Air Conditioner Service Manual 1. IMPORTANT NOTICE This service manual is intended for use by individuals possessing adequate backgrounds of electrical, electronic and mechanical experience. Any attempt to repair the appliance may result in personal injury and property damage.
Air Conditioner Service Manual 4.Operation Details Remote controller ON/OFF button To switch the conditioner on and off. ECO button In cooling mode,press this button ,the temperature will increase 2 on the base of setting temperature: In heating mode, press this button, the temperature will decrease 2 on the base of setting temperature.
Page 6
Air Conditioner Service Manual Electronic controller NOTES: RT-------Room Temperature. IPT------Indoor Pipe Temperature. ST------indoor Setting Temperature. OPT---Outdoor Pipe Temperature. CRT---Compensated Room Temperature 1. Automatic mode 1) The initial RT determines A/C working mode and the setting temperature (ST), the mode is determined effective only once unless A/C shut-down and then re-started.
Page 7
Air Conditioner Service Manual b. Indoor fan motor automatic airflow speed control, it works as shown in Figure 1: RT-ST 1°C 2°C 4°C Figure 1 Cooling automatic airflow When the temperature changing leads the fan speed variation, the switch can only be made orderly, and in every grade of air flow speed should run 1 minute at least.
Page 8
Air C Conditioner Se rvice Manual 6) Defro osting functio During de efrosting, on ce mode ch anging, eco nomic opera ation or temp perature set tting signals received, th buzzer an nd display w will make res sponse imme ediately, but t the other o...
Page 9
Air Conditioner Service Manual Running into defrosting under condition 3, defrosting time set is 10 min. a) Running into the first defrosting in 20 min after start-up. b) The interval from last defrosting equivalent to or more than 50 min (stopping the compressor or the machine in standby is allowed in the meantime).
Page 10
Air Conditioner Service Manual d. auxiliary electric heating is turned off for more than 30s。 e. ST-RT≥0°C; f. RT﹤25°C; g. IPT≤43°C; (3) The conditions of stopping auxiliary electric heating(any one of the following conditions met, the state stops) a.
Page 11
Air Conditioner Service Manual Under emergency operation, the function of compressor’s time-delay protection, Anti-frosting protection in cooling mode, Overheating protection in heating mode, sensor fault protection and defrost operate are effective. Under emergency operation, once effective signal from remote controller received, the A/C exits form of emergency mode without delay, and operates according to the setting value from remote controller immediately.
Page 12
Air Conditioner Service Manual b. When the indoor fan motor running at a low-speed under cold air prevention operation, once auxiliary electric heating works, the vane immediately withdraws from the cold air prevention location and turn back to normal vane angle. While auxiliary electric heating stops, indoor fan motor goes on to run at low-speed accordingly, the vane turns to cold air prevention location Set fan speed Set fan speed...
Air Conditioner Service Manual 5. WIRING DIAGRAM MODEL: TAC-07HRA/E1/TACO-07HRA/E1, TAC-09HRA/E1/TACO-09HRA/E1, TAC-12HRA/E1/TACO-12HRA/E1,TAC-18HRA/E1/TACO-18HRA/E1, TAC-24HRA/E1/TACO-24HRA/E1,TAC-09HRA/ES/TACO-09HRA/ES TAC-12HRA/ES/TACO-12HRA/ES, TAC-09HRA/EW/TACO-09HRA/EW TAC-12HRA/EW/TACO-09HRA/EW,TAC-18HRA/EW/TACO-09HRA/EW INDOOR UNIT: OUTDOOR UNIT...
Page 14
Air Conditioner Service Manual MODEL:TAC-28HRA/E1/TACO-28HRA/E1 INDOOR UNIT: OUTDOOR UNIT...
Page 15
Air Conditioner Service Manual MODEL: TAC-36HRA/WE/TACO-36HA/WE INDOOR UNIT: OUTDOOR UNIT...
