3.1.2 IEEE-488 Interface Function Codes and Messages

The IEEE-488 (GPIB) address is defined under the SYSTEM SETUP in the SYSTEM CONFIG
menu. Press [SYSTEM SETUP], then the numerical key [F3] to enter the SYSTEM CONFIG
menu. Press down arrow [⇓] to enter the GPIB ADDRESS code. To select a new IEEE-488
address, use the function keys. Refer to paragraph 2.3.2 for more information. The default setting
for the IEEE address is 17.
Table 3-2 defines the IEEE-488 interface codes and their function. Table 3-3 defines the IEEE-
488 interface messages the 1730T instrument responds to and their function.
Code
SH1
AH1
T6
L4
SR1
RL1
PP0
DC1
DT1
C0
Interface Function
Message
GTL Go To Local
To exit REMOTE Mode, press [F1] [F4] [SYSTEM SETUP]
Interface
Table 3-2: IEEE-488 Interface Functions
Function
Source Handshake (Talker)
Acceptor Handshake (Listener)
Basic Talker Function
Serial Poll Function
Listener-specified Talker Release Function
No TALK-ONLY Function
Basic Listener Function
Talker-specified Listener Release Function
Service Request Function
All Remote/Local Functions
No Parallel Poll Function
Device Clear Function
Device Trigger Function
No Controller Functions
Table 3-3: IEEE-488 Interface Messages
Description
Only addressed devices that receive this command are set to
local mode.
Cancels the remote control mode, making the front panel
switches operative.
NOTE:
150821/A4 Page 71 of 110
