Page 7: In Brief
Instrument Panel ...1-2 Initial Drive Information ...1-4 Remote Keyless Entry (RKE) System ...1-4 Remote Vehicle Start ...1-5 Door Locks ...1-5 Trunk Release ...1-6 Windows ...1-6 Seat Adjustment ...1-7 Heated and Ventilated Seats ...1-8 Head Restraint Adjustment ...1-8 Safety Belt ...1-9 Sensing System for Passenger Airbag ...1-9 Mirror Adjustment ...1-10 Steering Wheel Adjustment ...1-11...
Page 8: Instrument Panel
Instrument Panel Console-Shift Model shown, Column-Shift Model similar...
Page 9 A. Outlet Adjustment on page 4-41. B. Driver Information Center (DIC) Buttons. See Driver Information Center (DIC) on page 4-61. C. Exterior Lamps on page 4-25. D. Instrument Panel Cluster on page 4-47. E. Horn on page 4-3. F. Audio Steering Wheel Controls on page 4-119. G.
Page 10: Initial Drive Information
Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your speciﬁc vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual. Remote Keyless Entry (RKE) System The RKE transmitter is used to remotely lock and...
Page 11: Canceling A Remote Start
Remote Vehicle Start With this feature the engine can be started from outside of the vehicle. Starting the Vehicle 1. Aim the RKE transmitter at the vehicle. 2. Press 3. Immediately after completing Step 2, press and hold until the turn signal lamps ﬂash. When the vehicle starts, the parking lamps will turn on and remain on as long as the engine is running.
Page 12: Trunk Release
Power Door Locks On vehicles with power door locks, the switches are located on the front doors. " (Unlock): Press to unlock the doors. (Lock): Remove the key from the ignition and press to lock the doors. For more information, see: •...
Page 13: Seat Adjustment
Seat Adjustment Power Seats The power seat controls are on the outboard side of the seat. Move the seat forward or rearward by moving the control forward or rearward. Raise or lower the front or rear part of the seat cushion by moving the front or rear of the control up or down.
Page 14: Heated And Ventilated Seats
Power Lumbar Adjustment The control is located on the outboard side of the seat. Press the front or rear of the control to increase or decrease lumbar support. See Power Lumbar on page 2-4. Heated and Ventilated Seats On vehicles with heated and ventilated seats, the controls are located on the front doors and the ignition must be on to use the feature.
Page 15: Safety Belt
Safety Belt Refer to the following sections for important information on how to use safety belts properly. • Safety Belts: They Are for Everyone on page 2-12. • How to Wear Safety Belts Properly on page 2-17. • Lap-Shoulder Belt on page 2-26. •...
Page 16: Interior Mirror
Mirror Adjustment Exterior Mirrors Controls for the outside power folding mirrors are located on the driver door armrest. Press the selector switch (A) or (B) to choose either the left or right outside mirror. Then press the control pad to move the mirror to the desired direction. To fold the mirrors: Press the selector switch (C) to fold the mirrors out, then press (D) to fold the mirror toward the vehicle.
Page 17: Steering Wheel Adjustment
Steering Wheel Adjustment This feature allows the position of the steering wheel to be adjusted. The adjustment lever is located on the left side of the steering column. 1. Pull the lever to move the steering wheel up or down. 2.
Page 18: Interior Lighting
Interior Lighting Courtesy Lamps The courtesy lamps are located on the headliner above the rear seat. These lamps come on by turning the instrument panel brightness knob fully clockwise or when any door is opened and it is dark outside. Reading Lamps The reading lamps are located on the overhead console on the headliner and in the rear door opening.
Page 19: Windshield Wiper/Washer
Windshield Wiper/Washer The windshield wiper lever is located on the left side of the steering column. : Use for a single wiping cycle. : Delays wiping cycle. : Slow wipes. : Fast wipes. : Turns the wipers off. : Press and release this paddle, located at the top of the turn signal/multifunction lever, to spray washer ﬂuid on the windshield.
Page 20 Climate Controls Dual Climate Control System 1-14 Dual Climate Control System for Vehicles with Rear Climate Control A. Fan Control E. Air Conditioning B. Display F. Outside Air or AUX C. Air Delivery Mode G. Air Recirculation Control H. PASS (Passenger D.
Page 21: Vehicle Features
Vehicle Features Radio(s) Radio with CD : Press to turn the system on and off. Turn to increase or decrease the volume. BAND: Press to switch between AM, FM, or XM™. The selection displays. : Turn to select radio stations. ©...
Page 22: Setting The Clock
Setting the Clock The vehicle has an analog clock as well as the digital radio clock. At the time of new vehicle delivery, the digital radio clock display should be disabled. To use the digital radio clock and the analog clock, see detailed instructions in Setting the Clock on page 4-89 for your speciﬁc audio system.
Page 23: Satellite Radio
Satellite Radio XM is a satellite radio service that is based in the 48 contiguous United States and 10 Canadian provinces. XM satellite radio has a wide variety of programming and commercial-free music, coast-to-coast, and in digital-quality sound. A fee is required to receive the XM service. For more information, refer to: •...
Page 24: Navigation System
SRCE: Press to switch between the radio, CD, and for vehicles with, DVD, front auxiliary, and rear auxiliary. ¨ : Press seek the next radio station, or to select tracks on a CD or DVD. For more information, see Audio Steering Wheel Controls on page 4-119.
Page 25 The DIC buttons are located on the instrument panel to the left of the steering wheel. : Press to scroll through the trip and fuel displays. : Press to scroll through the vehicle information displays. : Press to customize the feature settings on your vehicle.
Page 26: Cruise Control
Cruise Control The cruise control buttons are located on the left side of the steering wheel. : Turns on the cruise control system. + RES: Press to accelerate or resume speed. SET–: Press to set the speed. : Press to cancel cruise control. For more information, see Cruise Control on page 4-12.
Page 27: Performance And Maintenance
Performance and Maintenance Traction Control System (TCS) The traction control system limits wheel spin. The system turns on automatically every time the vehicle is started. • To turn off traction control, press and release front of the shift lever. illuminates and the appropriate DIC message is displayed.
Page 28: Driving For Better Fuel Economy
Tire Sealant and Compressor Kit This vehicle may come with a jack and spare tire or a tire sealant and compressor kit. The kit can be used to seal small punctures in the tread area of the tire. See Tire Sealant and Compressor Kit on page 6-71 for complete operating information.
Page 29 Roadside Service U.S. or Canada: 1-800-882-1112 TTY Users: 1-888-889-2438 As the owner of a new Cadillac, you are automatically enrolled in the Roadside Service program which is available 24 hours a day, 365 days a year. Roadside Service and OnStar...
Page 30: How Onstar Service Works
How OnStar Service Works : This blue button connects you to a specially trained OnStar advisor to verify your account information and to answer questions. : Push this red emergency button to get priority help from specially trained OnStar emergency advisors. : Push this button for hands-free, voice-activated calling and to give voice commands for turn-by-turn navigation.
Page 31: Your Responsibility
Location information about the vehicle is only available if the GPS satellite signals are unobstructed and available. The vehicle must have a working electrical system, including adequate battery power, for the OnStar equipment to operate. There are other problems OnStar cannot control that may prevent OnStar from providing OnStar service at any particular time or place.
Page 32 ✍ NOTES 1-26...