Page 16
Air Conditioner Service Manual 6. Explosion view and parts Mode: TAC-07HRA/E1, TAC-09HRA/E1, TAC-12HRA/E1, TAC-18HRA/E1, TAC-24HRA/E1 TAC-09HRA/ES, TAC-12HRA/ES INDOOR UNIT:...
Page 17
Air Conditioner Service Manual PARTS LIST Indoor unit: TAC-07HRA/E1 Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738121 Base 210738389 Vertical Vane Assembly 210738131 Cross Fan 1070100010 Bearing Mount 211238000 Evaporator 210738120 Face Frame 210701846 Screw Cover 210738127 Vane...
Page 18
Air Conditioner Service Manual Indoor unit: TAC-09HRA/E1 Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738121 Base 210738389 Vertical Vane Assembly 210738131 Cross Fan 1070100010 Bearing Mount 211238000 Evaporator 210738120 Face Frame 210701846 Screw Cover 210738127 Vane 210738433 Air Filter 210705767 Display PCB Box 210901127S...
Page 19
Air Conditioner Service Manual Indoor unit: TAC-12HRA/E1 Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210737656 Base 210701880 Vertical Vane Assembly 210737655 Cross Fan 1070100010 Bearing Mount 211238554 Evaporator 210737662 Face Frame 210701846 Screw Cover 210737652 Vane 210701863 Air Filter 210705767 Display PCB Box 210901127S...
Page 20
Air Conditioner Service Manual Indoor unit: TAC-18HRA/E1 Part No. Part Name Remark Q’ty 1080030021 Installation Plate 210738678 Base 210738575 Vertical Vane Assembly 1070020024AA Cross Fan 1070100010 Bearing Mount 211237947 Evaporator 210738663 Face Frame 210701846 Screw Cover 210738661 Vane 210738606 Air Filter 210705767 Display PCB Box 210901127S...
Page 21
Air Conditioner Service Manual Indoor unit: TAC-24HRA/E1 Part No. Part Name Remark Q’ty 1080030021 Installation Plate 210738660 Base 210738575 Vertical Vane Assembly 1070020042AA Cross Fan 1070100010 Bearing Mount 211238333 Evaporator 210738663 Face Frame 210701846 Screw Cover 210738661 Vane 210738606 Air Filter 210705767 Display PCB Box 210901127S...
Page 22
Air Conditioner Service Manual Indoor unit: TAC-09HRA/ES Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738121A Base 210738389 Vertical Vane Assembly 210738131 Cross Fan 1070100010 Bearing Mount 211238000 Evaporator 210738120A Face Frame 210701846Y Screw Cover 210738127A Vane 210738433 Air Filter 210705767 Display PCB Box 210901127S...
Page 23
Air Conditioner Service Manual Indoor unit: TAC-12HRA/ES Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738411F Base 210701880 Vertical Vane Assembly 210737655 Cross Fan 1070100010 Bearing Mount 211238554 Evaporator 210737662C Face Frame 210701846Y Screw Cover 210737652B Vane 210701863 Air Filter 210705767 Display PCB Box 210901127S...
Page 24
Air Conditioner Service Manual Mode: TAC-07HRA/EW, TAC-09HRA/EW, TAC-12HRA/EW, TAC-18HRA/EW INDOOR UNIT:...
Page 25
Air Conditioner Service Manual Indoor unit: TAC-07HRA/EW, TAC-09HRA/EW Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738613A Base 210738389 Vertical Vane Assembly 210738432 Vertical Vane Connector 210738127 Vane 210738131 Cross Fan 1070100010 Bearing Mount 211238000 Evaporator 210738120 Face Frame 210701846 Screw Cover 210701863...
