- Page 1 AIR CURTAIN TECHNICAL DOCUMENTATION...
-
Page 2: Table Of Contents
2.3.ACOUSTIC PRESSURE LEVEL ..........................................................2.4.AIR VOLUME ....................................................................2.5.AIR FLOW SPEED ..................................................................3. HEAT OUTPUT DATA ..................................................................3.1. AIR COURTAIN SOLANO CEILING-W-100 ..................................................3.2. AIR COURTAIN SOLANO CEILING-W-150 ..................................................3.3. AIR COURTAIN SOLANO CEILING-W-200 ..................................................4. INSTALLATION ..................................................................... 5. CONTROL SYSTEMS .................................................................. -
Page 3: Technical Data
1. GENERAL INFORMATION Purpose of SOLANO CEILING is to minimalize heat losses (or unwanted heat gains) by door openings. Solano Ceiling is a recessed type and can be a part suspended ceiling. La gamme de rideaux d’air SOLANO CEILING types: CEILING-W-100 –... -
Page 4: Dimensions
2.2. DIMENSIONS CEILING-W/N/E-100 1057 mm 600 mm 561 mm 770 mm 297 mm 96 mm CEILING-W/N/E-150 1546 mm 600 mm 561 mm 1207 mm 297 mm 84 mm CEILING-W/N/E-200 2034 mm 600 mm 561 mm 1621 mm 297 mm 157 mm * Given height for CEILING, height for CEILING-E/N equels 284 mm 2.3. -
Page 5: Air Flow Speed
CEILING W/E-100/150/200 CEILING N-100/150/200 step 1 step 2 step 3 step 1 step 2 step 3 3. HEAT OUTPUT DATA 3.1. SOLANO CEILING-W-100 Δpw Δpw I / h °C I / h °C °C m Tw1 / Tw2 = 90/70... -
Page 6: Air Courtain Solano Ceiling-W-150
3.2. SOLANO CEILING-W-150 Δpw Δpw I / h °C I / h °C °C m Tw1 / Tw2 = 90/70 Tw1 / Tw2 = 80/60 20,9/21,9/23,5 923/968/1039 5,9/6,5/7,4 19,6/18,5/17,5 17,8/18,7/20,0 783/821/881 4,5/4,9/5,6 16,5/16,0/15,0 19,6/20,5/22,0 863/905/972 5,3/5,6/6,6 23,0/22,5/21,5 16,4/17,3/18,5 722/758/813 3,9/4,3/4,9 20,0/19,5/18,5 18,2/19,1/20,5 803/842/904... -
Page 7: Installation
4. INSTALLATION CEILING-..-100 572 mm 1024 mm CEILING-..-100 770 mm 121 mm 561 mm CEILING-..-150 572 mm 1510 mm CEILING-..-150 1207 mm 122 mm 561 mm CEILING-..-200 572 mm 2000 mm CEILING-..-200 1621 mm 123 mm 561 mm... - Page 8 4. INSTALLATION...