Page 33: Table Of Contents
Section 2 Head Restraints ...2-2 Front Seats ...2-3 Power Seats ...2-3 Power Lumbar ...2-4 Massaging Lumbar ...2-4 Heated and Ventilated Seats ...2-5 Memory Seat, Mirrors and Steering Wheel ...2-6 Power Reclining Seatbacks ...2-8 Center Seat ...2-9 Rear Seats ...2-10 Heated Seats ...2-10 Rear Seat Pass-Through Door ...2-11 Power Lumbar ...2-11 Safety Belts ...2-12...
Page 34: Head Restraints
Head Restraints The vehicle’s front seats have adjustable head restraints in the outboard seating positions. WARNING: With head restraints that are not installed and adjusted properly, there is a greater chance that occupants will suffer a neck/spinal injury in a crash.
Page 35: Front Seats
Pull the head restraint up to raise it. To lower the head restraint, press the button, located on the top of the seatback, and push the restraint down. Push down on the head restraint after the button is released to make sure that it is locked in place. The head restraints are not designed to be removed.
Page 36: Massaging Lumbar
Power Lumbar The power lumbar controls are located on the outboard side of the front seats. Press the front or rear of the lumbar control to increase or decrease support. Press the top or bottom of the control to raise or lower the support mechanism. Massaging Lumbar On vehicles with this feature, the switch is...
Page 37 Heated and Ventilated Seats On vehicles with heated and ventilated seats, the ignition must be on to use the feature. The buttons are located on the front doors. Driver’s Side Buttons shown (Heated Seat Cushion and Seatback): Press this button to heat the seat cushion and seatback. (Heated Seatback): Press this button to heat the seatback.
Page 38: Memory Seat, Mirrors And Steering Wheel
Memory Seat, Mirrors and Steering Wheel On vehicles with the memory package, the controls are located on the driver door panel. The controls are used to program and recall memory settings for the driver seat, outside mirror, and steering wheel position if the vehicle has the power tilt wheel and telescopic steering feature.
Page 39 If you use the RKE transmitter to enter the vehicle and the remote recall memory feature is on, automatic seat and mirror movement will occur. See “MEMORY SEAT RECALL” under DIC Vehicle Customization on page 4-80 for more information. To stop recall movement of the memory feature at any time, press one of the power seat controls, memory buttons, power tilt wheel control, or power mirror buttons.
Page 40: Power Reclining Seatbacks
Power Reclining Seatbacks The seats have power reclining seatbacks. Use the vertical power seat control located on the outboard side of the seat. • Press the control toward the rear of the vehicle to recline the seatback. • Press the control toward the front of the vehicle to raise the seatback.
Page 41: Center Seat
Do not have a seatback reclined if the vehicle is moving. Center Seat The vehicle may have a front center seat. This seat can be converted to a storage area by lowering the seatback. See Center Flex Storage Unit on page 3-56.
Page 42: Rear Seats
Rear Seats Heated Seats Your vehicle may have heated rear seats. To operate the rear heated seats, the ignition must be on. The buttons are located on the rear doors. (Heated Seatback): Press to turn on the heated seatback. (Heated Seat and Seatback): Press to turn on the heated seat and seatback.
Page 43: Rear Seat Pass-Through Door
Rear Seat Pass-Through Door Your vehicle has a pass-through door that provides access to the trunk from the rear seats. See “Rear Seat Pass-Through Door” under Trunk on page 3-12. Power Lumbar Your vehicle may be equipped with four-way lumbar support, without the massage feature, for the outboard rear seat positions.
Page 44: Safety Belts
Safety Belts Safety Belts: They Are for Everyone This section of the manual describes how to use safety belts properly. It also describes some things not to do with safety belts. WARNING: Do not let anyone ride where a safety belt cannot be worn properly.
Page 45: Why Safety Belts Work
In most states and in all Canadian provinces, the law requires wearing safety belts. Here is why: You never know if you will be in a crash. If you do have a crash, you do not know if it will be a serious one. A few crashes are mild, and some crashes can be so serious that even buckled up, a person would not survive.
Page 46 Put someone on it. 2-14 Get it up to speed. Then stop the vehicle. The rider does not stop.
Page 47 The person keeps going until stopped by something. or the instrument panel... In a real vehicle, it could be the windshield... 2-15...
Page 48: Questions And Answers About Safety Belts
or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense. 2-16 Questions and Answers About Safety Belts...
Page 49: How To Wear Safety Belts Properly
If I am a good driver, and I never drive far from home, why should I wear safety belts? You may be an excellent driver, but if you are in a crash — even one that is not your fault — you and your passenger(s) can be hurt.
Page 50 Sit up straight and always keep your feet on the ﬂoor in front of you. The lap part of the belt should be worn low and snug on the hips, just touching the thighs. 2-18 In a crash, this applies force to the strong pelvic bones and you would be less likely to slide under the lap belt.
Page 51 What is wrong with this? The shoulder belt is too loose. It will not give as much protection this way. WARNING: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury.
Page 52 What is wrong with this? The lap belt is too loose. It will not give nearly as much protection this way. 2-20 WARNING: You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force on your abdomen.
Page 53 What is wrong with this? The belt is buckled in the wrong buckle. WARNING: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not on the pelvic bones.
Page 54 What is wrong with this? The belt is over an armrest. 2-22 WARNING: You can be seriously injured if your belt goes over an armrest like this. The belt would be much too high. In a crash, you can slide under the belt. The belt force would then be applied on the abdomen, not on the pelvic bones, and that could cause serious or fatal injuries.
Page 55 What is wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. WARNING: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
Page 56 What is wrong with this? The belt is behind the body. 2-24 WARNING: You can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, you would not be restrained by the shoulder belt. Your body could move too far forward increasing the chance of head and neck injury.
Page 57 What is wrong with this? The belt is twisted across the body. WARNING: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer/retailer to ﬁx it.
Page 58: Lap-Shoulder Belt
Lap-Shoulder Belt All seating positions in the vehicle have a lap-shoulder except for the center front passenger position (if equipped), which has a lap belt. See Lap Belt on page 2-32 for more information. The following instructions explain how to wear a lap-shoulder belt properly.
Page 59 5. To make the lap part tight, pull up on the shoulder belt. It may be necessary to pull stitching on the safety belt through the latch plate to fully tighten the lap belt on smaller occupants. To unlatch the belt, push the button on the buckle. The belt should return to its stowed position.
Page 60 Shoulder Belt Height Adjuster The vehicle has a shoulder belt height adjuster for the driver and right front passenger seating positions. Adjust the height so that the shoulder portion of the belt is centered on the shoulder. The belt should be away from the face and neck, but not falling off the shoulder.
Page 61 Here is how to install a comfort guide to the safety belt: 2. Place the guide over the belt, and insert the two edges of the belt into the slots of the guide. 1. Remove the guide from its storage pocket on the rear side of the seatback.
Page 62 3. Be sure that the belt is not twisted and it lies ﬂat. The elastic cord must be under the belt and the guide on top. 2-30 WARNING: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured.
Page 63: Safety Belt Use During Pregnancy
4. Buckle, position, and release the safety belt as described earlier in this section. Make sure that the shoulder belt crosses the shoulder. To remove and store the comfort guide, squeeze the belt edges together so that the safety belt can be removed from the guide.
Page 64: Lap Belt
Lap Belt This part is only for the lap belt. To learn how to wear a lap-shoulder belt, see Lap-Shoulder Belt on page 2-26. You vehicle may have a center seating position. When you sit in the center front seating position, you have a lap safety belt, which has no retractor.
Page 65: Safety Belt Extender
Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt is not long enough, your dealer/retailer will order you an extender. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.
