Specifications - QuadTech 1730T Instruction Manual

Primary Parameters:
Secondary Parameters:
Measurement Accuracy:
Measurement Rate:
Measurement Mode:
Measurement Delay:
Averaging:
Ranging:
Equivalent Circuit:
Test Voltage:
Test Frequency:
Source Impedance:
150821/A4

Specifications

Ls, Lp, Cs, Cp, Rs, Rp and ⏐Z⏐, L2A and L2B
Ls, Lp: 0.001μH – 99.999kH
L2A, L2B: 0.001μH – 99.999kH
Cs, Cp: 0.001pF – 9.9999F
Rs, Rp: 0.01mΩ – 99.99MΩ
⏐Z⏐:
0.01mΩ – 99.99MΩ
D, Q, ESR, Xs, θ, N, 1/N, M, R2, and DCR
D: 0.0001 – 9999
Q: 0.0001 – 9999
ESR: 0.01mΩ – 99.99MΩ
Xs: 0.01mΩ – 99.99MΩ
θ:
-180.00° – 180.00°
N: 0.001 – 9999.9
1/N: 0.001 – 9999.9
M: 0.001μH – 99.999kH
R2: 0.01mΩ – 99.99MΩ
DCR 0.01mΩ – 99.99MΩ
Basic LCR: 0.1%
Fast: 62 measurements/second
Medium: 19 measurements/second
Slow: 3 measurements/second
Continuous or Trigger (INT, EXT or Manual)
0 – 10 seconds in 1ms increments
1-256 measurements
Automatic or User Selectable
Series or Parallel
10mV to 1.0V programmable in 10mV steps
10 User Selectable Test Frequencies: 50Hz, 60Hz, 100Hz, 120Hz,
1kHz, 10kHz, 20kHz, 40kHz, 50kHz and 100kHz
± (0.01% ±0.01Hz)
Accuracy:
100/25Ω: 100Ω±5% if DUT
10Ω/CC: 10Ω±10% if DUT
100Ω: 100Ω±5%; 25Ω±5%;
25Ω: 25Ω±5%;
Basic DQ: ±0.001
> 1Ω; 25 Ω±5% if DUT
IMPEDANCE
> 10Ω; CC: 100mA±5% if DUT
IMPEDANCE
< 1Ω;
IMPEDANCE
< 10Ω
IMPED
