Summary of Contents for Ford 1996 Explorer

  • Page 3: Table Of Contents

    Table of Contents Introductory Information Safety Restraints Starting Your Explorer Warning Lights and Gauges ....79 Instrument Panel Controls ....Steering Column Controls .
  • Page 4: Introductory Information

    Ford’s Commitment to You At Ford Motor Company, excellence is the continuous commitment to achieve the best result possible. It is dedication to learning what you want, determination to develop the right concept, and execution of that concept with care, precision, and attention to detail.
  • Page 5 This guide describes equipment and gives specifications for equipment that was in effect when this guide was approved for printing. Ford may discontinue models or change specifications or design without any notice and without incurring obligation. NOTES and WARNINGS NOTES give you additional information about the subject matter you are referencing.
  • Page 6 If you lose your Warranty Information Booklet, you can get a new one free of charge. Contact any Ford or Lincoln-Mercury dealer, or refer to the addresses and phone numbers on the first page of this owner guide.
  • Page 7 Buying a Ford Extended Service Plan If you bought your vehicle in the U.S., you can buy a Ford Extended Service Plan for your vehicle. This optional contract provides service protection for a longer period of time than the basic warranty that comes with your vehicle.
  • Page 8 500 miles/800 km after any wheel change or any other time the wheel lug nuts have been loosened. Use only the type of engine oil that Ford recommends. See Engine oil recommendations in the Index. Do not use special “break-in” oils.
  • Page 9: Cleaning The Outside Of Your Vehicle

    Ford, however, believes that continual improvement in customer satisfaction is a high priority. For this reason, Ford has authorized its dealers to repair, at no charge to the owner,...
  • Page 10 Introductory Information Cleaning Chrome and Aluminum Parts Wash chrome and aluminum parts with a mild detergent. Do not use steel wool, abrasive cleaners, fuel or strong detergents. Cleaning Plastic Parts Some of your vehicle’s exterior trim parts are plastic. Clean with a tar and road oil remover if necessary.
  • Page 11: Safety Restraints

    Important Safety Belt Information The use of safety belts helps to restrain you and your passengers in case of a collision. In most states and in Canada the law requires their use. Safety belts provide best restraint when: the seatback is upright the occupant is sitting upright (not slouched) the lap belt is snug and low on the hips the shoulder belt is snug against the chest...
  • Page 12 Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
  • Page 13: Combination Lap And Shoulder Belts

    Safety Restraints Combination Lap and Shoulder Belts While your vehicle is in motion, the combination lap and shoulder belt adjusts to your movement. However, if you brake hard, turn hard, or if your vehicle receives an impact of 5 mph (8 km/h) or more, the lap/shoulder belt locks and helps reduce your forward movement.
  • Page 14 Unfastening the outboard lap/shoulder belts While the belt retracts, guide the tongue to its original position to prevent it from striking you or the vehicle. Safety Belts for Front Outboard Passenger and Rear Outboard Seating Positions Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for the front seat outboard passenger and rear outboard passengers.
  • Page 15 Automatic locking mode In this operating mode, the shoulder belt retractor will be automatically locked and will remain locked when the combination lap/shoulder safety belt is buckled, and does not allow the occupant freedom of movement. This mode provides the following: A tight lap/shoulder belt on the occupant.
  • Page 16 NOTE: When the combination lap/shoulder belt is unbuckled and allowed to retract completely, the retractor will switch to the vehicle sensitive (emergency) locking mode. See the detailed instructions under Safety Seats for Children in this chapter. Shoulder Belt Height Adjustment Driver and right front passenger The driver and right front passenger shoulder belt height is adjustable to one of five (5) positions.
  • Page 17 Safety Restraints Adjusting shoulder belt height (2 door models) Shoulder belt height adjuster — full down position (2 door models)
  • Page 18 Shoulder belt height adjuster — full up position...
  • Page 19 Shoulder belt height adjuster — mid-way position (4 door models) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm. Never swing it around the neck over the inside shoulder. Never use a single belt for more than one person. Failure to follow these precautions could increase the risk and/or severity of injury in a collision.
  • Page 20 Unfastening the outboard lap/shoulder belts The rear seat shoulder safety belts have a feature which allows the seat belt webbing to be stowed out of the way when the rear seats are folded down (2 door only). To stow the belt while the seat is folded, attach the plastic snap on the seat belt to the metal mating part on the plastic trim panel.
  • Page 21 Safety Restraints Rear combination lap and shoulder belts (2 door model) Center Front Lap Belt (If equipped) The lap belt in the center of the front seat does not adjust automatically. You must adjust it to fit snugly around your hips.
  • Page 22 To unfasten the belt, push the release button on the buckle. This allows the tongue to unlatch from the buckle. Because the center front lap belt does not have a retractor, it should be shortened and fastened when not in use. Fastening and unfastening the front center safety belt The lap belts should fit snugly and as low as possible around the hips, not around the waist.
  • Page 23 Rear Lap Belt with Retractor Pull the belt out of the retractor with a steady motion and insert the tongue into the proper buckle until you hear a snap and feel the latch engage. Fastening and unfastening the rear center safety belts (4-door model) To Unfasten the Safety Belts with Retractors: Push the release button on the buckle.
  • Page 24: Safety Belt Maintenance

    Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended. Do not use extension to change the fit of the shoulder belt across the torso.
  • Page 25 Safety Restraints Energy absorbing sew pattern...
  • Page 26: Air Bag Supplemental Restraint System

    (slide bar) (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after any collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was...
  • Page 27 The Importance of Wearing Safety Belts Safety belts must be worn by all vehicle occupants to be properly restrained and help reduce the risk of injury in a collision. All occupants of the vehicle, including the driver, should always wear their safety belts, even when an air bag Supplemental Restraint System is provided.
  • Page 28 The Importance of Being Properly Seated In a collision, the air bag must inflate extremely fast to help provide additional protection for you. In order to do this, the air bag must inflate with considerable force. If you are not seated in a normal riding position with your back against the seatback, the air bag may not protect you properly and could possibly hurt you as it inflates.
  • Page 29 Your vehicle is equipped with a right front passenger air bag. Air bags deploy with great force, faster than the blink of an eye. Front passengers, especially children and small adults, must never sit on the front edge of the seat, stand near the glove compartment of the instrument panel, or lean over near the air bag cover when the vehicle is moving.
  • Page 30 For further information about the proper mounting of equipment in the front seat of this vehicle, please refer to Ford’s brochure entitled Some Important Information About Air Bag Supplemental Restraint System which can be obtained by calling Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
  • Page 31 Safety Restraints The location of the air bag and warning labels If a collision occurs, the sensors sense the severity of the impact and activate the air bags if necessary. The air bag system is designed to deploy in frontal and front-angled collisions more severe than hitting a parked vehicle (of similar size and weight) head-on at about 28 mph (45 km/h).
  • Page 32 Air bag system components get hot after inflation. Do not touch them after inflation. The air bag system uses a readiness light on the instrument cluster and a tone to indicate the condition of the system. When you turn the ignition key to the ON position, this light will illuminate for approximately six (6) seconds and then turn off.
  • Page 33 Inflated passenger-side air bag If the air bag is inflated, THE AIR BAG WILL NOT FUNCTION AGAIN AND MUST BE REPLACED IMMEDIATELY. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 34: Safety Restraints For Children

    Ford or Lincoln-Mercury dealer. Disposal of supplemental air bag equipped vehicles For disposal of air bags or air bag equipped vehicles, see your local Ford or Lincoln-Mercury dealer. Air bags MUST be disposed of by qualified personnel. Safety Restraints for Children In the U.S.
  • Page 35 Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. To prevent the risk of injury, make sure children sit where they can be properly restrained. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle.
  • Page 36 Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Never leave a child unattended in your vehicle. Built-In Child Seat (If equipped) The rear seat may include an optional built-in child safety seat (passenger side).
  • Page 37 Safety Restraints Figure 1: Built-in child safety seat in the closed position...
  • Page 38 Figure 2: Built-in child safety seat in the open position Children must be properly buckled before riding in the vehicle. It is the law in every state and province. This child seat conforms to all Federal/Canadian motor vehicle safety standards. Frequently check the child seat’s lap and shoulder harness belts for correct placement and tightness.
  • Page 39 Always adjust the lap and shoulder harness belts provided with this child seat snugly around your child. Never leave a child unattended in your vehicle. Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child.
  • Page 40 To release the head restraint, grasp the pull strap and pull toward you (approximately one inch), which will allow you to insert your hand at the bottom of the head restraint, as shown in Figure 3. Figure 3: Releasing the child safety seat head restraint...
  • Page 41 Release strap and slide the head restraint to the full up position. Refer to Figure 4. Figure 4: Positioning child safety seat head restraint and release of child seat cushion Pull both velcro straps to release the child seat cushion. Refer to Figure 4.
  • Page 42 Lower the child seat cushion onto the adult seat cushion. Read the information and warnings carefully on the child seat cushion protector flap and shoulder safety belt. Check the child’s size, weight and age to be sure that the child is not too small or too large for the seat.
  • Page 43 Safety Restraints Unfold cushion protector flap onto adult seat cushion. Refer to Figures 5 and 6. Figure 6: Shoulder safety belt placement on the child...
  • Page 44 Place child on the child seat cushion. Then position the right shoulder belt over the child’s shoulder as shown in Figure 6. Insert the right safety belt tongue into the single opening of the crotch safety belt buckle as shown in Figure 7. Figure 7: Fastening the crotch safety belt NOTE: Read the following steps carefully to become familiar with the color indicator windows located on each...
  • Page 45 Safety Restraints Position the left shoulder belt over the child’s shoulder and insert the left tongue into the buckle as shown in Figure 8. The color green must appear in the color indicator window on each buckled tongue. Figure 8: Fastening the crotch safety belt...
  • Page 46 Figure 9: Fastening the chest clip Pull on both safety belt tongues to be sure that both tongues are latched. If both tongues do not latch in the buckle, do not use the child seat. See your dealer for repairs. RWARNING...
  • Page 47 Safety Restraints Fasten both halves of the chest clip below the child’s shoulders and adjust the clip (up or down) to comfortably hold the shoulder belts in place on the child’s chest. The indicator on the chest clip will show green when the clip is latched.
  • Page 48 Figure 11: Fastening the chest clip...
  • Page 49 Safety Restraints Tug on the crotch safety belt buckle and the chest clip to ensure they are properly fastened. Refer to Figure 12. Figure 12: Securing the chest clip...
  • Page 50 If the child is sleeping or tries to get out of the child seat, pull shoulder belts fully out to put the retractor into the lock mode. At this time, the shoulder belts are in an automatic lock mode. Allow belts to tighten snugly against the child’s shoulders.
  • Page 51 When properly used, the child safety seat should look like Figure 14. Figure 14: Built-in child seat properly being used Built-In Child Seat Belt Retractors The belts on the Built-In Child Seat are equipped with a dual locking mode retractor. The child seat belts can be used with the retractor in either the emergency locking mode or the automatic mode.
  • Page 52 locking mode when the belts are unbuckled and the shoulder belts retract completely. The automatic locking mode must be used to hold small children in position, particularly sleeping children and those who may try to squirm out of the belts. The emergency locking mode is also used while buckling the belts.
  • Page 53 To remove the child from the built-in child seat: Open the chest clip. Refer back to Figure 9. Press release button on the crotch safety buckle. Refer back to Figure 8. Slide the shoulder safety belts off the child’s shoulders and remove the child from the seat.
  • Page 54 Built-in child seat maintenance Regularly inspect the lap and shoulder belts system of your child seat. See your Ford Dealer if the shoulder belt webbing is frayed, or if the buckle and tongue are damaged and/or do not function properly.
  • Page 55 information on top tether straps see Attaching Safety Seats With Tether Straps in this chapter. When installing a child safety seat, be sure to use the correct safety belt buckle for that seating position, and make sure the tongue is securely fastened in the buckle. For a shoulder/lap belt combination with a sliding tongue, make sure the retractor is in the automatic locking mode.
  • Page 56 Seatbacks should be upright for use with child safety seats. Always keep the buckle release button pointing upward and away from the child seat, with the tongue between the child seat and the release button as shown in the following illustration. RWARNING RWARNING...
  • Page 57 Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps see your Ford or Lincoln-Mercury dealer.
  • Page 58 If you do not properly secure the safety seat, the child occupying the seat may be injured during a collision or sudden stop. An unsecured safety seat could also injure other passengers. Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
  • Page 59 Installing Safety Seats in Combination Lap and Shoulder Belt Seating Positions Position the child safety seat in a seat with a combination lap and shoulder belt. If you choose to install a child safety seat in the front passenger seat, move the seat as far back as possible. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
  • Page 60 While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. Routing the lap/shoulder belt...
  • Page 61 Safety Restraints Insert the belt tongue into the proper buckle for that seating position until you hear and feel the latch engage. Make sure the tongue is latched securely by pulling on it. Buckling the belt...
  • Page 62 Grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard to put the retractor in the automatic locking mode. Setting the retractor to automatic locking mode...
  • Page 63 Safety Restraints Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode. Allowing shoulder belt to retract...
  • Page 64 Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down on the child seat. Removing slack from the belt Allow the safety belt to retract to remove any slack in the belt.
  • Page 65 Safety Restraints Checking that the seat is secure Try to pull belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat steps 2 through 9.
  • Page 66 Follow the child seat manufacturer’s instructions to attach the tether strap to the tether bracket. Ford recommends placement of tethered safety seats in a rear seating position with the tether strap installed to the tether anchoring point as shown in the instructions provided with the child tether strap anchor kit.
  • Page 67 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards. Belt-positioning booster...
  • Page 68 thighs, or if the thighs are too short to let the child sit all the way back on the seat cushion when the lower legs hang over the edge of the seat cushion. You may wish to discuss the specific needs of your child with your pediatrician. Lap belts and the lap belt portion of lap and shoulder belts should always be worn snugly and below the hips, touching the child’s thighs.
  • Page 69: Starting Your Explorer