Page 66 The manufacturer’s instructions that come with the booster seat, state the weight and height limitations for that booster. Use a booster seat with a lap-shoulder belt until the child passes the below ﬁt test: • Sit all the way back on the seat. Do the knees bend at the seat edge? If yes, continue.
Page 67 WARNING: Never do this. Never allow two children to wear the same safety belt. The safety belt can not properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A safety belt must be used by only one person at a time. 2-35...
Page 68 WARNING: Never do this. Never allow a child to wear the safety belt with the shoulder belt behind their back. A child can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, the child would not be restrained by the shoulder belt.
Page 69: Infants And Young Children
Infants and Young Children Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 70 WARNING: Never do this. Never hold an infant or a child while riding in a vehicle. Due to crash forces, an infant or a child will become so heavy it is not possible to hold it during a crash. For example, in a crash at only 40 km/h (25 mph), a 5.5 kg (12 lb) infant will suddenly become a 110 kg (240 lb) force on a person’s arms.
Page 71 WARNING: Never do this. Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Never put a rear-facing child restraint in the right front seat. Secure a rear-facing child restraint in a rear seat.
Page 72 What are the different types of add-on child restraints? Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic types. Selection of a particular restraint should take into consideration not only the child’s weight, height, and age but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.
Page 73: Child Restraint Systems
WARNING: A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should. Instead, it may settle up around the child’s abdomen. In a crash, the belt would apply force on a body area that is unprotected by any bony structure.
Page 74 A booster seat (C-D) is a child restraint designed to improve the ﬁt of the vehicle’s safety belt system. A booster seat can also help a child to see out the window. 2-42 Securing an Add-On Child Restraint in the Vehicle WARNING: A child can be seriously injured or killed in a crash if the child restraint is not properly secured in the...
Page 75: Securing The Child Within The Child Restraint
When securing an add-on child restraint, refer to the instructions that come with the restraint which may be on the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not available, obtain a replacement copy from the manufacturer.
Page 76: Where To Put The Restraint
Where to Put the Restraint According to accident statistics, children and infants are safer when properly restrained in a child restraint system or infant restraint system secured in a rear seating position. We recommend that children and child restraints be secured in a rear seat, including: an infant or a child riding in a rear-facing child restraint;...
Page 77: Lower Anchors And Tethers For Children (Latch)
WARNING: A child in a child restraint in the center front seat can be badly injured or killed by the frontal airbags if they inﬂate. Never secure a child restraint in the center front seat. It is always better to secure a child restraint in a rear seat.
Page 78: Top Tether Anchor
Lower Anchors Lower anchors (A) are metal bars built into the vehicle. There are two lower anchors for each LATCH seating position that will accommodate a child restraint with lower attachments (B). 2-46 Top Tether Anchor A top tether (A, C) anchors the top of the child restraint to the vehicle.
Page 79 Some child restraints that have top tethers are designed for use with or without the top tether being attached. Others require the top tether always to be attached. In Canada, the law requires that forward-facing child restraints have a top tether, and that the tether be attached.
Page 80: Securing A Child Restraint Designed For The Latch System
Do not secure a child restraint in a position without a top tether anchor if a national or local law requires that the top tether be attached, or if the instructions that come with the child restraint say that the top tether must be attached.
Page 81 WARNING: Do not attach more than one child restraint to a single anchor. Attaching more than one child restraint to a single anchor could cause the anchor or attachment to come loose or even break during a crash. A child or others could be injured. To reduce the risk of serious or fatal injuries during a crash, attach only one child restraint per anchor.
Page 82 2. If the child restraint manufacturer recommends that the top tether be attached, attach and tighten the top tether to the top tether anchor, if equipped. Refer to the child restraint instructions and the following steps: 2.1. Find the top tether anchor. 2.2.
Page 83: Securing A Child Restraint In A Rear Seat Position
Securing a Child Restraint in a Rear Seat Position When securing a child restraint in a rear seating position, study the instructions that came with the child restraint to make sure it is compatible with this vehicle. If the child restraint has the LATCH system, see Lower Anchors and Tethers for Children (LATCH) on page 2-45 for how and where to install the child restraint using LATCH.
Page 84 3. Push the latch plate into the buckle until it clicks. 4. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 85: Securing A Child Restraint In The Center Front Seat Position
5. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. When installing a forward-facing child restraint, it may be helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 86: Securing A Child Restraint In The Right Front Seat Position
Securing a Child Restraint in the Right Front Seat Position This vehicle has airbags. A rear seat is a safer place to secure a forward-facing child restraint. See Where to Put the Restraint on page 2-44. In addition, the vehicle has a passenger sensing system which is designed to turn off the right front passenger frontal airbag and seat-mounted side impact airbag under certain conditions.
Page 87 If the child restraint has the LATCH system, see Lower Anchors and Tethers for Children (LATCH) on page 2-45 for how and where to install the child restraint using LATCH. If a child restraint is secured using a safety belt and it uses a top tether, see Lower Anchors and Tethers for Children (LATCH) on page 2-45 for top tether anchor locations.
Page 88 4. Push the latch plate into the buckle until it clicks. 5. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 89 6. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. When installing a forward-facing child restraint, it may be helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 90: Airbag System
Airbag System The vehicle has the following airbags: • A frontal airbag for the driver. • A frontal airbag for the right front passenger. • A seat-mounted side impact airbag for the driver. • A seat-mounted side impact airbag for the right front passenger.
Page 91 Here are the most important things to know about the airbag system: WARNING: You can be severely injured or killed in a crash if you are not wearing your safety belt — even if you have airbags. Airbags are designed to work with safety belts, but do not replace them.
Page 92: Where Are The Airbags
WARNING: Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor its airbag system is designed for them.
Page 93 The right front passenger frontal airbag is in the instrument panel on the passenger’s side. Driver Side shown, Passenger Side similar The seat-mounted side impact airbags for the driver and right front passenger are in the side of the seatbacks closest to the door.
Page 94 Driver Side shown, Passenger Side similar If the vehicle has roof-rail airbags for the driver, right front passenger, and second row outboard passengers, they are in the ceiling above the side windows. 2-62 WARNING: If something is between an occupant and an airbag, the airbag might not inﬂate properly or it might force the object into that person causing severe injury or even death.
Page 95: When Should An Airbag Inﬂate
When Should an Airbag Inﬂate? Frontal airbags are designed to inﬂate in moderate to severe frontal or near-frontal crashes to help reduce the potential for severe injuries mainly to the driver’s or right front passenger’s head and chest. However, they are only designed to inﬂate if the impact exceeds a predetermined deployment threshold.
Page 96 Your vehicle also has a dual-depth passenger airbag that adjusts the restraint according to crash severity, seat location, and safety belt status using electronic frontal sensor(s) and other special sensors which enable the sensing system to monitor the position of the front passenger seat.
Page 97: What Makes An Airbag Inﬂate
What Makes an Airbag Inﬂate? In a deployment event, the sensing system sends an electrical signal triggering a release of gas from the inﬂator. Gas from the inﬂator ﬁlls the airbag causing the bag to break out of the cover and deploy. The inﬂator, the airbag, and related hardware are all part of the airbag module.
Page 98: What Will You See After An Airbag Inﬂates
What Will You See After an Airbag Inﬂates? After the frontal airbags and seat-mounted side impact airbags inﬂate, they quickly deﬂate, so quickly that some people may not even realize an airbag inﬂated. Roof-rail airbags may still be at least partially inﬂated for some time after they deploy.
Page 99: Passenger Sensing System
WARNING: A crash severe enough to inﬂate the airbags may have also damaged important functions in the vehicle, such as the fuel system, brake and steering systems, etc. Even if the vehicle appears to be drivable after a moderate crash, there may be concealed damage that could make it difficult to safely operate the vehicle.
