface. • Never use a stiff brush. It can cause damage to your vehicle’s interior surfaces. •...
Page 355: Instrument Panel, Vinyl, And Other Plastic Surfaces
To clean, use the following instructions: 1. Saturate a lint-free, clean white cloth with water or club soda. 2. Wring the cloth to remove excess moisture. 3. Start on the outside edge of the soil and gently rub toward the center. Continue cleaning, using a clean area of the cloth each time it becomes soiled.
Page 356: Care Of Safety Belts
Care of Safety Belts Keep belts clean and dry. CAUTION: Do not bleach or dye safety belts. If you do, it may severely weaken them. In a crash, they might not be able to provide adequate protection. Clean safety belts only with mild soap and lukewarm water.
Page 357: Cleaning Exterior Lamps/Lenses
Cleaning Exterior Lamps/Lenses Use only lukewarm or cold water, a soft cloth and a car washing soap to clean exterior lamps and lenses. Follow instructions under Washing Your Vehicle on page 356. Finish Care Occasional waxing or mild polishing of the vehicle by hand may be necessary to remove residue from the paint ﬁnish.
Page 358: Windshield And Wiper Blades
Windshield and Wiper Blades If the windshield is not clear after using the windshield washer, or if the wiper blade chatters when running, wax, sap, or other material may be on the blade or windshield. Clean the outside of the windshield with a glass cleaning liquid or powder and water solution.
Page 359: Tires
Notice: If you drive your vehicle through an automatic car wash that has silicone carbide tire cleaning brushes, you could damage the aluminum or chrome-plated wheels. The repairs would not be covered by your warranty. Never drive a vehicle equipped with aluminum or chrome-plated wheels through an automatic car wash that uses silicone carbide tire cleaning brushes.
Page 360: Underbody Maintenance
Underbody Maintenance Chemicals used for ice and snow removal and dust control can collect on the underbody. If these are not removed, corrosion and rust can develop on the underbody parts such as fuel lines, frame, ﬂoor pan, and exhaust system even though they have corrosion protection.
Page 361: Vehicle Identiﬁcation
Description Removes light scratches Cleaner Wax and protects ﬁnish. Cleans, shines and Foaming Tire Shine Low protects in one easy step, Gloss no wiping necessary. Medium foaming shampoo. Cleans and Wash Wax Concentrate lightly waxes. Biodegradable and phosphate free. Quickly and easily removes spots and stains Spot Lifter from carpets, vinyl and...
Page 362: Service Parts Identiﬁcation Label
Service Parts Identiﬁcation Label You will ﬁnd this label in the trunk, on the driver side, near the spare tire cover. It is very helpful if you ever need to order parts. On this label, you will ﬁnd the following: •...
Page 363: Headlamp Wiring
Headlamp Wiring The headlamp wiring is protected by fuses. Should your headlamps fail to function, have your headlamp system checked right away. Windshield Wiper Fuses The windshield wiper motor is protected by a circuit breaker and a fuse. If the motor overheats due to heavy snow or ice, the wiper will stop until the motor cools.
Page 364: Floor Console Fuse Block
Floor Console Fuse Block The ﬂoor console fuse block is located on the passenger’s side of the ﬂoor console behind the forward panel. The panel has three clips. Pull the panel to disconnect the three clips, and access the fuses. Use the fuse puller to remove fuses. Fuses Usage Fuse Puller...
Page 365: Engine Compartment Fuse Block
Fuses Usage Ignition Switch, PASS-Key Stoplamp Heating, Ventilation, Air Conditioning, PASS-Key Empty Spare Airbag Spare Windshield Wiper Climate Control System, Ignition Empty Empty Electric Power Steering, Steering Wheel Control Sunroof Spare Empty Audio System Sensing and Diagnostic Module (Airbag) Fuses ®...
Page 366 Fuses SPARES Spares Blank Not Used Usage Blank REAR DEFOG Fuses Usage Not Used Rear Defogger...
Page 367 Fuses Usage COOL FAN2 Engine Cooling Fan High Speed CRNK Starter COOL FAN 1 Engine Cooling Fan Low Speed BCM3 Body Control Module 3 BCM2 Body Control Module 2 FOG LAMP Fog Lamps HORN Horn RT HI BEAM Passenger’s Side High Beam LT HI BEAM Driver’s Side High Beam RT LO BEAM...
