Summary of Contents for Makita DS4011
- Page 1 INSTRUCTION MANUAL Drill DS4011 DS5000 IMPORTANT: Read Before Using.
-
Page 2: Specifications
SPECIFICATIONS Model DS4011 DS5000 Steel 13 mm (1/2") 16 mm (5/8") Capacities Wood 36 mm (1-7/16") No load speed (RPM) 600/min. Overall length 340 mm (13-3/8") 348 mm (13-3/4") Net weight 2.8 kg (6.3 lbs) 3.0 kg (6.6 lbs) • Due to our continuing programme of research and development, the specifications herein are subject to change without notice. -
Page 3: Drill Safety Warnings
16. If devices are provided for the connection of power tool repaired before use. Many accidents dust extraction collection facilities, are caused by poorly maintained power tools. ensure these are connected and properly used. 22. Keep cutting tools sharp and clean. Properly Use of dust collection can reduce dust-related maintained cutting tools with sharp cutting edges hazards. -
Page 4: Functional Description
The switch is reversible, providing either clockwise or SAVE THESE INSTRUCTIONS. counterclockwise rotation. To start the tool, simply pull the lower part of the switch trigger for clockwise or the WARNING: upper part for counterclockwise. Release the switch trigger to stop. DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence ASSEMBLY... -
Page 5: Drilling Operation
If you need any assistance for more details regarding Never use gasoline, benzine, thinner, alcohol or the • these accessories, ask your local Makita Service Center. like. Discoloration, deformation or cracks may Drill bits • result.