Page 100 When the system check is complete, either the word ON or OFF, or the symbol for on or off, will be visible. See Passenger Airbag Status Indicator on page 4-51. The passenger sensing system turns off the right front passenger frontal airbag and seat-mounted side impact airbag under certain conditions.
Page 101 The passenger sensing system is designed to turn off the right front passenger airbag and seat-mounted side impact airbag if: • The right front passenger seat is unoccupied. • The system determines that an infant is present in a rear-facing infant seat. •...
Page 102 If the On Indicator is Lit for a Child Restraint If a child restraint has been installed and the on indicator is lit: 1. Turn the vehicle off. 2. Remove the child restraint from the vehicle. 3. Remove any additional items from the seat such as blankets, cushions, seat covers, seat heaters, or seat massagers.
Page 103 If the Off Indicator is Lit for an Adult-Size Occupant If a person of adult-size is sitting in the right front passenger seat, but the off indicator is lit, it could be because that person is not sitting properly in the seat. If this happens, use the following steps to allow the system to detect that person and enable the right front passenger frontal airbag and seat-mounted side...
Page 104: Servicing Your Airbag-Equipped Vehicle
Additional Factors Affecting System Operation Safety belts help keep the passenger in position on the seat during vehicle maneuvers and braking, which helps the passenger sensing system maintain the passenger airbag status. See “Safety Belts” and “Child Restraints” in the Index for additional information about the importance of proper restraint use.
Page 105: Adding Equipment To Your Airbag-Equipped Vehicle
Adding Equipment to Your Airbag-Equipped Vehicle Is there anything I might add to or change about the vehicle that could keep the airbags from working properly? Yes. If you add things that change your vehicle’s frame, bumper system, height, front end or side sheet metal, they may keep the airbag system from working properly.
Page 106: Restraint System Check
Restraint System Check Checking the Restraint Systems Safety Belts Now and then, check that the safety belt reminder light, safety belts, buckles, latch plates, retractors, and anchorages are all working properly. Look for any other loose or damaged safety belt system parts that might keep a safety belt system from doing its job.
Page 107: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts After a Crash WARNING: A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary replacements made as soon as...
Page 108 ✍ NOTES 2-76...
Page 109: Features And Controls
Section 3 Keys ...3-3 Remote Keyless Entry (RKE) System ...3-4 Remote Keyless Entry (RKE) System Operation ...3-4 Remote Vehicle Start ...3-7 Doors and Locks ...3-9 Door Locks ...3-9 Central Door Unlocking System ...3-10 Power Door Locks ...3-10 Programmable Automatic Door Locks ...3-10 Rear Door Security Locks ...3-10 Lockout Protection ...3-11 Trunk ...3-12...
Page 110 Section 3 Object Detection Systems ...3-40 Ultrasonic Front and Rear Parking Assist (UFRPA) ...3-40 Side Blind Zone Alert (SBZA) ...3-43 Lane Departure Warning (LDW) ...3-46 Universal Home Remote System ...3-48 Universal Home Remote System Operation (With Three Round LED) ...3-49 Features and Controls Storage Areas ...3-55 Glove Box ...3-55...
Page 111: Keys
Keys WARNING: Leaving children in a vehicle with the ignition key is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keys in the ignition and children could be seriously injured or killed if caught in the path of a closing window.
Page 112: Remote Keyless Entry (Rke) System
Remote Keyless Entry (RKE) System See Radio Frequency Statement on page 8-20 for information regarding Part 15 of the Federal Communications Commission (FCC) Rules and RSS-210/211 of Industry and Science Canada. Changes or modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment.
Page 113 (Lock): Press to lock all the doors. If enabled through the Driver Information Center (DIC), the parking lamps may ﬂash once to indicate locking has occurred. The horn may chirp when is pressed again within ﬁve seconds. See DIC Vehicle Customization on page 4-80 for additional information.
Page 114: Battery Replacement
Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer/retailer. When the replacement transmitter is programmed to the vehicle, all remaining transmitters must also be programmed.
Page 115: Remote Vehicle Start
Remote Vehicle Start The remote vehicle starting feature allows you to start the engine from outside of the vehicle. It also starts up the vehicle’s automatic climate control system. When the remote start system is active, the climate control system will heat and cool the inside of the vehicle according to the previous settings of the system before turning the vehicle off.
Page 116: Remote Start Ready
After entering the vehicle during a remote start, insert and turn the key to ON/RUN to drive the vehicle. If the vehicle is left running it will automatically shut off after 10 minutes unless a time extension has been done. To manually shut off a remote start: •...
Page 117: Doors And Locks
Doors and Locks Door Locks WARNING: Unlocked doors can be dangerous. • Passengers, especially children, can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle will not open it. The chance of being thrown out of the vehicle in a crash is increased if the doors are not locked.
Page 118: Central Door Unlocking System
Central Door Unlocking System The vehicle has a central door unlocking mode. When unlocking the driver door, the other doors can be unlocked at the same time by turning the key clockwise in the door lock cylinder twice. Power Door Locks On vehicles with power door locks, the switches are located on the front doors.
Page 119: Lockout Protection
To assist in ﬁnding the lock, the vehicle has the following: To use the lock: 1. Insert the key into the security lock slot and turn it so the slot is in the horizontal position. 2. Close the door. 3. Do the same for the other rear door. To open a rear door when the security lock is on, do the following: 1.
Page 120: Trunk
Trunk WARNING: Exhaust gases can enter the vehicle if it is driven with the liftgate, trunk/hatch open, or with any objects that pass through the seal between the body and the trunk/hatch or liftgate. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled.
Page 121: Emergency Trunk Release Handle
Emergency Trunk Release Handle Notice: Do not use the emergency trunk release handle as a tie-down or anchor point when securing items in the trunk as it could damage the handle. The emergency trunk release handle is only intended to aid a person trapped in a latched trunk, enabling them to open the trunk from the inside.
Page 122: Windows
Windows WARNING: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 123: Power Windows
Power Windows WARNING: Leaving children in a vehicle with the keys is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function and they could be seriously injured or killed if caught in the path of a closing window.
Page 124 Express-Down/Up Windows Windows with the express feature allow the windows to be raised and lowered all the way without holding the switch. Press or pull the switch fully and release it to activate the express feature. The express mode can be canceled at any time by brieﬂy pressing or pulling the switch.
Page 125: Sun Visors
Programming the Power Windows If the battery on the vehicle has been recharged, disconnected, or is not working, you will need to reprogram each front power window for the express-up feature to work. Before reprogramming, replace or recharge the vehicle’s battery. To program each front window, follow these steps: 1.
Page 126: Theft-Deterrent Systems
Rear Power Sunshade If your vehicle has a rear power sunshade, it helps to reduce the amount of heat and light entering the rear window. The switch is located on the overhead console. The rear power sunshade is located in the rear shelf. It only works while the ignition is on or while the Retained Accessory Power (RAP) is active.
Page 127: Content Theft-Deterrent
— (On): Press this side of the button to turn the lockout feature on. When the lockout feature is turned on, the trunk cannot be unlocked with the keyless entry transmitter or the trunk release button located near the headlamp switch on the instrument panel. If the valet lockout feature is on it will also disable the Universal Home Remote transmitter, if equipped.
Page 128: Testing The Alarm
The theft-deterrent system will not arm if you lock the doors with a key or use the manual door lock. It arms only if you use a power door lock with the door open or the RKE transmitter. To avoid arming the alarm by accident: •...
