2007 Pontiac G5 Owner Manual Seats and Restraint Systems ... 7 Front Seats ... 9 Rear Seats ... 17 Safety Belts ... 19 Child Restraints ... 41 Airbag System ... 66 Restraint System Check Features and Controls ... 85 Keys ...
Page 2 Bulb Replacement ... 311 Windshield Wiper Blade Replacement ... 317 Tires ... 318 Appearance Care ... 351 Vehicle Identiﬁcation ... 360 Electrical System ... 361 Capacities and Speciﬁcations Maintenance Schedule ... 371 Maintenance Schedule Customer Assistance Information ... 393 Customer Assistance and Information Reporting Safety Defects ...
Page 3: Canadian Owners
GENERAL MOTORS, GM, the GM Emblem, PONTIAC, the PONTIAC Emblem are registered trademarks, and the name G5 is a trademark of General Motors Corporation. This manual includes the latest information at the time it was printed. We reserve the right to make changes after that time without further notice.
Page 4: How To Use This Manual
How to Use This Manual Many people read the owner manual from beginning to end when they ﬁrst receive their new vehicle. If this is done, it can help you learn about the features and controls for the vehicle. Pictures and words work together in the owner manual to explain things.
Page 5: Vehicle Symbols
Vehicle Damage Warnings Also, in this manual you will ﬁnd these notices: Notice: These mean there is something that could damage your vehicle. A notice tells about something that can damage the vehicle. Many times, this damage would not be covered by your vehicle’s warranty, and it could be costly.
Page 6 These are some examples of symbols that may be found on the vehicle:...
Page 7: Seats And Restraint Systems
Section 1 Front Seats ... 9 Manual Seats ... 9 Driver Seat Height Adjuster ... 10 Manual Lumbar ... 10 Heated Seats ... 11 Reclining Seatbacks ... 12 Head Restraints ... 15 Easy Entry Seat (Coupe) ... 16 Rear Seats ... 17 Split Folding Rear Seat ...
Page 8 Section 1 Passenger Sensing System ... 76 Servicing Your Airbag-Equipped Vehicle ... 80 Adding Equipment to Your Airbag-Equipped Vehicle ... 81 Seats and Restraint Systems Restraint System Check ... 82 Checking the Restraint Systems ... 82 Replacing Restraint System Parts After a Crash ...
Page 9: Front Seats
Front Seats Manual Seats CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to.
Page 10: Manual Lumbar
Driver Seat Height Adjuster The driver’s seat height adjuster is located on the outboard side of the seat. To raise the seat, move the lever upward repeatedly until the seat is at the desired height. To lower the seat, move the lever downward repeatedly until the seat is at the desired height.
Page 11: Heated Seats
Heated Seats Your vehicle may have heated front seats. The switches are located on the instrument panel above the climate control system. Press the side of the switch with the double indicator lights to turn on the heated seat at the highest setting.
Page 12: Reclining Seatbacks
Reclining Seatbacks CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to.
Page 13 To recline the seatback, do the following: 1. Lift the recline lever. 2. Move the seatback to the desired position, then release the lever to lock the seatback in place. 3. Push and pull on the seatback to make sure it is locked.
Page 14 CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts cannot do their job when you are reclined like this. CAUTION: (Continued) CAUTION: (Continued) The shoulder belt cannot do its job because it will not be against your body.
Page 15: Head Restraints
Head Restraints Adjust the head restraint so that the top of the restraint is at the same height as the top of the occupant’s head. This position reduces the chance of a neck injury in a crash. Pull the head restraint up to raise it.
Page 16: Easy Entry Seat (Coupe)
Easy Entry Seat (Coupe) CAUTION: If the easy entry right front seat is not locked, it can move. In a sudden stop or crash, the person sitting there could be injured. After you have used it, be sure to push rearward on an easy entry seat to be sure it is locked.
Page 17: Rear Seats
To use the easy entry seat, do the following: 1. Push down the easy entry seat handle located on the rear of the seatback on the outboard side to release the seatback. 2. Tilt the seatback forward completely while pushing the seat forward. 3.
Page 18 Notice: Folding a rear seat with the safety belts still fastened may cause damage to the seat or the safety belts. Always unbuckle the safety belts and return them to their normal stowed position before folding a rear seat. 2. Once the handle is pulled, the seatback can be pushed open through the trunk, or pulled down from the inside of the vehicle.
Page 19: Safety Belts
Safety Belts Safety Belts: They Are for Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts. CAUTION: Do not let anyone ride where he or she cannot wear a safety belt properly.
Page 20 You never know if you will be in a crash. If you do have a crash, you do not know if it will be a bad one. A few crashes are mild, and some crashes can be so serious that even buckled up, a person would not survive.
Page 21 Put someone on it. Get it up to speed. Then stop the vehicle. The rider does not stop.
Page 22 The person keeps going until stopped by or the instrument panel... something. In a real vehicle, it could be the windshield...
Page 23: Questions And Answers About Safety Belts
or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense. Questions and Answers About Safety Belts Will I be trapped in the vehicle after an...
Page 24: How To Wear Safety Belts Properly
If I am a good driver, and I never drive far from home, why should I wear safety belts? You may be an excellent driver, but if you are in an accident — even one that is not your fault — you and your passengers can be hurt. Being a good driver does not protect you from things beyond your control, such as bad drivers.
Page 25: Driver Position
Driver Position Lap-Shoulder Belt The driver has a lap-shoulder belt. Here is how to wear it properly. 1. Close and lock the door. 2. Adjust the seat so you can sit up straight. To see how, see “Seats” in the Index. 3.
Page 26 6. To make the lap part tight, pull up on the shoulder belt. It may be necessary to pull stitching on the safety belt through the latch plate to fully tighten the lap belt on smaller occupants. The lap part of the belt should be worn low and snug on the hips, just touching the thighs.
Page 27 What is wrong with this? The shoulder belt is too loose. It will not give nearly as much protection this way. CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury.
Page 28 What is wrong with this? The lap belt is too loose. It will not give nearly as much protection this way. CAUTION: You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force at your abdomen.
Page 29 What is wrong with this? The belt is buckled in the wrong place. CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen.
Page 30 What is wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
Page 31 What is wrong with this? The belt is twisted across the body. CAUTION: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer/retailer to ﬁx it.
Page 32: Shoulder Belt Height Adjustment
To unlatch the belt, push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.
Page 33: Safety Belt Use During Pregnancy
Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they do not wear safety belts. A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy.
Page 34: Rear Seat Passengers
Rear Seat Passengers It is very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who are not safety belted can be thrown out of the vehicle in a crash.
Page 35 2. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. When the shoulder belt is pulled out all the way, it will lock. If it does, let it go back all the way and start again.
Page 36 The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you would be less likely to slide under the lap belt.
Page 37: Rear Safety Belt Comfort Guides
Rear Safety Belt Comfort Guides Rear shoulder belt comfort guides may provide added safety belt comfort for older children who have outgrown booster seats and for some adults. When installed on a shoulder belt, the comfort guide positions the belt away from the neck and head.
Page 38 2. Slide the guide under and past the belt. The elastic cord must be under the belt. Then, place the guide over the belt and insert the two edges of the belt into the slots of the guide. 3. Be sure that the belt is not twisted and it lies ﬂat.
Page 39 CAUTION: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.
Page 40: Safety Belt Pretensioners
Safety Belt Pretensioners Your vehicle has safety belt pretensioners for the driver and right front passenger. Although you cannot see them, they are part of the safety belt assembly. They help tighten the safety belts during the early stages of a moderate to severe frontal and near frontal crash if the threshold conditions for pretensioner activation are met.
Page 41: Child Restraints
Child Restraints Older Children Older children who have outgrown booster seats should wear the vehicle’s safety belts. What is the proper way to wear safety belts? An older child should wear a lap-shoulder belt and get the additional restraint a shoulder belt can provide.
Page 42 CAUTION: Never do this. Here two children are wearing the same belt. The belt cannot properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time.
Page 43 CAUTION: Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt.
Page 44: Infants And Young Children
Infants and Young Children Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 45 CAUTION: Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer protection for adults and older children, but not for CAUTION: (Continued) CAUTION: (Continued) young children and infants. Neither the vehicle’s safety belt system nor its airbag system is designed for them.
Page 46 What are the different types of add-on child restraints? Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic types. Selection of a particular restraint should take into consideration not only the child’s weight, height, and age but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.
Page 47: Child Restraint Systems
CAUTION: The body structure of a young child is quite unlike that of an adult or older child, for whom the safety belts are designed. A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should.
Page 48 A rear-facing infant seat (B) provides restraint with the seating surface against the back of the infant. The harness system holds the infant in place and, in a crash, acts to keep the infant positioned in the restraint. A forward-facing child seat (C-E) provides restraint for the child’s body with the harness and also sometimes with surfaces such as T-shaped or shelf-like shields.
Page 49 A booster seat (F-G) is a child restraint designed to improve the ﬁt of the vehicle’s safety belt system. Some booster seats have a shoulder belt positioner, and some high-back booster seats have a ﬁve-point harness. A booster seat can also help a child to see out the window.
Page 50 Securing an Add-on Child Restraint in the Vehicle CAUTION: A child can be seriously injured or killed in a crash if the child restraint is not properly secured in the vehicle. Make sure the child restraint is properly installed in the vehicle using the vehicle’s safety belt or LATCH system, following the instructions that came with that restraint,...
Page 51 Securing the Child Within the Child Restraint There are several systems for securing the child within the child restraint. One system, the three-point harness, has straps that come down over each of the infant’s shoulders and buckle together at the crotch. The ﬁve-point harness system has two shoulder straps, two hip straps, and a crotch strap.
Page 52: Where To Put The Restraint
Where to Put the Restraint Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. We recommend that children be secured in a rear seat, including: an infant or a child riding in a rear-facing child restraint;...
Page 53: Lower Anchors And Tethers For Children (Latch)
Wherever you install a child restraint, be sure to secure the child restraint properly. Keep in mind that an unsecured child restraint can move around in a collision or sudden stop and injure people in the vehicle. Be sure to properly secure any child restraint in your vehicle —...
Page 54 Lower Anchors Lower anchors (A) are metal bars built into the vehicle. There are two lower anchors for each LATCH seating position that will accommodate a child restraint with lower attachments (B). Top Tether Anchor A top tether (A, C) anchors the top of the child restraint to the vehicle.
Page 55 Your child restraint may have a single tether (A) or a dual tether (C). Either will have a single attachment (B) to secure the top tether to the anchor. Some child restraints that have a top tether are designed for use with or without the top tether being attached.
Page 56 To assist you in locating the top tether anchors, the top tether anchor symbol is located on the trim cover. The top tether anchors are located under the trim covers on the rear seatback ﬁller panel. Pull open the trim cover to access the anchor. Be sure to use an anchor located on the same side of the vehicle as the seating position where the child restraint will be placed.
Page 57 Securing a Child Restraint Designed for the LATCH System CAUTION: If a LATCH-type child restraint is not attached to anchors, the restraint will not be able to protect the child correctly. In a crash, the child could be seriously injured or killed.
Page 58 CAUTION: Children can be seriously injured or strangled if a shoulder belt is wrapped around their neck and the safety belt continues to tighten. Secure any unused safety belts behind the child restraint so children cannot reach them. Pull the shoulder belt all the way out of the retractor to set the lock, if your vehicle has one, after the child restraint has been...
Page 59 2. If the child restraint manufacturer recommends that the top tether be attached, attach and tighten the top tether to the top tether anchor, if equipped. Refer to the child restraint instructions and the following steps: 2.1. Find the top tether anchor. 2.2.
Page 60: Securing A Child Restraint In A Rear Seat Position
If the position you are using has a ﬁxed or adjustable head restraint and you are using a dual tether, route the tether around the head restraint. 3. Push and pull the child restraint in different directions to be sure it is secure. Securing a Child Restraint in a Rear Seat Position If your child restraint has the LATCH system, see...
Page 61 3. Buckle the belt. Make sure the release button 4. Pull the rest of the shoulder belt all the way is positioned so you would be able to unbuckle out of the retractor to set the lock. the safety belt quickly if you ever had to.
Page 62: Securing A Child Restraint In The Right Front Seat Position
5. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt, and feed the shoulder belt back into the retractor. If you are using a forward-facing child restraint, you may ﬁnd it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 63 See Passenger Sensing System on page 76 and Passenger Airbag Status Indicator on page 164 for more information on this including important safety information. A label on your sun visor says, “Never put a rear-facing child seat in the front.” This is because the risk to the rear-facing child is so great, if the airbag deploys.
