(134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 11/18/2011
Krystal Clear
Saltwater System
& Filter Pump
Model CS8221 220 - 230 V~,
Model CS8231 230 - 240 V~
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool accessories,
inflatable pools and in-home toys, airbeds and boats available at fine
retailers or visit our website.
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., P.O. Box nr. 1075 – 4700 BB Roosendaal – The Netherlands
IMPORTANT
SAFETY RULES
Read, understand, and follow all
instructions carefully before
installing and using this product.
©2011 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
English
TM
134-*A*-R1-1211
134A

Advertisement

Table of Contents
loading

Related Manuals for Intex Krystal Clear CS8221

Summary of Contents for Intex Krystal Clear CS8221

  • Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., P.O.

  • Page 2: Table Of Contents

    Product Information & Specifications........ 10 Setup Instructions............... 11-14 Salt & Pool Water Volumes..........15 Intex Pools Salt Table............16 Intex Pools Operating Time Table ........17 Intex Pools Cyanuric Acid Table......... 18 Non-Intex Pools Salt Table..........19 Non-Intex Pools Operating Time Table....... 19 Non-Intex Pools Cyanuric Acid Table.........

  • Page 3: Warnings

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.

  • Page 4: Parts List & References

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A PARTS LIST NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 4...
  • Page 5 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A PARTS LIST (continued) * Optional * Optional * Optional * Optional NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 5...
  • Page 6 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 6...
  • Page 7 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. SPARE PART REF.
  • Page 8 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only.
  • Page 9 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SAVE THESE INSTRUCTIONS Page 9...

  • Page 10: Product Information & Specifications

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A HOW THE CHLORINE IS GENERATED This product is specially designed for above ground pools. It will destroy the bacteria, oxidize bather organics and control algae, which provide you a safe, clean and comfortable swimming pool.

  • Page 11: Setup Instructions

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A STRAINER & PLUNGER VALVE SETUP IMPORTANT The Saltwater System/Filter Pump must be installed as the last piece of pool equipment in the water return line to the pool. This location extends the life of the titanium plates.
  • Page 12 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A STRAINER & PLUNGER VALVE SETUP (continued) The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring.
  • Page 13 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A NOZZLE & PLUNGER VALVE SETUP 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (24) (see drawing 5). Be careful not to lose the step rubber washer (21).
  • Page 14 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SALTWATER SYSTEM/FILTER PUMP Saltwater System/Filter Pump 1. Remove the Saltwater System/Filter Pump and hoses from the packaging. 2. Place the Saltwater System/Filter Pump in a location for hose (8) connections to the plunger valve assemblies.

  • Page 15: Salt & Pool Water Volumes

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SALT & POOL WATER VOLUMES • Which kind of salt to use: Use only Sodium Chloride Salts Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use water conditioning salt pellets (the compressed forms of evaporated salt).

  • Page 16: Intex Pools Salt Table

    Easy Set & Oval Pool) 3.0g/L (3000ppm) (CODE “91”) (Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs) INTEX ABOVE GROUND POOLS (AGP’s) 15' x 33" (457cm x 84cm) 2587 9792 15' x 36" (457cm x 91cm) 2822 10681 15' x 42" (457cm x 107cm) 3284 12430 15' x 48"...

  • Page 17: Intex Pools Operating Time Table

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID) Operating Time (hours) Water Capacity (Calculated at at different ambient/air 90% for Frame Pool and 80% temperatures for Easy Set &...

  • Page 18: Intex Pools Cyanuric Acid Table

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A INTEX POOLS CYANURIC ACID TABLE Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet rays. To maintain maximum performance, we recommend that the cyanuric acid level be maintained at approximately 1% of the salt, i.e.

  • Page 19: Non-Intex Pools Salt Table

    22500 8000 30000 10000 37500 12000 45500 14000 53000 OPERATING TIME TABLE FOR COMMON NON-INTEX POOLS Operating Time (hours) Water Capacity at different ambient/air temperatures 10 - 19°C 20 - 28 °C 29 - 36 °C (Gals) (Liters) (50 - 66°F) (68 - 82 °F)

  • Page 20: Operating Instructions

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A FILTER PUMP OPERATION 1. Make sure the unit is switched off. The switch is located on the control station. 2. Connect the power cord to a GFCI/RCD protected electrical outlet. WARNING Risk of electric shock.
  • Page 21 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SALTWATER SYSTEM OPERATION 1. Start up the unit: Plug the power cord into the electrical outlet and test the GFCI/RCD (circuit breaker). Switch on the unit. With the Filter Pump turned “ON”...
  • Page 22 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SALTWATER SYSTEM OPERATION (continued) 6. Boost cycle • If the test result is below 0.1ppm, press and hold “BOOST” button for 5 seconds until the indicator lights up and the LED display display “80”.