    Ignition Understanding the Positions of the Ignition The positions of the key in the ignition lock cylinder. ACCESSORY allows some of your vehicle’s electrical accessories such as the radio and the windshield wipers to operate while the engine is not running. In order to turn the key from the ON or OFF position to the ACCESSORY position, you must push the key release button if your vehicle’s manual transmission gearshift is mounted on the...
  • Page 70 OFF allows you to shut off the engine and all accessories without locking the steering wheel or the automatic transmission gearshift lever. ON allows you to test your vehicle’s warning lights (except the brake system warning light) to make sure they work before you start the engine.
  • Page 71 Turn the ignition key to LOCK. Remove the key. If your vehicle’s gearshift lever is mounted on the floor: Put the gearshift in 1 (First). Turn the ignition key to OFF. Set the parking brake fully before removing your foot from the service brake.
  • Page 72: Starting Your Vehicle

    Fuel-Injected Engines When starting a fuel-injected engine, the most important thing to remember is to avoid pressing down on the accelerator before or during starting. Only use the accelerator when you have problems getting your vehicle started. See Starting Your Engine in this chapter for details about when to use the accelerator while you start your vehicle.
  • Page 73: Warning Lights And Gauges

    Before you start your vehicle, you should test the warning lights on the instrument panel to make sure that they work. Refer to the Warning Lights and Gauges chapter. Starting Your Engine To start your engine: Follow the steps under Preparing to Start Your Vehicle at the beginning of this section.
  • Page 74 For a warm engine: Do not hold the key in the START position for more than five (5) seconds at a time. If the engine does not start within five (5) seconds on the first try, turn the key to the OFF position.
  • Page 75 Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
  • Page 76 If the Engine Cranks but Does Not Start or Does Not Start After a Collision The Fuel Pump Shut-off Switch If the engine cranks but does not start or does not start after a collision, the fuel pump shut-off switch may have been triggered.
  • Page 77 If your engine cranks but does not start after a collision or major jolt: Turn the key in the ignition to OFF. Check under the vehicle for leaking fuel. If you do not see or smell fuel, push the red reset button down.
  • Page 78 Guarding Against Exhaust Fumes Carbon monoxide, although colorless and odorless, is present in exhaust fumes. Take precautions to avoid its dangerous effects. Never let your vehicle idle in an enclosed area, and do not sit in a parked vehicle, (with the engine running) for more than a short period of time.
  • Page 79 Improve your ventilation by keeping all air inlet vents clear of snow, leaves, and other debris. If the engine is idling while you are stopped in an open area for long periods of time, open the windows at least one inch (2.5 cm).
  • Page 80 Warning Lights and Gauges The instrument panel (dashboard) on your vehicle is divided into several different sections. The illustrations on the following pages show the major parts of the instrument panel that are described in this chapter. Some items shown may not be on all vehicles.
  • Page 82 The Mechanical Cluster The following warning lights and gauges are on the mechanical cluster. All of the warning lights and gauges alert you to possible problems with your vehicle. Some of the lights listed are optional. The following sections detail what each of these indicators means.
  • Page 83 Anti-lock Brake Warning Light To check the ABS brake warning light, turn the ignition key to ON. The ABS brake warning light should glow momentarily. Anti-lock warning light symbol If the anti-lock brake system warning light remains on or comes on while driving, have the braking system checked by a qualified service technician as soon as possible.
  • Page 84 If any of these things happen, even intermittently, have the air bag system serviced at your Ford or Lincoln-Mercury dealer immediately. Air bag readiness light symbol...
  • Page 85 Door Ajar Warning Light (If equipped) If the ignition switch is in the ON position and any door or the liftgate is not completely closed, the light will illuminate. Door ajar warning light symbol Check Engine Warning Light The Powertrain On-Board Diagnostic II (OBD II) system consists of the hardware and software necessary to monitor the operation of the powertrain.
  • Page 86 Warning Lights and Gauges If the light turns on and off at one (1) second intervals while you are driving the vehicle, it means that the engine is misfiring. If this condition persists, damage could occur to the engine or catalytic convertor. Have your vehicle serviced at the first opportunity.
  • Page 87 Overdrive Off Indicator (If equipped) This light tells you that the Transmission Control Switch (TCS) on the gearshift lever has been pushed. When the light is on, the transmission does not shift into overdrive. Depressing the button on the shifter once more returns the vehicle to overdrive mode.
  • Page 88 Warning Lights and Gauges Speed control light Charging System Light This light, shown as a battery symbol on your cluster, indicates that your battery is not being charged and that you need to have the electrical system checked. Charging system light symbol This light comes on every time you turn the ignition to the ON or START position (engine off).
  • Page 89 Anti-Theft Alarm Light (If equipped) This light flashes on and off when the ignition switch is OFF and any door is opened. As soon as you lock the doors, the light glows steadily. Within 30 seconds of closing all the doors, the light flashes intermittently (every 2 seconds).
  • Page 90 Warning Lights and Gauges Fuel Reset Light (If Equipped) Your vehicle may have a fuel reset light. The fuel reset light will come on when you turn the ignition key to ON and the fuel pump shut-off switch has been triggered. Refer to Fuel pump shut-off switch in the Index to find additional information.
  • Page 91 Engine Oil Pressure Gauge This gauge indicates the engine’s oil pressure, not the oil level. However, if your engine’s oil level is low, it could affect the oil pressure. With the engine running, the pointer should move into the NORMAL band. If the pointer drops below the NORMAL band while the engine is running, you have lost oil pressure and continued operation will cause severe engine damage.
  • Page 92 Warning Lights and Gauges High Beam Light This light comes on when the headlamps are turned on high beam or when you flash the lights. High beam indicator light symbol “Headlamps On” Alert Chime This chime sounds if you open the driver’s door while the headlamps or parking lamps are on, and the key is removed from the ignition.
  • Page 93 Fuel gauge — mechanical cluster with tachometer Engine Coolant Temperature Gauge This gauge tells you the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level or mixture, the gauge indicator will not be accurate. The pointer moves from the C (cold) mark into the Normal band as the engine coolant warms up.
  • Page 94 Warning Lights and Gauges If the coolant continues to overheat, have the coolant system serviced as soon as possible. Engine coolant temperature gauge — mechanical cluster with tachometer Speedometer The speedometer tells you how many miles (kilometers) per hour your vehicle is moving. Some vehicles are equipped with a vehicle speed (mph/km/h) limiting device that is contained within the Powertrain Control Module (PCM).
  • Page 95 Speedometer Odometer The odometer tells you the total number of miles (kilometers) your vehicle has been driven. Trip Odometer If you want to track your mileage up to 999.9 miles (kilometers), use the trip odometer. Simply set the trip odometer to zero by pressing the reset button firmly when beginning the distance you wish to measure.
  • Page 96 Some vehicles are equipped with an engine speed (RPM) limiting device contained within the Powertrain Control Module (PCM). The purpose of this device is to maintain peak engine speed (RPM) below a specified limit. This feature is only evident on automatic transmission vehicles when shifting manually (1, 2, D) and on all manual transmission units.
  • Page 97 The Electronic Message Center (If equipped) The Electronic Message Center (M/C) display, located in the center of the floor console, works only when your ignition is in the ON position. Each time the M/C is powered, the display goes through a self-test by displaying a blank message for two seconds.
  • Page 98 Warning Lights and Gauges Electronic message center English/Metric A press of the ENGLISH/METRIC switch allows you to change the M/C and electronic climate control displays from English to metric units. When you press this switch, all the displays change from English to metric or metric to English units. The displays remain in the units you have chosen until you change them again, even after you turn off the vehicle and start it again.
  • Page 99 To ensure accuracy, turn the ignition OFF when you fill the fuel tank. NOTE: Distance to empty is calculated using a “Running Average Fuel Economy” initialized by the factory. The value is not the same as the Average Fuel Economy Display.
  • Page 100 Warning Lights and Gauges Because of factors like rounding of numbers and fuel movement in the tank, the M/C and the service station fuel pump readings may disagree slightly. Fuel Economy A press of the FUEL ECON switch allows you to display one of two features (Average Fuel Economy or Instantaneous Fuel Economy).
  • Page 101 Fuel Economy cannot be reset. That is, these three features are unaffected by pushing the RESET switch. System Check A press of the SYSTEM CHECK switch causes the M/C to cycle through a status of each of the systems being monitored. For each of the monitored systems, the M/C will indicate either an OK message or a warning message for two seconds.
  • Page 102 for service as soon as possible. For Fuel Level, the first message will indicate the fuel level status (OK or LOW) and the second message will indicate the range (distance to empty). Message center operation during system check The M/C switches will operate as follows during the System Check sequence: A press of the SYSTEM CHECK switch will advance the cycle to the next system message without waiting the two...
  • Page 103 In the event of a multiple warning situation, the M/C will cycle the display to show all warnings by displaying each warning message for 4 seconds. Using the message center while a warning is active If you want to display the operator selectable features of the M/C while a warning is displayed, the warning message may be removed from the M/C display by pressing the RESET switch.
  • Page 104 Warning Lights and Gauges The following is a list of warning messages and their associated reset category: Check Engine Temp This warning message is displayed when the engine coolant is overheating. Stop the vehicle as soon as safely possible, turn off engine and let it cool.
  • Page 105 Low Fuel Level This warning message is displayed when you have approximately 50 miles (80 km) left before you run out of fuel. Low Oil Level This warning message is displayed when your engine oil level is low. If this warning message is displayed, check the level of the engine oil.
  • Page 106 If you use additional lights, such as trailer lights, or if you replace the headlamps or bulbs with equipment that is not equal to the original equipment from Ford, you may get a false “CHECK LAMPS” warning or no warning at all.
  • Page 107 An oil change is required whenever indicated by the M/C. USE ONLY RECOMMENDED ENGINE OILS (See Engine oil in the Index). The M/C will tell you the percent of oil life left during System Check. This percentage is based on your driving history and the time since your last oil change.
  • Page 108 Press the RESET switch to complete the procedure. A press of any switch besides RESET or OIL CHANGE RESET will abort this procedure and will not establish your new Personalized Oil Reset Percentage. When your Personalized Oil Reset Percentage has been established, it will be used beginning with the completion of your next OIL CHANGE RESET procedure.
  • Page 110 The main controls for the climate control system, lights, message center, lamps, clocks and radio are on the instrument panel. NOTE: Any cleaner or polish that increases the gloss (shine) of the upper part of the instrument panel should be avoided.
  • Page 111: Instrument Panel Controls