Page 64 There is no top tether anchor at the right front seating position. Do not secure a child restraint in this position if a national or local law requires that the top tether be anchored or if the instructions that come with the child restraint say that the top tether must be anchored.
Page 65 5. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. 6. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt, and feed the shoulder belt back into the retractor.
Page 66: Airbag System
8. If your vehicle has a passenger sensing system and the airbag is off, the off indicator on the instrument panel will be lit and stay lit when the key is turned to RUN or START. If a child restraint has been installed and the on indicator is lit, turn the vehicle off.
Page 67 Here are the most important things to know about the airbag system: CAUTION: You can be severely injured or killed in a crash if you are not wearing your safety belt — even if you have airbags. Wearing your safety belt during a crash helps reduce your chance of hitting things inside the vehicle or being ejected from it.
Page 68 CAUTION: Both frontal and side impact airbags inﬂate with great force, faster than the blink of an eye. If you are too close to an inﬂating airbag, as you would be if you were leaning forward, it could seriously injure you. Safety belts help keep you in position for airbag inﬂation before and during a crash.
Page 69: Where Are The Airbags
There is an airbag readiness light on the instrument panel cluster, which shows the airbag symbol. The system checks the airbag electrical system for malfunctions. The light tells you if there is an electrical problem. See Airbag Readiness Light on page 163 for more information.
Page 70 The right front passenger’s frontal airbag is in the instrument panel on the passenger’s side. If your vehicle has a roof-mounted side impact airbag for the driver and the person seated directly behind the driver, it is located in the ceiling above the side windows.
Page 71 If your vehicle has a roof-mounted side impact airbag for the right front passenger and the person directly behind that passenger, it is located in the ceiling above the side windows. CAUTION: If something is between an occupant and an airbag, the bag might not inﬂate properly or it might force the object into that person causing severe injury or even death.
Page 72: When Should An Airbag Inﬂate
When Should an Airbag Inﬂate? The driver’s and right front passenger’s frontal airbags are designed to inﬂate in moderate to severe frontal or near-frontal crashes. But they are designed to inﬂate only if the impact exceeds a predetermined deployment threshold. Deployment thresholds take into account a variety of desired deployment and non-deployment events and are used to predict how severe a crash is likely to be in...
Page 73: What Makes An Airbag Inﬂate
Frontal airbags (driver and right front passenger) are not intended to inﬂate during vehicle rollovers, rear impacts, or in many side impacts. Your vehicle may or may not have roof-mounted side impact airbags. See Airbag System on page 66. Roof-mounted side impact airbags are intended to inﬂate in moderate to severe side crashes.
Page 74: How Does An Airbag Restrain
How Does an Airbag Restrain? In moderate to severe frontal or near frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. In moderate to severe side collisions, even belted occupants can contact the inside of the vehicle. Airbags supplement the protection provided by safety belts.
Page 75 CAUTION: When an airbag inﬂates, there may be dust in the air. This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in the vehicle should get out as soon as it is safe to do so.
Page 76: Passenger Sensing System
Passenger Sensing System If your vehicle has one of the indicators pictured in the following illustrations, then your vehicle has a passenger sensing system for the right front passenger’s position. A passenger airbag status indicator on the instrument panel will be visible when you turn your ignition key to START or RUN.
Page 77 CAUTION: A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger’s airbag inﬂates. This is because the back of the rear-facing child restraint would be very close to the inﬂating airbag. Even though the passenger sensing system is designed to turn off the passenger’s frontal airbag if the system detects a rear-facing child restraint, no...
Page 78 If a child restraint has been installed and the on indicator is lit, turn the vehicle off. Remove the child restraint from the vehicle and reinstall the child restraint following the child restraint manufacturer’s directions and refer to Securing a Child Restraint in the Right Front Seat Position on page 62.
Page 79 CAUTION: If the airbag readiness light in the instrument panel cluster ever comes on and stays on, it means that something may be wrong with the airbag system. If this ever happens, have the vehicle serviced promptly, because an adult-size person sitting in the right front passenger’s seat may not have the protection of the airbag(s).
Page 80: Servicing Your Airbag-Equipped Vehicle
See Adding Equipment to Your Airbag-Equipped Vehicle on page 81 for more information about modiﬁcations that can affect how the system operates. CAUTION: Stowing of articles under the passenger’s seat or between the passenger’s seat cushion and seatback may interfere with the proper operation of the passenger sensing system.
Page 81 Adding Equipment to Your Airbag-Equipped Vehicle Is there anything I might add to the front or sides of the vehicle that could keep the airbags from working properly? Yes. If you add things that change your vehicle’s frame, bumper system, height, front end or side sheet metal, they may keep the airbag system from working properly.
Page 82: Restraint System Check
Restraint System Check Checking the Restraint Systems Now and then, make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired.
Page 83: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts After a Crash CAUTION: A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary...
Page 84 ✍ NOTES...
Page 85: Features And Controls
Section 2 Keys ... 87 Remote Keyless Entry (RKE) System ... 88 Remote Keyless Entry (RKE) System Operation ... 90 Doors and Locks ... 96 Door Locks ... 96 Power Door Locks ... 97 Delayed Locking ... 97 Automatic Door Lock ... 98 Programmable Automatic Door Unlock ...
Page 86: Onstar
Section 2 Mirrors ... 127 Manual Rearview Mirror ... 127 Manual Rearview Mirror with OnStar Outside Remote Control Mirror ... 127 Outside Power Mirrors ... 128 Outside Convex Mirror ... 128 ® OnStar System ... 129 Features and Controls Storage Areas ... 133 Glove Box ...
Page 87: Keys
Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keys in the ignition and they could be seriously injured or killed if caught in the path of a...
Page 88: Remote Keyless Entry (Rke) System
One key is used for the ignition, the doors and all other locks. When a new vehicle is delivered, the dealer removes the key tag from the key and gives it to the ﬁrst owner. Each tag has a code on it that tells your dealer or a qualiﬁed locksmith how to make extra keys.
Page 89: Operation
This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device. Changes or modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment.
Page 90: Remote Keyless Entry (Rke) System Operation
Remote Keyless Entry (RKE) System Operation The vehicle’s doors may be locked and unlocked, and the trunk can be opened from about 3 feet (1 m) up to 197 feet (60 m) away with the remote keyless entry transmitter. If your vehicle has the remote vehicle start feature, you can also start the vehicle’s engine with the Remote Keyless Entry (RKE) transmitter.
Page 91 The interior lamps will turn on and stay on for 20 seconds or until the ignition is turned on. If enabled through the DIC, the remote unlock feedback can be programmed to have the horn chirp and/or the turn signals ﬂash when the RKE transmitter is used to unlock the vehicle’s doors.
Page 92 Matching Transmitter(s) to Your Vehicle Each RKE transmitter is coded to prevent another transmitter from unlocking your vehicle. If a transmitter is lost or stolen, a replacement can be purchased through your dealer. Remember to bring any additional transmitters so they can also be re-coded to match the new transmitter.
Page 93 2. Remove the battery and replace it with the new one. Make sure the positive (+) side of the battery faces up. Use one three-volt, CR2032, or equivalent, type battery. 3. Snap the front and back together tightly so moisture will not get inside the transmitter. 4.
Page 94 (Remote Start): If your vehicle has the remote start feature, the RKE transmitter will have a button with this symbol on it. To start the vehicle using the remote start feature, do the following: 1. Aim the transmitter at the vehicle. 2.
Page 95 • The check engine light is on. See Malfunction Indicator Lamp on page 170. • The engine coolant temperature is too high. • The oil pressure is low. • Two remote vehicle starts have already been provided for that ignition cycle. Vehicles that have the remote vehicle start feature are shipped from the factory with the remote start system enabled.
Page 96: Doors And Locks
Doors and Locks Door Locks CAUTION: Unlocked doors can be dangerous. • Passengers, especially children, can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle will not open it. You increase the chance of being thrown out of the vehicle in a crash if the doors are not locked.
Page 97: Power Door Locks
Power Door Locks Your vehicle may have power door locks. The locks are located on the driver’s and front passenger’s door armrest. Driver’s Switch shown, Front Passenger’s Switch similar Press the side of the switch with the lock symbol to lock the doors. This is the right side for the driver’s switch and the left side for the front passenger’s switch.
Page 98: Automatic Door Lock
Automatic Door Lock If your vehicle has power door locks, the doors will automatically lock when the shift lever is moved out of PARK (P) for a vehicle with an automatic transaxle. For a vehicle with a manual transaxle, the speed must be greater than 5 mph (8 km/h). The automatic door locking feature cannot be disabled.
Page 99: Lockout Protection
To cancel the rear door security lock, do the following: 1. Unlock the door and open it from the outside. 2. Insert the key into the security lock slot and turn it so the slot is in the vertical position. Lockout Protection If your vehicle has power door locks, it will have this feature.
Page 100 Remote Trunk Release To open the trunk from inside the vehicle, press the remote trunk release button located inside the driver’s storage compartment located on the lower left side of the instrument panel. See Instrument Panel Overview on page 138 or Driver’s Storage Compartment on page 133.
Page 101: Windows
Windows CAUTION: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 102: Power Windows
Power Windows CAUTION: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome from extreme heat in warm or hot weather and suffer permanent injuries or even death from heat stroke. Leaving children in a vehicle with the ignition key is dangerous for many reasons, children or others could be badly...
Page 103: Theft-Deterrent Systems
Express-Down Window The driver’s window switch has an express-down feature which allows the window to be lowered fully without continuously pressing the switch. This switch is labeled AUTO. Press the front of the switch to the ﬁrst position, and the driver’s window will open a small amount.
Page 104: Content Theft-Deterrent
Content Theft-Deterrent Your vehicle may have a content theft-deterrent alarm system. Arming the System With the ignition off, you can arm the system by pressing the remote keyless entry transmitter lock button. The system will arm after either of these things occur: •...
Page 105 How the System Alarm is Activated If the system is armed, it can be activated by either: • Opening the driver’s door or trunk. This will cause a ten second pre-alarm chirp followed by a thirty second full alarm of horn and lights. •...
Page 106: Pass-Key Iii+ Operation
This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device. Changes or modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment.
Page 107 It may be possible for the PASS-Key to “learn” the transponder value of a new or replacement key. Up to 10 keys may be programmed for the vehicle. The following procedure is for programming additional keys only. If all the currently programmed keys are lost or do not operate, you must see your dealer or a locksmith who can service PASS-Key have keys made and programmed to the system.
Page 108: Starting And Operating Your Vehicle
Starting and Operating Your Vehicle New Vehicle Break-In Notice: Your vehicle does not need an elaborate break-in. But it will perform better in the long run if you follow these guidelines: • Do not drive at any one constant speed, fast or slow, for the ﬁrst 500 miles (805 km).
Page 109 (LOCK): This position locks your steering column. It is a theft-deterrent feature. You will only be able to remove your key when the ignition is turned to LOCK. If you have an automatic transaxle, the ignition switch cannot be turned to LOCK unless the shift lever is in PARK (P).
Page 110 Key In the Ignition Never leave your vehicle with the keys inside, as it is an easy target for joy riders or thieves. If you leave the key in the ignition and park your vehicle, a chime will sound, when you open the driver’s door.
Page 111: Retained Accessory Power (Rap)
3. Locate the plunger. 4. Press and hold the plunger toward the driver’s door while turning the ignition key to LOCK. Remove the key. Have your vehicle serviced at your GM dealer as soon as possible. Retained Accessory Power (RAP) Your vehicle has a Retained Accessory Power (RAP) feature which allow’s the radio, power windows, and sunroof to continue to work up...
Page 112: Starting The Engine
Starting the Engine Place the transaxle in the proper gear. Automatic Transaxle Move your shift lever to PARK (P) or NEUTRAL (N). Your engine will not start in any other position — this is a safety feature. To restart when you are already moving, use NEUTRAL (N) only.
Page 113: Engine Coolant Heater
2. If the engine does not start after 5-10 seconds, especially in very cold weather (below 0°F or −18°C), it could be ﬂooded with too much gasoline. Try pushing the accelerator pedal all the way to the ﬂoor and holding it there as you hold the key in START for up to a maximum of 15 seconds.
Page 114: Automatic Transaxle Operation
3. Plug it into a normal, grounded 110-volt AC outlet. CAUTION: Plugging the cord into an ungrounded outlet could cause an electrical shock. Also, the wrong kind of extension cord could overheat and cause a ﬁre. You could be seriously injured. Plug the cord into a properly grounded three-prong 110-volt AC outlet.
Page 115 CAUTION: It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly.
Page 116 NEUTRAL (N): In this position, your engine does not connect with the wheels. To restart when you are already moving, use NEUTRAL (N) only. Also, use NEUTRAL (N) when your vehicle is being towed. CAUTION: Shifting into a drive gear while your engine is running at high speed is dangerous.
Page 117: Manual Transaxle Operation
INTERMEDIATE (I): This position is also used for normal driving. However, it reduces vehicle speed without using your brakes for slight downgrades where the vehicle would otherwise accelerate due to steepness of grade. If constant upshifting or downshifting occurs while driving up steep hills, this position can be used to prevent repetitive types of shifts.