Page 129: Pass-Key Iii+ Electronic Immobilizer
® PASS-Key III+ Electronic Immobilizer See Radio Frequency Statement on page 8-20 for information regarding Part 15 of the Federal Communications Commission (FCC) Rules and RSS-210/211 of Industry and Science Canada. ® PASS-Key III+ Electronic Immobilizer Operation ® Your vehicle has PASS-Key III+ (Personalized Automotive Security System) theft-deterrent system.
Page 130: Starting And Operating Your Vehicle
See your dealer/retailer or a locksmith who can service ® PASS-Key III+ to get a new key blank that is cut exactly as the ignition key that operates the system. To program the new key: 1. Verify that the new key has a 2.
Page 131: Ignition Positions
Ignition Positions The ignition switch has four different positions: In order to shift out of P (Park), ignition must be in the ON/RUN or ACC/ACCESSORY and the brake pedal must be applied. Notice: Using a tool to force the key to turn in the ignition could cause damage to the switch or break the key.
Page 132: Retained Accessory Power (Rap)
C (ON/RUN): This position is where the key returns to after the vehicle is started. This position displays some of the warning and indicator lights. The battery could be drained if you leave the key in the ACC/ACCESSORY or ON/RUN position with the engine off.
Page 133 The vehicle has a Computer-Controlled Cranking System. This feature assists in starting the engine and protects components. If the ignition key is turned to the START position, and then released when the engine begins cranking, the engine will continue cranking for a few seconds or until the vehicle starts.
Page 134: Engine Coolant Heater
Engine Coolant Heater The engine coolant heater can provide easier starting and better fuel economy during engine warm-up in cold weather conditions at or below 0°F (−18°C). Vehicles with an engine coolant heater should be plugged in at least four hours before starting. To Use the Engine Coolant Heater 1.
Page 135: Automatic Transmission Operation
Automatic Transmission Operation The automatic transmission may have a shift lever located either on the steering column or on the console between the seats. There are several different positions for the shift lever. P (Park): This position locks the front wheels. It is the best position to use when you start the engine because the vehicle cannot move easily.
Page 136 R (Reverse): Use this gear to back up. Notice: Shifting to R (Reverse) while the vehicle is moving forward could damage the transmission. The repairs would not be covered by the vehicle warranty. Shift to R (Reverse) only after the vehicle is stopped.
Page 137: Performance Shifting
D (Drive) can be used for towing. You may want to shift the transmission to 3 (Third) or, if necessary, to a lower gear if the transmission shifts too often under heavy loads and/or hilly conditions. See Towing a Trailer on page 5-26 for more information. 3 (Third): This position is also used for normal driving.
Page 138: Parking Brake
Parking Brake The parking brake pedal is located to the left of the regular brake pedal, near the driver door. To set the parking brake, hold the regular brake pedal down, then push the parking brake pedal down. If the ignition is on, the brake system warning light on the instrument panel cluster should come on.
Page 139: Shifting Into Park
Shifting Into Park WARNING: It can be dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake ﬁrmly set. The vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 140: Shifting Out Of Park
Leaving the Vehicle With the Engine Running WARNING: It can be dangerous to leave the vehicle with the engine running. The vehicle could move suddenly if the shift lever is not fully in P (Park) with the parking brake ﬁrmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch ﬁre.
Page 141: Parking Over Things That Burn
Console Shift If the console shift cannot be moved out of P (Park) 1. Apply the regular brakes. 2. Turn the ignition to ON/RUN or ACC/ACCESSORY position. See Ignition Positions on page 3-23 for more information. 3. Push the shift lever all the way into P (Park). 4.
Page 142: Engine Exhaust
Engine Exhaust WARNING: Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. Exposure to CO can cause unconsciousness and even death. Exhaust may enter the vehicle if: • The vehicle idles in areas with poor ventilation (parking garages, tunnels, deep snow that may block underbody airﬂow or tail pipes).
Page 143: Running The Vehicle While Parked
Running the Vehicle While Parked It is better not to park with the engine running. But if you ever have to, here are some things to know. WARNING: Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle.
Page 144: Mirrors
Mirrors Automatic Dimming Rearview Mirror The vehicle has an automatic dimming inside rearview mirror with a compass display. Automatic dimming reduces the glare of lights from behind the vehicle. The dimming feature comes on and the indicator light illuminates each time the vehicle is started. (On/Off): Press and hold seconds to turn the dimming feature and compass display on or off.
Page 145: Outside Power Foldaway Mirrors
Compass Variance The compass is set to zone eight. If you do not live in zone eight or drive out of the area, the compass variance needs to be changed to the appropriate zone. To adjust for compass variance: 1. Find the current location and variance zone number on the following zone map.
Page 146: Mirror Adjustment
Mirror Adjustment 1. Press (C) to unfold the mirrors out to the driving position. 2. Press (D) to fold the mirrors toward the vehicle. Resetting the Power Foldaway Mirrors Reset the power foldaway mirrors if: • The mirrors are accidentally obstructed while folding.
Page 147: Park Tilt Mirrors
Park Tilt Mirrors If your vehicle is equipped with memory mirrors, it is capable of performing the park tilt mirror feature. This feature allows the driver and passenger side mirror to tilt to a factory programmed position when the vehicle is in R (Reverse).
Page 148: Object Detection Systems
Object Detection Systems Ultrasonic Front and Rear Parking Assist (UFRPA) For vehicles with the Ultrasonic Front and Rear Parking Assist (UFRPA) system, it operates at speeds less than 8 km/h (5mph), and assists the driver with parking and avoiding objects. It can determine how close objects are to the front bumper, up to 1.2 m (4 ft.) in front of the vehicle and the rear bumper, up to 2.5 m (8 ft.) behind the vehicle.
Page 149: How The System Works
Rear Parking Assist Front Parking Assist Display The front display is located on top of the instrument panel to the right of the driver. The front display will have either three or six lights to provide distance and system information. With Adaptive Cruise control (ACC), it will have three lights along with the ACC lights.
Page 150 Moving Forward When the vehicle is started, the front display will brieﬂy illuminate to let you know the system is working. The following describes what will occur with the front display as you get closer to a object detected in the front of the vehicle: Description Metric...
Page 151: Side Blind Zone Alert (Sbza)
When the System Does Not Seem to Work Properly If the URPA system will not activate due to a temporary condition, the message PARK ASSIST OFF will be displayed on the DIC and a red light will be shown on the rear URPA display when the shift lever is moved into R (Reverse).
Page 152 SBZA Detection Zones The SBZA sensor covers a zone of approximately one lane over from both sides of the vehicle, 3.5 m (11 ft). This zone starts at each side mirror and goes back approximately 5 m (16 ft). The height of the zone is approximately between 0.5 m (1.5 ft) and 2.0 m (6 ft) off the ground.
Page 153 When the System Does Not Seem To Work Properly Occasional missed alerts can occur under normal circumstances and will increase in wet conditions. The system does not need to be serviced due to an occasional missed alert. The number of missed alerts will increase with increased rainfall or road spray.
Page 154: Lane Departure Warning (Ldw)
FCC Information See Radio Frequency Statement on page 8-20 for FCC information. Frequency of operation: 24.05GHz – 24.25GHz Field Strength: Not greater than 2.5V/m peak (0.25V/m average) at a distance of 3 m. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modiﬁcations to this equipment.
Page 155 WARNING: (Continued) LDW will indicate the system is working whenever it detects either the left or right lane marking. So if you depart on the side of the lane that LDW is not detecting, LDW will not warn you. If you do not carefully maintain your vehicle position within the lane, vehicle damage, injury, or death could occur.
