- Page 1 CAL3 User Manual 3. November 2021 Image Engineering GmbH & Co. KG · Im Gleisdreieck 5 · 50169 Kerpen-Horrem · Germany T +49 2273 99991-0 · F +49 2273 99991-10 · www.image-engineering.com...
-
Page 2: Table Of Contents
4.3.1 Spectrometer settings ..................8 4.3.2 iQ-LED calibration................... 8 4.4 Low intensity use ....................9 ADDITIONAL INFORMATION ..................10 5.1 Maintenance ......................10 5.2 Care instructions ....................10 5.3 Disposal instructions .....................10 TECHNICAL DATA SHEET ..................11 Image Engineering CAL3 Seite 2 von 11... -
Page 3: Introduction
Keep these instructions in a safe place and pass them to any future user. Conformity We, Image Engineering GmbH & Co. KG, hereby declare, that the CAL3 corresponds to the essential requirements of the following EC directive in its current version: •... -
Page 4: General Safety Information
Do not look directly in the open sphere or light source when using high intensities or sequences with low response time. • Do not open the device without any instructions from the Image Engineering support team or when connected to the power supply. 2 GETTING STARTED Scope of delivery •... -
Page 5: Operating Instructions Hardware
1: illuminant A (default illuminant) 2: illuminant D50 3: illuminant D75 Note: To store your own generated illuminants or sequernces on your device, please follow the instructions in the iQ-LED SW user manual. Image Engineering CAL3 Seite 5 von 11... -
Page 6: Connecting The Hardware
(See 2.1 optional equipment) Connecting the hardware 1. Connect the power cord to the power supply on the back of CAL3. 2. Connect the USB cable to the CAL3 and your PC. 3. Turn on the CAL3; the power switch is located beside the power supply. -
Page 7: Camera Positioning
• minimum lens depth: 10 mm Make sure, that • your DUT is as close as possible to the CAL3 opening • the lens is exactly in the middle of the diffusor • the front surface of the lens is least 10 mm inside the diffusor •... -
Page 8: Operating Instructions Software
Image Engineering support. 4.3.2 iQ-LED calibration The individual LED lights of the iQ-LED inside the CAL3 depends on many different types and wavelengths. Some LEDs will change their intensity level and peak wavelength slightly in the first 500-600 working hours because of a burn-in effect. -
Page 9: Low Intensity Use
The light intensity will continue to get lower when the influence of the noise continues to get higher. When using standard illuminants with an intensity lower than 25 lux, it will no longer be possible to get a correct value. Image Engineering CAL3 Seite 9 von 11... -
Page 10: Additional Information
Image Engineering. Please send the complete device to Image Engineering. Pack the CAL3 with a notation for calibration in the hard case it was delivered in. Please contact support@image-engineering.de for conditions and procedure. After the spectrometer has been calibrated, perform a spectral calibration (iQ-LED calibration). -
Page 11: Technical Data Sheet
Technical data sheet 6 TECHNICAL DATA SHEET See annex for the technical data sheet. It can also be downloaded from the website of Image Engineering: www.image-engineering.com. Image Engineering CAL3 Seite 11 von...