Page 118 SECOND (2): Press the clutch pedal as you let up on the accelerator pedal and shift into SECOND (2). Then, slowly let up on the clutch pedal as you press the accelerator pedal. THIRD (3), FOURTH (4) and FIFTH (5): Shift into THIRD (3), FOURTH (4) and FIFTH (5) the same way you do for SECOND (2).
Page 119 Shift Speeds CAUTION: If you skip a gear when you downshift, you could lose control of your vehicle. You could injure yourself or others. Do not shift down more than one gear at a time when you downshift. Up-Shift Light If you have a manual transaxle, you may have an up-shift light.
Page 120: Parking Brake
Parking Brake Automatic Shown, Manual Similar The parking brake lever is located between the front seats. For vehicles equipped with an armrest, lift the console armrest in order to access the parking brake lever. To set the parking brake, hold the brake pedal down and pull up on the parking brake lever.
Page 121: Shifting Into Park (P) (Automatic
Shifting Into Park (P) (Automatic Transaxle) CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 122 Leaving Your Vehicle With the Engine Running CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch ﬁre.
Page 123: Shifting Out Of Park (P) (Automatic
Shifting Out of Park (P) (Automatic Transaxle) This vehicle is equipped with an electronic shift lock release system. The shift lock release is designed to: • Prevent ignition key removal unless the shift lever is in PARK (P) with the shift lever button fully released, and •...
Page 124: Parking Your Vehicle
Parking Your Vehicle (Manual Transaxle) Before leaving your vehicle, fully press the clutch pedal in, move the shift lever into REVERSE (R), and ﬁrmly apply the parking brake. Once the shift lever has been placed in REVERSE (R) with the clutch pedal pressed in, you can turn the ignition key to LOCK, remove the key and release the clutch.
Page 125: Engine Exhaust
Engine Exhaust CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you cannot see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: • The exhaust system sounds strange or different. •...
Page 126: Running The Engine While Parked
Running the Engine While Parked It is better not to park with the engine running. But if you ever have to, here are some things to know. CAUTION: Idling the engine with the climate control system off could allow dangerous exhaust into your vehicle.
Page 127: Mirrors
Mirrors Manual Rearview Mirror While sitting in a comfortable driving position, adjust the mirror so you can see clearly behind your vehicle. Grip the mirror in the center to move it up or down and side to side. The control at the bottom of the mirror is the day/night feature that allows adjustment to the mirror so that the glare of headlamps from behind is reduced.
Page 128: Outside Power Mirrors
Outside Power Mirrors The controls for the outside power mirrors are located on the driver’s door armrest. Move the selector switch located below the four-way control pad to the left or right to choose either the driver’s side or passenger’s side mirror. To adjust a mirror, use the arrows located on the four-way control pad to move the mirror in the desired direction.
Page 129: Onstar System
® OnStar System ® OnStar uses several innovative technologies and live advisors to provide you with a wide range of safety, security, information, and convenience services. If your airbags deploy, the system is designed to make an automatic call to OnStar Emergency advisors who can request emergency services be sent to your location.
Page 130 Available Services with Safe & ® Sound Plan • Automatic Notiﬁcation of Airbag Deployment • Advanced Automatic Crash Notiﬁcation (AACN) (If equipped) • Link to Emergency Services • Roadside Assistance • Stolen Vehicle Location Assistance • AccidentAssist • Remote Door Unlock/Vehicle Alert ®...
Page 131 ® OnStar Virtual Advisor ® OnStar Virtual Advisor is a feature of OnStar Hands-Free Calling that uses your minutes to access location-based weather, local traffic reports, and stock quotes. By pressing the phone button and giving a few simple voice commands, you can browse through the various topics.
Page 132 ® OnStar service cannot work unless your vehicle ® is in a place where OnStar has an agreement with a wireless service provider for service in that ® area. OnStar service also cannot work unless you are in a place where the wireless service ®...
Page 133: Storage Areas
Storage Areas Glove Box Open the glove box by lifting up on the lever. Close the glove box with a ﬁrm push. Cupholder(s) There are two cupholders located at the front of the center console, in front of the shift lever. There are also cupholders for the rear seat passengers located at the rear of the center console.
Page 134: Sunroof
Sunroof If the vehicle has a sunroof, the switch that operates it is located on the headliner between the map lamps. The sunroof will only operate while the ignition is on, or turned to ACC, or if Retained Accessory Power (RAP) is active. See Retained Accessory Power (RAP) on page 111.
Page 135: Instrument Panel
Section 3 Instrument Panel Overview ... 138 Hazard Warning Flashers ... 140 Other Warning Devices ... 140 Horn ... 140 Tilt Wheel ... 141 Turn Signal/Multifunction Lever ... 141 Turn and Lane-Change Signals ... 142 Headlamp High/Low-Beam Changer ... 142 Flash-to-Pass ...
Page 136 Section 3 Enhanced Traction System Warning Light ... 168 Engine Coolant Temperature Warning Light ... 169 Malfunction Indicator Lamp ... 170 Oil Pressure Light ... 173 Security Light ... 174 Fog Lamp Light ... 174 Highbeam On Light ... 175 Fuel Gage ...
Page 137 ✍ NOTES...
Page 138: Instrument Panel Overview
Instrument Panel Overview...
Page 139 The main components of your instrument panel are the following: A. Side Window Outlets. See Climate Control System on page 154. B. Air Outlets. See Outlet Adjustment on page 157. C. Turn Signal/Multifunction Lever. See Turn Signal/Multifunction Lever on page 141. D.
Page 140: Hazard Warning Flashers
Hazard Warning Flashers The hazard warning ﬂashers let you warn the police and others that you have a problem. The front and rear turn signal lamps will ﬂash on and off. The hazard warning ﬂasher button is located in the center of the instrument panel.
Page 141: Tilt Wheel
Tilt Wheel A tilt wheel allows you to adjust the steering wheel before you drive. You can raise the steering wheel to the highest level to give your legs more room when you enter and exit the vehicle. The lever that allows you to tilt the steering wheel is located on the left side of the steering column.
Page 142: Turn And Lane-Change Signals
Turn and Lane-Change Signals The turn signal has two upward (for right) and two downward (for left) positions. These positions allow you to signal a turn or a lane change. To signal a turn, move the lever all the way up or down.
Page 143: Flash-To-Pass
Flash-to-Pass This feature lets you use your high-beam headlamps to signal a driver in front of you that you want to pass. To use it, pull the turn signal/multifunction lever toward you until the high-beam headlamps come on, then release the lever to turn them off. Windshield Wipers Use this lever, located on the right side of the steering wheel, to operate the windshield wipers.
Page 144: Windshield Washer
(High Speed): Move the lever up to the second setting past intermittent, for wiping at high speed. (Mist): Move the lever all the way down to this position for a single wiping cycle. Hold it there until the windshield wipers start; then let go. The windshield wipers stop after one wiping cycle.
Page 145: Cruise Control
Cruise Control With cruise control, you can maintain a speed of about 25 mph (40 km/h) or more without keeping your foot on the accelerator. This can really help on long trips. Cruise control does not work at speeds below 25 mph (40 km/h). CAUTION: Cruise control can be dangerous where you cannot drive safely at a steady speed.
Page 146 (On/Off): Press this button to turn the cruise control system on and off. RES+ (Resume): Press this button to resume a set speed and to accelerate the speed. SET– (Set): Press this button to set a speed and to decrease the speed. To set a speed do the following: 1.
Page 147 Reducing Speed While Using Cruise Control If the cruise control system is already engaged, • Push and hold the SET– part of the button until you reach the lower speed you want, then release it. • To slow down in very small amounts, push the SET–...
Page 148: Headlamps
Headlamps The lever on the left side of the steering column operates the exterior lamps. The exterior lamp switch has the following four positions: (Headlamps): Turn the switch to this position to turn on the headlamps, parking lamps, and taillamps. (Parking Lamps): Turn the switch to this position to turn on the parking lamps and taillamps only.
Page 149: Wiper Activated Headlamps
Wiper Activated Headlamps This feature activates the headlamps and parking lamps after the windshield wipers are turned on. For this feature to work, automatic lighting must be enabled. See Headlamps on page 148 for additional information. When the ignition is turned off, the wiper-activated headlamps will immediately turn off.
Page 150: Fog Lamps
Fog Lamps If equipped, the fog lamp button is located on the instrument panel, to the left of the steering wheel. The ignition must be on to turn your fog lamps on. Push the button to turn the fog lamps on. An indicator light on the cluster will come on when the fog lamps are on.
Page 151: Entry/Exit Lighting
Entry/Exit Lighting The lamps inside your vehicle will go on when you open any door. These lamps will fade out after about 20 seconds after all of the doors have been closed or when the ignition is turned to RUN. These lamps will also go on when you press the trunk release, unlock symbol button or the horn symbol on the keyless entry system...
Page 152: Battery Run-Down Protection
A high electrical load occurs when several of the following loads are on: headlamps, high beams, fog lamps, rear window defogger, climate control fan at high speed, heated seats, engine cooling fans, trailer loads, and loads plugged into accessory power outlets. EPM works to prevent excessive discharge of the battery.
Page 153: Ashtray(S) And Cigarette Lighter
Notice: Adding any electrical equipment to your vehicle may damage it or keep other components from working as they should. The repairs would not be covered by your warranty. Do not use equipment exceeding maximum amperage rating of 20 amperes. Check with your dealer/retailer before adding electrical equipment.
Page 154: Climate Controls
Climate Controls Climate Control System With this system you can control the heating, cooling, and ventilation for the vehicle. Vehicles with Air Conditioning shown, without Air Conditioning similar Operation To change the current mode, select one of the following: (Vent): This mode directs air to the instrument panel outlets.
Page 155 (Recirculate): Press this button to prevent outside air and odors from entering the vehicle or to help heat or cool the air inside the vehicle more quickly. An indicator light above the button will come on in this mode. The air conditioning compressor also comes on.
Page 156 Defogging and Defrosting Fog on the inside of windows is a result of high humidity (moisture) condensing on the cool window glass. This can be minimized if the climate control system is used properly. There are two modes to clear fog or frost from the windshield and side windows.
Page 157: Outlet Adjustment
Outlet Adjustment Use the thumbwheels located next to and below the air outlets to change the direction of the airﬂow and to open and close the outlets. Operation Tips • Clear away any ice, snow or leaves from the air inlets at the base of the windshield that may block the ﬂow of air into your vehicle.
Page 158 3. Open the passenger compartment air ﬁlter door by reaching through the opening in the back of the glove box and raising the tab until the door can be opened downward. 4. Remove the ﬁlter by sliding it out of the housing.
Page 159: Warning Lights, Gages, And Indicators
Warning Lights, Gages, and Indicators This part describes the warning lights and gages on your vehicle. The pictures help to locate them. Warning lights and gages can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement. Paying attention to the warning lights and gages could also save you or others from injury.
Page 160: Instrument Panel Cluster
Instrument Panel Cluster Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You will know how fast you are going, about how much fuel is left in the tank, and many other things you will need to drive safely and economically.
Page 161: Speedometer And Odometer
Speedometer and Odometer Your speedometer lets you see your speed in both miles per hour (mph) and kilometers per hour (km/h). Your vehicle’s odometer works together with the driver information center. You can set a Trip A and Trip B odometer. See “Trip Information” under DIC Operation and Displays on page 176.
Page 162: Safety Belt Reminder Light
Safety Belt Reminder Light When the key is turned to RUN or START, a chime will sound for several seconds to remind you and your passengers to buckle your safety belts. The driver safety belt light will also come on and stay on for several seconds, then it will ﬂash for several more.
Page 163: Airbag Readiness Light
Airbag Readiness Light There is an airbag readiness light on the instrument panel cluster, which shows the airbag symbol. The system checks the airbag’s electrical system for malfunctions. The light tells you if there is an electrical problem. The system check includes the airbag sensor, the airbag modules, the wiring and the crash sensing and diagnostic module.
Page 164: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator If your vehicle has the passenger sensing system, then your instrument panel has a passenger airbag status indicator. See Passenger Sensing System on page 76. United States When the ignition key is turned to RUN or START, the passenger airbag status indicator will light ON and OFF, or the symbol for on and off, for several seconds as a system check.
Page 165 CAUTION: Even though the passenger sensing system is designed to turn off the right front passenger’s frontal airbag if the system detects a rear-facing child restraint, no system is fail-safe, and no one can guarantee that an airbag will not deploy under some unusual circumstance, even though it is turned off.
Page 166: Charging System Light
Charging System Light The charging system light will come on brieﬂy when you turn on the ignition, and the engine is not running, as a check to show you it is working. Then it should go out when the engine is started. If it stays on, or comes on while you are driving, you may have a problem with the electrical charging system.
Page 167: Brake System Warning Light
Brake System Warning Light Your vehicle’s hydraulic brake system is divided into two parts. If one part is not working, the other part can still work and stop you. For good braking, though, you need both parts working well. If the warning light comes on, there is a brake problem.
Page 168: Anti-Lock Brake System Warning Light
Anti-Lock Brake System Warning Light Your vehicle may have an Anti-Lock Brake System (ABS) warning light. The ABS warning light will come on brieﬂy when you turn the ignition key to LOCK. This is normal. If the light does not come on then, have it ﬁxed so it will be ready to warn you if there is a problem.
