Soundoff Signal ULTRALITE PLUS Installation page 2

ULTRALITE PLUS
INTERIOR WARNING BAR
WINDSHIELD LIGHT
EL3PHØ2AØ+(x)
TECHNICAL SPECIFICATIONS
Overall Dimensions: 6.9"L x 1.54"H x 3.56"D
Flash Patterns: 33 flash patterns
Input Voltage Range:
Current Consumption:
# of LEDs: 6 Generation 3 LEDs
Operating Temperature: -40º to +65º C
*Pattern Dependent
1.800.338.7337 / www.soundoffsignal.com
2
10 - 16 Vdc
<1 amp*
Flash Patterns
Alternating Patterns (Flashes per Minute)
1. Quint
2. Warp
3. Inter-Cycle Flash
4. Double Flash
5. Quad Flash
6. Power Pulse
7. RoadRunner
8. Q-Switch
9. RoadRunner Steady Burn
10. Quad Steady Burn
11. E-Ideal Single Flash
12. E-Ideal Double Flash
13. Quad2 Flash
14. Double2 Flash
15. X-Warp
16. X-Double
17. PowerRunner
18. LCR Quint
19. Warp 3
20. UltraWarp
21. Thunder and Lightning
22. LiteSpeed
23. SuperSonic
24. LCR LiteSpeed
25. SuperSonic Ultra
26. TempoShift
27. TempoShift Warp
28. SBE2
29. C
2
30. U
2
31. UltraGlow
32. Cyclone
33. Chameleon
OPERATION:
FPM
1. Plug the 12V adaptor into the
appropriate receptacle and turn plug
70
switch ON.
350
2. Press the button for less than one
second (momentary) to move
70
forward one pattern.
3. Press and hold the button for one
80
second (until the lights dim) to move
180
to the first pattern.
113
4. Press and hold the button for more
than two seconds (until the lights
turn off) to turn off the UltraLITE.
113
5. To turn the unit back on, press the
80
button again.
200
146
67
95
545
85
170
67
200
176
EL3PHØ2AØ+(X) 0919