Page 26
Air Conditioner Service Manual Indoor unit: TAC-12HRA/EW Part No. Part Name Remark Q’ty 1080030003 Installation Plate 210738411D Base 210701883 Vertical Vane Assembly 210701903 Vertical Vane Connector 210737652 Vane 210737655 Cross Fan 1070100010 Bearing Mount 211238554 Evaporator 210737662 Face Frame 210701846 Screw Cover 210701863 Air Filter...
Page 27
Air Conditioner Service Manual Indoor unit: TAC-18HRA/EW Part No. Part Name Remark Q’ty 1080030021 Installation Plate 210738660 Base 210738575 Vertical Vane Assembly 210738582 Vertical Vane Connector 210738574 Vane 1070020024AA Cross Fan 1070100010 Bearing Mount 211237947 Evaporator 210738663 Face Frame 210701846 Screw Cover 210738606 Air Filter...
Page 28
Air Conditioner Service Manual Mode: TAC-28HRIA/E1 INDOOR UNIT:...
Page 29
Air Conditioner Service Manual Indoor unit: TAC-28HRA/E1 Part No. Part Name Remark Q’ty 210836849 Installation Plate 210738535A Base 210738389 Vertical Vane Assembly 210738395 Vertical Vane Connector 210738387 Vane 210738396 Cross Fan 1070100010 Bearing Mount 211238060 Evaporator 210738539 Face Frame 210701846 Screw Cover 210738391A Air Filter...
Page 30
Air Conditioner Service Manual Mode: TAC-36HRA/WE INDOOR UNIT:...
Page 31
Air Conditioner Service Manual Indoor unit: TAC-36HRA/WE Q’ty Part No. Part Name Remark 210826433 Installation Plate 210826434 In And Out Pipe Fixer 210735863 Base 210735759 Cross Fan Supporter 210735912 Middle Bearing Mount 210735760 Cross Fan Supporter Cover 210735861 Cross Fan1 210735862 Cross Fan2 1070100010...
Page 32
Air Conditioner Service Manual MODEL: TACO-07HRA/E1,TACO-09HRA/E1,TACO-12HRA/E1,TACO-18HRA/E1,TACO-24HRA/E1 TACO-07HA/E2, TACO-09HA/E2, TACO-12HA/E2, TACO-18HA/E2 OUTDOOR UNIT: ...
Page 33
Air Conditioner Service Manual Outdoor unit: TACO-07HRA/E1 Part No. Part Name Remark Q’ty 1071990038 Grille Optional 1081990014 Top Cover 211232279A Condenser 1081990018 Outdoor Motor Supporter 1170040071 Outdoor Motor 1070030006AA Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1070251929 Fan Guard 1100110034 Compressor And It Accessories 1120110016...
Page 34
Air Conditioner Service Manual Outdoor unit: TACO-09HRA/E1 Part No. Part Name Remark Q’ty 1071990038 Grille Optional 1081990014 Top Cover 211232279A Condenser 1081990018 Outdoor Motor Supporter 1170040071 Outdoor Motor 1070030006AA Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1070251929 Fan Guard 211238496 Compressor And It Accessories 1120110016...
Page 35
Air Conditioner Service Manual Outdoor unit: TACO-12HRA/E1 Part No. Part Name Remark Q’ty 1071990039 Back Grille Optional 1080320105 Top Cover 211238586 Condenser 1080050004 Outdoor Motor Supporter 1170040058 Outdoor Motor 1070030050AA Propeller Fan 1080050001 Left Grille Supporter 210800274 Front Plate 1070251931 Fan Guard 1100011049 Compressor...
Page 36
Air Conditioner Service Manual Outdoor unit: TACO-18HRA/E1 Part No. Part Name Remark Q’ty 1071990040 back Grille Optional 1080050011 Top Cover 211200883A Condenser 1080050004 Outdoor Motor Supporter 1170040059 Outdoor Motor 1070030038AA Propeller Fan 1080050001 Left Grille Supporter 210800275 Front Plate 1070251931 Fan Guard 211238303 Compressor...