Page 169: Engine Coolant Temperature Warning Light
The ETS warning light may come on for the following reasons: • If you turn the system off by moving the shift lever to LOW (L), the warning light will come on and stay on. To turn the system back on, move the shift lever back to a position other than LOW (L).
Page 170: Malfunction Indicator Lamp
Malfunction Indicator Lamp Check Engine Light Your vehicle has a computer which monitors operation of the fuel, ignition, and emission control systems. This system is called OBD II (On-Board Diagnostics-Second Generation) and is intended to assure that emissions are at acceptable levels for the life of the vehicle, helping to produce a cleaner environment.
Page 171 This light should come on, as a check to show you it is working, when the ignition is on and the engine is not running. If the light does not come on, have it repaired. This light will also come on during a malfunction in one of two ways: •...
Page 172 If the Light Is On Steady You may be able to correct the emission system malfunction by considering the following: Did you recently put fuel into your vehicle? If so, reinstall the fuel cap, making sure to fully install the cap. See Filling the Tank on page 274. The diagnostic system can determine if the fuel cap has been left off or improperly installed.
Page 173: Oil Pressure Light
Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or may begin programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. Here are some things you need to know to help your vehicle pass an inspection: Your vehicle will not pass this inspection if the check engine light is on or not working properly.
Page 174: Security Light
• If you are idling at a stop sign, the light may blink on and then off. • If you make a hard stop, the light may come on for a moment. This is normal. CAUTION: Do not keep driving if the oil pressure is low.
Page 175: Highbeam On Light
Highbeam On Light This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 142 for more information. Fuel Gage Your fuel gage tells you about how much fuel you have left. Here are four things that some owners ask about. None of these show a problem with your fuel gage: •...
Page 176: Driver Information Center (Dic)
Driver Information Center (DIC) Your vehicle has a Driver Information Center (DIC). The DIC display gives you the status of many of your vehicle’s systems. The DIC is also used to display driver personalization menu modes and warning/status messages. All messages will appear in the DIC display, located at the bottom of the instrument panel cluster.
Page 177 Information Modes (Information): Press this button to scroll through the following vehicle information modes: Outside Air Temperature and Odometer Press the information button until the outside air temperature and the odometer are displayed. This mode shows the temperature outside of the vehicle in either degrees Fahrenheit (°F) or degrees Celsius (°C) and the total distance the vehicle has been driven in either miles (mi) or...
Page 178 ECON (Economy) Press the information button until ECON is displayed. This mode shows how many miles per gallon (mpg) or liters per 100 kilometers (L/100 km) your vehicle is getting based on current and past driving conditions. Press and hold the reset button while ECON is displayed to reset the average fuel economy.
Page 179: Dic Warnings And Messages
DIC Warnings and Messages These messages appear if there is a problem detected in one of your vehicle’s systems. A message will clear when the vehicle’s condition is no longer present. To acknowledge a message and clear it from the display, press and hold any of the DIC buttons.
Page 180 COOLING MODE ON This message may display on some vehicles. Under severe conditions, hot ambient temperatures, steep grades, and towing, your vehicle may experience more transaxle shifting. This is temporary and normal under these conditions. This does not require engine or transaxle service.
Page 181: Dic Vehicle Personalization
LOW FUEL This message displays when your vehicle is low on fuel. Reﬁll the fuel tank as soon as possible. See Fuel Gage on page 175, Fuel on page 270, and Filling the Tank on page 274 for more information. LOW TRACTION If your vehicle has the Enhanced Traction System (ETS), this message displays when the system...
Page 182 To change feature settings, use the following procedure: Entering Personalization Menu 1. Turn the ignition on while the vehicle is stopped. To avoid excessive drain on the battery, it is recommended that the headlamps are turned off. 2. Press and hold the information and reset buttons at the same time for one second, then release to enter the personalization menu.
Page 183 REMOTE START If your vehicle has remote start, this feature allows remote start to be turned off or on. Remote start allows you to start the engine from outside of the vehicle using your Remote Keyless Entry (RKE) transmitter. When REMOTE START appears on the display, press and hold the reset button for at least one second to scroll through the available settings:...
Page 184 ON: The horn will chirp on the ﬁrst press of the unlock button on the RKE transmitter. See Remote Keyless Entry (RKE) System Operation on page 90 for more information. Choose one of the available settings and press the information button to select it and move on to the next feature.
Page 185 Choose one of the available settings and press the information button to select it and move on to the next feature. AUTO UNLK (Unlock) This feature, which allows the vehicle to automatically unlock certain doors, can be enabled or disabled. When AUTO UNLK appears on the display, press and hold the reset button for at least one second to scroll through the available settings: ALL (default): All of the doors will automatically...
Page 186 EXT (Exterior) LIGHTS If your vehicle has Remote Keyless Entry (RKE), this feature, which allows the vehicle’s exterior perimeter lighting to turn on each time the unlock button on the RKE transmitter is pressed, can be enabled or disabled. When EXT LIGHTS appears on the display, press and hold the reset button for at least one second to scroll through the available settings:...
Page 187: Audio System(S)
Exiting Personalization Menu The personalization menu will be exited when any of the following conditions occur: • A ten second time period has elapsed. • The ignition is turned off. • The end of the personalization menu list is reached. Audio System(s) Determine which radio your vehicle has and then read the pages following to familiarize yourself...
Page 188: Setting The Time (Without Date Display)
While your vehicle is parked: • Familiarize yourself with all of its controls. • Familiarize yourself with its operation. • Set up your audio system by presetting your favorite radio stations, setting the tone, and adjusting the speakers. Then, when driving conditions permit, you can tune to your favorite radio stations using the presets and steering wheel controls if the vehicle has them.
Page 189: Setting The Time (With Date Display)
4. Press the clock button again until the clock display stops ﬂashing to set the currently displayed time; otherwise, the ﬂashing stops after ﬁve seconds and the current time displayed will be automatically set. To change the time default setting from 12 hour to 24 hour, press the clock button and then the pushbutton located under the forward arrow label.
Page 190 To set the time and date, follow these instructions: 1. Turn the ignition key to ACC (accessory) or RUN. Press the power knob, located in the center of the radio, to turn the radio on. 2. Press the MENU button. Once the clock option is displayed.
Page 191: Radio With Cd (Base)
Radio with CD (Base) Playing the Radio (Power/Volume): Press this knob to turn the system on and off. Turn this knob clockwise or counterclockwise to increase or decrease the volume. The radio goes to the previous volume setting whenever the radio is turned on. The volume can still be adjusted by using the volume knob.
Page 192 Setting Preset Stations Up to 18 stations (six FM1, six FM2, and six AM), can be programmed on the six numbered pushbuttons, by performing the following steps: 1. Turn the radio on. 2. Press BAND to select FM1, FM2, or AM. 3.
Page 193 Playing a CD (Single CD Player) Insert a CD partway into the slot, label side up. The player pulls it in and the CD should begin playing. If the ignition or radio is turned off with a CD in the player, it stays in the player.
Page 194 EJECT: Press the CD eject button to eject the CD. If the CD is not removed, after several seconds, the CD automatically pulls back into the player. (Tune): Turn this knob to select tracks on the CD currently playing. © ¨...
Page 195 CD/AUX (CD/Auxiliary): Press this button to play a CD while listening to the radio. The CD icon and track number displays while a CD is in the player. Press this button again and the system automatically searches for an auxiliary input device such as a portable audio player.
Page 196: Radio With Cd (Mp3)
Radio with CD (MP3) To use a portable audio player, connect a 3.5 mm (1/8 inch) cable to the radio’s front auxiliary input jack. When a device is connected, press the radio CD/AUX button to begin playing audio from the device over the car speakers. (Power/Volume): Turn this knob clockwise or counterclockwise to increase or decrease the volume of the portable player.
Page 197 Radio Data System (RDS) The audio system has a Radio Data System (RDS). The RDS feature is available for use only on FM stations that broadcast RDS information. This system relies upon receiving speciﬁc information from these stations and only works when the information is available.
Page 198 4. Press the pushbutton under the desired Speed Compensated Volume setting (OFF, Low, Med (medium), or High) to select the level of radio volume compensation. The display times out after approximately 10 seconds. Each higher setting allows for more radio volume compensation at faster vehicle speeds.
Page 199 Each page of favorites can contain any combination of AM, FM, or XM™ (if equipped) stations. To store a station as a favorite, perform the following steps: 1. Tune to the desired radio station. 2. Press the FAV button to display the page where you want the station stored.
Page 200 To quickly adjust all tone and speaker controls to the middle position, press the tune knob for more than two seconds until a beep sounds. EQ (Equalization): Press this button to select preset equalization settings. To return to the manual mode, press the EQ button until Manual displays or start to manually adjust the bass, midrange, or treble by pressing the tune knob.
Page 201 Undesired XM™ categories can be removed through the setup menu. To remove an undesired category, perform the following: 1. Press the MENU button to display the radio setup menu. 2. Press the pushbutton located below the XM CAT label. 3. Turn the tune knob to display the category you want removed.
Page 202 Playing a CD(s) (Six-Disc CD Player) LOAD : Press this button to load CDs into the CD player. This CD player holds up to six CDs. To insert one CD, do the following: 1. Press and release the load button. 2.
Page 203 If there is no apparent damage, try a known good CD. Notice: If a label is added to a CD, or more than one CD is inserted into the slot at a time, or an attempt is made to play scratched or damaged CDs, the CD player could be damaged.
Page 204 RDM (Random): With the random setting, you can listen to the tracks in random, rather than sequential order, on one CD or all CDs in a six-disc CD player. To use random, do one of the following: • Press the CD/AUX button, or for a single CD player, insert a disc partway into the slot of the CD player.
Page 205 CD Messages CHECK DISC: If an error message displays and/or the CD comes out, it could be for one of the following reasons: • It is very hot. When the temperature returns to normal, the CD should play. • You are driving on a very rough road. When the road becomes smoother, the CD should play.
Page 206: Using An Mp3
BAND: Press this button to listen to the radio while a portable audio device is playing. The portable audio device continues to play, so you might want to stop it or turn it off. CD/AUX (CD/Auxiliary): Press this button to play a CD while a portable audio device is playing.
Page 207 • Avoid subfolders. The system can support up to 8 subfolders deep, however, keep the total number of folders to a minimum in order to reduce the complexity and confusion in trying to locate a particular folder during playback. • Make sure playlists have a .mp3 or .wpl extension (other ﬁle extensions may not work).
Page 208 No Folder When the CD-R contains only compressed ﬁles, the ﬁles are located under the root folder. The next and previous folder functions are not displayed on a CD-R that was recorded without folders or playlists. When displaying the name of the folder the radio displays ROOT.
Page 209 Playing an MP3 Insert a CD-R partway into the slot (Single CD Player), or press the load button and wait for the message to insert disc (Six-Disc CD Player), label side up. The player pulls it in, and the CD-R should begin playing.
Page 210 A beep will sound and Ejecting Disc displays. Once the disc is ejected, Remove Disc displays. The CD-R can be removed. If the CD-R is not removed, after several seconds, the CD-R automatically pulls back into the player and begins playing. For the Six-Disc CD player, press and hold the eject button for two seconds to eject all discs.
Page 211 (Music Navigator): Use the music navigator feature to play MP3 ﬁles on the CD-R in order by artist or album. Press the pushbutton located below the music navigator label. The player scans the disc to sort the ﬁles by artist and album ID3 tag information.
Page 212: Xm Radio Messages
XM Radio Messages Radio Display Message XL (Explicit Language XL on the radio display, Channels) after the channel name, indicates content with explicit language. XM Updating Updating encryption code The encryption code in the receiver is being updated, and No XM Signal Loss of signal Loading XM Acquiring channel audio...
Page 213 Radio Display Message No Information No Text/Informational message available CAT Not Found No channel available for the chosen category XM Theft Locked Theftlock XM Radio ID Radio ID label (channel 0) If tuned to channel 0, this message alternates with the Unknown Radio ID not known (should only be if...
Page 214: Theft-Deterrent Feature
Theft-Deterrent Feature ® THEFTLOCK is designed to discourage theft of your vehicle’s radio. The feature works automatically by learning a portion of the Vehicle Identiﬁcation Number (VIN). If the radio is moved to a different vehicle, it will not operate and LOCK or LOCKED will appear on the display.
Page 215: Radio Reception
+ − (Volume): Press the plus or minus button to increase or to decrease the volume. (Mute/Voice Activation): Press this button to silence the system. Press this button again to turn the sound on. If your vehicle is equipped with ®...
Page 216: Care Of Your Cds
Care of Your CDs Handle CDs carefully. Store them in their original cases or other protective cases and away from direct sunlight and dust. The CD player scans the bottom surface of the disc. If the surface of a CD is damaged, such as cracked, broken, or scratched, the CD does not play properly or not at all.
Page 217: Driving Your Vehicle