    Instrument Panel Controls and temperature you select. The function selector control knob allows you to select heating or cooling and determine where the air will be directed. The temperature control knob setting determines the temperature of the air that flows into the vehicle. Climate control knobs To turn your air conditioner and heater system on, select any position except OFF.
  • Page 112 H Fan speed adjustment The H (left) knob on the control is the fan control knob which controls the volume of air flow. Rotate the H knob to the right to increase fan speed and increase the amount of air entering the vehicle.
  • Page 113 Instrument Panel Controls S (Panel and Floor) Select S to direct airflow to the floor and through the instrument panel registers at the same time. This selection can be used to either heat or cool your vehicle. The air conditioner will operate to cool the air if the outside temperature is about 50˚F (10˚C) or warmer.
  • Page 114 Operating tips The following tips will help you to get the most satisfaction from your air conditioning and heater system. In humid weather, select V before starting your engine. This will help to prevent windshield fogging. After a few minutes of operation, you may select another function. To prevent humidity buildup inside your vehicle, always drive with the air conditioner or heater system turned on.
  • Page 115 Instrument Panel Controls Electronic automatic temperature control system To turn your EATC on, push the AUTOMATIC button or any of the six override buttons along the bottom of the control. To turn your EATC off, press the OFF button. When the system is off, the display window will be blank (dark) when the ignition is on.
  • Page 116 To change the temperature in the display window, select any temperature between 65˚F (18˚C) and 85˚F (29˚C) using the BLUE (cooler) or RED (warmer) buttons. The Electronic Automatic Temperature Control will do the rest. To change the temperature display from ˚F to ˚C or from ˚C to ˚F, press and hold the MAX A/C and the DEF V buttons at the same time for one second.
  • Page 117 Instrument Panel Controls Automatic operation Push the AUTOMATIC button and select the desired temperature. The selected temperature and AUTO will be shown in the display window. The EATC will automatically heat or cool to achieve the set temperature. Under normal conditions, your EATC will need no additional attention.
  • Page 118 When in AUTOMATIC and weather conditions require heat, air will be sent to the floor. However, a feature is included in your EATC to prevent blowing cold air to the floor if the engine coolant is not warm enough to allow heating. In 3 1/2 minutes or less, the fan speed will start to increase and the air flow will be to the floor area.
  • Page 119 Instrument Panel Controls The average temperature range used is between 68˚F (20˚C) and 78˚F (26˚C). Changing the temperature setting by several degrees outside this range will not speed up the heating or cooling process. Fan speed and thumbwheel Your EATC automatically adjusts the fan speed to the existing conditions.
  • Page 120 When you move the thumbwheel, the fan speed will go to manual control. The display window will show the H symbol in the upper left corner along with the selected temperature and operating function. You can override the fan speed at any time. If you use the thumbwheel to override the fan speed, the EATC will continue to control the temperature but you control the fan speed.
  • Page 121 Instrument Panel Controls Manual override buttons Your EATC has six buttons which allow you to make special selections. The buttons are located along the bottom edge of the EATC Control and allow you to determine where the air will be discharged.
  • Page 122 VENT Button Push this button to select outside air through the instrument panel registers. The display window will show the set temperature and VENT to the lower right of the temperature. Your EATC will heat the air if the temperature you have selected is warmer than the outside air coming into the vehicle.
  • Page 123 DEF V Button Press the defrost button to obtain maximum airflow to the windshield. Adjust the temperature setting as required for defrosting. The display window will show the temperature setting and V symbol to the left of the temperature. When the outside temperature is about 50˚F (10˚C) or warmer, the air will be dehumidified to remove moisture.
  • Page 124 To prevent humidity buildup inside your vehicle, always drive with the EATC System turned on. Do not put objects under the front seats that interfere with the flow of air to the back seat area. Remove any snow, ice, or leaves from the air intake area of your EATC System which could block the air intake.
  • Page 125 Instrument Panel Controls Rear climate controls...
  • Page 126 Rear Window Defroster (If equipped) The defroster for the rear window clears frost, fog, or thin ice from both the inside and outside of the rear window. The control switch is located on the instrument panel to the right of the radio. Rear window defroster switch To defrost the rear window: Clear any snow from the rear window.
  • Page 127: The Interior And Exterior Lights

    Liftgate Wiper and Washer (If equipped) The wiper/washer switch is to the right of the radio. To turn on the wiper, rotate the wiper/washer switch to the WIPE position. To select an interval wipe rotate switch between OFF and HI. To turn on the washer, push the switch all the way in and hold for spray.
  • Page 128 Rotate the thumb wheel when the headlamp control knob is in an “ON” position to brighten or dim the instrument panel lamps. Rotate fully upward to operate courtesy and cargo lamps. Headlamp control knob Setting the Autolamp Delay System (If equipped) The autolamp sets the headlamps to turn on and off automatically.
  • Page 129 Your vehicle may have one of the following autolamp systems depending on when it was built: If your vehicle is equipped with the first autolamp (with the ON/OFF button) use the following directions: To set the autolamp: Make sure the headlamp switch is in the OFF position. If the switch for the headlamps is ON, you cancel the autolamp.
  • Page 130 Turn the ignition key to ON or start your vehicle. Find the autolamp delay slide knob on the right hand side of the mirror. Slide the knob all the way to the left. Press the autolamp “On/Off” button. An indicator light will glow when the autolamp is on.
  • Page 131 The further you move the slide knob toward the right, the longer the headlamps stay on after you leave your vehicle. Similarly, if you move the slide knob only slightly toward the left, the headlamps stay on for only a moment after you turn your vehicle off.
  • Page 132 Cleaning the Exterior Lamps Do not use dry paper towel, chemical solvents or abrasive cleaners to clean the lamps, as these may cause scratches or crack the lamps. Daytime Running Light System (Canadian vehicles only) The Daytime Running Light (DRL) system turns the high beam headlamps on, with a reduced light output, when: The headlamp system is in the OFF position, and The vehicle has a fully released parking brake.
  • Page 133 Instrument Panel Controls Cargo and Map Lamps The cargo lamp is located on the roof headliner near the liftgate. The lamp will come on whenever the driver’s door or passenger’s door is open or when the headlamp switch thumbwheel is rotated fully upward. Cleaning the Interior Lamps Your interior dome lamps and map lamps are plastic and should be cleaned with a mild detergent diluted in water.
  • Page 134 Map lamps (if equipped) High-mount Brakelamp The high-mount brakelamp is located outside the vehicle, directly over the rear window. High-mount brakelamp Clock Controls on Electronic Radios The electronic radios have a built-in clock. For complete operating instructions, refer to Electronic Sound Systems in this Owner Guide.
  • Page 135: Steering Column Controls

    The controls on the steering column and wheel are designed to give you easy access to the controls while you are driving. The Turn Signal Lever You can use the turn signal lever on the left side of the steering column to: operate the turn signals and cornering lamps turn the high beams on/off...
  • Page 136: Windshield Wipers And Washer

    High Beams and Flashing the Lamps Headlamp high beam switch and turn signal lever on steering column Windshield Wipers and Washer To turn on the windshield wipers, the ignition key must be turned to the ON or ACC position. Interval wiper on turn signal lever To set the interval wipers, rotate the knob at the end of the turn signal lever toward or away from the instrument panel to the interval operation you desire.
  • Page 137: Steering Column Controls

    To clean the windshield, push in the end of the wiper knob for a single wipe. For a constant spray, keep the knob pushed in. After you release the knob, the wipers operate for two to three cycles before turning off (if wipers were off) or returning to the interval setting selected.
  • Page 138 Gearshift Lever (Automatic transmission only) The gearshift lever on your Explorer is mounted on the steering column. On the end of the gearshift lever is the Overdrive On/Off button. For additional information about the gearshift lever and the Overdrive On/Off button, see the Driving Your Explorer chapter.
  • Page 139 Hazard Flasher The hazard flasher is used to alert other drivers to hazardous situations. The flashers will flash and the high-mount brakelamp will stay on steadily (not flash) with the brake pedal depressed. The flashers work whether your vehicle is running or not. The flashers work for up to two hours when the battery is fully charged and in good condition without draining the battery excessively.
  • Page 140 Horn To sound the horn, press the center of the horn pad. Check the horn regularly to make sure it operates properly. Horn location Tilt Steering (If equipped) Never adjust the steering column/wheel when the vehicle is moving. You could lose control of the vehicle and injure someone.
  • Page 141 To change the position of the steering wheel, push the release lever under the steering column away from you. Tip the steering wheel to the desired position. Pull the lever back into place to lock the steering wheel. Be sure the steering wheel locks in a notch. It is not infinitely adjustable.
  • Page 142 Press SET ACCEL switch and release it immediately. This will set your speed. If you keep this switch pressed, your speed will continue to increase and will not be set until the switch is released. Take your foot off the accelerator pedal. Your vehicle will maintain the speed you set.
  • Page 143 Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved. In mountainous areas, at higher elevations, or when pulling a trailer, the speed control may not be able to maintain the preset speed with the transmission in j (Overdrive).
  • Page 144 Transmission control switch Accelerating With the Speed Control Operating You can use the accelerator pedal to speed up momentarily. When you take your foot off the accelerator, the vehicle will return to the set speed. Resetting the Speed Control To reset the speed control to a lower speed, press and hold the COAST switch.
  • Page 145 TAP-UP — This allows you to increase your current speed in increments of 1 mph (1.6 km/h) by a momentary tap of the SET-ACCEL switch. Multiple taps of the SET-ACCEL switch will increase your vehicle speed 1 mph (1.6 km/h) for each tap.
  • Page 146 Cancelling and Resuming a Set Speed If you press the brake pedal, the speed control is cancelled. You can return to the speed you set by using the RSM switch, as long as you did not press the OFF switch. To resume the speed you had before, you must be driving at least 30 mph (50 km/h).
  • Page 147 Features Your vehicle has a variety of features designed for your comfort, convenience and safety. Read this chapter to find out about standard and optional features. Doors Door Handles and Locks Inside handles...
  • Page 148 Outside handles and locks Two step unlock feature (if equipped) This feature allows you to unlock all vehicle doors with the key. Unlock driver door with key. Repeat unlock procedure within 5 seconds. All doors will unlock when the key is returned to the vertical position (position of the key before removal).
  • Page 149: Features

    Features Setting the Childproof Locks for the Rear Doors In addition to standard or power locks, your vehicle has childproof locks for the rear doors. If you set these locks, the rear doors cannot be opened from the inside of the vehicle. The doors can still be opened from the outside when the lock knobs are raised.
  • Page 150 Liftgate Handle and Locks Liftgate handle and locks You can unlock the liftgate by using the key. To open the liftgate, rotate the handle clockwise and to open the liftgate window, rotate the handle counterclockwise. You can lock the liftgate by using the key, pushing the lock button down, or using the power door lock switch on the left side of the cargo area.
  • Page 151 Cargo Area Shade (If equipped) This removable shade hides cargo and also secures lightweight objects in the cargo area of your vehicle. To install the shade: Position the shade in the mounting brackets located behind the rear seat on each rear trim panel. The tongue end of the shade should face the rear of your vehicle.
  • Page 152 The cargo shade The shade is a wind-up type, just like a window shade. Over time the shade may lose its spring tension. If this happens, you can easily rewind the shade with the help of another person. To rewind the shade: Remove the shade from its side anchor slots by compressing telescoping tube.
  • Page 153 Fold the edges of the vinyl toward the center. Make sure the edges of the vinyl clear the end cap slots (see Figure 2). Use masking tape or a rubber band to hold the vinyl on the left side of the roller tube. While holding the vinyl and roller tube as shown in Figure 2, push the right end cap (marked with an “R”) about 1/4 inch to disengage the clutch.
  • Page 154 Figure 2 Let go of the right end cap. The clutch should now engage and stop the shade from losing its spring tension. Unfold the vinyl and place it into the end cap slots. With the vinyl fully wound around the roller tube, insert the shade into the side mounting brackets.
  • Page 155 Features Power Door Locks (If equipped) The power door lock switches are located in the front doors and in the driver side trim panel of the cargo area. To lock all doors push the switch button marked L. To unlock all doors push the switch button marked U.
  • Page 156 Using the Keyless Entry System (If equipped) If your vehicle has the keyless entry system, you can lock or unlock the vehicle doors without using a key. The buttons for the system are near the outside door handle on the driver’s side.
  • Page 157 Programming your own entry code You can program a personal code to unlock your vehicle with the keypad. This code does not replace the permanent code that the dealership gave you. Use your personal code in the same manner as you would your original code. To program your own code: Select five digits for your personal code.
  • Page 158 Unlocking the doors with the keyless entry system You must unlock the driver’s door before you unlock any of the other doors. If you let more than five seconds pass between pressing numbers, the system shuts down, and you have to enter the code again.
  • Page 159 Autolock (With automatic transmission vehicles only) The Autolock feature is part of your remote keyless entry system and is enabled at the factory. With the Autolock feature enabled, all of the doors will automatically lock when: the vehicle doors, liftgate and liftgate window are fully closed the ignition key is turned to the ON position the brake pedal is pressed...
  • Page 160 Within 5 more seconds, press and release 3/4. Release 7/8. To reactivate the Autolock system, simply repeat the instructions for deactivating the system. By re-entering the code that deactivates the Autolock, the keyless entry system reinstates the Autolock feature. You can also deactivate or reactivate the Autolock feature by this method: Make sure the anti-theft system is not armed or triggered, ignition is off, and all doors and liftgate window are closed.
  • Page 161 Features Remote Entry System (If equipped) If your vehicle has the remote entry system, you can lock or unlock the vehicle doors and liftgate without using a key. The remote also has a personal alarm feature. The buttons for the system are located on the two hand held transmitters that came with your vehicle.
  • Page 162 and the liftgate window are completely closed, the doors and liftgate will lock again, the horn will chirp and the external lamps will flash. If a door, liftgate or the liftgate window is open or ajar, the horn will give two short chirps warning you that a door or the liftgate is open.
  • Page 163 The remote entry system may not arm and disarm non-factory installed anti-theft systems. Remote Memory Seat Feature (If equipped) Your vehicle allows the remote keyless entry system to control the Memory Seat system (see Memory Seat section of this Owner Guide).
  • Page 164 2016 batteries (included) that should last for several years of normal use. If you notice a significant decrease in operating range, the batteries should be replaced. Replacement batteries can be purchased at most pharmacies, watch stores or at your Ford or Lincoln-Mercury dealer.
  • Page 165 NOTE: The operating range of the remote entry system can also be affected by weather conditions (such as very cold temperatures) or structures around the vehicle (buildings, other vehicles, radio and TV towers, etc.). Typical operating range will allow you to be up to 33 feet (10 meters) away from your vehicle.
  • Page 166: Battery Saver