Page 37
Air Conditioner Service Manual Outdoor unit: TACO-24HRA/E1 Part No. Part Name Remark Q’ty 1083520101 Back Grille Optional 1081990056 Top Cover 211206428 Condenser 1081990060 Outdoor Motor Supporter 1170040100 Outdoor Motor 1070030040AA Propeller Fan 1081990053 Left Grille Supporter 1081990258 Front Plate 1071990096 Fan Guard 211232872 Compressor...
Page 38
Air Conditioner Service Manual Outdoor unit: TACO-07HA/E2 Part No. Part Name Remark Q’ty 1071990038 Grille Optional 1081990014 Top Cover 211232279A Condenser 1081990018 Outdoor Motor Supporter 1170040071 Outdoor Motor 1070030006AA Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1070251929 Fan Guard 1100110034 Compressor 1120110016...
Page 39
Air Conditioner Service Manual Indoor unit: TACO-09HA/E2 Part No. Part Name Remark Q’ty 1071990038 Grille Optional 1081990014 Top Cover 211232279A Condenser 1081990018 Outdoor Motor Supporter 1170040071 Outdoor Motor 1070030006AA Propeller Fan 1081990011 Left Grille Supporter 1081990016 Front Plate 1070251929 Fan Guard 211238496 Compressor 1120110016...
Page 40
Air Conditioner Service Manual Outdoor unit: TACO-12HA/E2 Part No. Part Name Remark Q’ty 1071990039 Back Grille Optional 1080320105 Top Cover 211238586 Condenser 1080050004 Outdoor Motor Supporter 1170040058 Outdoor Motor 1070030050AA Propeller Fan 1080050001 Left Grille Supporter 210800274 Front Plate 1070251931 Fan Guard 1100011049 Compressor...
Page 41
Air Conditioner Service Manual Outdoor unit: TACO-18HA/E2 Part No. Part Name Remark Q’ty 1071990040 back Grille Optional 1080050011 Top Cover 211200883A Condenser 1080050004 Outdoor Motor Supporter 1170040059 Outdoor Motor 1070030038AA Propeller Fan 1080050001 Left Grille Supporter 210800275 Front Plate 1070251931 Fan Guard 211238303 Compressor...
Page 42
Air Conditioner Service Manual MODEL: TACO-28HRA/E1, TACO-36HA/WE OUTDOOR UNIT: ...
Page 43
Air Conditioner Service Manual Outdoor unit: TACO-28HRA/E1 Part No. Part Name Remark Q’ty 1071990041 Grille Optional 1081990038 Top Cover 211238231 Condenser 1081990042 Outdoor Motor Supporter 1170040102 Outdoor Motor 1170120146AA Propeller Fan 1081990040 Left Grille Supporter 1081990047 Front Plate 1070251945 Fan Guard 1100011034 Compressor 1120110017...
Page 44
Air Conditioner Service Manual Outdoor unit: TACO-36HA/WE Q’ty Part No. Part Name Remark 1071990055 Grille Optional 1080050045 Top Cover 211231303A Condenser 210800644 Outdoor Motor Supporter 210900509 Outdoor Motor 210702407 Propeller Fan 1080050042 Left Grille Supporter 210800337 Front Plate 210702363 Fan Guard 211233665 Compressor 1120110021...
Air Conditioner Service Manual 7. Precaution 7.1 SAFETY RULES AND RECOMMENDATIONS FOR THE INSTALLATION Read this guide before installing and using the appliance. During the installation of the indoor and outdoor units the access to the working area should be forbidden to children.
Page 46
Air Conditioner Service Manual 7.2 SAFETY RULES AND RECOMMENDATIONS FOR THE USER Do not try to install the conditioner alone; always contact specialized technical personnel. Cleaning and maintenance must be carried out by specialized technical personnel. In any case disconnect the appliance from the mains electricity supply before carrying out any cleaning or maintenance.