Section 4 Your Driving, the Road, and Your Vehicle ... 218 Defensive Driving ... 218 Drunken Driving ... 219 Control of a Vehicle ... 222 Braking ... 222 Anti-Lock Brake System (ABS) ... 223 Braking in Emergencies ... 225 Enhanced Traction System (ETS) ... 226 Steering ...
Page 218: Your Driving, The Road, And Your Vehicle
Your Driving, the Road, and Your Vehicle Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. See Safety Belts: They Are for Everyone on page 19. CAUTION: Defensive driving really means “Be ready for anything.”...
Page 219: Drunken Driving
Drunken Driving Death and injury associated with drinking and driving is a national tragedy. It is the number one contributor to the highway death toll, claiming thousands of victims every year. Alcohol affects four things that anyone needs to drive a vehicle: •...
Page 220 According to the American Medical Association, a 180 lb (82 kg) person who drinks three 12 ounce (355 ml) bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4 ounce (120 ml) glasses of wine or three mixed drinks if each had 1-1/2 ounces (45 ml) of liquors like whiskey, gin, or vodka.
Page 221 But the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night. All drivers are impaired at BAC levels above 0.05 percent.
Page 222: Control Of A Vehicle
Control of a Vehicle You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering, and the accelerator. All three systems have to do their work at the places where the tires meet the road.
Page 223: Anti-Lock Brake System (Abs)
Avoid needless heavy braking. Some people drive in spurts — heavy acceleration followed by heavy braking — rather than keeping pace with traffic. This is a mistake. The brakes may not have time to cool between hard stops. The brakes will wear out much faster if you do a lot of heavy braking.
Page 224 Let us say the road is wet and you are driving safely. Suddenly, an animal jumps out in front of you. You slam on the brakes and continue braking. Here is what happens with ABS: A computer senses that wheels are slowing down.
Page 225: Braking In Emergencies
Remember: ABS does not change the time you need to get your foot up to the brake pedal or always decrease stopping distance. If you get too close to the vehicle in front of you, you will not have time to apply your brakes if that vehicle suddenly slows or stops.
Page 226: Enhanced Traction System (Ets)
Enhanced Traction System (ETS) Your vehicle may have an Enhanced Traction System (ETS) that limits wheel spin. This is especially useful in slippery road conditions. The system operates only if it senses that one or both of the front wheels are spinning or beginning to lose traction.
Page 227: Steering
• The warning light will come on when you set your parking brake with the engine running, and it will stay on if your parking brake does not release fully. If the transaxle shift lever is in any position other than LOW (L) and the warning light stays on after your parking brake is fully released, it means there is a problem with the system.
Page 228 Steering Tips It is important to take curves at a reasonable speed. A lot of the “driver lost control” accidents mentioned on the news happen on curves. Here is why: Experienced driver or beginner, each of us is subject to the same laws of physics when driving on curves.
Page 229 Adding non-GM accessories can affect your vehicle’s performance. See Accessories and Modiﬁcations on page 268. Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and ﬁnd a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 230: Off-Road Recovery
Off-Road Recovery You may ﬁnd that your vehicle’s right wheels have dropped off the edge of a road onto the shoulder while you are driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that your vehicle straddles the edge of the pavement.
Page 231 the road ahead is clear. Never cross a solid line on your side of the lane or a double solid line, even if the road seems empty of approaching traffic. • Do not get too close to the vehicle you want to pass while you are awaiting an opportunity.
Page 232: Loss Of Control
Loss of Control Let us review what driving experts say about what happens when the three control systems — brakes, steering, and acceleration — do not have enough friction where the tires meet the road to do what the driver has asked. In any emergency, do not give up.
Page 233: Driving At Night
Learn to recognize warning clues — such as enough water, ice, or packed snow on the road to make a mirrored surface — and slow down when you have any doubt. If you have the Anti-Lock Brake System (ABS), remember: It helps avoid only the braking skid. If you do not have ABS, then in a braking skid, where the wheels are no longer rolling, release enough pressure on the brakes to get the wheels...
Page 234: Driving In Rain And On Wet Roads
You can be temporarily blinded by approaching headlamps. It can take a second or two, or even several seconds, for your eyes to re-adjust to the dark. When you are faced with severe glare, as from a driver who does not lower the high beams, or a vehicle with misaimed headlamps, slow down a little.
Page 235 The heavier the rain, the harder it is to see. Even if your windshield wiper blades are in good shape, a heavy rain can make it harder to see road signs and traffic signals, pavement markings, the edge of the road, and even people walking. It is wise to keep your windshield wiping equipment in good shape and keep your windshield washer ﬂuid reservoir ﬁlled with washer ﬂuid.
Page 236 Driving Through Deep Standing Water Notice: If you drive too quickly through deep puddles or standing water, water can come in through the engine’s air intake and badly damage the engine. Never drive through water that is slightly lower than the underbody of your vehicle.
Page 237: City Driving
City Driving One of the biggest problems with city streets is the amount of traffic on them. You will want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving: •...
Page 238: Freeway Driving
Freeway Driving Mile for mile, freeways — also called thruways, parkways, expressways, turnpikes, or superhighways — are the safest of all roads. But they have their own special rules. The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving.
Page 239: Before Leaving On A Long Trip
Once you are moving on the freeway, make certain you allow a reasonable following distance. Expect to move slightly slower at night. When you want to leave the freeway, move to the proper lane well in advance. If you miss your exit, do not, under any circumstances, stop and back up.
Page 240: Highway Hypnosis
Here are some things you can check before a trip: • Windshield Washer Fluid: Is the reservoir full? Are all windows clean inside and outside? • Wiper Blades: Are they in good shape? • Fuel, Engine Oil, Other Fluids: Have you checked all levels? •...
Page 241: Hill And Mountain Roads
Then here are some tips: • Make sure your vehicle is well ventilated, with a comfortably cool interior. • Keep your eyes moving. Scan the road ahead and to the sides. Check your rearview mirrors and your instruments frequently. • If you get sleepy, pull off the road into a rest, service, or parking area and take a nap, get some exercise, or both.
Page 242 If you drive regularly in steep country, or if you are planning to visit there, here are some tips that can make your trips safer and more enjoyable. • Keep your vehicle in good shape. Check all ﬂuid levels and also the brakes, tires, cooling system, and transaxle.
Page 243: Winter Driving
• Stay in your own lane when driving on two-lane roads in hills or mountains. Do not swing wide or cut across the center of the road. Drive at speeds that let you stay in your own lane. • As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident.
Page 244 Include an ice scraper, a small brush or broom, a supply of windshield washer ﬂuid, a rag, some winter outer clothing, a small shovel, a ﬂashlight, a red cloth, and a couple of reﬂective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet, or a couple of burlap bags to help provide traction.
Page 245 What is the worst time for this? Wet ice. Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get wet ice when it is about freezing, 32°F (0°C), and freezing rain begins to fall.
Page 246 If You Are Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow.
Page 247 CAUTION: Snow can trap exhaust gases under your vehicle. This can cause deadly CO (carbon monoxide) gas to get inside. CO could overcome you and kill you. You cannot see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that is blocking the exhaust pipe.
Page 248: If Your Vehicle Is Stuck In Sand, Mud, Ice, Or Snow
If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you do not want to spin your wheels too fast. The method known as rocking can help you get out when you are stuck, but you must use caution.
Page 249: Loading Your Vehicle
Loading Your Vehicle It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo and all nonfactory-installed options. Two labels on your vehicle show how much weight it may properly carry, the Tire and Loading Information label and the Certiﬁcation label.
Page 250 The Tire and Loading Information label also shows the tire size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D). For more information on tires and inﬂation see Tires on page 318 and Inﬂation - Tire Pressure on page 325.
Page 251 Example 1 Item Description Vehicle Capacity Weight for Example 1 = Subtract Occupant Weight 150 lbs (68 kg) × 2 = Available Occupant and Cargo Weight = Total Item 1,000 lbs (453 kg) 300 lbs (136 kg) 700 lbs (317 kg) Example 2 Description Vehicle Capacity Weight...
Page 252 Example 3 Item Description Vehicle Capacity Weight for Example 3 = Subtract Occupant Weight 200 lbs (91 kg) × 5 = Available Cargo Weight = Refer to your vehicle’s Tire and Loading Information label for speciﬁc information about your vehicle’s capacity weight and seating positions.
Page 253 CAUTION: Do not load your vehicle any heavier than the Gross Vehicle Weight Rating (GVWR), or either the maximum front or rear Gross Axle Weight Rating (GAWR). If you do, parts on your vehicle can break, and it can change the way your vehicle handles. These could cause you to lose control and crash.
Page 254: Towing
Towing Towing Your Vehicle Consult your dealer or a professional towing service if you need to have your disabled vehicle towed. See Roadside Assistance Program on page 400. If you want to tow your vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see “Recreational Vehicle Towing”...
Page 255 Dinghy Towing You may dinghy tow your vehicle from the front following these steps: 1. Set the parking brake. 2. Turn the ignition key to ACC to unlock the steering wheel. 3. Shift an automatic transaxle to NEUTRAL (N) or a manual transaxle to NEUTRAL. 4.
Page 256: Towing A Trailer (Manual Transaxle)
Notice: Towing your vehicle from the rear could damage it. Also, repairs would not be covered by the warranty. Never have your vehicle towed from the rear. Dolly Towing Your vehicle cannot be dolly towed, but can be dinghy towed. See “Dinghy Towing” earlier in this section.
Page 257: Towing A Trailer (Automatic Transaxle)
Towing a Trailer (Automatic Transaxle) CAUTION: If you do not use the correct equipment and drive properly, you can lose control when you pull a trailer. For example, if the trailer is too heavy, the brakes may not work well — or even at all. You and your passengers could be seriously injured.
Page 258 If You Do Decide To Pull A Trailer If you do, here are some important points: • There are many different laws, including speed limit restrictions, having to do with trailering. Make sure your rig will be legal, not only where you live but also where you will be driving.
Page 259 Maximum trailer weight is calculated assuming only the driver is in the tow vehicle and it has all the required trailering equipment. The weight of additional optional equipment, passengers and cargo in the tow vehicle must be subtracted from the maximum trailer weight. You can ask your dealer for our trailering information or advice.
Page 260 Hitches It is important to have the correct hitch equipment. Crosswinds, large trucks going by and rough roads are a few reasons why you will need the right hitch. Here are some rules to follow: • The rear bumper on your vehicle is not intended for hitches.
Page 261 Before you start, check all trailer hitch parts and attachments, safety chains, electrical connector, lamps, tires and mirror adjustment. If the trailer has electric brakes, start your vehicle and trailer moving and then apply the trailer brake controller by hand to be sure the brakes are working. This lets you check your electrical connection at the same time.
Page 262 Turn Signals When Towing a Trailer When you tow a trailer, your vehicle may need a different turn signal ﬂasher and/or extra wiring. Check with your dealer. The arrows on your instrument panel will ﬂash whenever you signal a turn or lane change. Properly hooked up, the trailer lamps will also ﬂash, telling other drivers you are about to turn, change lanes or stop.
Page 263 Parking on Hills CAUTION: You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged.
Page 264 Maintenance When Trailer Towing Your vehicle will need service more often when you are pulling a trailer. See Scheduled Maintenance on page 375 for more on this. Things that are especially important in trailer operation are automatic transaxle ﬂuid (do not overﬁll), engine oil, drive belt, cooling system and brake system.
Page 265: Service And Appearance Care
Section 5 Service ... 268 Accessories and Modiﬁcations ... 268 California Proposition 65 Warning ... 269 Doing Your Own Service Work ... 269 Adding Equipment to the Outside of Your Vehicle ... 270 Fuel ... 270 Gasoline Octane ... 270 Gasoline Speciﬁcations ...
Page 266 Section 5 Windshield Wiper Blade Replacement ... 317 Tires ... 318 Tire Sidewall Labeling ... 319 Tire Terminology and Deﬁnitions ... 322 Inﬂation - Tire Pressure ... 325 Tire Inspection and Rotation ... 326 When It Is Time for New Tires ... 328 Buying New Tires ...
Page 267 Section 5 Vehicle Identiﬁcation ... 360 Vehicle Identiﬁcation Number (VIN) ... 360 Service Parts Identiﬁcation Label ... 360 Electrical System ... 361 Add-On Electrical Equipment ... 361 Headlamp Wiring ... 361 Windshield Wiper Fuses ... 361 Service and Appearance Care Power Windows and Other Power Options ...
Page 268: Service
Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you will go to your dealer for all your service needs. You will get genuine GM parts and GM-trained and supported service people. We hope you will want to keep your GM vehicle all GM.
Page 269: California Proposition 65 Warning
California Proposition 65 Warning Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems (including some inside the vehicle), many ﬂuids, and some component wear by-products contain and/or emit these chemicals.
Page 270: Fuel
Adding Equipment to the Outside of Your Vehicle Things you might add to the outside of your vehicle can affect the airﬂow around it. This may cause wind noise and affect windshield washer performance. Check with your dealer before adding equipment to the outside of your vehicle. Fuel Use of the recommended fuel is an important part of the proper maintenance of your vehicle.
Page 271: Gasoline Speciﬁcations
Gasoline Speciﬁcations At a minimum, gasoline should meet ASTM speciﬁcation D 4814 in the United States or CAN/CGSB-3.5 in Canada. Some gasolines may contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT). General Motors recommends against the use of gasolines containing MMT. See Additives on page 272 for additional information.
