OXY5500 Analyzer
Table A-1 OXY5500 analyzer specifications (Continued)
Physical
Enclosure Type
Analyzer Dimensions
Controller to Probe Cable
Length
Weight
Sample Probe Construction
Area Classification -
Certification
Probe assemblies and other such equipment required for analyzer
operation must meet with all manufacturer specifications.

Technical Notes

•
Waterproof Enclosure: The enclosure and fittings are designed for
IP66/NEMA4X ratings. In order to maintain this rating, all
connections must be made with proper hardware and adhering to
suggested procedures. Use of incorrect materials can compromise
the integrity of the environmental seals.
For a complete listing of new or updated certificates, please visit
the product page at www.spectrasensors.com.
–
A 2
NEMA Type 4X and IP66 rated, 304 and 316 (optional) Stainless
Steel
280 x 230 x 114 mm (11 x 9 x 4.5 inches) H X W x D
(not including Sample Conditioning System)
0.7 m - Standard
2.5 m and 5.0 m - Optional
2.2 Kg (4.9 lbs) (not including Sample Conditioning System)
316 Stainless Steel
CSA: Class 1, Div. 2, Groups A, B, C and D T4
ATEX/IECEx: II 3 G, Ex nA IIC T3 Gc IP66,
LCIE 16 ATEX 1012 X, IECEx LCIE 16.0009 X
4900002247 rev. B 4-7-17