-
Page 9: Control Systems
5. CONTROL SYSTEMS S-ECM CONTROL: • Connecting curtains – controlling up to 5 units with one controller S-C; • controlling up to 31 units with one controller S-TOUCH • Connecting to curtain room thermostat*, door contact*, valves with actuator*, speed controller*; •... -
Page 10: Connecting Guide
5.2 CONNECTING GUIDE CEILING B-W/N CEILING B-E... -
Page 11: Control System S-Ecm
5.3. S-ECM CONTROL SYSTEM ❶Power supply 230V/50Hz; ❷Connectors for thermostat and fan step switch; ❸Door contact connector; ❹Valve actuator connector SOLANO-..-W; heaters contactor connector SOLANO-..-E; ❺BMS system connection; ❻T-box connectors; ❼MASTER-SLAVE connectors; ❽PT-1000 connectors; LED INDICATORS: Switch de service G1, G2, G3 – signalize number of fan speed operating Mode MAITRE Mode ESCLAVE S1, S2, S3 –... -
Page 12: Regulation S-C - Wiring Diagrams Solano Ceiling-W/N
5.3.1. REGULATION S-C - SOLANO CEILING-W/N WIRING DIAGRAMS ❶ Power supply 230V/50Hz (OMY 3x1mm ❷ Air curtain step switch with thermostat S-C (OMY 5x0,5mm Heat - heating mode Fan - room thermostat deactivated Cool - cooling mode ❸ Door contact S-DS-MEC/S-DS-MAG (door closed – contacts opened; door opened – contacts closed) ❹... -
Page 13: Regulation S-C - Wiring Diagrams Solano Ceiling-E
5.3.2. REGULATION S-C - SOLANO CEILING-W/N WIRING DIAGRAMS ❶ Power supply 3x400V/50Hz SOLANO CEILING-E-100 (min. 5x4 mm ) (Overcurrent B16) SOLANO CEILING-E-150 (min. 5x6 mm ) (Overcurrent B20) SOLANO CEILING-E-200 (min. 5x6 mm ) (Overcurrent B25) ❷ Air curtain step switch with thermostat S-C (OMY 5x0,5mm HEAT- heating mode FAN - room thermostat deactivated COOL - cooling mode... -
Page 14: Regulation S-Touch - Wiring Diagrams Solano Ceiling-W/N
5.3.3. REGULATION S-TOUCH - SOLANO CEILING-W/N WIRING DIAGRAMS ❶Power supply 230V/50Hz (OMY 3x1mm ❷S-touch (LIYCY 4x0,5mm A and B braided wire pair max. 50 m) ❸Door contact S-DS-MAG/S-DS-MEC (door closed – contacts opened; door opened – contacts closed) ❹Valve with actuator S-V-3 (OMY 3x0,5mm ) or S-V-2 (OMY 3x0,5mm A –... -
Page 15: Regulation S-Touch - Wiring Diagrams Solano Ceiling-E
5.3.4. REGULATION S-TOUCH - SOLANO CEILING-E WIRING DIAGRAMS ❶Power supply 3x400V/50Hz • SOLANO CEILING-E-100 (min. 5x4 mm ) (Overcurrent B16) • SOLANO CEILING-E-150 (min. 5x6 mm ) (Overcurrent B20) • SOLANO CEILING-E-200 (min. 5x6 mm ) (Overcurrent B25) ❷S-touch (LIYCY 4x0,5mm A and B braided wire pair max. -
Page 16: Control System - Master-Slave Communication
5.3.5. CONTROL SYSTEM - MASTER-SLAVE COMMUNICATION Electrical air curtain chaining provides control from 1 to 5 devices using one S-C and DS-MAG / S-DS-MEC. Electri- cal air curtain chaining might be done by cable OMY 3x0,5mm using connectors CURTAIN IN; CURTAIN OUT. Connecting units among themselves ensure transfer of controlling signals. -
Page 17: Chaining Appliances
5.3.7. CONTROL SYSTEM – APPLIANCES CHAINING NOTE: In last appliance in line, dipswitch SW2 has to be switched to the right – T120. The maximum length of the connecting cable 50 m (LIYCY 3x 0,5 mm... -
Page 18: Setting Bms Address
5.3.8. CONTROL SYSTEM – SETTING BMS ADDRESS When connecting S-ECM modules to the T-box controller or BMS, you have to binary set addresses on each (each S-ECM must have individual address) S-ECM module by DIP-switch SW1. To address modules check if the power supply is turned off, than set then the addresses as shown in the table, than turn on the power supply . -
Page 19: Door Contact Installation
6. DOOR CONTACT INSTALLATION Sample of door contact installation. S-DS-MEC In case of installation in way S-DS-MAG In the case of sliding doors (with a parallel which is show on drawing below, connec- installation of the sensor and magnet ) is required distance tors 21 and 22 need to be used. -
Page 20: Operation
9. OPERATION • The device is designed for operation inside buildings, at temperatures above 0oC. In low temperatures (be- low 0ºC) there is a danger of freezing of the medium. The manufacturer bears no responsibility for damage of the heat exchanger resulting from freezing of the medium in the exchanger. - Page 24 Made in Poland Made in EU Manufacturer: OUEST ISOL & VENTIL Z.I. de la Rangle 27460 ALIZAY...