Page 272: Additives
Additives To provide cleaner air, all gasolines in the United States are now required to contain additives that will help prevent engine and fuel system deposits from forming, allowing your emission control system to work properly. In most cases, you should not have to add anything to your fuel. However, some gasolines contain only the minimum amount of additive required to meet U.S.
Page 273: Fuels In Foreign Countries
Some gasolines that are not reformulated for low emissions may contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT); ask the attendant where you buy gasoline whether the fuel contains MMT. General Motors recommends against the use of such gasolines. Fuels containing MMT can reduce the life of spark plugs and the performance of the emission control system may be affected.
Page 274: Filling The Tank
Filling the Tank CAUTION: Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the pump island. Turn off your engine when you are refueling.
Page 275 While refueling, hang the tethered fuel cap from the hook on the fuel door. CAUTION: Fuel can spray out on you if you open the fuel cap too quickly. If you spill fuel and then something ignites it, you could be badly burned.
Page 276: Checking Things Under The Hood
Filling a Portable Fuel Container CAUTION: Never ﬁll a portable fuel container while it is in your vehicle. Static electricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle damaged if this occurs. To help avoid injury to you and others: •...
Page 277: Hood Release
Hood Release To open the hood, do the following. 1. Pull the interior hood release lever with this symbol on it. It is located under the instrument panel on the driver’s side of the vehicle. 2. Then go to the front of the vehicle and push the secondary hood release lever to the left.
Page 278: Engine Compartment Overview
Engine Compartment Overview When you open the hood on the 2.2L L4 engine (2.4L L4 engine similar), here is what you will see:...
Page 279: Engine Oil
A. Engine Air Cleaner/Filter. See Engine Air Cleaner/Filter on page 284. B. Engine Oil Fill Cap. See “When to Add Engine Oil” under Engine Oil on page 279. C. Engine Oil Dipstick (Out of View). See “Checking Engine Oil” under Engine Oil on page 279.
Page 280 When to Add Engine Oil If the oil is below the MIN (minimum) mark, you need to add at least one quart/liter of oil. But you must use the right kind. This section explains what kind of oil to use. For engine oil crankcase capacity, see Capacities and Speciﬁcations on page 368.
Page 281 What Kind of Engine Oil to Use Look for three things: • GM6094M Your vehicle’s engine requires oil meeting GM Standard GM6094M. Look for and use only an oil that meets GM Standard GM6094M. • SAE 5W-30 As shown in the viscosity chart, SAE 5W-30 is best for your vehicle.
Page 282: Engine Oil Life System
® GM Goodwrench oil meets all the requirements for your vehicle. If you are in an area of extreme cold, where the temperature falls below −20°F (−29°C), it is recommended that you use either an SAE 5W-30 synthetic oil or an SAE 0W-30 oil. Both provide easier cold starting and better protection for the engine at extremely low temperatures.
Page 283 How to Reset the Engine Oil Life System The Engine Oil Life System calculates when to change your engine oil and ﬁlter based on vehicle use. Anytime your oil is changed, reset the system so it can calculate when the next oil change is required.
Page 284: Engine Air Cleaner/Filter
Engine Air Cleaner/Filter See Engine Compartment Overview on page 278 for the location of the engine air cleaner/ﬁlter. When to Inspect the Engine Air Cleaner/Filter Inspect the air cleaner/ﬁlter at the Maintenance II intervals and replace it at the ﬁrst oil change after each 50,000 mile (85 000 km) interval.
Page 285: Automatic Transaxle Fluid
To inspect or replace the ﬁlter, remove the screws that hold the cover on and lift off the cover. Be sure to reinstall the cover tightly. CAUTION: Operating the engine with the air cleaner/ ﬁlter off can cause you or others to be burned.
Page 286: Hydraulic Clutch
Hydraulic Clutch The hydraulic clutch linkage in your vehicle is self-adjusting. This system does not have its own reservoir. It receives ﬂuid from the brake master cylinder reservoir. See Brakes on page 298 for more information. Engine Coolant The cooling system in your vehicle is ﬁlled with ®...
Page 287 What to Use Use a mixture of one-half clean, drinkable water ® and one-half DEX-COOL coolant which will not damage aluminum parts. If you use this coolant mixture, you do not need to add anything else. CAUTION: Adding only plain water to your cooling system can be dangerous.
Page 288 Checking Coolant The coolant surge tank is located in the engine compartment on the driver’s side of the vehicle. See Engine Compartment Overview on page 278 for more information on location. CAUTION: Turning the surge tank pressure cap when the engine and radiator are hot can allow steam and scalding liquids to blow out and burn you badly.
Page 289: Coolant Surge Tank Pressure Cap
Adding Coolant If you need more coolant, add the proper ® DEX-COOL coolant mixture at the coolant surge tank, but only when the engine is cool. If the coolant surge tank is empty, a special ﬁll procedure is necessary. See Engine Overheating on page 289 for instructions on “How to Add Coolant to the Coolant Surge Tank.”...
Page 290 If Steam Is Coming From Your Engine CAUTION: Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Just turn it off and get everyone away from the vehicle until it cools down.
Page 291 If you get the engine coolant temperature warning with no sign of steam, try this for a minute or so: 1. If you have an air conditioner and it is on, turn it off. 2. In heavy traffic, let the engine idle in NEUTRAL (N) for automatic transaxle or NEUTRAL for manual transaxle, while stopped.
Page 292: Cooling System
Cooling System When you decide it is safe to lift the hood, here is what you will see: 2.2L L4 Engine shown, 2.4L L4 Engine similar A. Electric Engine Cooling Fan B. Coolant Surge Tank and Pressure Cap CAUTION: An electric engine cooling fan under the hood can start up even when the engine is not running and can injure you.
Page 293 CAUTION: Heater and radiator hoses, and other engine parts, can be very hot. Do not touch them. If you do, you can be burned. Do not run the engine if there is a leak. If you run the engine, it could lose all coolant.
Page 294 If no coolant is visible in the coolant surge tank, add coolant as follows: CAUTION: Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They are under pressure, and if you turn the coolant surge tank pressure cap —...
Page 295 CAUTION: You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Do not spill coolant on a hot engine. 1. You can remove the coolant surge tank pressure cap when the cooling system, including the coolant surge tank pressure cap and upper radiator hose, is no longer hot.
Page 296 3. Fill the coolant surge tank with the proper mixture, to the COLD FILL line. Wait about ﬁve minutes, then check to see if the level is below the COLD FILL line. If the level is below the line, add additional coolant to bring the level up to the line.
Page 297: Windshield Washer Fluid
Windshield Washer Fluid What to Use When you need windshield washer ﬂuid, be sure to read the manufacturer’s instructions before use. If you will be operating your vehicle in an area where the temperature may fall below freezing, use a ﬂuid that has sufficient protection against freezing.
Page 298: Brakes
Brakes Brake Fluid The brake master cylinder and, on manual transmission vehicles, the clutch hydraulic system use the same reservoir. The reservoir is ﬁlled with DOT-3 brake ﬂuid. See Engine Compartment Overview on page 278 for the location of the reservoir. There are only two reasons why the brake ﬂuid level in the reservoir might go down.
Page 299 What to Add When you do need brake ﬂuid, use only DOT-3 brake ﬂuid. Use new brake ﬂuid from a sealed container only. See Recommended Fluids and Lubricants on page 385. Always clean the brake ﬂuid reservoir cap and the area around the cap before removing it.
Page 300 Brake Wear Your vehicle has front disc brakes and could have rear drum brakes or rear disc brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed. The sound can come and go or be heard all the time your vehicle is moving, except when you are pushing on the brake pedal ﬁrmly.
Page 301: Battery
Brake Adjustment Every time you make a moderate brake stop, the disc brakes adjust for wear. If you rarely make a moderate or heavier stop, then the brakes might not adjust correctly. If you drive in that way, then — very carefully — make a few moderate brake stops about every 1,000 miles (1 600 km), so the brakes will adjust properly.
Page 302: Jump Starting
Vehicle Storage If you are not going to drive your vehicle for 25 days or more, remove the black, negative (−) cable from the battery. This will help keep your battery from running down. CAUTION: Batteries have acid that can burn you and gas that can explode.
Page 303 Notice: Ignoring these steps could result in costly damage to your vehicle that would not be covered by your warranty. Trying to start your vehicle by pushing or pulling it will not work, and it could damage your vehicle. 1. Check the other vehicle. It must have a 12-volt battery with a negative ground system.
Page 304 4. Open the hood on the other vehicle and locate the positive (+) and negative (−) terminal locations on that vehicle. You will not see the battery of your vehicle under the hood. It is located in the trunk. You will not need to access your battery for jump starting.
Page 305 CAUTION: Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a ﬂashlight if you need more light. Be sure the battery has enough water. You do not need to add water to the battery installed in your new vehicle.
Page 306 6. Connect the red positive (+) cable to the positive (+) terminal location on the vehicle with the dead battery. Use a remote positive (+) terminal if the vehicle has one. 7. Do not let the other end touch metal. Connect it to the positive (+) terminal of the good battery.
Page 307 Jumper Cable Removal A. Heavy, Unpainted Metal Engine Part or Remote Negative (−) Terminal (GND) B. Good Battery or Remote Positive (+) and Remote Negative (−) Terminals C. Dead Battery or Remote Positive (+) Terminal To disconnect the jumper cables from both vehicles, do the following: 1.
Page 308: Headlamp Aiming
Headlamp Aiming The optical headlamp aiming system has been preset at the factory and should need no further adjustment However, If the vehicle is damaged in an accident, the headlamp aim may be affected and adjustment may be necessary. If oncoming vehicles ﬂash their high beams at you, this may also mean the vertical aim needs to be adjusted.
Page 309 Headlamp aiming is done with the vehicle’s low-beam headlamps. The high-beam headlamps will be correctly aimed if the low-beam headlamps are aimed properly. The vertical headlamp aiming screws are located under the hood near the headlamps. The adjustment screw can be turned with a 6 mm socket wrench.
Page 310 4. At the wall measure from the ground upward (A) to the recorded distance from Step 3 and mark it. 5. Draw or tape a horizontal line (B) on the wall the width of the vehicle at the height of the mark in Step 4.
Page 311: Bulb Replacement
9. Make sure that the light from the headlamp is positioned at the bottom edge of the horizontal tape line. The lamp on the left (A) shows the correct headlamp aim. The lamp on the right (B) shows the incorrect headlamp aim. 10.
Page 312: Headlamps, Front Turn Signal, Sidemarker, And Parking Lamps
Headlamps, Front Turn Signal, Sidemarker, and Parking Lamps A. Front Turn Signal/Parking Lamp B. Sidemarker C. Headlamp To replace one of these bulbs, do the following: 1. Open the hood. See Hood Release on page 277 for more information. 2. Remove the two hex bolts from the headlamp assembly.
Page 313: Center High-Mounted Stoplamp (Chmsl)
4. Pull the front fascia back. You may need someone else to assist you with Steps 3 and 4. 5. Pull the headlamp assembly up on an angle and towards the radiator to remove it. 6. Disconnect the bulb base from the wiring harness by lifting the plastic locking tab.
Page 314: Taillamps And Turn Signal Lamps (Coupe)
4. Pull the bulb assembly down to access the bulbs. 5. Remove the bulb by pulling it straight out. 6. Install a new bulb. 7. Align the tabs in the bulb assembly with the assembly in the trunk lid. Push the bulb assembly back into place until it snaps in.
Page 315: Taillamps, Turn Signal, Stoplamps And Back-Up Lamps (Sedan)
Taillamps, Turn Signal, Stoplamps and Back-up Lamps (Sedan) To replace one of these bulbs, do the following: 1. Open the trunk. See Trunk on page 99 for more information. 2. Remove the fastener which holds down the trunk trim. Once you have removed the trim, there will be one more fastener to remove.
Page 316: Back-Up Lamps (Coupe)
Back-Up Lamps (Coupe) To replace a back-up lamp bulb, do the following: 1. Remove the two screws from the face of the back-up lamp. 2. Pull the lamp straight out from the fascia pocket. 3. Hold and turn the bulb socket clockwise and then release it from the lamp housing.
Page 317: Replacement Bulbs
Replacement Bulbs Exterior Lamps Back-Up Lamps Center High-Mounted Stoplamp (CHMSL) Front Parking/Turn Signal Lamps Halogen Headlamps, High/Low-Beam License Plate Lamp and Sidemarker Stoplamp, Taillamp and Turn Signal Lamps For replacement bulbs not listed here, contact your dealer/retailer. Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear or cracking.
Page 318: Tires
Tires Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your GM Warranty booklet for details. For additional information refer to the tire manufacturer’s booklet included with your vehicle.
Page 319: Tire Sidewall Labeling
Tire Sidewall Labeling Useful information about a tire is molded into its sidewall. The examples below show a typical passenger vehicle tire and a compact spare tire sidewall. Passenger (P-Metric) Tire Example (A) Tire Size: The tire size is a combination of letters and numbers used to deﬁne a particular tire’s width, height, aspect ratio, construction type and service description.
Page 320 (D) Tire Identiﬁcation Number (TIN): The letters and numbers following DOT (Department of Transportation) code is the Tire Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured. The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture.
Page 321 (B) Tire Ply Material: The type of cord and number of plies in the sidewall and under the tread. (C) Tire Identiﬁcation Number (TIN): The letters and numbers following the DOT (Department of Transportation) code is the Tire Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured.
Page 322: Tire Terminology And Deﬁnitions
(B) Tire Width: The three-digit number indicates the tire section width in millimeters from sidewall to sidewall. (C) Aspect Ratio: A two-digit number that indicates the tire height-to-width measurements. For example, if the tire size aspect ratio is 60, as shown in item C of the illustration, it would mean that the tire’s sidewall is 60 percent as high as it is wide.
Page 323 Cold Tire Pressure: The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has built up heat from driving. See Inﬂation - Tire Pressure on page 325. Curb Weight: This means the weight of a motor vehicle with standard and optional equipment including the maximum capacity of fuel, oil, and coolant, but without passengers and cargo.