Page 368 Fuses S BAND/ ® Audio, OnStar ONSTAR ABS3 Anti-lock Brake System 3 Cigarette Lighter Mirrors HTD SEATS Heated Seats CNSTR VENT Canister Vent Relays REAR DEFOG Rear Defogger COOL FAN2 Engine Cooling Fan 2 WPR HI/LO Windshield Wiper High/Low Speed CRNK Starter Usage...
Page 369: Capacities And Speciﬁcations
Capacities and Speciﬁcations The following approximate capacities are given in English and metric conversions. Please refer to Recommended Fluids and Lubricants on page 385 for more information. Application Air Conditioning Refrigerant Cooling System 2.2L and 2.4L Engines Engine Oil with Filter 2.2L L4 and 2.4L L4 Engines Fuel Tank 2.2L L4 Engine (with NU6 emissions) sold new in CA, ME,...
Page 370: Engine Specifications
Application Transaxle, Automatic (Complete Drain and Reﬁll) Transaxle, Manual (Complete Drain and Reﬁll) Wheel Nut Torque All capacities are approximate. When adding, be sure to ﬁll to the appropriate level, as recommended in this manual. Engine 2.2L L4 2.4L L4 Engine Speciﬁcations VIN Code Transaxle...
Page 371 Section 6 Maintenance Schedule ... 372 Introduction ... 372 Maintenance Requirements ... 372 Your Vehicle and the Environment ... 373 Using the Maintenance Schedule ... 373 Scheduled Maintenance ... 375 Additional Required Services ... 378 Maintenance Footnotes ... 379 Owner Checks and Services ... 380 Maintenance Schedule At Each Fuel Fill ...
Page 372: Maintenance Schedule
Maintenance Schedule Introduction Important: Keep engine oil at the proper level and change as recommended. Have you purchased the GM Protection Plan? The Plan supplements your new vehicle warranties. See your Warranty and Owner Assistance booklet or your dealer for details. Maintenance Requirements Notice: Maintenance intervals, checks, inspections, replacement parts, and...
Page 373: Your Vehicle And The Environment
Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also helps the environment. All recommended maintenance is important. Improper vehicle maintenance can even affect the quality of the air we breathe.
Page 374 This schedule is for vehicles that: • carry passengers and cargo within recommended limits. You will ﬁnd these limits on the Tire and Loading Information label. See Loading Your Vehicle on page 249. • are driven on reasonable road surfaces within legal driving limits.
Page 375: Scheduled Maintenance
When you go to your GM Goodwrench your service needs, you will know that GM-trained and supported service technicians will perform the work using genuine GM parts. If you want to purchase service information, see Service Publications Ordering Information on page 410. Owner Checks and Services on page 380 tells you what should be checked, when to check it, and what you can easily do to help keep your vehicle in...
Page 376 If the engine oil life system is ever reset accidentally, you must service your vehicle within 3,000 miles (5 000 km) since your last service. Remember to reset the oil life system whenever the oil is changed. See Engine Oil Life System on page 282 for information on the Engine Oil Life System and resetting the system.
Page 377 Scheduled Maintenance Service Maintenance I Maintenance II Change engine oil and ﬁlter. See Engine Oil on page 279. Reset oil life system. See Engine Oil Life System on page 282. An Emission Control Service. Visually check for any leaks or damage. See footnote (j). Inspect engine air cleaner ﬁlter.
Page 378: Additional Required Services
Additional Required Services The following services should be performed at the ﬁrst maintenance service (I or II) after the indicated miles (kilometers) shown for each item. Service and Miles (Kilometers) Inspect fuel system for damage or leaks. Inspect exhaust system for loose or damaged components.
Page 379: Maintenance Footnotes
Maintenance Footnotes (a) Visually inspect brake lines and hoses for proper hook-up, binding, leaks, cracks, chaﬁng, etc. Inspect disc brake pads for wear and rotors for surface condition. Inspect drum brake linings/shoes for wear or cracks. Inspect other brake parts, including drums, wheel cylinders, calipers, parking brake, etc.
Page 380: Owner Checks And Services
(h) Change automatic transaxle ﬂuid and ﬁlter if the vehicle is mainly driven under one or more of these conditions: − In heavy city traffic where the outside temperature regularly reaches 90°F (32°C) or higher. − In hilly or mountainous terrain. −...
Page 381: At Each Fuel Fill
At Each Fuel Fill It is important to perform these underhood checks at each fuel ﬁll. Engine Oil Level Check Check the engine oil level and add the proper oil if necessary. See Engine Oil on page 279 for further details. Notice: It is important to check your oil regularly and keep it at the proper level.