Air Conditioner Service Manual 8. Names of parts INDOOR UNIT Indoor unit 2-3 4 Name Front panel Air filter Special filter(option) Display PCB Vertical vane Horizontal vane Remote controller ...
20 meters Max. 20 meters Max. In do o r unit Outdoor unit Refrigerant Standard length: Additional refrigerant piping Max. Mode Calculation: ×g=20g/m(A-5m) length: m TAC-07HRA/E1, TAC-09HRA/E1 TAC-07HRA/EW, TAC-09HRA/EW 20g/m TAC-09HRA/ES TAC-12HRA/E1, TAC-12HRA/EW 20g/m TAC-12HRA/ES TAC-18HRA/E1, TAC-12HRA/EW 30g/m TAC-24HRA/E1, TAC-28HRA/E1 30g/m...
Page 49
Air Conditioner Service Manual 9.2 Installation for the first time Indoor unit Install the indoor unit level on a strong wall that is not subject to vibrations The inlet and outlet ports should not be Mounting plate obstructed: the air should be able to blow all over the room.
Page 50
Air Conditioner Service Manual Install the indoor unit in the room to be air conditioning, avoiding to installation in corridors or communal areas. Install the indoor unit at a height of at least 2.5m from the ground. To install, proceed as follows: 9.2.1 Installation of the mounting plate.
Page 51
Air Conditioner Service Manual 6).The plug must be accessible also after the appliance has been installed so that it can be pulled out if necessary. .An efficient earth connection must be ensured. 8).If the power cable is damaged, it must be replaced by an authorized Service Centre.
Page 52
Air Conditioner Service Manual 4).If the piping is installed to the right, the pipes, power cable and drain hose must be lagged and secured onto the rear of the unit with a pipe connection. Insert the pipe connection into the relative ...
Air Conditioner Service Manual 10. Trouble shooting 10.1 Product does not operate at all. Power receptable voltage Product input voltage Power supply voltage check PCB assembly Power input voltage Driving load terminal Connector contact check Display PCB connector Power trans output voltage AC about 12±3V ...
Page 54
Air Conditioner Service Manual 10.2 Indoor fan does not operate at all (E6). Check: Connector contact Motor output connector Motor capacitor Check: Motor bearing inserted Motor-related parts state Fan(Blower) fixed state Fan(Blower) contact state Motor detail check ...
Page 55
Air Conditioner Service Manual 10.3 Compressor or outdoor fan does not operate at all. Re-input after power off Set the desired temperature of remote controller to be lower by 2°C or over than room temperature, and start the cooling operation. ...
Page 56
Air Conditioner Service Manual 10.4 Vane does not operate at all. Vane bending, structures interference check Connector check (Broken/short circuit/mal- connection) Replace the vane motor Vane motor check ...
Page 57
TCL Air Conditioner Service Manual 11.5 Examples of repairing 11.5.1 Display E1 or E2 Reasons: 1) The sensor connection terminal loose or not plugged in. Solution: Check the connecter of sensor and slot (CN6), if loose or not plugged in, please connect again.
Page 58
TCL Air Conditioner Service Manual 2) The indoor motor damage. Solution: Check and replace the motor. 3) The indoor main PCB damage. Solution: Replace the indoor main PCB.
Page 59
Air Conditioner Service Manual 10.6 THERMISTOR TEMPERATURE CHARACTERISTICS Indoor unit room temperature and pipe temperature characteristics TEMP. Resistance Voltage of TEMP. Resistance Voltage of TEMP. Resistance Voltage of (℃) (k Ohm) resistance (℃) (k Ohm) resistance (℃) (k Ohm) resistance 63.513 4.628 7.447...
Page 60
Air Conditioner Service Manual Resistance at 25℃: 5 kΩ. TH1: indoor room temperature sensor and outside air temperature sensor TH2: indoor exchange temperature sensor and outside exchange temperature sensor Before measuring resistance, disconnect connectors as shown above.