Page 324 Occupant Distribution: Designated seating positions. Outward Facing Sidewall: The side of an asymmetrical tire that has a particular side that faces outward when mounted on a vehicle. The side of the tire that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same moldings on the other sidewall of the tire.
Page 325: Inﬂation - Tire Pressure
Vehicle Maximum Load on the Tire: Load on an individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. Vehicle Placard: A label permanently attached to a vehicle showing the vehicle’s capacity weight and the original equipment tire size and recommended inﬂation pressure.
Page 326: Tire Inspection And Rotation
When to Check Check your tires once a month or more. Do not forget to check the compact spare tire, it should be at 60 psi (420 kPa). For additional information regarding the compact spare tire, see Compact Spare Tire on page 350. How to Check Use a good quality pocket-type gage to check tire pressure.
Page 327 When rotating your tires, always use the correct rotation pattern shown here. Do not include the compact spare tire in your tire rotation. After the tires have been rotated, adjust the front and rear inﬂation pressures as shown on the Tire and Loading Information label.
Page 328: When It Is Time For New Tires
When It Is Time for New Tires One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining.
Page 329 If the tires have an all-season tread design, the TPC spec number is followed by an MS for mud and snow. See Tire Sidewall Labeling on page 319 for additional information. CAUTION: Mixing tires could cause you to lose control while driving. If you mix tires of different sizes, brands, or types (radial and bias-belted tires), the vehicle may not handle properly, and you could have a...
Page 330: Different Size Tires And Wheels
Different Size Tires and Wheels If you add wheels or tires that are a different size than your original equipment wheels and tires, this may affect the way your vehicle performs, including its braking, ride and handling characteristics, stability, and resistance to rollover. Additionally, if your vehicle has electronic systems such as, anti-lock brakes, traction control, and electronic stability control, the performance...
Page 331 While the tires available on General Motors passenger cars and light trucks may vary with respect to these grades, they must also conform to federal safety requirements and additional General Motors Tire Performance Criteria (TPC) standards. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speciﬁed government test course.
Page 332: Wheel Alignment And Tire Balance
Wheel Alignment and Tire Balance The tires and wheels on your vehicle were aligned and balanced carefully at the factory to give you the longest tire life and best overall performance. Adjustments to wheel alignment and tire balancing will not be necessary on a regular basis. However, if you notice unusual tire wear or your vehicle pulling to one side or the other, the alignment may need to be checked.
Page 333 CAUTION: Using the wrong replacement wheels, wheel bolts, or wheel nuts on your vehicle can be dangerous. It could affect the braking and handling of your vehicle, make your tires lose air and make you lose control. You could have a collision in which you or others could be injured.
Page 334: Tire Chains
Tire Chains CAUTION: If your vehicle has P205/55R16 or P205/50R17 size tires, do not use tire chains. They can damage your vehicle because there is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension, or other vehicle parts.
Page 335: If A Tire Goes Flat
If a Tire Goes Flat It is unusual for a tire to blowout while you are driving, especially if you maintain your vehicle’s tires properly. If air goes out of a tire, it is much more likely to leak out slowly. But if you should ever have a blowout, here are a few tips about what to expect and what to do: If a front tire fails, the ﬂat tire will create a drag...
Page 336: Changing A Flat Tire
Changing a Flat Tire If a tire goes ﬂat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning ﬂashers. CAUTION: Changing a tire can be dangerous. The vehicle can slip off the jack and roll over or fall on you or other people.
Page 337: Removing The Spare Tire And Tools
The following information will tell you how to use the jack and change a tire. Removing the Spare Tire and Tools The equipment you will need is located in the trunk. Base Models 1. Open the trunk. See Trunk on page 99 for more information.
Page 338 A. Cover B. Retainer C. Spare Tire D. Wing Nut E. Jack and Wheel Wrench F. Bolt...
Page 339 3. Remove the retainer (B) that holds down the spare tire. See Compact Spare Tire on page 350 for more information. 4. Remove the spare tire (C) by gently pulling it up and out of the trunk. 5. Remove the wing nut (D) that holds the jack and remove the jack and wheel wrench (E).
Page 340 A. Retainer C. Spare Tire B. Jack and Wheel D. Foam Support Wrench E. Bolt 3. Remove the retainer (A) that holds down the jack, wheel wrench (B) and spare tire (C). 4. Remove the spare tire by gently pulling it up and out of the trunk.
Page 341 You will need to turn the plastic wheel nut counterclockwise to loosen the wheel wrench from the jack. Press the button and then pull on the end of the wheel wrench to extend the handle.
Page 342: Removing The Flat Tire And Installing The Spare Tire
Removing the Flat Tire and Installing the Spare Tire 1. If your vehicle has plastic wheel covers, use the wheel wrench to loosen the plastic wheel nut caps. Once you have loosened the plastic wheel nut caps with the wheel wrench, you can ﬁnish loosening them with your ﬁngers.
Page 343 Notice: Make sure that the jack lift head is in the correct position or you may damage your vehicle. The repairs would not be covered by your warranty. 5. Position the jack lift head at the jack location nearest the ﬂat tire. The front location is about 8 inches (20 cm) behind the front wheel opening.
Page 344 8. Raise the vehicle by turning the jack handle clockwise. Raise the vehicle far enough off the ground so there is enough room for the compact spare tire to ﬁt under the vehicle. 9. Remove all of the Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts.
Page 345 10. Remove any rust or 11. Place the compact spare tire on the wheel-mounting surface. dirt from the wheel bolts, mounting surfaces, and spare Never use oil or grease on studs or nuts. wheel. If you do, the nuts might come loose. Your wheel could fall off, causing a serious accident.
Page 346 CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to come loose and even come off. This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts.
Page 347: Storing A Flat Or Spare Tire And Tools
Notice: Wheel covers will not ﬁt on your compact spare. If you try to put a wheel cover on the compact spare, you could damage the cover or the spare. Do not try to put a wheel cover on your compact spare tire.
Page 348 Base Model A. Cover B. Retainer C. Jack and Wheel Wrench D. Stow Bolt Extension Rod E. Spare Tire F. Bolt...
Page 349 Uplevel Model A. Cover E. Spare Tire B. Retainer F. Foam Support C. Jack and Wheel G. Bolt Wrench D. Stow Bolt Extension Rod To store a ﬂat or spare tire and tools, do the following: 1. Remove the stow bolt extension rod and sleeve from the jack.
Page 350: Compact Spare Tire
7. Place the smaller jack hold-down nut (base models only) in a safe place for use when you put the compact spare tire back into the trunk. 8. Remove the plastic sleeve from the stow bolt extension rod. Secure the jack and road wheel using the larger plastic retainer.
Page 351: Appearance Care
Appearance Care Cleaning the Inside of Your Vehicle Your vehicle’s interior will continue to look its best if it is cleaned often. Although not always visible, dust and dirt can accumulate on your upholstery. Dirt can damage carpet, fabric, leather, and plastic surfaces.
Page 352: Fabric/Carpet
Do not clean your vehicle using the following cleaners or techniques: • Never use a knife or any other sharp object to remove a soil from any interior surface. • Never use a stiff brush. It can cause damage to your vehicle’s interior surfaces. •...
Page 353: Instrument Panel, Vinyl, And Other Plastic Surfaces
4. Continue to gently rub the soiled area until the cleaning cloth remains clean. 5. If the soil is not completely removed, use a mild soap solution and repeat the cleaning process that was used with plain water. If any of the soil remains, a commercial fabric cleaner or spot lifter may be necessary.
Page 354: Weatherstrips
Weatherstrips Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth. During very cold, damp weather frequent application may be required. See Recommended Fluids and Lubricants on page 385. Washing Your Vehicle The paint ﬁnish on the vehicle provides beauty, depth of color, gloss retention, and durability.
Page 355: Windshield And Wiper Blades
The vehicle has a basecoat/clearcoat paint ﬁnish. The clearcoat gives more depth and gloss to the colored basecoat. Always use waxes and polishes that are non-abrasive and made for a basecoat/clearcoat paint ﬁnish. Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from industrial chimneys, etc., can damage the vehicle’s...
Page 356: Aluminum Or Chrome-Plated Wheels And Trim
Aluminum or Chrome-Plated Wheels and Trim Your vehicle may have either aluminum or chrome-plated wheels. Keep the wheels clean using a soft clean cloth with mild soap and water. Rinse with clean water. After rinsing thoroughly, dry with a soft clean towel.
Page 357: Tires
Tires To clean the tires, use a stiff brush with tire cleaner. Notice: Using petroleum-based tire dressing products on your vehicle may damage the paint ﬁnish and/or tires. When applying a tire dressing, always wipe off any overspray from all painted surfaces on your vehicle. Sheet Metal Damage If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair...
Page 358: Underbody Maintenance
Underbody Maintenance Chemicals used for ice and snow removal and dust control can collect on the underbody. If these are not removed, corrosion and rust can develop on the underbody parts such as fuel lines, frame, ﬂoor pan, and exhaust system even though they have corrosion protection.
Page 359: Vehicle Care/Appearance Materials
Vehicle Care/Appearance Materials Description Polishing Cloth Interior and exterior Wax-Treated polishing cloth. Tar and Road Oil Removes tar, road oil and Remover asphalt. Chrome Cleaner and Use on chrome or Polish stainless steel. White Sidewall Tire Removes soil and black Cleaner marks from whitewalls.
Page 360: Vehicle Identiﬁcation
Vehicle Identiﬁcation Vehicle Identiﬁcation Number (VIN) This is the legal identiﬁer for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver side. You can see it if you look through the windshield from outside your vehicle.
Page 361: Electrical System
Electrical System Add-On Electrical Equipment Notice: Do not add anything electrical to your vehicle unless you check with your dealer ﬁrst. Some electrical equipment can damage your vehicle and the damage would not be covered by your warranty. Some add-on electrical equipment can keep other components from working as they should.
Page 362: Fuses And Circuit Breakers
Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses, circuit breakers and fusible thermal links. This greatly reduces the chance of damage caused by electrical problems. Look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse.
Page 363 Fuses Usage Fuse Puller Empty Empty Empty Empty Ampliﬁer Cluster Ignition Switch, PASS-Key Fuses ® III+ Usage Stoplamp Heating, Ventilation, Air ® Conditioning, PASS-Key III+ Empty Spare Airbag Spare Windshield Wiper Climate Control System, Ignition Empty Empty Electric Power Steering, Steering Wheel Control Sunroof Spare...
Page 364: Engine Compartment Fuse Block
Fuses Power Windows Relays Climate Control System Empty Retained Accessory Power (RAP) Engine Compartment Fuse Block Usage The engine compartment fuse block is located on the driver’s side of the vehicle. Lift off the cover Usage to check the fuses. See Engine Compartment Overview on page 278 for more information on location.
Page 365 Fuses SPARES Spares Blank Not Used Blank Not Used Usage Fuses REAR DEFOG COOL FAN2 CRNK Usage Rear Defogger Engine Cooling Fan High Speed Starter...
Page 366 Fuses COOL FAN 1 Engine Cooling Fan Low Speed BCM3 Body Control Module 3 BCM2 Body Control Module 2 FOG LAMP Fog Lamps HORN Horn RT HI BEAM Passenger’s Side High Beam LT HI BEAM Driver’s Side High Beam RT LO BEAM Passenger’s Side Low Beam LT LO BEAM Driver’s Side Low Beam...
Page 367 Relays Usage REAR DEFOG Rear Defogger COOL FAN2 Engine Cooling Fan 2 WPR HI/LO Windshield Wiper High/Low Speed CRNK Starter COOL FAN1 Engine Cooling Fan 1 FUEL PUMP Fuel Pump WPR ON/OFF Windshield Wiper On/Off COOL FANS Engine Cooling Fans PWR/TRN Powertrain Relays...
Page 368: Capacities And Speciﬁcations
Capacities and Speciﬁcations The following approximate capacities are given in English and metric conversions. Please refer to Recommended Fluids and Lubricants on page 385 for more information. Application Air Conditioning Refrigerant Cooling System 2.2L and 2.4L Engines Engine Oil with Filter 2.2L L4 and 2.4L L4 Engines Fuel Tank 2.2L L4 Engine (with NU6 emissions) sold new in CA, ME,...
Page 369 Engine Speciﬁcations Engine VIN Code 2.2L L4 2.4L L4 Transaxle Spark Plug Gap Automatic 0.040 inch (1.01 mm) Manual Automatic 0.040 inch (1.01 mm) Manual...
Page 370 ✍ NOTES...
Page 371: Maintenance Schedule
Section 6 Maintenance Schedule ... 372 Introduction ... 372 Maintenance Requirements ... 372 Your Vehicle and the Environment ... 373 Using the Maintenance Schedule ... 373 Scheduled Maintenance ... 375 Additional Required Services ... 378 Maintenance Footnotes ... 379 Maintenance Schedule Owner Checks and Services ...
Page 372: Maintenance Schedule
Maintenance Schedule Introduction Important: Keep engine oil at the proper level and change as recommended. Have you purchased the GM Protection Plan? The Plan supplements your new vehicle warranties. See your Warranty and Owner Assistance booklet or your dealer for details. Maintenance Requirements Notice: Maintenance intervals, checks, inspections, replacement parts, and...
Page 373: Your Vehicle And The Environment
Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also helps the environment. All recommended maintenance is important. Improper vehicle maintenance can even affect the quality of the air we breathe.
Page 374 This schedule is for vehicles that: • carry passengers and cargo within recommended limits. You will ﬁnd these limits on the Tire and Loading Information label. See Loading Your Vehicle on page 249. • are driven on reasonable road surfaces within legal driving limits.
Page 375: Scheduled Maintenance
When you go to your GM Goodwrench your service needs, you will know that GM-trained and supported service technicians will perform the work using genuine GM parts. If you want to purchase service information, see Service Publications Ordering Information on page 411.
Page 376 When the CHANGE OIL SOON message appears, certain services, checks, and inspections are required. Required services are described in the following for “Maintenance I” and “Maintenance II.” Generally, it is recommended that your ﬁrst service be Maintenance I, your second service be Maintenance II, and that you alternate Maintenance I and Maintenance II thereafter.