Page 382: At Least Once A Year
At Least Once a Year Starter Switch Check CAUTION: When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before you start, be sure you have enough room around the vehicle. 2.
Page 383: Ignition Transaxle Lock Check
Automatic Transaxle Shift Lock Control System Check CAUTION: When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before you start, be sure you have enough room around the vehicle. It should be parked on a level surface.
Page 384: Underbody Flushing Service
Parking Brake and Automatic Transaxle Park (P) Mechanism Check CAUTION: When you are doing this check, your vehicle could begin to move. You or others could be injured and property could be damaged. Make sure there is room in front of your vehicle in case it begins to roll.
Page 385: Recommended Fluids And Lubricants
Recommended Fluids and Lubricants Fluids and lubricants identiﬁed below by name, part number, or speciﬁcation may be obtained from your dealer. Usage Fluid/Lubricant Engine oil which meets GM Standard GM6094M and displays the American Petroleum Institute Certiﬁed for Gasoline Engines starburst symbol. Engine Oil GM Goodwrench requirements for your vehicle.
Page 386 Usage Fluid/Lubricant ® Automatic DEXRON -VI Automatic Transaxle Transmission Fluid. Multi-Purpose Lubricant, Superlube Key Lock (GM Part No. U.S. 12346241, Cylinders in Canada 10953474). Chassis Lubricant Manual (GM Part No. U.S. 12377985, Transaxle Shift in Canada 88901242) or lubricant Linkage meeting requirements of NLGI #2, Category LB or GC-LB.
Page 387: Normal Maintenance Replacement Parts
Normal Maintenance Replacement Parts Replacement parts identiﬁed below by name, part number, or speciﬁcation can be obtained from your GM dealer. Normal Maintenance Replacement Parts Part Engine Air Cleaner/Filter Engine Oil Filter Spark Plugs Passenger’s Compartment Air Filter Windshield Wiper Blade (Hook Type) Driver’s Side —...
Page 388: Engine Drive Belt Routing
Engine Drive Belt Routing 2.2L L4 and 2.4L L4 Engines...
Page 389: Maintenance Record
Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. See Maintenance Requirements on page 372. Any additional information from Owner Checks and Services on page 380 can be added on the following record pages.
Page 390 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 391 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 392 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 393: Customer Assistance Information
Section 7 Customer Assistance and Information ... 394 Customer Satisfaction Procedure ... 394 Online Owner Center ... 396 Customer Assistance for Text Telephone (TTY) Users ... 397 Customer Assistance Offices ... 397 GM Mobility Reimbursement Program ... 398 Roadside Assistance Program ... 399 Courtesy Transportation ...
Page 394: Customer Assistance And Information
Information Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and to Pontiac. Normally, any concerns with the sales transaction or the operation of your vehicle will be resolved by your dealer’s sales or service departments. Sometimes, however, despite the best intentions of all concerned, misunderstandings can occur.
Page 395 STEP THREE: Both General Motors and your dealer are committed to making sure you are completely satisﬁed with your new vehicle. However, if you continue to remain unsatisﬁed after following the procedure outlined in Steps One and Two, you should ﬁle with the BBB Auto Line Program to enforce any additional rights you may have.
Page 396: Online Owner Center
Online Owner Center Online Owner Center (United States only) The Owner Center is a resource for your GM ownership needs. Speciﬁc vehicle information can be found in one place. The Online Owner Center allows you to: • Get e-mail service reminders. •...
Page 397: Customer Assistance For Text Telephone (Tty) Users
1-800-263-3830.) Customer Assistance Offices Pontiac encourages customers to call the toll-free number for assistance. However, if a customer wishes to write or e-mail Pontiac, the letter should be addressed to: United States — Customer Assistance Pontiac Customer Assistance Center P.O.
Page 398: Overseas - Customer Assistance
Overseas — Customer Assistance Please contact the local General Motors Business Unit. Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) — Customer Assistance General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center Paseo de la Reforma #2740 Col.
Page 399: Roadside Assistance Program
Roadside Assistance Program As the owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance program. This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road. Contact Pontiac’s Roadside Assistance toll-free at...
Page 400: Canadian Roadside Assistance
Pontiac Roadside Assistance: 1-800-ROADSIDE (762-3743), text telephone (TTY) users, call 1-888-889-2438. Pontiac reserves the right to limit services or reimbursement to an owner or driver when, in Pontiac’s judgement, the claims become excessive in frequency or type of occurrence.