  • Page 23: Led Code Chart

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A LED CODE CHART LED Reading Definitions Filter Pump Working Mode Boost Mode Stand-By Mode (Start-up) Minimum Operating Hour (1 hour remaining) Operating Hours (2 hours remaining) Operating Hours (3 hours remaining) Operating Hours (4 hours remaining) Operating Hours (5 hours remaining)

  • Page 24: Stationary Mounting Option

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A SALTWATER SYSTEM/FILTER PUMP STATIONARY MOUNTING OPTION Some countries, especially in the European community, require the product to be secured to the ground or to a base in a permanent upright position. Check your local authorities to determine if there is a regulation in your area regarding above-the-ground swimming pool filter-pumps.

  • Page 25: Maintenance

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A MAINTENANCE WARNING Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any adjustment to the product. IMPORTANT Close plunger valves on your pool or insert black hat-like plugs in strainer opening to prevent water spillage.
  • Page 26 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A MAINTENANCE (continued) 1. Switch off the unit, unplug the power cord from the electrical socket. 2. Grasp a plunger valve handle. Turn the handle counter-clockwise, push down until it stops and then turn it clockwise until the plastic protruding notch anchor is in the "0/I"...
  • Page 27 (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A MAINTENANCE (continued) CLEANING OR REPLACING FILTER CARTRIDGES It is recommended that the filter cartridge be replaced at least every 2 weeks. Make sure the unit is turned off, and disconnect the power cord from the electrical outlet.

  • Page 28: Long Term Storage

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A MAINTENANCE (continued) INTEX ® COPPER ION TEST STRIPS (PACKED WITH THE PRODUCT) The Copper Ion Test Strips can be used to test the copper ion concentration in the water.

  • Page 29: Pool Maintenance And Chemical Definitions

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A POOL MAINTENANCE & CHEMICAL DEFINITIONS Preferred Water Chemistry Reading Minimum Ideal Maximum Copper Ions 0.1 - 0.2 ppm 0.2 ppm Free Chlorine 0.4 - 1.5 ppm 3.0 ppm Combined Chlorine 0 ppm...

  • Page 30: Troubleshooting Guide

    • Turn and pull valve handle to full upright • Service light on. position. • Unscrew two air release valve on the chamber to fullfill water. • Contact Intex Service Center. • O-ring missing. TOP COVER • Remove cover & check for O-ring. • Cover is not tight.
  • Page 31 See “Operating Instructions”. • Copper electrode defective. • Remove the cell for inspection, clean it if necessary. See “Maintenance”. • Contact Intex Service Center. • Drain about 20% of the pool water and POOL IS STAINED • High copper ion concentration.
  • Page 32 • Ensure that the cell cord is plugged 3. Electrolytic cell cord is loose. firmly into the cell housing receptacle. • Contact Intex Service Center. Replace 4. Possible electrolytic cell failure. the cell if needed. • Partially drain the pool and refill it with 1.

  • Page 33: General Aquatic Safety

    (134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011 English 134A GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions.

  • Page 34: Limited Warranty

    Saltwater System and accessories listed below. The following provision is only valid within the European member states countries: The legal regulation of Directive 1999/44/EC will not be effected by this Intex warranty. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable.

  • Page 35: Intex Service Center Locations

    PRINCE AMIR MAJED STREET, E-mail: service@intexcorp.nl AL-SAFA DISTRICT. JEDDAH, Website: www.intexcorp.nl KINGDOM OF SAUDI ARABIA • FRANCE UNITEX / INTEX SERVICE FRANCE S.A.S TEL: 966-2-693 8496 Z.A. DE MILLEURE FAX: 966-2-271 4084 BOIS DU BAN - N°4 E-mail: toy@samaco.com.sa 71480 LE MIROIR Website: www.samaco.com.sa...