Page 156 This symbol will change to amber and ﬂash and three beeps will sound if you cross a detected lane marking without using the turn signal. If the LDW symbol does not appear, LDW is not currently operating and will not warn you. To change the volume of the warning chime, see Chime Volume under DIC Vehicle Customization on page 4-80 for more information.
Page 157: Universal Home Remote System
Universal Home Remote System Operation (With Three Round LED) This vehicle may have the Universal Home Remote System. If there are three round Light Emitting Diode (LED) indicator lights above the Universal Home Remote buttons, follow the instructions below. This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices.
Page 158 Programming a garage door opener involves time-sensitive actions, so read the entire procedure before starting. Otherwise, the device will time out and the procedure will have to be repeated. To program up to three devices: 1. From inside the vehicle, press the two outside buttons at the same time for one to two seconds, and immediately release them.
Page 159 4. Immediately, within one second, release the button when the garage door moves. The indicator light will blink rapidly until programming is complete. 5. Press and release the same button again. The garage door should move, conﬁrming that programming is successful and complete. To program another Rolling Code device such as an additional garage door opener, a security device, or home automation device, repeat Steps 1 through 5,...
Page 160 The garage door opener receiver (motor head unit) could also have a row of dip switches that can be used when programming the Universal Home Remote. If the total number of switches on the motor head and hand held transmitter are different, or if the dip switch settings are different, use the dip switch settings on the motor head unit to program the Universal Home Remote.
Page 161 2. Write down the eight to 12 switch settings from left to right as follows: • When a switch is in the up position, write “Left.” • When a switch is in the down position, write “Right.” • If a switch is set between the up and down position, write “Middle.”...
Page 162: Reprogramming Universal Home Remote Buttons
5. After entering all of the switch positions, again, ﬁrmly press and release all three buttons at the same time. The indicator lights will turn on. 6. Press and hold the button that will be used to control the garage door until the garage door moves.
Page 163: Storage Areas
Storage Areas Glove Box Lift the glove box handle up to open it. Use the key to lock and unlock the glove box. Cupholders There are cupholders located in the full ﬂoor console, or in the front of the center seat console. Cupholders are also located in the rear armrest.
Page 164: Center Flex Storage Unit
Center Flex Storage Unit This vehicle may have a center ﬂex storage unit that includes a front center seat with a lap belt and an underseat storage compartment. The center seatback can also be used as an armrest. Cupholders are also located at the front edge of the storage unit and can be accessed by folding the compartment forward.
Page 165: Sunroof
Sunroof The vehicle may have a power sunroof. The switches that operate the sunroof are located on the overhead console. To open or close the sunroof, the ignition must be turned to ON/RUN or Retained Accessory Power (RAP) must be active. See Retained Accessory Power (RAP) on page 3-24.
Page 166 ✍ NOTES 3-58...
Page 167 Section 4 Instrument Panel Overview ...4-3 Hazard Warning Flashers ...4-3 Horn ...4-3 Tilt Wheel ...4-3 Power Tilt Wheel and Telescopic Steering Column ...4-4 Heated Steering Wheel ...4-4 Turn Signal/Multifunction Lever ...4-5 Turn and Lane-Change Signals ...4-5 Headlamp High/Low-Beam Changer ...4-6 Forward Collision Alert (FCA) System ...4-6 Flash-to-Pass ...4-10 Windshield Wipers ...4-10...
Page 168 Section 4 Charging System Light ...4-52 Brake System Warning Light ...4-52 Antilock Brake System (ABS) Warning Light ...4-53 Traction Control System (TCS) Warning Light ...4-54 ® StabiliTrak Indicator Light ...4-54 Lane Departure Warning (LDW) Light ...4-55 Engine Coolant Temperature Warning Light ...4-55 Engine Coolant Temperature Gage ...4-56 Tire Pressure Light ...4-56 Malfunction Indicator Lamp ...4-57...
Page 169: Instrument Panel Overview
Instrument Panel Overview Hazard Warning Flashers (Hazard Warning Flasher): Press this button located on the instrument panel, to make the front and rear turn signal lamps ﬂash on and off. This warns others that you are having trouble. Press again to turn the ﬂashers off. Horn Press near or on the horn symbols on the steering wheel pad to sound the horn.
Page 170: Power Tilt Wheel And Telescopic Steering Column
Power Tilt Wheel and Telescopic Steering Column If the vehicle has this feature, the power tilt and telescope wheel control is located on the outboard side of the steering column. Press the control up or down to tilt the steering wheel up or down.
Page 171: Turn Signal/Multifunction Lever
Turn Signal/Multifunction Lever The lever on the left side of the steering column includes the following: : Turn and Lane-Change Signals : Headlamp High/Low-Beam Changer : Windshield Wipers : Windshield Washer Flash-To-Pass Feature. Information for these features is on the pages following. Turn and Lane-Change Signals An arrow on the instrument panel cluster ﬂashes in the...
Page 172: Headlamp High/Low-Beam Changer
Turn Signal On Chime If the turn signal is left on, a warning chime sounds and the Driver Information Center (DIC) will display TURN SIGNAL ON after driving about a mile as a reminder to turn it off. See DIC Warnings and Messages on page 4-67.
Page 173 The Forward Collision Alert (FCA) system provides an audible and visual alert if you approach a vehicle too quickly that is directly ahead. FCA also provides a visual alert with no audible alert if you are following another vehicle much too closely. The FCA alert symbol is located on top of the instrument panel to the right of the driver.
Page 174 FCA is enabled when the green light on the button is lit. FCA is disabled when the indicator light is amber. WARNING: • On winding roads, FCA may not detect a vehicle ahead. You could crash into a vehicle ahead of you. Do not rely on FCA on winding roads.
Page 175: Other Messages
WARNING: When the Adaptive Cruise Control radar is blocked by snow, ice, or dirt, it may not detect a vehicle ahead. FCA may not help you avoid a collision under these conditions. Do not use FCA when the radar is blocked by snow, ice, or dirt. Keep your radar clean.
Page 176: Flash-To-Pass
Flash-to-Pass This feature lets you use the high-beam headlamps to signal the driver in front of you that you want to pass. The ﬂash-to-pass feature will only work with the headlamps on. It does not work with Daytime Running Lamps (DRL). Pull and hold the turn signal lever toward you to use.
Page 177: Windshield Washer
The system operates in the delay mode. If the system is left on for long periods of time, occasional wipes may occur without any moisture on the windshield. This is normal and indicates that the Rainsense is active. ™ The Rainsense system is activated by turning the wiper control band to one of the ﬁve sensitivity levels within the delay area.
Page 178: Cruise Control
Cruise Control With cruise control, a speed of approximately 40 km/h (25 mph) or more can be maintained without keeping your foot on the accelerator. Cruise control does not work at speeds below about 40 km/h (25 mph). A cruise control light appears in the instrument panel cluster when the cruise control is on.
Page 179 The cruise control buttons are located on left side of the steering wheel. (On): Turns on the cruise control system. + RES (Resume/Accelerate): Press to make the vehicle accelerate or resume to a previously set speed. SET– (Set): Press to set the speed. (Cancel): Press to cancel cruise control.
Page 180: Increasing Speed While Using Cruise Control
Increasing Speed While Using Cruise Control There are two ways to go to a higher speed: • Use the accelerator pedal to get to the higher speed. Press the SET– button, then release the button and the accelerator pedal. The vehicle now cruises at the higher speed.