Page 401: Courtesy Transportation
Courtesy Transportation To enhance your ownership experience, we and our participating dealers are proud to offer Courtesy Transportation, a customer support program for new vehicles. The Courtesy Transportation program is offered to customers in conjunction with the Bumper-to-Bumper coverage provided by the New Vehicle Limited Warranty.
Page 402: Additional Program Information
Public Transportation or Fuel Reimbursement If your vehicle requires overnight warranty repairs, reimbursement of public transportation expenses may be available, for up to a maximum of ﬁve days. In addition, should you arrange transportation through a friend or relative, reimbursement for reasonable fuel expenses may be available, up to a ﬁve-day maximum.
Page 403: Vehicle Data Collection And Event Data Recorders
Canadian Vehicles: For warranty repairs during the Complete Vehicle Coverage period of the General Motors of Canada New Vehicle Limited Warranty, alternative transportation may be available under the Courtesy Transportation Program. Please consult your dealer for details. General Motors reserves the right to unilaterally modify, change or discontinue Courtesy Transportation at any time and to resolve all questions of claim eligibility pursuant to the terms...
Page 404: Collision Damage Repair
To read this information, special equipment is needed and access to the vehicle or the device that stores the data is required. GM will not access information about a crash event or share it with others other than: • with the consent of the vehicle owner or, if the vehicle is leased, with the consent of the lessee, •...
Page 405: Collision Parts
Collision Parts Genuine GM Collision parts are new parts made with the same materials and construction methods as the parts with which your vehicle was originally built. Genuine GM Collision parts are your best choice to assure that your vehicle’s designed appearance, durability, and safety are preserved.
Page 406: Insuring Your Vehicle
Insuring Your Vehicle Protect your investment in your GM vehicle with comprehensive and collision insurance coverage. There are signiﬁcant differences in the quality of coverage afforded by various insurance policy terms. Many insurance policies provide reduced protection to your GM vehicle by limiting compensation for damage repairs by using aftermarket collision parts.
Page 407 • If your vehicle cannot be driven, know where the towing service will be taking it. Get a card from the tow truck operator or write down the driver’s name, the service’s name, and the phone number. • Remove any valuables from your vehicle before it is towed away.
Page 408: Managing The Vehicle Damage Repair Process
Managing the Vehicle Damage Repair Process In the event that your vehicle requires damage repairs, GM recommends that you take an active role in its repair. If you have a pre-determined repair facility of choice, take your vehicle there, or have it towed there.
Page 409: Reporting Safety Defects To The United States Government
Reporting Safety Defects to General Motors In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at 1-800-762-2737, or write: Pontiac Customer Assistance Center P.O. Box 33172 Detroit, MI 48232-5172...
Page 410: Service Publications Ordering Information
In Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French). Or, write: General Motors of Canada Limited Customer Communication Centre, CA1-163-005 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 Service Publications Ordering Information Service Manuals Service Manuals have the diagnosis and repair information on engines, transmission, axle suspension, brakes, electrical, steering, body, etc.
Page 411: Owner's Information
Owner’s Information Owner publications are written speciﬁcally for owners and intended to provide basic operational information about the vehicle. The owner’s manual will include the Maintenance Schedule for all models. In-Portfolio: Includes a Portfolio, Owner’s Manual, and Warranty Booklet. RETAIL SELL PRICE: $35.00 Without Portfolio: Owner’s Manual only.
Page 412 NOTES...
Page 413 Accessories and Modiﬁcations ... 268 Accessory Power Outlet(s) ... 150 Additives, Fuel ... 272 Add-On Electrical Equipment ... 362 Air Cleaner/Filter, Engine ... 284 Air Conditioning ... 152 Airbag Passenger Status Indicator ... 162 Readiness Light ... 161 Airbag Sensing and Diagnostic Module (SDM) ...
Page 414 Audio System(s) ... 185 Audio Steering Wheel Controls ... 214 Care of Your CD Player ... 216 Care of Your CDs ... 216 Fixed Mast Antenna ... 216 Radio with CD ... 189, 194 Setting the Time ... 186, 187 Theft-Deterrent Feature ...
Page 415 California Fuel ... 271 California Proposition 65 Warning ... 269 Capacities and Speciﬁcations ... 369 Carbon Monoxide ... 98, 123, 243, 256, 257 Care of Safety Belts ... 356 Your CD Player ... 216 Your CDs ... 216 CD, MP3 ... 205 Center Console Storage Area ...