Page 377 Change engine oil and ﬁlter. See Engine Oil on page 279. Reset oil life system. See Engine Oil Life System on page 282. An Emission Control Service. Visually check for any leaks or damage. See footnote (j). Inspect engine air cleaner ﬁlter. If necessary, replace ﬁlter. See Engine Air Cleaner/Filter on page 284.
Page 378: Additional Required Services
Additional Required Services The following services should be performed at the ﬁrst maintenance service (I or II) after the indicated miles (kilometers) shown for each item. Service and Miles (Kilometers) Inspect fuel system for damage or leaks. Inspect exhaust system for loose or damaged components.
Page 379: Maintenance Footnotes
Maintenance Footnotes (a) Visually inspect brake lines and hoses for proper hook-up, binding, leaks, cracks, chaﬁng, etc. Inspect disc brake pads for wear and rotors for surface condition. Inspect drum brake linings/shoes for wear or cracks. Inspect other brake parts, including drums, wheel cylinders, calipers, parking brake, etc.
Page 380: Owner Checks And Services
(h) Change automatic transaxle ﬂuid and ﬁlter if the vehicle is mainly driven under one or more of these conditions: − In heavy city traffic where the outside temperature regularly reaches 90°F (32°C) or higher. − In hilly or mountainous terrain. −...
Page 381: At Each Fuel Fill
At Each Fuel Fill It is important to perform these underhood checks at each fuel ﬁll. Engine Oil Level Check Check the engine oil level and add the proper oil if necessary. See Engine Oil on page 279 for further details. Notice: It is important to check the engine oil regularly and keep it at the proper level.
Page 382: At Least Once A Year
At Least Once a Year Starter Switch Check CAUTION: When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before you start, be sure you have enough room around the vehicle. 2.
Page 383 Automatic Transaxle Shift Lock Control System Check CAUTION: When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before you start, be sure you have enough room around the vehicle. It should be parked on a level surface.
Page 384 Parking Brake and Automatic Transaxle Park (P) Mechanism Check CAUTION: When you are doing this check, your vehicle could begin to move. You or others could be injured and property could be damaged. Make sure there is room in front of your vehicle in case it begins to roll.
Page 385: Recommended Fluids And Lubricants
Recommended Fluids and Lubricants Fluids and lubricants identiﬁed below by name, part number, or speciﬁcation can be obtained from your dealer. Usage Fluid/Lubricant Engine oil which meets GM Standard GM6094M and displays the American Petroleum Institute Certiﬁed for Gasoline Engines Engine Oil starburst symbol.
Page 386 Usage Fluid/Lubricant Chassis Lubricant (GM Part No. U.S. 12377985, in Chassis Canada 88901242) or lubricant Lubrication meeting requirements of NLGI #2, Category LB or GC-LB. Hood Latch Assembly, Lubriplate Lubricant Aerosol Secondary (GM Part No. U.S. 12346293, in Latch, Canada 992723) or lubricant Pivots, Spring meeting requirements of NLGI #2, Anchor, and...
Page 387: Normal Maintenance Replacement Parts
Normal Maintenance Replacement Parts Replacement parts identiﬁed below by name, part number, or speciﬁcation can be obtained from your GM dealer. Normal Maintenance Replacement Parts Part Engine Air Cleaner/Filter Engine Oil Filter Spark Plugs Passenger’s Compartment Air Filter Windshield Wiper Blade (Hook Type) Driver’s Side —...
Page 388: Engine Drive Belt Routing
Engine Drive Belt Routing 2.2L L4 and 2.4L L4 Engines...
Page 389: Maintenance Record
Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. See Maintenance Requirements on page 372. Any additional information from Owner Checks and Services on page 380 can be added on the following record pages.
Page 390 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 391 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 392 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 393: Customer Assistance Information
Section 7 Customer Assistance and Information ... 394 Customer Satisfaction Procedure ... 394 Online Owner Center ... 397 Customer Assistance for Text Telephone (TTY) Users ... 398 Customer Assistance Offices ... 398 GM Mobility Reimbursement Program ... 399 Roadside Assistance Program ... 400 Courtesy Transportation ...
Page 394: Customer Assistance And Information
Information Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and to Pontiac. Normally, any concerns with the sales transaction or the operation of your vehicle will be resolved by your dealer’s sales or service departments. Sometimes, however, despite the best intentions of all concerned, misunderstandings can occur.
Page 395 STEP THREE — U.S. Owners: Both General Motors and your dealer are committed to making sure you are completely satisﬁed with your new vehicle. However, if you continue to remain unsatisﬁed after following the procedure outlined in Steps One and Two, you should ﬁle with the BBB Auto Line Program to enforce your rights.
Page 396 STEP THREE — Canadian Owners: In the event that you do not feel your concerns have been addressed after following the procedure outlined in Steps One and Two, General Motors of Canada Limited wants you to be aware of its participation in a no-charge Mediation/Arbitration Program.
Page 397: Online Owner Center
Online Owner Center Online Owner Center (United States only) The Owner Center is a resource for your GM ownership needs. Speciﬁc vehicle information can be found in one place. The Online Owner Center allows you to: • Get e-mail service reminders. •...
Page 398: Customer Assistance For Text Telephone (Tty) Users
(TTY users in Canada can dial 1-800-263-3830.) Customer Assistance Offices Pontiac encourages customers to call the toll-free number for assistance. However, if a customer wishes to write or e-mail Pontiac, the letter should be addressed to: United States — Customer Assistance Pontiac Customer Assistance Center P.O.
Page 399: Gm Mobility Reimbursement Program
Overseas — Customer Assistance Please contact the local General Motors Business Unit. Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) — Customer Assistance General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center Paseo de la Reforma #2740 Col.
Page 400: Roadside Assistance Program
In the U.S., call 1-800-ROADSIDE (762-3743). In Canada, call 1-800-268-6800. Service is available 24 hours a day, 365 days a year. As the owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance program. Who is Covered? Roadside Assistance coverage is for the vehicle operator, regardless of ownership.
Page 401 $100 upon submission of the original receipt to Roadside Assistance. In many instances, mechanical failures are covered under Pontiac’s Bumper-to-Bumper warranty, and the duration of the Base Warranty Coverage for Canadian customers of the new Vehicle Limited Warranty. However, any cost for parts and labor for non-warranty repairs are the responsibility of the driver.
Page 402: Courtesy Transportation
While we hope you never have the occasion to use our service, it is added security while traveling for you and your family. Remember, we are only a phone call away. Pontiac Roadside Assistance: 1-800-ROADSIDE (762-3743), text telephone (TTY) users, call 1-888-889-2438, Canadian customers call 1-800-268-6800.
Page 403 Several courtesy transportation options are available to assist in reducing your inconvenience when warranty repairs are required. Courtesy Transportation is not a part of the New Vehicle Limited Warranty and is available only at participating dealers/retailers. A separate booklet entitled “Warranty and Owner Assistance Information”...
Page 404 Public Transportation or Fuel Reimbursement If your vehicle requires overnight warranty repairs, and public transportation is used as ‘shuttle service,’ the reimbursement is limited to the associated shuttle allowance and must be supported by original receipts. In addition, for U.S. customers, should you arrange transportation through a friend or relative, limited reimbursement for reasonable fuel expenses may be available.
Page 405: Vehicle Data Collection And Event Data Recorders
Vehicle Data Collection and Event Data Recorders Your vehicle, like other modern motor vehicles, has a number of sophisticated computer systems that monitor and control several aspects of the vehicle’s performance. Your vehicle uses on-board vehicle computers to monitor emission control components to optimize fuel economy, to monitor conditions for airbag deployment and, if so equipped, to provide anti-lock braking and to help...
Page 406: Collision Damage Repair
In addition, once GM collects or receives data, GM may: • use the data for GM research needs, • make it available for research where appropriate conﬁdentiality is to be maintained and need is shown, or • share summary data which is not tied to a speciﬁc vehicle with non-GM organizations for research purposes.
Page 407 performance, however, the history of these parts is not known. Such parts are not covered by your GM New Vehicle Limited Warranty, and any related failures are not covered by that warranty. Aftermarket collision parts are also available. These are made by companies other than GM and may not have been tested for your vehicle.
Page 408 If an Accident Occurs Here is what to do if you are involved in an accident. • Try to relax and then check to make sure you are all right. If you are uninjured, make sure that no one else in your vehicle, or the other vehicle, is injured.
Page 409 • Choose a reputable collision repair facility for your vehicle. Whether you select a GM dealer/ retailer or a private collision repair facility to ﬁx the damage, make sure you are comfortable with them. Remember, you will have to feel comfortable with their work for a long time.
Page 410: Reporting Safety Defects
Reporting Safety Defects Reporting Safety Defects to the United States Government If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying General Motors.
Page 411: Reporting Safety Defects To General Motors
In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at 1-800-762-2737, or write: Pontiac Customer Assistance Center P.O. Box 33172 Detroit, MI 48232-5172 In Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French).
Page 412 Owner Information Owner publications are written speciﬁcally for owners and intended to provide basic operational information about the vehicle. The owner manual includes the Maintenance Schedule for all models. In-Portfolio: Includes a Portfolio, Owner Manual, and Warranty Booklet. RETAIL SELL PRICE: $35.00 US + Processing Fee Without Portfolio: Owner Manual only.
Page 413 Accessories and Modiﬁcations ... 268 Adding Equipment to Your Airbag-Equipped Vehicle ... 81 Additives, Fuel ... 272 Add-On Electrical Equipment ... 361 Air Cleaner/Filter, Engine ... 284 Air Conditioning ... 154 Airbag Passenger Status Indicator ... 164 Readiness Light ... 163 Airbag Sensing and Diagnostic Module (SDM) ...
Page 414 Audio System ... 187 Audio Steering Wheel Controls ... 214 Care of Your CD Player ... 216 Care of Your CDs ... 216 Fixed Mast Antenna ... 216 Radio with CD ... 191, 196 Setting the Time ... 188, 189 Theft-Deterrent Feature ...
Page 415 Care of Safety Belts ... 353 Your CD Player ... 216 Your CDs ... 216 CD, MP3 ... 206 Center Console Storage Area ... 133 Center High-Mounted Stoplamp (CHMSL) ... 313 Chains, Tire ... 334 Charging System Light ... 166 Check Engine Light ...
Page 416 Cruise Control ... 145 Cupholder(s) ... 133 Customer Assistance Information Courtesy Transportation ... 402 Customer Assistance for Text Telephone (TTY) Users ... 398 Customer Assistance Offices ... 398 Customer Satisfaction Procedure ... 394 GM Mobility Reimbursement Program ... 399 Reporting Safety Defects to General Motors ...
Page 417 Easy Entry Seat ... 16 Electrical System Add-On Equipment ... 361 Engine Compartment Fuse Block ... 364 Floor Console Fuse Block ... 362 Fuses and Circuit Breakers ... 362 Headlamp Wiring ... 361 Power Windows and Other Power Options ... 361 Windshield Wiper Fuses ...
Page 418 Fuel ... 270 Additives ... 272 California Fuel ... 271 Filling a Portable Fuel Container ... 276 Filling Your Tank ... 274 Fuels in Foreign Countries ... 273 Gage ... 175 Gasoline Octane ... 270 Gasoline Speciﬁcations ... 271 Fuses Engine Compartment Fuse Block ...
Page 419 How to Use This Manual ... 4 How to Wear Safety Belts Properly ... 24 Hydraulic Clutch ... 286 Ignition Positions ... 108 Infants and Young Children, Restraints ... 44 Inﬂation - Tire Pressure ... 325 Instrument Panel Overview ... 138 Instrument Panel (I/P) Brightness ...
Page 420 Lighting Entry/Exit ... 151 Loading Your Vehicle ... 249 Lockout Protection ... 99 Locks Automatic Door Lock ... 98 Delayed Locking ... 97 Door ... 96 Lockout Protection ... 99 Power Door ... 97 Programmable Automatic Door Unlock ... 98 Rear Door Security Locks ...
Page 421 New Vehicle Break-In ... 108 Normal Maintenance Replacement Parts ... 387 Odometer ... 161 Off-Road Recovery ... 230 Engine ... 279 Pressure Light ... 173 Oil, Engine Oil Life System ... 282 Older Children, Restraints ... 41 Online Owner Center ... 397 ®...
Page 422 Questions and Answers About Safety Belts ... 23 Radios ... 187 Care of Your CD Player ... 216 Care of Your CDs ... 216 Radio with CD ... 191, 196 Setting the Time ... 188, 189 Theft-Deterrent ... 214 Understanding Reception ... 215 Rear Door Security Locks ...
Page 423 Safety Belts Care of ... 353 Driver Position ... 25 How to Wear Safety Belts Properly ... 24 Questions and Answers About Safety Belts ... 23 Rear Safety Belt Comfort Guides ... 37 Rear Seat Passengers ... 34 Right Front Passenger Position ... 33 Safety Belt Extender ...
Page 424 Speedometer ... 161 Split Folding Rear Seat ... 17 Starting Your Engine ... 112 Steering ... 227 Steering Wheel Controls, Audio ... 214 Steering Wheel, Tilt Wheel ... 141 Storage Areas Center Console Storage Area ... 133 Convenience Net ... 133 Cupholder(s) ...
Page 425 Tires (cont.) Wheel Alignment and Tire Balance ... 332 Wheel Replacement ... 332 When It Is Time for New Tires ... 328 Towing Recreational Vehicle ... 254 Towing a Trailer ... 256, 257 Your Vehicle ... 254 Traction Enhanced Traction System (ETS) ... 226 Enhanced Traction System (ETS) Warning Light ...
Page 426 Wheels Alignment and Tire Balance ... 332 Different Size ... 330 Replacement ... 332 Where to Put the Restraint ... 52 Windows ... 101 Manual ... 101 Power ... 102 Windshield Washer ... 144 Washer Fluid ... 297 Wiper Blade Replacement ... 317 Wiper Blades, Cleaning ...

This manual is also suitable for:

2007 g5

Pontiac G5 Owner's Manual

M 2007 Pontiac G5 Owner Manual

Section 2 Features and Controls

Features and Controls

Keys

Doors and Locks

Windows

Theft-Deterrent Systems

Starting and Operating Your Vehicle

Mirrors

Onstar System

Storage Areas

Sunroof

Section 3 Instrument Panel

Instrument Panel

Instrument Panel Overview

Climate Controls

Warning Lights, Gages, and Indicators

Driver Information Center (DIC)

Audio System(S)

Section 4 Driving Your Vehicle

Driving Your Vehicle

Your Driving, the Road, and Your Vehicle

Towing

Section 5 Service and Appearance Care

Service and Appearance Care

Service

Fuel

Checking Things under the Hood

Headlamp Aiming

Bulb Replacement

Windshield Wiper Blade Replacement

Tires

Appearance Care

Vehicle Identiﬁcation

Electrical System

Capacities and Speciﬁcations

Section 6 Maintenance Schedule

Quick Links

Chapters

Related Manuals for Pontiac G5

Summary of Contents for Pontiac G5