    Replacing lost transmitters In the event a transmitter is lost, you should take your vehicle’s transmitters to your dealer to have the remote entry system deprogrammed for the lost transmitter. This is necessary to prevent further unauthorized use of the lost transmitter. You can also purchase additional transmitters (up to 4 transmitters can be used) from your dealer.
  • Page 167 This will prevent draining of the battery if these lights have been left on inadvertently or if a door or the liftgate is not completely closed. Battery voltage to these lamps will be restored when the remote entry transmitter is used, any door is opened, the liftgate is opened, or the ignition key is turned ON again.
  • Page 168 Close all doors, liftgate and liftgate window Once all doors, liftgate and liftgate window are closed, if any were open, the system will begin a 30 second countdown to become armed. The 30 second countdown allows people who may still be in the vehicle time to exit without triggering the alarm.
  • Page 169 When unlocking the vehicle with a key, turn the key all the way to the end of its travel or the system may not disarm. NOTE: The flashing lights and honking horn will shut off automatically within 2 minutes 45 seconds after the system is triggered.
  • Page 170 In 4WD Low, the automatic ride control system raises the vehicle approximately two inches above its lowest height. Shock dampening is locked in firm mode. The height change improves body clearance. The combination of firm dampening and the height change also provides maximum suspension feedback for improved off-road safety and performance.
  • Page 171 Features Automatic Ride Control service switch Windows Operating the Windows Manually The door windows are opened and closed by turning the handle crank. Manual window operation...
  • Page 172 Flip quarter window (2 door model only) To open, press outward on the window latches, then depress the levers on each side of the latch and pull inward. Move the latch out and into the open position. To close, depress the levers on each side of the latch.
  • Page 173 To close the window, hold the window switch to the up position until the window closes. Do not let children play with the power windows. They may seriously hurt themselves. Make sure occupants are clear of the window(s) before closing. Master control switch RWARNING Features...
  • Page 174 Seats Four-Way Head Restraints (If equipped) Adjust the head restraints so that the cushion contacts the back of your head when you move your head rearward. The head restraint may be adjusted in four directions. To raise or lower the head restraint, push in the lock release button. The button is located on the outboard side of the post of the head restraint for the driver’s side and the inboard side for the passenger side.
  • Page 175 Adjusting the bucket seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. To reduce the risk of serious injury in a collision, always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 176 Reclining Bucket Seats (If equipped) You can tilt the seat back of your bucket seats backward. On the outboard side of the seat, lift the recliner handle up and hold it in place. Lean against the back of the seat and adjust it to the position you want.
  • Page 177 Folding Rear Seat 2 door models To fold down the rear split seat: Rotate the head restraint fully forward. Lower the head restraint to the top of the seatback. Pull upward on the latch release handle at the side of the seatback, while pulling the seatback forward with the other hand.
  • Page 178 To fold down the rear split seat: Push the lower release handle (located on side of seat) downward to unlatch the seat back latch. Rotate the seat downward into the latched load floor position. NOTE: When you hear a “click” type sound, this ensures the seatback will be in the latched load floor position.
  • Page 179 Reclining Rear Seat (If equipped) To recline the rear seatback: Turn the recliner handle (upper handle) rearward while pushing the seatback rearward. To return the seatback from the recline position: Turn the recliner handle (upper handle) rearward. The seatback will automatically return to its upright position. Features...
  • Page 180 Tilt Slide Seat (If equipped) 2 door models only With the front seatback tilted forward, the tilt slide seat can be moved to provide additional entry space to access the rear seat compartment of the vehicle. To operate the tilt slide seat: Lift the seatback release lever on the outboard side of the seat cushion to unlock the slide mechanism and seatback.
  • Page 181 Features Tilt slide seat Prior to operating the vehicle, check to ensure that the seat assembly is locked by pushing or pulling the seat forward or rearward. If seat does not lock, repeat steps 2 and 3. Locking tilt slide seat...
  • Page 182 To operate the seat adjuster: To adjust the seats forward or rearward, locate the release bar at the lower front area of the seat cushion. Lift the release bar and hold until the desired seat position is obtained, then release the bar to relock the seat. Adjusting seat 60/40 Split Front Bench (If equipped) The seat back release operates the same as the basic bucket seat.
  • Page 183 Features Using the Power Seats (If equipped) If your vehicle has the power seat option, you can adjust it in several directions. The controls are on the outboard side of the seat. The power controls on the driver’s seat Three Person Memory Seats — Explorer Limited Only Your Explorer Limited has a three person memory driver seat which includes power tracks.
  • Page 184 The power controls on the driver’s seat To adjust the infinite position seatback, pull up on the handle while leaning against the back of the seat. Release the handle to lock the seat in its new position. You can tilt the seat back or bring it forward.
  • Page 185 For an alternative memory position, place seat in the second desired position, depress the “SET” button, then press the “2” button within 5 seconds or until the light goes off. For the third memory position, move the seat to the desired position, depress the “SET”...
  • Page 186 Power lumbar and side bolsters switch — sport bucket seat Cleaning the Seats Fabric Remove dust and loose dirt with a whisk broom or a vacuum cleaner. Remove fresh spots immediately. Follow the directions that come with the cleaner. NOTE: Before using any cleaner, test it on a small, hidden area of fabric.
  • Page 187 Positive Location Floor Mats (If equipped) Installation Move driver’s seat to most rearward position. Locate driver’s side floor mat in vehicle with rear of mat against left (outboard) front edge of seat track mounting bracket (see Figure 1). Use a screwdriver to screw locator post into vehicle carpeting.
  • Page 188 Mirrors Automatic Dimming Inside Rearview Mirror (If equipped) The automatic non-glare mirror The electronic day/night mirror will change from the normal state to the non-glare state when bright lights (glare) reach the mirror. This mirror functions at night, and has a limited function at dusk or dawn.
  • Page 189 Features The electronic mirror measures the brightness of the light coming in from the rear of the vehicle. It automatically makes a correction in the glare state. The mirror may be turned off in either the normal or non-glare position. There are two light sensors (photocells) in this mirror.
  • Page 190 Illuminated Vanity Mirror (If equipped) Your vehicle may feature illuminated vanity mirrors on the sun visors. You can turn on the lighted mirror by lifting the mirror door cover. Visor vanity mirror Visors that are equipped with the lighted vanity mirror also have an auxiliary visor.
  • Page 191 Dual Electric Remote Control Mirrors (If equipped) To adjust the remote controlled side mirrors: Find the control switch in the driver’s door panel. Select the right or left mirror by moving the selector switch to the right or left. Move the control knob in the direction you want to move the mirror.
  • Page 192 Rear Storage Compartment with Net (If equipped) Your vehicle may have a small storage compartment which is located on the inside rear passenger quarter panel. This compartment has a net which will secure small objects. Rear storage compartment with net Moon Roof (If equipped) You can move the moon roof back to open the glass panel, or you can tilt it up to ventilate the vehicle.
  • Page 193 Features The moon roof has a sliding shade that you can manually open or close to block the sun when the glass panel is shut. To close the sliding shade, pull the shade toward the front of the vehicle. The shade automatically opens when the moon roof is opened.
  • Page 194 Your vehicle may have a full console. The full console has the features shown in the illustration below. NOTE: Ford recommends the use of 12 oz. (355 ml.) beverage cans in the cupholder. With manual transmissions there may be an interference of the shift lever, when in reverse, with taller beverage cans.
  • Page 195 Features Storage armrest — 60/40 split bench...
  • Page 196 High series console Replacing the Tissue Box Slide coinholder/tissue tray out of the console in an upward motion. Replace tissue box. Slide coinholder/tissue tray into console locating pins at bottom of tray. Fit in slots in console bracket.
  • Page 197 Overhead Console (If equipped) Your Explorer comes with an overhead console located between the sun visors. The console includes: Compass/temperature display Map lamps Storage compartment Compass/Temperature display This display provides the outside temperature and the compass direction of the vehicle. The MODE button is used to select one of the following features: Display Off...
  • Page 198 Electronic compass Factors affecting compass accuracy The compass reading can be affected when you drive near a number of things — such as large buildings, bridges, power lines, and powerful antennas. Your compass can also be affected by magnetic or metallic objects placed in or on the vehicle.
  • Page 199 Zone map Press and hold the “MODE” button until the “VAR” indicator appears in the display (approximately 4 seconds). Release the “MODE” button. The display will now show the current zone number that is stored in the compass. Press the “MODE” button repeatedly (or press and hold in) until the desired zone number appears in the display (once it reaches 15, the next press of the button will set it to 1).
  • Page 200 Calibration adjustment: Find an open area that is free from steel structures and high voltage lines. An open parking lot is a good example. Press and hold the “MODE” button until the “CAL” indicator appears in the display (approximately 8 seconds). NOTE: You cannot perform calibration unless the display reads “CAL.”...
  • Page 201 Features Storage Compartment (If equipped) The storage compartment can be accessed by pushing the “OPEN” button. The door will open approximately one inch then it can be manually moved to the full open position. The compartment can be used to store a variety of items such as: tissues, parking pass, cigarettes or sunglasses.
  • Page 202 Installing “aftermarket” transmitter Place the piece of Velcro hook onto your aftermarket transmitter, opposite side as that of the actuator button. Place the transmitter into the console housing, button down, as shown. Place the height adapters provided into the back side of the “GARAGE”...
  • Page 203 Rear Console (If equipped) Your Explorer comes with a rear console that is located between the bucket seats. The console includes: Air vents, with rear seat controls Radio controls Beverage holder Rear console Features...
  • Page 204 Power Point Electrical Outlet The power point outlet should be used in place of the cigarette lighter for optional electrical accessories. NOTE: Do not plug optional electrical accessories into the cigarette lighter. Use the power point. Power point electrical outlet Power point electrical outlet (high series console)
  • Page 205 Features Luggage Rack (If equipped) Loading the Luggage Rack If your vehicle is equipped with the luggage rack, load your luggage as far back as it will safely go on the rack. Do not carry more than 100 pounds (45 kg) or cause the vehicle to exceed the gross vehicle weight rating (GVWR) or its gross axle weight rating (GAWR front and rear), which are shown on the Safety Compliance Certification Label.
  • Page 206 The rear rack can be completely removed in the “UNLOCKED” position by sliding the crossbar toward the rear of the vehicle until it becomes free of the guide rails. “D” Ring Adjustment The luggage rack has two “D” rings (one on each side of the luggage rack guide rails) that can be adjusted to secure cargo.
  • Page 209: Electronic Sound Systems

