Endress+Hauser ORIA15 Brief Operating Instructions
Endress+Hauser ORIA15 Brief Operating Instructions

Endress+Hauser ORIA15 Brief Operating Instructions

Loop-powered indicator

Advertisement

Quick Links

KA01149O/09/EN/05.23-00
71625101
2023-05-30
*71625101*
71625101
These Instructions are Brief Operating Instructions; they do not replace the Operating Instructions included in the scope of supply.
Please refer to the Operating Instructions and other documentation provided by your supplier for detailed information.
Safety Instructions
Requirements for the personnel
The personnel must fulfill the following requirements for its tasks:
Trained, qualified specialists must have a relevant qualification for this
specific function and task.
Are authorized by the plant owner/operator.
Are familiar with federal/national regulations.
Before starting work, read and understand the instructions in the manual
and supplementary documentation as well as the certificates (depending on
the application).
Follow instructions and comply with basic conditions.
Intended use
The process indicator displays analog process variables or HART
variables (option) on its screen.
The device is powered via the 4 to 20 mA current loop and does not require an
additional power supply.
• The manufacturer accepts no liability for damages resulting from improper or
non-intended use. The device must not be converted or modified in any way.
• Panel-mounted device:
The device is designed for installation in a panel and must only be operated in
an installed state.
Incoming acceptance and product identification
Product identification
Name and address of manufacturer
Name of manufacturer:
Endress+Hauser Wetzer GmbH + Co. KG
Address of manufacturer:
Obere Wank 1, D-87484 Nesselwang or
Brief Operating Instructions
Loop-powered indicator ORIA15
Loop-powered 4 to 20 mA process indicator with optional HART® communication
®
process
www.endress.com
• Field device:
The device is designed for mounting in the field.
• The device may be operated only under the permitted ambient conditions.
Workplace safety
When working on and with the device:
Wear the required personal protective equipment as per national regulations.
Operational safety
Damage to the device!
Operate the device in proper technical condition and fail-safe condition only.
The operator is responsible for the interference-free operation of the device.
Product safety
This measuring device is designed in accordance with good engineering practice
to meet state-of-the-art safety requirements, has been tested, and left the
factory in a condition in which it is safe to operate.
It meets general safety standards and legal requirements. It also complies with
the EU directives listed in the device-specific EU Declaration of Conformity. The
manufacturer confirms this by affixing the CE mark to the device.
Certificates and approvals
For certificates and approvals valid for the device: see the data on the
nameplate

Advertisement

loading
Need help?

Need help?

Do you have a question about the ORIA15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Endress+Hauser ORIA15

  • Page 1 Certificates and approvals For certificates and approvals valid for the device: see the data on the Name and address of manufacturer nameplate Name of manufacturer: Endress+Hauser Wetzer GmbH + Co. KG Address of manufacturer: Obere Wank 1, D-87484 Nesselwang or www.endress.com...
  • Page 2 KA01149O Mounting Installation conditions Wall mounting with mounting kit (optionally available) • Operating altitude: according to IEC61010-1 up to 5 000 m (16 400 ft) above • Electrical safety: protection class III, overvoltage protection category II, pollution degree 2 • The permitted storage temperature is: –40 to +85 °C (–40 to +185 °F); it is possible to store the device at borderline temperatures for a limited period (48 hours maximum).
  • Page 3 KA01149O • Panel housing: Terminal Description The terminals are located on the rear of the housing. • Field device: • Field housing: Terminal in the housing The terminals are located inside the housing. The device has two M16 cable entries. The housing must be opened for wiring purposes. Operation of the spring terminals Shielding and grounding Optimum electromagnetic compatibility (EMC) can only be guaranteed if the...
  • Page 4 KA01149O Maintenance and cleaning No special maintenance work is required for the device. A clean, dry cloth can be used to clean the device.