Page 181: Adaptive Cruise Control
Using Cruise Control on Hills How well your cruise control works on hills depends upon the vehicle speed, load, and the steepness of the hills. When going up steep hills, you might have to step on the accelerator pedal to maintain the vehicle’s speed.
Page 182 application of the vehicle’s brakes. To disengage ACC, apply the brake. If no vehicle is in your path, the vehicle will react like traditional cruise control. WARNING: Adaptive Cruise Control will not apply hard braking or bring the vehicle to a complete stop. It will not respond to stopped vehicles, pedestrians or animals.
Page 183 WARNING: (Continued) • When weather limits visibility, such as when in fog, rain, or snow conditions, Adaptive Cruise Control performance is limited. There may not be enough distance to adapt to the changing traffic conditions. Do not use cruise control when visibility is low.
Page 184 Engaging ACC With the Set Button WARNING: If you leave your Adaptive Cruise Control switch on when you are not using cruise, you might hit a button and go into cruise when you do not want to. You could be startled and even lose control. Keep the Adaptive Cruise Control switch off until you want to use cruise control.
Page 185 Your vehicle will not reach the set speed until the system determines there is not a vehicle in front of you. At that point, your vehicle speed will increase to the set speed. Decreasing Set Speed While Using ACC Press the SET– button until you reach the lower speed desired, then release it.
Page 186 Alerting the Driver The ACC alert symbol is located on the display at the top of the instrument panel to the right of the driver. The alert symbol ﬂashes and a warning beep sounds when driver action may be required. If ACC is engaged, the alert symbol will ﬂash when: •...
Page 187 If this symbol does not appear, or disappears brieﬂy, ACC will not respond to vehicles you may see ahead. WARNING: When the Adaptive Cruise Control radar is blocked by snow, ice, or dirt, it may not detect a vehicle ahead. Adaptive Cruise Control may not have time to slow your vehicle enough to avoid a collision.
Page 188 Low-Speed Deactivation If your vehicle speed falls below 32 km/h (20 mph) while following a vehicle ahead, ACC will begin to disengage. The Driver Alert symbol will ﬂash and the warning beep will sound. The driver must take action since ACC will not slow the vehicle to a stop.
Page 189 When following a vehicle and entering a curve, ACC could lose track of the vehicle in your lane and accelerate your vehicle. When this happens the Vehicle Ahead symbol will not appear. ACC may detect a vehicle that is not in your lane and apply the brakes.
Page 190 Highway Exit Ramps WARNING: Adaptive Cruise Control may lose track of the vehicle ahead and accelerate up to your set speed while entering or on highway exit ramps. You could be startled by this acceleration and even lose control of the vehicle. Disengage Adaptive Cruise Control before entering a highway exit ramp.
Page 191: Exterior Lamps
Erasing Set Speed Memory Press the ACC button or turn the ignition off. Other Messages There are three additional messages that may appear on the DIC. They are SERVICE RADAR CRUISE, RADAR CRUISE NOT READY and CLEAN RADAR. These messages will appear to indicate a problem with the ACC.
Page 192 AUTO (Automatic): Automatically turns on the headlamps at normal brightness, together with the following: • Parking Lamps • Instrument Panel Lights • IntelliBeam™ (Parking Lamps): Turns on the parking lamps together with the following: • Instrument Panel Lights • License Plate Lamps •...
Page 193 Driving with IntelliBeam™ IntelliBeam only activates the high-beams when driving over 20 mph (32 km/h). The high-beam headlamps remain on, under the automatic control of IntelliBeam, until any of the following situations occur: • The system detects an approaching vehicle’s headlamps.
Page 194 • Your vehicle is loaded such that the front end of the vehicle points upward, causing the IntelliBeam sensor to aim high and not detect headlamps and taillamps. • You are driving on winding or hilly roads. You might need to manually disable or cancel the high-beam headlamps by turning the low-beam headlamps on, if any of the above conditions exist.
Page 195: Wiper Activated Headlamps
Wiper Activated Headlamps This feature activates the headlamps and parking lamps after the windshield wipers are turned on and have completed eight wipe cycles within four minutes. When the ignition is turned to LOCK/OFF, the wiper-activated headlamps immediately turn off. The wiper-activated headlamps also turn off if the windshield wipers are turned off.
Page 196: Fog Lamps
To idle the vehicle with the DRL off at night, turn off automatic lighting and shift the transmission into P (Park). Placing the vehicle in P (Park) disables the DRL. The DRL will stay off until the vehicle is shifted out of P (Park). To drive the vehicle with the DRL off, turn off automatic lighting and manually turn on the parking lamps or fog lamps, if the vehicle has them.
Page 197: Instrument Panel Brightness
Instrument Panel Brightness (Instrument Panel Brightness): This feature controls the brightness of the instrument panel and footwell lights, if equipped. The button for this control is located below the exterior lamps control. Push the button in and release to extend the button. Turn the button clockwise or counterclockwise to brighten or dim the lights.
Page 198: Reading Lamps
Reading Lamps The reading lamps are located on the overhead console on the headliner and in the rear door opening. These lamps come on automatically when any door is opened and it is dark outside. For manual operation, press the button to turn them on. Press it again to turn them off.
Page 199: Electric Power Management
Electric Power Management The vehicle has Electric Power Management (EPM) that estimates the battery’s temperature and state of charge. It then adjusts the voltage for best performance and extended life of the battery. When the battery’s state of charge is low, the voltage is raised slightly to quickly bring the charge back up.
Page 200: Battery Run-Down Protection
Battery Run-Down Protection This feature helps prevent the battery from being drained, if the interior courtesy lamps, reading/map lamps, visor vanity lamps or trunk lamp are accidentally left on. If any of these lamps are left on, they automatically turn off after 10 minutes, if the ignition is off.
Page 201: Ashtray(S)
Follow the proper installation instructions that are included with any electrical equipment you install. Notice: Improper use of the power outlet can cause damage not covered by the vehicle warranty. Do not hang any type of accessory or accessory bracket from the plug because the power outlets are designed for accessory power plugs only.
Page 202: Climate Controls
Climate Controls Dual Climate Control System The heating, cooling, and ventilation for the vehicle can be controlled with this system. Dual Climate Control System 4-36 Dual Climate Control System for Vehicles with Rear Climate Control A. Fan Control B. Display C.
Page 203: Automatic Operation
Automatic Operation AUTO (Automatic Fan): When this position is selected on the fan control, the system adjusts the fan ® speed. If the OnStar system is activated when this position is selected, the climate control fan speed will lower. AUTO (Automatic Mode): 1.
Page 204: Manual Operation
Manual Operation (Off): Turns the entire climate control system off. Outside air still enters the vehicle and is directed to the ﬂoor. The airﬂow direction and temperature can be adjusted, as indicated below. If the temperature is adjusted while the system is off, the display will light to show the current settings.
Page 205 (Defrost): This mode clears the windshield of fog or frost more quickly. Air is directed to the windshield and side window outlets. When selected, the system automatically turns off recirculation and runs the air conditioning compressor, unless the outside temperature is at or below freezing. Recirculation cannot be selected while in the defrost mode.
Page 206: Rear Window Defogger
Rear Window Defogger The rear window defogger uses a warming grid to remove fog or frost from the rear window. < (Rear Defogger): Press to turn the rear window defogger on or off. Be sure to clear as much snow from the rear window as possible.
Page 207: Outlet Adjustment
There is also an interior temperature sensor located next to the steering wheel that measures the temperature of the air inside the vehicle. There is also an exterior temperature sensor located behind the front grille. This sensor reads the outside air temperature and helps maintain the temperature inside the vehicle.