    Luxury Audio System Using the Controls on Your New Radio How to turn the radio on and off Press the “VOL/PUSH ON” knob to turn the radio on. Press again to turn it off. How to adjust the volume Turn the “VOL/PUSH ON” knob clockwise to increase the volume and counterclockwise to decrease the volume.
  • Page 210 How to tune radio stations There are four ways for you to tune in a particular station. You can use the “TUNE”, “SEEK”, “SCAN” or memory buttons. Using the “TUNE” function You can change the frequency up or down one increment at a time by pressing and releasing either the left ( b ) or right ( a ) side of the “TUNE”...
  • Page 211 Select a band, then select a frequency. Press one of the memory buttons and hold until the sound returns and the lamp above the memory button lights up. That memory button is now set. Follow the above steps for each memory preset button. Using the Automatic Memory Store feature (“AUTOSET”) If the memory buttons have been set, either by using the Auto...
  • Page 212 Adjusting the tone balance of your radio Increasing or decreasing bass and treble response Push the “BASS/TREB” popout knob to gain access to the bass and treble controls. Bass control allows you to adjust the lower, bass frequencies to your preference. The outer ring of the “BASS/TREB”...
  • Page 213 Using the Digital Signal Processing (DSP) Feature Push the “DSP” button to activate the feature. The display will indicate which signal mode is in effect. To change the signal mode press either the left ( b ) or right ( a ) side of the selector button (located under the “DSP”...
  • Page 214 Using the Controls of Your Cassette Tape Player NOTE: Radio power must be on to use the cassette tape player. How to insert a tape Your cassette tape player is equipped with power loading. Once you insert a tape and push slightly (with the open edge to the right), the loading mechanism draws the tape the rest of the way in and play will begin after a momentary tape tightening process.
  • Page 215 Using the “SEEK” function with your cassette tape player While in the tape mode, push the right ( a ) side of the “SEEK” button to seek forward to the next selection on the tape. Push the left ( b ) side to restart a currently playing tape selection.
  • Page 216 How to store the tape Press the “AM/FM” button to stop the tape player and resume radio play. Using the Dolby B noise reduction feature NOTE: Noise reduction system manufactured under license from Dolby Labs Licensing Corporation. “Dolby” and double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
  • Page 217 Rear Seat Radio Controls How to turn the rear seat radio controls on and off Press memory preset buttons “3” and “5” simultaneously on the face of your radio to turn the rear seat radio controls on. A headphone symbol (j) will appear in the display when the rear seat controls are on.
  • Page 218 In order to keep your cassette tape player performing the way it was meant to, read and follow these simple precautions: Using a Ford Cassette Cleaning Cartridge to clean the tape player head after 10-12 hours of play will help maintain the best playback sound and proper tape operation.
  • Page 219 Protect cassettes from exposure to direct sunlight, high humidity and extreme heat or cold. If they are exposed to extreme conditions, allow them to reach a moderate temperature before playing. If a tape is loose inside the cassette, tighten it before playing by putting your finger or a pencil into one of the holes and turning the hub until the tape is tight.
  • Page 222 Premium Stereo Cassette and Stereo Cassette with CD DJ Using the Controls on Your New Radio How to turn the radio on and off Press the “VOL/PUSH” knob to turn the radio on. Press again to turn it off. How to adjust the volume Turn the “VOL/PUSH”...
  • Page 223 How to tune radio stations There are four ways for you to tune in a particular station. You can use the “TUNE”, “SEEK”, “SCAN” or the memory buttons. Using the “TUNE” function You can change the frequency up or down one increment at a time by pressing and releasing either the left ( b ) or right ( a ) side of the “TUNE”...
  • Page 224 Setting the station MEMORY PRESET buttons Your radio is equipped with 6 station memory buttons. These buttons can be used to select up to 6 preset AM stations and 12 FM stations (6 in FM1 and 6 in FM2) Follow the easy steps below to set these buttons to the desired frequencies: Select a band, then select a frequency.
  • Page 225 Adjusting the tone balance of your radio Increasing or decreasing bass response Press the top ( c ) of the “BASS” button to increase bass; press the bottom ( d ) of the “BASS” button to decrease bass. Increasing or decreasing treble response Press the top ( c ) of the “TREBLE”...
  • Page 226 Using the Controls of Your Cassette Tape Player NOTE: Radio power must be on to use the cassette tape player. How to insert a tape Your cassette tape player is equipped with power loading. Once you insert a tape and push slightly (with the open edge to the right), the loading mechanism draws the tape the rest of the way in and play will begin after a momentary tape tightening process.
  • Page 227 Using the “SEEK” function with your cassette tape player While in the tape mode, push the right ( a ) side of the “SEEK” button to seek forward to the next selection on the tape. Push the left ( b ) side to seek the previous tape selection.
  • Page 228 Push the k button to activate Dolby B Noise Reduction. Push again to deactivate. Two mini 3.5mm (1/8") jack headphone sets may be used with the headphone jacks on your Rear Seat Radio Controls. Ford approved headphones are also available for purchase by calling 1-800-231-4429.
  • Page 229 Loose labels on cassette tapes can become lodged in the mechanism. Remove any loose label material before inserting cassette. Do not leave a tape in the cassette tape player. High heat in the vehicle can cause the cassette to warp. Clock Operation How to view the clock mode Press the “CLK”...
  • Page 230 Ford 6-CD Changer (If equipped) The Ford Explorer 6-CD Changer is mounted in your center console and holds 6 CDs, all controlled by using buttons on the Audio System. Unit Loading Instructions Open Compact Disc Changer unit by sliding door rearward (Figure 1).
  • Page 231 Push the “i” button to eject the disc “magazine” (holds 6 discs) (Figure 2). Figure 2 Load discs into the disc magazine slots (numbered 1 through 6) one at a time with labeled surfaces upward, starting with bottom slot number 1 (Figure 3). Figure 3 Electronic Sound Systems...
  • Page 232 How to Operate the Ford 6-CD Changer Using the Controls on the Radio (Luxury and Premium Audio Systems only) If your vehicle is equipped with the Ford 6-CD Changer System, you can operate it through the controls of your Luxury or Premium Audio System.
  • Page 233 If the CD Changer is empty, “NO” and “DISC” will flash in the display and radio play will continue. How to change the disc being played When in the CD mode, you can change discs by pressing the right side ( a ) of the “TUNE DISC” button (to select the next discs) or the left side ( b ) of the “TUNE DISCS”...
  • Page 234 Operating the CD Compression feature Because of the wide dynamic range of Ford’s 6-CD Changer System, soft passages may be difficult to hear under certain driving conditions while maintaining a reasonable volume level in the louder passages. The compression feature will bring these soft and loud passages closer together for a more consistent listening level.
  • Page 235 CD format. Because of this, a new disc that is free of dust and scratches could be defective and may not play on your Ford Compact Disc Player. If play does not begin after the CD button is pushed: The radio is not on.
  • Page 236 If the sound skips: Badly scratched discs or extremely rough roads will cause the sound to skip. Skipping will not damage the disc player or scratch the discs. How to take care of and clean the CD Changer and discs To ensure the continued performance of your CD Changer carefully read the following precautions: Always handle a disc by the edge.
  • Page 238 Midline Stereo Radio Using the Controls on Your New Radio How to turn the radio on and off Press the “VOL/PUSH ON” knob to turn the radio on. Press again to turn it off. How to adjust the volume Turn the “VOL/PUSH ON” knob clockwise to increase the volume and counterclockwise to decrease the volume.
  • Page 239 Using the ”TUNE“ function You can change the frequency up or down one increment at a time by pressing and releasing either the left ( b ) or right ( a ) side of the ”TUNE“ button. Manual tuning adjusts your radio to any allowable broadcast frequency, whether or not a station is present on that frequency.
  • Page 240 Press one of the memory preset buttons and hold the button until the sound returns. That station is now held in memory on that button. Follow the two steps above for each station memory preset button you want to set. Adjusting the tone balance and speaker output of your radio Increasing or decreasing bass response...
  • Page 241 Clock Operation How to view the clock mode Press the ”CLK“ button to display time. The time will continue to be displayed until a radio or tape function is chosen. After approximately 10 seconds, the time will again appear in the display.
  • Page 242 Terrain The terrain (hilly, mountainous, tall buildings) of the area over which the signal travels may prevent the FM signal from being noise-free. If there is a building or large structure between the antenna and station, some of the signal ”bends“ around the building, but certain spots receive almost no signal.
  • Page 243 Ask your dealer for a copy of this limited warranty. Service At Ford Electronics, we stand behind our audio systems with a comprehensive service and repair program. If anything should go wrong with your Ford audio system, return to your dealer for service.
  • Page 244 Notes...
  • Page 245: Driving Your Explorer

    Procedures for driving your vehicle will vary depending on which type of transmission your vehicle has. a manual transmission an Automatic Overdrive Transmission 4R55E or 4R70W Automatic Transmission Operation 4R44E/4R55E/4R70W The 4R44E, 4R55E and 4R70W transmissions are electronically controlled four speed overdrive automatic transmissions with lockup torque converter.
  • Page 246 Overdrive Off Indicator Light is flashing, contact your Ford dealer as soon as possible. If this condition persists, damage to the transmission could occur. Putting Your Vehicle in Gear Your vehicle’s gearshift is on the steering column. The transmission control switch is located on the end of the gearshift lever.
  • Page 247: Driving Your Explorer

    Hold the brake pedal down while you move the gearshift lever from position to position. If you do not hold the brake pedal down, your vehicle may move unexpectedly and injure someone. Once you place the gearshift securely into position, gradually release the brake pedal and use the accelerator as necessary.
  • Page 248 R (Reverse) With the gearshift in the R (Reverse) position, the vehicle will move backward. You should always come to a complete stop before shifting into or out of R (Reverse). N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll.
  • Page 249 Driving Your Explorer Transmission control switch (located on the end of the gearshift lever) To return the transmission to the normal j Overdrive operation, press the transmission control switch again. The Transmission Control Indicator Light will not be illuminated when Overdrive operation resumes. This switch may be used to select O/D ON or O/D OFF any time the vehicle is being driven.
  • Page 250 P (Park) Always come to a complete stop before you shift into P (Park). This position locks the transmission and prevents the rear wheels from turning. To securely latch the gearshift in the P (Park) position, pull it toward you, push it completely counterclockwise against the stop, and then push it toward the instrument panel.
  • Page 251: Manual Transmission Operation

    Driving Your Explorer Manual Transmission Operation Using the Clutch Make sure the gearshift lever is in the N (Neutral) position and your right foot is holding down the brake pedal. Then press the clutch pedal to the floor with your left foot. Manual transmission vehicles have a starter interlock switch.
  • Page 252 Backing up To shift into R (Reverse): Push the clutch pedal in all the way to the floor and hold it. If you do not hold the clutch pedal in all the way, you may hear a grinding noise when you shift. Bring your vehicle to a complete stop.
  • Page 253 Driving Your Explorer Recommended Shift Speeds Engines with 5-Speed Manual Overdrive Transmission...
  • Page 254 When you slow down or climb a steep hill, always downshift before the engine starts to lose power. Downshifting reduces the chance of stalling and gives your vehicle better acceleration to increase speed again. When you drive down steep hills, downshifting helps you keep a safe speed and helps prevent unnecessary wear on the brakes.
  • Page 255: Steering Your Vehicle

    Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Steering Your Vehicle Your vehicle comes with power steering. Power steering uses energy from the engine to help steer your vehicle. If the amount of effort needed to steer your vehicle changes at a constant vehicle speed, have the power steering system checked.
  • Page 256 Four-Wheel Drive (4WD) System (If equipped) When you select the 4WD mode, your vehicle uses all four wheels to power itself. This increases traction, enabling you to drive your 4x4 over terrain and road conditions not travelled normally by two-wheel drive vehicles. Power is supplied to all four wheels through a transfer case that allows you to select four-wheel drive when necessary.
  • Page 257 Driving Your Explorer 4WD LOW mode — Only the 4WD LOW light is lit. To shift from Two-Wheel Drive to 4WD AUTO: To shift into 4WD AUTO, rotate the 4WD switch located on the instrument panel to 4WD AUTO. This shift can be done at a stop or on the fly.
  • Page 258 To shift from 4WD AUTO or 2WD to 4WD LOW: Stop the vehicle, depress the brake and place the automatic transmission in N (Neutral) or depress the clutch on vehicles with a manual transmission. Rotate the 4WD switch on the instrument panel to 4WD LOW.
  • Page 259 4WD. For more information on driving off-road, see Driving Off Road with 4-Wheel Drive and AWD and the Four Wheeling With Ford supplement in your owner’s portfolio. Driving Off Road with 4-Wheel Drive and AWD...
  • Page 260 Sand When driving over sand, try to keep all four wheels of the vehicle on the most solid area of the trail. Do not reduce the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply accelerator slowly and avoid spinning the wheels.
  • Page 261 When climbing a steep hill, start in a lower gear, rather than finding it necessary to downshift from a higher gear after the ascent has started. This reduces strain on the engine and the possibility of stalling. When descending a steep hill avoid sudden braking. Rapid pumping of the brake pedal will help slow the vehicle and still maintain steering control.
  • Page 262 Rear Disc Brakes The rear disc brakes are self-adjusting. They do not require any service other than periodic inspection for pad wear. Hydraulic Power Brakes The hydraulic brake system is made up of two independent hydraulic circuits. One hydraulic circuit supplies fluid to the front disc brakes and the other hydraulic circuit supplies fluid to the rear drum or disc brakes.
  • Page 263 The Anti-lock system does NOT assist the vehicle in stopping quickly on wet or icy surfaces. Heavy braking combined with poor road conditions could cause you to lose steering control of your vehicle. Using anti-lock brakes The operation of a vehicle with 4WABS is not similar to the operation of normal brakes.
  • Page 264 Anti-lock system. NOTE: Mobile phones or radio transmitters not installed by Ford Motor Company may interfere with the Anti-lock System. Should the Anti-lock system activate unexpectedly or the Anti-lock Warning Light illuminate after installation of such a unit, have the installation of the unit checked.
  • Page 265 If Brakes Pull Check tire pressure. If pull occurs during the first 500 miles (800 km), make 10 moderatley fast stops from 40 mph (64 km/h). It may be necessary to repeat this operation to properly seat new brakes. If pull occurs during the first 500 miles (800 km), make 10 moderately fast stops from 40 mph (65 km/h) and then perform the self-adjustment procedure above.
  • Page 266 Using the Parking Brake The parking brake should be used whenever you park your vehicle. The parking brake pedal is suspended just below the bottom of the instrument panel to the left of service brake and/or clutch pedals. To set the parking brake while parking your vehicle, press the brake pedal with your right foot and hold it while you push the parking brake pedal down firmly and fully with your left foot.
  • Page 267 When parking, do not use the gearshift in place of the parking brake. Turn the key to LOCK whenever you leave your vehicle. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission).
  • Page 268 For 4x4 vehicles, engage 4WD, and try to drive away. High Speed Driving Ford Motor Company recommends obeying posted speed limits. Driving too fast for conditions creates the possibility of loss of vehicle control. Driving at very high speeds for extended periods of time may result in damage to vehicle components.
  • Page 269 Driving in Bad Weather Slippery roads Drive cautiously on wet or snowy roads: Do not quickly move the steering wheel unless necessary. Drive slower than you normally would. Give your vehicle more distance to stop. Pump the brake pedal steadily and evenly to avoid locking your front wheels (except with 4WABS).
  • Page 270 To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire. High water Never attempt to cross water that is fast flowing or of unknown depth. Do not drive through flooded areas unless you are sure that the water is below the bottom of the wheel hubs.
  • Page 271 engine and transmission, causing damage to both. In addition, other vehicle systems and components may also be damaged. Do not spin the wheels at over 35 mph (55 km/h). The tires may fail and injure a passenger or bystander. Driving With a Heavy Load There are limits to the amount of weight your vehicle can carry or tow.
  • Page 272 Trailer Towing (may require trailer tow option package) Towing a trailer puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires and suspension. For your safety and for the good of your vehicle, use the right equipment for the type of trailer you tow. Your trailer towing capability will vary based on the standard and optional equipment on your vehicle.
  • Page 273 Trucks, unlike passenger cars, are basically custom vehicles designed to carry a load. Most owners start with a base vehicle and add production and dealer installed and/or aftermarket components to suit their tastes and purposes. Even trucks that are purchased for personal transportation only are likely to have considerable optional equipment, such as step bumpers and light bars, for example.
  • Page 274 Safety Compliance Certification Label Do not use the sample numbers on the Safety Compliance Certification Label shown. Use the actual numbers from your vehicle certification label. Understanding Loading/Towing Information The following terms are used to describe the ability to carry or tow a load: Base Curb Weight Payload...
  • Page 275 GCWR (Gross Combined Weight Rating) Maximum Trailer Weight Rating Maximum Trailer Weight Trailer Weight Range Base Curb Weight The Base Curb Weight is the weight of the vehicle including fuel, coolants, lubricants, emergency tools, spare wheel and tire. It also includes any equipment that is standard on that model. It does not include passengers, cargo or optional equipment installed by factory, dealer, aftermarket supplier or customer.
  • Page 276 Gross Axle Weight Rating (GAWR) We have all seen a car or a truck that is loaded down in the rear and riding high in the front. This is a dangerous condition that usually means that the rear suspension components are under severe strain and that vehicle handling is impaired.
  • Page 277 GCWR (Gross Combined Weight Rating) GCWR is the maximum combined weight of the towing vehicle (including passengers and cargo) and the loaded trailer. The GCWR is specified by the manufacturer to indicate the combined maximum loaded weight that the vehicle is designed to tow.
  • Page 278 — If you do not plan on pulling a trailer, do not include these ratings into your calculations. Weigh your vehicle as you customarily operate the vehicle (without cargo). Subtract the total weight of passengers, driver and optional equipment added by the factory, dealer or aftermarket supplier to determine how much cargo weight you can carry.
  • Page 279 Use this chart to perform your calculations. NOTE: The Truck Safety Compliance Certification Label has two weight related entries that sometimes cause confusion. Driving Your Explorer...
  • Page 280 Front Axle Reserve Capacity in Pounds (kgs): If this value is given as 83 pounds (38 kgs) on the label, does this mean that you are limited to adding only 83 pounds (38 kgs) of accessories to the front end capacity? Not exactly. This says that you can load 83 pounds (38 kgs) of options on the front axle, add 150 pound (68 kgs) passengers to all seating positions, and add evenly distributed cargo in the box without exceeding the...
  • Page 281 If your vehicle exceeds the GVWR, remove cargo from your vehicle accordingly. If your vehicle exceeds the GAWR for either axle, shift the load or remove cargo accordingly. If the GVWR or the GAWR specified on the Safety Compliance Certification Label is exceeded, your vehicle may be damaged or you may lose control and injure someone.
  • Page 283 Driving Your Explorer...
  • Page 284 Manual Transmissions...
  • Page 285 Driving Your Explorer...
  • Page 286 Automatic Transmissions...
  • Page 287 Driving Your Explorer...
  • Page 288 Also, make sure that all towing equipment is properly attached to your vehicle. If you are not certain that you are using the right equipment in the proper manner, see your Ford or Lincoln-Mercury dealer.
  • Page 289 Hitches Do not install a single or multi-clamp type bumper hitch, or a hitch which attaches to the axle. Underbody mounted hitches are acceptable if installed properly. Follow towing instructions of a reputable rental agency. Whenever a trailer hitch and hardware are removed, make sure all mounting holes in the underbody are properly sealed to prevent noxious gases or water from entering.
  • Page 290 Safety Chains Located near the step bumper hitch ball position are two holes in the underside of the hitch plate for a Class II trailer (max). These holes may be used for safety chain attachment when towing with the step bumper. Always use safety chains when towing.
  • Page 291 Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Driving while you tow Be especially careful when driving while you tow a trailer. Never drive faster than 45 mph (70 km/h) when you tow in hilly country on hot days.
  • Page 292 Servicing Your Vehicle If You Tow If you tow a trailer for a long distance, your vehicle will need to be serviced more frequently than usual. Refer to the Maintenance Schedule and Record booklet for additional information. Trailer towing tips Before starting on a trip, practice turning, stopping and backing in an area away from heavy traffic.
  • Page 293 Vehicles with trailers should not be parked on a grade. However, if you must park on a grade, place wheel chocks under the trailer’s wheels as follows: Apply the brake pedal and hold. Have another person place the wheel chocks under the trailer wheels.
  • Page 294 Any modifications to the suspension or steering systems can reduce your vehicle’s performance capability and adversely affect driver and passenger safety. Ford recommends that you DO NOT make modifications such as adding or removing parts (like lift kits, stabilizer bars or snowplowing equipment) or by using replacement parts non-equivalent to the original factory equipment.
  • Page 295: Roadside Emergencies

    Jump-Starting Your Vehicle Your vehicle’s battery may die if you leave the lights on or any electrical equipment on after you turn the engine off. If this happens, you may be able to jump-start your vehicle with a booster battery. The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes.
  • Page 296 Do not push-start your vehicle. You could damage the catalytic converter. For further information, see Jumper Cables in the Index. To avoid damage or injury, follow these directions in the order they are given. If in doubt, call for road service. Preparing Your Vehicle Your vehicle has a 12-volt starting system, so you need to use a 12-volt jumper system.
  • Page 297: Roadside Emergencies

    Connecting the jumper cables Connect one end of the first jumper cable to the positive (+) terminal of the discharged battery. (You can connect either jumper cable to the positive (+) terminal, as long as you use the same cable for both positive terminals.) Most jumper cables have a red cable and a black cable.
  • Page 298 Attaching jumper cables Jump-Starting Make sure that the jumper cables are not in the way of moving engine parts, then start the booster vehicle. Run the engine at a moderate speed. Let the discharged battery charge for a few minutes and then start the disabled vehicle.
  • Page 299: Changing A Tire

    Remove the other end of the positive (+) cable from the discharged battery. After the vehicle is started, let it idle for a while to let the engine “relearn” its idle conditions. Drive it around for a while with all electrical accessories turned off to let the battery recharge.
  • Page 300 It is not recommended that vehicles equipped with 4WD be operated in the 4WD modes with a temporary spare. If 4WD operation is necessary, do not operate at speeds above 10 mph (16 km/h) or for distances above 50 miles (80 km). Extended operation in 4WD with a temporary spare may result in damage to powertrain components.
  • Page 301 drive through an automatic car wash with this tire. Because the temporary spare tire is smaller than a conventional tire, it reduces the ground clearance. Your vehicle may get caught in the rails and it could be damaged. Spare Tire Location The spare tire for your vehicle is stowed at the rear under the frame.
  • Page 302 The spare tire location and assembly To stow spare tire: Insert the jack handle or lug nut wrench into the actuator hole and turn counterclockwise until the cable/retainer is extended for insertion into the wheel.
  • Page 303 Install the retainer through wheel center with valve stem facing up. NOTE: Stow aluminum wheel and tire with valve stem down. Rotate the handle clockwise to secure tire. Continue until the lift mechanism “slips”. Check for proper seating against underbody supports and retighten if necessary.
  • Page 304 Explorer Limited 4x2/4x4 Make sure the spare tire and jacking equipment are stowed and secured in the proper storage location. Preparing to Change the Tire NOTE: To lift your vehicle by other than the front or rear jacking points, be sure to use only hoist adapters with a wide contact surface.
  • Page 305 Roadside Emergencies instruction sheet and a pair of tire changing gloves. The jack handle is stowed behind the second row passenger seats under the carpet. Assemble handle sections and lug wrench together. Assembling the jack handle Jack stowage area...
  • Page 306 Jack handle location and installation (2-door model) Jack handle location and installation (4-door model) Insert the tapered end of the lug nut wrench behind wheel covers or hubcaps and twist off. Use only the lug nut wrench provided to remove wheel ornaments.
  • Page 307 Not using the tapered end of the lug nut wrench at the pry-off notches may result in damage to the finish of the wheel and ornament. Loosen the wheel nuts by pulling up on the handle of the lug nut wrench about one-half turn (counterclockwise). Do not remove the wheel lug nuts until you raise the tire off the ground.
  • Page 308 Front jacking position c. Turn the jack handle clockwise until the wheel is a maximum of one inch off the ground. Rear jacking position NOTE: Do not use the differential housing as a lift point.
  • Page 309 To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. Remove the lug nuts with the lug nut wrench.
  • Page 310 Lug nut tightening sequence Use of wheels or lug nuts other than original equipment could cause damage to the wheel or mounting system and allow the wheels to come off while the vehicle is in motion. Replace any wheel covers, ornaments, or hub caps that your vehicle has.
  • Page 311: Towing Your Vehicle