Page 416 Control of a Vehicle ... 222 Convenience Net ... 131 Coolant Engine Temperature Warning Light ... 167 Heater, Engine ... 112 Surge Tank Pressure Cap ... 290 Cooling System ... 292 Cruise Control ... 143 Cupholder(s) ... 131 Customer Assistance Information Courtesy Transportation ...
Page 417 Driving (cont.) Hill and Mountain Roads ... 241 In Rain and on Wet Roads ... 235 Rocking Your Vehicle to Get it Out ... 248 Winter ... 243 Easy Entry Seat ... 14 Electric Power Management ... 149 Electrical System Add-On Equipment ...
Page 418 Filter Engine Air Cleaner ... 284 Finish Damage ... 359 Fixed Mast Antenna ... 216 Flashers, Hazard Warning ... 138 Flash-to-Pass ... 141 Flat Tire ... 337 Flat Tire, Changing ... 338 Flat Tire, Storing ... 349 Fluid Automatic Transaxle ... 286 Manual Transaxle ...
Page 419 Hazard Warning Flashers ... 138 Head Restraints ... 13 Headlamp Aiming ... 309 Headlamp Wiring ... 363 Headlamps ... 146 Bulb Replacement ... 312 Daytime Running Lamps ... 147 Flash-to-Pass ... 141 Halogen Bulbs ... 312 Headlamps, Front Turn Signal, Sidemarker, and Parking Lamps ...
Page 420 Labeling, Tire Sidewall ... 321 Lamps Battery Run-Down Protection ... 150 Dome ... 149 Electric Power Management ... 149 Fog ... 148 Mirror Reading ... 149 LATCH System Child Restraints ... 51 License Plate Lamps ... 318 Light Airbag Readiness ... 161 Anti-Lock Brake System Warning ...
Page 421 Maintenance Schedule Additional Required Services ... 378 At Each Fuel Fill ... 381 At Least Once a Month ... 381 At Least Once a Year ... 382 Introduction ... 372 Maintenance Footnotes ... 379 Maintenance Record ... 389 Maintenance Requirements ... 372 Normal Maintenance Replacement Parts ...
Page 422 Odometer ... 159 Off-Road Recovery ... 230 Engine ... 279 Pressure Light ... 171 Oil, Engine Oil Life System ... 282 Older Children, Restraints ... 39 Online Owner Center ... 396 ® OnStar System, see OnStar Other Warning Devices ... 138 Outlet Adjustment ...
Page 423 Questions and Answers About Safety Belts ... 21 Radios ... 185 Care of Your CD Player ... 216 Care of Your CDs ... 216 Radio with CD ... 189, 194 Setting the Time ... 186, 187 Theft-Deterrent ... 214 Understanding Reception ... 215 Rear Door Security Locks ...
Page 424 Safety Belt Passenger Reminder Light ... 160 Pretensioners ... 38 Reminder Light ... 160 Safety Belts Care of ... 356 Driver Position ... 22 How to Wear Safety Belts Properly ... 22 Questions and Answers About Safety Belts ... 21 Rear Safety Belt Comfort Guides ...
Page 425 Servicing Your Airbag-Equipped Vehicle ... 78 Setting the Time ... 186, 187 Sheet Metal Damage ... 359 Shifting Into Park (P) ... 119 Shifting Out of Park (P) ... 121 Shoulder Belt Height Adjuster ... 30 Signals, Turn and Lane-Change ... 140 Spare Tire Compact ...
Page 426 Tires (cont.) Removing the Flat Tire ... 344 Removing the Spare Tire and Tools ... 339 Storing a Flat or Spare Tire and Tools ... 349 Tire Sidewall Labeling ... 321 Tire Terminology and Deﬁnitions ... 324 Uniform Tire Quality Grading ... 333 Wheel Alignment and Tire Balance ...
Page 427 Vehicle Control ... 222 Loading ... 249 Vehicle Data Collection and Event Data Recorders ... 403 Vehicle Identiﬁcation Number (VIN) ... 361 Service Parts Identiﬁcation Label ... 362 Vehicle Personalization DIC ... 179 Ventilation Adjustment ... 155 Visors ... 102 Warning Lights, Gages and Indicators ...
Page 428 Windshield Washer ... 142 Washer Fluid ... 297 Wiper Blade Replacement ... 319 Wiper Blades, Cleaning ... 358 Wiper Fuses ... 363 Wipers ... 141 Winter Driving ... 243 Wiper Activated Headlamps ... 147 XM Radio Messages ... 212 XM™ Satellite Radio Antenna System ... 216 Your Vehicle and the Environment ...