    It is recommended that your vehicle be towed with wheel lift or flatbed equipment. Do not tow with slingbelt equipment. Ford Motor Company has not developed or approved a T-hook or slingbelt towing procedure.
  • Page 312 When calling for a tow truck, tell the operator what kind of vehicle you have. A towing manual is available from Ford Motor Company for all authorized tow truck operators. Have your tow truck driver refer to this manual for the proper...
  • Page 313 Neutral Tow Feature Neutral tow feature is an option which can be activated at any dealership that has a Service Bay Diagnostic System (SBDS). When activated the feature may be enabled by following the instruction located on the visor or the headliner. The feature is available in vehicles with Control Trac and automatic transmission only.
  • Page 314 Disconnect the driveshaft at the rear differential and properly support it under the vehicle. Mark the driveshaft and axle flanges to ensure proper position when reconnecting the driveshaft. Refer to service manual for proper driveshaft fastener torque specification. (See the Accessories chapter for information on ordering service manuals.) When disconnecting/installing the driveshaft, the parking brake must be set and the wheels blocked to ensure the...
  • Page 315 If a distance of 50 miles (80 km) or speed of 35 mph (56 km/h) will be exceeded, you must: Remove the rear driveshaft or have the neutral tow feature enabled at your dealership. Mark the driveshaft and transfer case/axle flanges to ensure proper position when installing the driveshaft.
  • Page 316 To return the vehicle to a towable condition, you must: Place the transfer case in 2WD by rotating the 4WD switch to 2WD. NOTE: Both the 4WD and 4WD Low indicator lights in the instrument cluster will be off when the transfer case is in 2WD.
  • Page 317: Customer Assistance

    To purchase Roadside Assistance coverages beyond this period (available through Ford Auto Club in the United States or Ford and Lincoln-Mercury dealers in Canada), contact your Ford or Lincoln-Mercury dealer. Additional Roadside Assistance coverage is unavailable in Puerto Rico and the Virgin Islands.
  • Page 318 Service/Maintenance Concerns (U.S. or Canada) Ford recommends taking your vehicle to your selling dealer who wants to ensure your continued satisfaction. You may, however, take your vehicle to any authorized Ford or Lincoln-Mercury dealer.
  • Page 319: Customer Assistance

    Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this process at any time without notice and without incurring...
  • Page 320 What Kind of Cases Does the Board Review? The Board reviews unresolved warranty performance complaints on Ford, Mercury and Lincoln cars and Ford and Mercury Light Trucks under warranty that have not been resolved by a dealer or Ford Motor Company, except those involving:...
  • Page 321 It will also provide you with a form to indicate your acceptance or rejection of an award decision. The decisions of the Board are binding on the dealer and Ford, but customers may have other options available to them under state or federal law.
  • Page 322 Board address. At the same time, your dealer and Ford Motor Company representative are asked to submit statements. To review your case properly, the Board needs the following...
  • Page 323: Reporting Safety Defects

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington, D.C.
  • Page 324 Ford of Canada Customer Assistance Ford Motor Company of Canada, Limited If you live in Canada and have any questions or concerns that the dealership cannot answer, contact the Customer Assistance Centre. Please have the following information available when contacting...
  • Page 325 Mediation/Arbitration Program (Canada only) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 326 Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write to: If you are in other foreign countries, contact the nearest Ford dealership. If the dealership cannot help you, they can direct you to the appropriate Ford affiliate office.
  • Page 327 Accessories Ford Accessories for Your Vehicle Ford has many fine products available from your dealer to clean your vehicle and protect its finishes. For best results, use the following, or products of equivalent quality: A wide selection of accessories is available through your local authorized dealer.
  • Page 328 Safety, Comfort, and Convenience...
  • Page 329: Accessories

    NOTE: Because we have no control over the installation, design, or manufacture of such systems, Ford cannot assume responsibility for any adverse effects or damage that may result if you use this equipment.
  • Page 331 Accessories...
  • Page 333: Servicing Your Explorer

    Service Made Easy Ford has two goals for servicing your vehicle. When we can, we design parts that do not need to be serviced. We want to make servicing your vehicle as easy as possible. To help you: We highlight do-it-yourself items in yellow in the engine compartment so that you can find them easily.
  • Page 334 NOTE: Always dispose of used automotive fluids in a responsible manner. Follow your community’s standards for disposing of these types of fluids. Call your local recycling center to find out about recycling automotive fluids. Precautions When Servicing Your Vehicle Be especially careful when inspecting or servicing your vehicle. Here are some general precautions for your safety: If you must work with the engine running, avoid wearing loose clothing or jewelry that could get caught in moving...
  • Page 335: Servicing Your Explorer

    Working with the engine on: Set the parking brake fully, and make sure the gearshift is securely latched in P (Park) (automatic transmission) or Neutral (manual transmission) and block the wheels. Block the wheels. This will prevent your vehicle from moving unexpectedly.
  • Page 336: Engine Compartment

    Hood NOTE: Read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter before opening the hood. Close the hood with enough force to make it latch. Be sure to oil the hood latch every six months to maintain smooth operation.
  • Page 339: Filling The Fuel Tank

    Cleaning the Engine A clean engine is more efficient because a buildup of grease and dirt acts as an insulator, keeping the engine warmer than usual. Extreme care must be used if a power washer is used to clean the engine. The high pressure fluid could penetrate sealed parts and assemblies causing damage or malfunctions.
  • Page 340 Opening the Fuel Filler Door To open the fuel filler door of your vehicle, just insert your finger in the divot and pull the door open all the way. Filling the fuel tank Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire.
  • Page 341 If you lose the fuel cap, replace it with an authorized Motorcraft or equivalent part. If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision.
  • Page 342 Choosing the Right Fuel Use only UNLEADED FUEL in your vehicle. Using leaded fuel is prohibited by federal law. Your warranty may not apply if your vehicle is damaged because you used the wrong fuel. Vehicle inspection programs may detect misfueling. Under these circumstances, you may be required by law to make costly repairs at your own expense.
  • Page 343 In some parts of the country, “premium” grade fuels are sold with octane ratings of less than 91, especially in high altitude areas. It is recommended that you use only those “premium” fuels with an octane rating of 91 or higher. Fuel Quality If you are experiencing starting, rough idle or hesitation problems when the engine is cold, it may be caused by fuel...
  • Page 344 Gasolines For Clean Air Fuels in certain areas of the country are required to contain oxygenates to improve air quality. Common oxygenates are ethanol or grain alcohol (blended at no more than 10%), methanol or wood alcohol (blended at no more than 5% with cosolvents and additives) and MTBE or methyl tertiary butyl ether (blended at no more than 15%).
  • Page 345 Servicing Your Explorer If gasoline is swallowed, do not induce vomiting. If a gasoline-methanol blend is swallowed, induce vomiting under the direction of a physician or poison control center. Gasoline and gasoline-methanol blends may contain small amounts of carcinogens, such as benzene. Long-term exposure to unleaded gasoline vapors has caused cancer in laboratory animals.
  • Page 346 Running Out of Fuel If your vehicle runs out of fuel, try to stop on level ground away from traffic. Add at least two gallons (8 liters) of fuel to start your vehicle again. If your vehicle is not on level ground, you may need as much as five gallons (20 liters) of fuel to start You may need to crank the engine several times before the fuel system starts to pump fuel from the tank to the engine.
  • Page 347 Comparisons With Environmental Protection Agency (EPA) and Transport Canada (TC) Fuel Economy Estimates EPA fuel economy figures are obtained from laboratory tests under simulated road conditions and may not reflect the actual conditions you experience or your style of driving. The EPA fuel economy estimate is not a guarantee that you will achieve the fuel economy shown.
  • Page 348 Engine Oil Recommendations We recommend using Motorcraft oil or an equivalent oil meeting Ford Specification WSS-M2C193-F and displaying the American Petroleum Institute CERTIFICATION MARK on the front of the container. The API Certification Mark Never use: “Non-Detergent” oils Oils labeled API SA, SB, SC, SD, SE, SF or SG...
  • Page 349 Checking and Adding Engine Oil Since the proper amount of engine oil is important for safe engine operation, check the oil using the dipstick each time you put fuel in your vehicle. Remember the engine must be off, the oil must be warm and the vehicle must be parked on level ground.
  • Page 350 Engine oil dipstick — 5.0L engine Carefully, pull the dipstick out again. If the oil level is below the “ADD” line, add engine oil as necessary. If the oil level is beyond the letter “F” in Full, engine damage or high oil consumption may occur and some oil must be removed from the engine.
  • Page 351 Changing the Engine Oil and the Oil Filter Change the engine oil and oil filter per the following, whichever occurs first: Refer to the Maintenance Schedule and Record Booklet for additional information. NOTE: See Refill Capacities, Motorcraft Parts and Lubrication Specifications in this chapter for the appropriate oil filter and engine oil refill quantity.
  • Page 352: Engine Coolant

    Continuous contact with USED motor oil has caused cancer in laboratory mice. Protect your skin by washing with soap and water. Engine Coolant Checking the engine coolant NOTE: Be sure to read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter. Your vehicle’s engine coolant protects the engine from overheating in the summer and from freezing in the winter.
  • Page 353 Step back while the pressure releases. When you are sure that all the pressure has been released, use the cloth to turn and remove cap. Stand away from the radiator opening. Hot steam may blow out or hot engine coolant may even splash out. Adding engine coolant Adding engine coolant Be careful not to add engine coolant to the windshield...
  • Page 354 Ford specification ESE-M97B44-A. Ford Premium Engine Coolant is an optimized formula that will protect all metals and rubber elastomers used in Ford cooling systems for 4 years or 50,000 miles (80,000 km). Do not use alcohol or methanol antifreeze or any engine coolants mixed with alcohol or methanol antifreeze.
  • Page 355 Ford Motor Company recommends that Ford and Lincoln-Mercury dealers use recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44-A, and use of such coolant may harm engine and cooling system components.
  • Page 356 Engine Coolant Drain and Flush To drain your vehicle’s engine coolant: Turn off the engine and let it cool. Fully depressurize the engine cooling system by covering the radiator cap with a thick cloth and turning it slowly counterclockwise to the first stop.
  • Page 357 (engine coolant temperature gauge below the N of NORMAL) topping off the coolant overflow bottle to the cold fill mark If coolant loss continues after 7,500 miles (12,000 km), consult your Ford Dealer. Servicing Your Explorer...
  • Page 358 Windshield Washer Fluid and Wipers Washer Fluid Check the level of the windshield washer fluid every time you stop for fuel. The reservoir for washer fluid is located on the passenger’s side of the engine compartment. Visual inspection can determine if the washer fluid is adequate. Do not operate the washer when the reservoir is empty.
  • Page 359 protection without damaging the vehicle’s paint finish, wiper blades, and windshield washer system. If you choose to use a windshield washing solution that must be mixed, follow the manufacturer’s mixing instructions. Improperly mixed solutions may freeze unexpectedly. Windshield washer fluid contains methanol and it is poisonous.
  • Page 360 Wiper Blades Check the windshield wiper blades at least twice a year. Also check them whenever they seem less effective than usual. Such substances as tree sap and some hot wax treatments used by commercial car washes reduce the effectiveness of wiper blades. If the blades do not wipe properly, clean both the windshield and the wiper blades.
  • Page 361 Servicing Your Explorer Replacing the wiper blades...
  • Page 362 If you do not take these precautions, your tires may fail or go flat. Ford Motor Company recommends obeying posted speed limits. Driving too fast for conditions creates the possibility of loss of vehicle control. Driving at very high speeds for extended periods of time may result in damage to vehicle components.
  • Page 363 Tire inspection and maintenance Inspect the tire treads, and remove stones, nails, glass or other objects that may be wedged in the tread grooves. Check for holes or cuts that may permit air to leak from the tire, and make the necessary repairs. Inspect the tire side walls for cuts, bruises and other damage.
  • Page 364 To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire. Tire Rotation Because your vehicle’s front and rear tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them at the mileage shown in the Maintenance Schedule and Record booklet which came with your vehicle.
  • Page 365 Servicing Your Explorer Tire rotation pattern After each rotation, adjust individual tire pressure as specified on the Safety Compliance Certification Label. Tighten wheel lug nuts to the required torque specification and retighten again after 500 miles (800 km). If your vehicle has aluminum wheels, you may demount the full size, non-temporary spare tire (if so equipped) and remount on an aluminum wheel to rotate the spare tire into your vehicle’s rotation pattern.
  • Page 366 Replacing the Tires Replace any tires that show wear bands. When your tire shows a wear band, it has only 1/16 inch (2 mm) of tread left. A worn-out tire Because your vehicle’s tires may wear unevenly, you may need to replace them before a wear band appears across the entire tread.
  • Page 367 Make sure that all replacement tires are of the same size, type, load-carrying capacity, and tread design (e.g. “All Terrain”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires, or larger size tires. Do not use P235/75R15 “All Season”...
  • Page 368 Tire identification chart RWARNING Use of aftermarket wheel assemblies may damage your vehicle or cause accidents resulting in serious injuries.
  • Page 369 Wheel and Tire Matching See an authorized tire dealer for proper servicing procedures. Wheels and tires must be properly removed, matched and remounted to maintain the best possible ride. Snow Tires and Chains The tires on your vehicle have all-weather treads that provide traction in rain or snow.
  • Page 370 Local regulations may prohibit or restrict the use of tire chains. Investigate the laws and regulations in your area before installing chains. Put the chains on tightly with the ends held down securely. Verify that no chain touches any wiring, brake lines, or fuel lines.
  • Page 371 Servicing Your Explorer Battery Your vehicle may have a Motorcraft maintenance-free battery. The Motorcraft maintenance-free battery does not require additional water during its life of service. The vents are part of the cover and cannot be removed. For longer, trouble-free operation, keep the top of the battery clean and dry.
  • Page 372 Help Us Protect Our Environment Ford Motor Company strongly recommends that used lead-acid batteries be returned to an authorized recycling facility for disposal. Battery recycling symbol Because your vehicle’s engine is electronically controlled by a computer, some control conditions are maintained by power from the battery.
  • Page 373: Automatic Transmission Fluid

    Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lit tobacco to come near the battery. When charging or working near a battery, always cover your face and protect your eyes, and also provide ventilation. Batteries contain sulfuric acid which burns skin, eyes, and clothing.
  • Page 374 without having to drive 20 miles to obtain a normal operating temperature if outside temperatures are above 50˚F (10˚C). NOTE: If the vehicle has been operated for an extended period at high speeds or in city traffic during hot weather, or pulling a trailer, the vehicle should be turned off for about 30 minutes to allow the fluid to cool before checking.
  • Page 375 Adding Automatic Transmission Fluid The fluid type is stamped on the dipstick. Before adding any fluid, be sure that the correct type will be used. Add fluid in 1/2 pint (.25L) increments through the filler tube to bring the level to the correct area on the dipstick. If an overfill occurs, excess fluid should be removed by a qualified technician.
  • Page 376 Remove the internal diaphragm and then add only a DOT 3 brake fluid such as Ford High Performance DOT 3 Brake Fluid, meeting Ford...
  • Page 377: Brake Fluid

    Servicing Your Explorer Clutch fluid reservoir Driveline Universal Joint and Slip Yoke The universal joints that come standard with your vehicle do not require lubrication. If your original equipment universal joints are replaced with universal joints equipped with grease fittings, lubrication will be necessary at the intervals shown in the Maintenance Schedule and Record booklet.
  • Page 378 If the fluid is low, carefully clean and remove the cap from the reservoir. Fill the reservoir to the MAX line with Ford High Performance DOT 3 Brake Fluid C6AZ-19542-AA, C6AZ-19542-BA, or equivalent DOT 3 fluid meeting Ford specification ESA-M6C25-A.
  • Page 379: Power Steering Fluid

    Brake master cylinder Power Steering Fluid Check the level of the power steering fluid at least twice a year (i.e., every Spring and Fall). Checking and Adding Power Steering Fluid Start the engine and let it run until the power steering fluid reaches normal operating temperature.
  • Page 380 FULL HOT range. Do not overfill. When you are finished, put the dipstick back in and make sure that it fits snugly. Use only power steering fluid that meets Ford specification such as MERCON Automatic Transmission Fluid (or equivalent).
  • Page 381 If the power steering fluid is low, do not drive your vehicle for a long period of time before adding fluid. This can damage the power steering pump. If you check the power steering fluid when it is cold, make sure that the fluid reaches the FULL COLD range on the dipstick.
  • Page 382 Fuse panel (located left side of instrument panel)
  • Page 383 Servicing Your Explorer Fuse panel (located under the left hand side of the instrument panel)
  • Page 385 Servicing Your Explorer...
  • Page 386 40 amp - orange, 50 amp - red, 60 amp -blue. Always disconnect the battery before servicing high current fuses. Ford recommends that high current fuses be replaced by a qualified technician. Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
  • Page 387 Servicing Your Explorer RWARNING Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Power distribution box...
  • Page 388 Checking and Replacing Fuses If you need to check a fuse, follow these steps: Find the fuse panel, which is located in the left end of the instrument panel. The power distribution box (described earlier in this section) is found in the engine compartment, mounted on a bracket attached to the left fender apron.
  • Page 389 Replace the fuse with one that has the right amperage rating (see previous chart). Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire.
  • Page 392 Lights and Bulb Replacement It is a good idea to check the operation of the following lights frequently: headlamps high-mount brakelamp tail lamps brakelamps hazard flasher turn signals license plate lamp fog lamps The alignment of your headlamps should be checked if: oncoming motorists frequently signal you to turn off your vehicle’s high beams when you do not have the high beams the headlamps do not seem to give you enough light to see...
  • Page 393 Headlamp Bulb The headlamps on your vehicle use replaceable bulbs. When the lamp burns out, simply replace the bulb, rather than the whole lamp. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass.
  • Page 394 Removing the headlamp bulb Make sure that the headlamp switch is in the OFF position. Lift the hood, open the hinged headlamp cover, and behind the headlamp remove the electrical connector by grasping the wires and pulling rearward. Remove the bulb retaining ring by turning it 1/8 of a turn to free it from the socket.
  • Page 395 Servicing Your Explorer Map Lamp Bulb (Overhead Console) To remove the lens, pry with a small screwdriver as shown: Removing the lens To remove the bulbs, use a screwdriver or coin to push up and rotate counterclockwise 90˚. The bulb and bulb holder will then drop out from the lamp as shown: Removing bulb...
  • Page 396 Tail Lamp Bulb Removing the tail lamp bulb Remove the two (2) screws retaining rear lamp to vehicle. Remove rear lamp by pulling rearward to disengage two lower barbed retainers. Remove socket from lamp. Remove bulb from socket. Installing the tail lamp bulb Install bulb in socket.
  • Page 397 Servicing Your Explorer Replacing the tail lamp bulb...
  • Page 398 Bulb Specifications...
  • Page 399: Emission Control System

    Rear lighting wire functions Emission Control System Your vehicle is equipped with a catalytic converter which enables your vehicle to comply with applicable exhaust emission requirements. To make sure that the catalytic converter and the other emission control parts continue to work properly: Use only unleaded fuel.
  • Page 400 Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. On vehicles without original equipment floor covering or insulation, do not let passengers ride in your truck in a manner that allows contact between skin and the metal floor.
  • Page 401 Servicing Your Explorer Never use a metal exhaust collector when you service your vehicle. If the metal collector contacts any of your vehicle’s plastic trim or bumper parts they could melt or deform. Do not drive your vehicle if it does not operate properly. See your dealer if the engine runs on for more than five seconds after you shut it off or if it misfires, surges, stalls, or backfires.
  • Page 402 The engine must be warmed up and at operating temperature before proceeding with the drive modes of the following OBD II Drive Cycle. Start the engine. Drive or idle (in neutral) the vehicle for 4 minutes. Idle the vehicle in drive (neutral for automatic transmissions) for 40 seconds.
  • Page 403 Accelerate the vehicle up to between 45 and 60 mph (72-97 km/h) (manual transmissions upshift to 5th gear). This should take approximately 8 seconds. Drive vehicle and hold the throttle steady at the selected speed between 45 and 60 mph (72-97 km/h) (manual transmissions use 5th gear) for approximately 5 minutes.
  • Page 404 Refill Capacities, Motorcraft Parts, and Lubricant Specifications...
  • Page 405 Servicing Your Explorer Motorcraft Parts...
  • Page 406 Lubricant Specifications...
  • Page 407 Servicing Your Explorer...
  • Page 408: Vehicle Storage

    Vehicle Storage Maintenance Tips If you plan on storing your vehicle for an extended period of time (60 days or more), refer to the following maintenance recommendations to ensure your vehicle stays in good operating condition. General Store all vehicles in a dry, ventilated place. Protect from sunlight, if possible.
  • Page 409 If vehicles are stored outside, they require regular maintenance to protect against rust and damage. Body Wash vehicle thoroughly to remove dirt, grease, oil, tar or mud from exterior surfaces, rear wheel housing and underside of front fenders. Periodically wash vehicles stored in exposed locations. Touch-up raw or primed metal to prevent rust.
  • Page 410 Ford Gas Stabilizer should be added whenever actual or expected storage periods exceed 60 days. Follow the instructions on the label. The vehicle should then be operated at idle speed to circulate the additive throughout the fuel system. A volatile corrosion inhibitor added to the fuel system will protect the fuel system’s inner surfaces from corrosion.
  • Page 421 Update:Thu Feb 29 09:21:09 1996 Accessory position on the ignition... . . 67 Accessory power source, power point outlet ..Additives, engine oil ....Air bag supplemental restraint system and child safety seats .
  • Page 422 Update:Thu Feb 29 09:21:09 1996 Anti-theft system (continued) triggering ..... warning light ..... Appeals (see Dispute settlement board) .
  • Page 423: Index

    Update:Thu Feb 29 09:21:09 1996 Brake fluid brake warning light ....81 checking and adding ....description .
  • Page 424 Update:Thu Feb 29 09:21:09 1996 Canada, customer assistance ....Canada, warranty information ....Carbon monoxide in exhaust ....Car seats for children (see Child safety seats) .
  • Page 425 Update:Thu Feb 29 09:21:09 1996 Cleaning your vehicle (continued) instrument panel ....interior ..... . . interior lamps.
  • Page 426 Cruise control (see Speed control)... . Customer Assistance Centre, Ford of Canada ..Dashboard (see Instrument panel) ... .
  • Page 427 Update:Thu Feb 29 09:21:09 1996 Electrical system fuses ..... . operating when the engine is off ... . 67 power point outlet .
  • Page 428 Update:Thu Feb 29 09:21:09 1996 Engine (continued) starting ..... starting after a collision ....storing your vehicle .
  • Page 429 Exhaust fumes..... . 76 Extended Service Plan, Ford ....
  • Page 430 Update:Thu Feb 29 09:21:09 1996 Fuel cap removing..... . replacing ....Fuel filler door override, manual .
  • Page 431 Update:Thu Feb 29 09:21:09 1996 GAWR (Gross Axle Weight Rating) calculating ..... definition ....driving with a heavy load .
  • Page 432 Update:Thu Feb 29 09:21:09 1996 High beams indicator light ....operation....High-mount brakelamp, description .
  • Page 433 Update:Thu Feb 29 09:21:09 1996 Jack operation ....positioning ....storage .
  • Page 434 Update:Thu Feb 29 09:21:09 1996 Lamps (continued) interior lamps ....replacing bulbs ....trailer .
  • Page 435 Update:Thu Feb 29 09:21:09 1996 Manual transmission (continued) shifting gears ....shift speeds ..... Master cylinder, brakes.
  • Page 436 Update:Thu Feb 29 09:21:09 1996 Overdrive ..... . Overhead console compass/temperature display ... . map lamps .
  • Page 437 Update:Thu Feb 29 09:21:09 1996 Rear window (continued) defroster ..... . washer reservoir ....Regulations, National Highway Traffic Safety Administration .
  • Page 438 Update:Thu Feb 29 09:21:09 1996 Safety restraints (continued) for infants ....for pregnant women ....lap and shoulder belts .
  • Page 439 Update:Thu Feb 29 09:21:09 1996 Snowplowing ..... Snow tires and chains ....Spare tire changing the tire .
  • Page 440 Update:Thu Feb 29 09:21:09 1996 Storing your vehicle ....Sunroof (moon roof) ....Supplemental air bag readiness light .
  • Page 441 Update:Thu Feb 29 09:21:09 1996 Trailer towing calculating maximum trailer weight ..safety chains ....trailer brakes .
  • Page 442 Update:Thu Feb 29 09:21:09 1996 Ventilating your vehicle (see Climate control) ..Viscosity (see Engine oil)....Voltmeter (see Battery voltage gauge) ..Warm engine, starting .
  • Page 443 Update:Thu Feb 29 09:21:09 1996 Windshield defrosting ..... washing ..... . Windshield washer fluid and wipers checking and adding fluid .
  • Page 444: Service Station Information

    Service Station Information...

This manual is also suitable for:

Explorer

Table of Contents

Save PDF