Page 208: Rear Climate Control System
Rear Climate Control System For vehicles with a rear climate control system, the rear seat passengers can adjust the direction of the airﬂow, fan speed and temperature for the rear seating area. This system also works with the main climate control system in the vehicle. The rear climate control system is located on the back of the center console.
Page 209 Automatic Operation « A ª (Fan Control): Press until AUTO appears on the display to place the system in automatic mode. When automatic operation is active, the system automatically controls the fan speed. If in auto fan mode, pressing the up arrow button will cancel automatic operation and places the system in manual mode.
Page 210: Passenger Compartment Air Filter
Passenger Compartment Air Filter The passenger compartment air ﬁlter traps most of the pollen from the air entering the vehicle. The ﬁlter may need to be changed periodically. For how often to change the passenger compartment air ﬁlter, see Scheduled Maintenance on page 7-3. The access panel for the passenger compartment air ﬁlter is located under the hood near the windshield, on the passenger’s side of the vehicle.
Page 211 2. Then, insert a tool behind the push pin located on the inboard side of the air ﬁlter compartment to carefully pry the pin out. 3. To remove the air ﬁlter, insert a tool between the air ﬁlter and the compartment wall on the outboard side of the vehicle.
Page 212: Warning Lights, Gages, And Indicators
Warning Lights, Gages, and Indicators Warning lights and gages can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement. Paying attention to the warning lights and gages could prevent injury. Warning lights come on when there might be or there is a problem with one of the vehicle’s functions.
Page 213: Instrument Panel Cluster
Instrument Panel Cluster United States version shown, Canada similar 4-47...
Page 214: Speedometer And Odometer
Speedometer and Odometer The speedometer shows the speed in both miles per hour (mph) and kilometers per hour (km/h). See “MPH (km)” under DIC Operation and Displays on page 4-62 for more information. The odometer mileage can be checked without the vehicle running.
Page 215: Safety Belt Reminders
Safety Belt Reminders Safety Belt Reminder Light When the engine is started, a chime sounds for several seconds to remind a driver to fasten the safety belt, unless the driver safety belt is already buckled. The safety belt light comes on and stays on for several seconds, then ﬂashes for several more.
Page 216: Airbag Readiness Light
Airbag Readiness Light The system checks the airbag’s electrical system for possible malfunctions. If the light stays on it indicates there is an electrical problem. The system check includes the airbag sensor, the pretensioners, the airbag modules, the wiring and the crash sensing and diagnostic module.
Page 217: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator The vehicle has the passenger sensing system. See Passenger Sensing System on page 2-67 for important safety information. The overhead console has a passenger airbag status indicator. United States When the vehicle is started, the passenger airbag status indicator will light ON and OFF, or the symbol for on and off, for several seconds as a system check.
Page 218: Charging System Light
Charging System Light This light comes on brieﬂy when the ignition key is turned to START, but the engine is not running, as a check to show it is working. If it does not, have the vehicle serviced by your dealer/retailer.
Page 219: Antilock Brake System (Abs) Warning Light
If the light comes on while driving, pull off the road and stop carefully.The pedal may be harder to push, or the pedal may go closer to the ﬂoor. It may take longer to stop. If the light is still on, have the vehicle towed for service.
Page 220: Traction Control System (Tcs) Warning Light
Traction Control System (TCS) Warning Light This warning light comes on brieﬂy while starting the engine. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light will then go off. If it stays on, or comes on while driving, there may be a problem with the traction control system and the vehicle needs service.
Page 221: Lane Departure Warning (Ldw) Light
Lane Departure Warning (LDW) Light For vehicles with the lane departure warning system, this light brieﬂy comes on green, while starting the vehicle, to indicate that it is working. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light will then go off.
Page 222: Engine Coolant Temperature Gage
Engine Coolant Temperature Gage This gage shows the engine coolant temperature. It indicates when the engine has warmed up and if the cooling system is operating properly. If the gage pointer moves into the shaded area, the engine coolant is too hot and the engine coolant temperature warning light comes on.
Page 223: Malfunction Indicator Lamp
When the Light Flashes First and Then is On Steady This indicates that there may be a problem with the Tire Pressure Monitor System. The light ﬂashes for about a minute and stays on steady for the remainder of the ignition cycle. This sequence repeats with every ignition cycle.
Page 224 This light comes on during a malfunction in one of two ways: Light Flashing: A misﬁre condition has been detected. A misﬁre increases vehicle emissions and could damage the emission control system on the vehicle. Diagnosis and service might be required. To prevent more serious damage to the vehicle: •...
Page 225: Maintenance Schedule
Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or might begin programs to inspect the emission control equipment on the vehicle. Failure to pass this inspection could prevent getting a vehicle registration. Here are some things to know to help the vehicle pass an inspection: •...
Page 226: Security Light
If the light comes on and stays on, it means that oil is not ﬂowing through the engine properly. The vehicle could be low on oil and it might have some other system problem. Security Light For information regarding this light and the vehicle’s security system, see Content Theft-Deterrent on page 3-19.
Page 227: Highbeam On Light
Highbeam On Light This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 4-6 for more information. Fuel Gage The fuel gage shows approximately how much fuel is in the tank. It works only when the engine is on.
Page 228: Dic Operation And Displays
The DIC comes on when the ignition is on. After a short delay, the DIC will display the information that was last displayed before the engine was turned off. The top line of the DIC display shows the vehicle system information and the warning/status messages.
Page 229 Trip/Fuel Display Menu Items (Trip/Fuel): The following display menu items can be displayed by pressing the trip/fuel button: TRIP A or TRIP B These displays show the current distance traveled since the last reset for each trip odometer in either kilometers (km) or miles (mi).
Page 230: Battery Voltage
TIMER ON/OFF This display can be used like a stopwatch. You can record the time it takes to travel from one point to another. To access the timer, press the trip/fuel button until 00:00:00 TIMER OFF displays. To turn on the timer, press the set/reset button until TIMER ON displays.
Page 231: Parking Assist
Vehicle Information Display Menu Items (Vehicle Information): The following display menu items can be displayed by pressing the vehicle information button: OIL LIFE REMAINING If the vehicle has this display, it shows the estimated oil life remaining. If you see 99% OIL LIFE REMAINING on the display, that means that 99% of the current oil life remains.
Page 232: Speed Alert
SIDE BLIND ZONE ALERT If your vehicle has the Side Blind Zone Alert (SBZA) system, this display allows the system to be turned on or off. Once in this display, press the set/reset button to select between ON or OFF. If you choose ON, the system will be turned on.
Page 233: Dic Warnings And Messages
RELEARN REMOTE KEY This display allows you to match Remote Keyless Entry (RKE) transmitters to your vehicle. This procedure will erase all previously learned transmitters. Therefore, they must be relearned as additional transmitters. To match an RKE transmitter to your vehicle: 1.
Page 234: Battery Saver Active
AUTOMATIC LIGHT CONTROL ON This message displays when the automatic headlamps are turned on. See Exterior Lamps on page 4-25 for more information. BATTERY SAVER ACTIVE This message displays when the system detects that the battery voltage is dropping beyond a reasonable level.
Page 235 CLEAN RADAR This message displays when the Adaptive Cruise Control (ACC) system and the Forward Collision Alert (FCA) system are disabled because the radar is blocked and cannot detect vehicles in your path. It may also activate during heavy rain or due to road spray. To clean the system, see “Cleaning the System”...
Page 236: Engine Power Reduced
ENGINE OVERHEATED IDLE ENGINE Notice: If you drive your vehicle while the engine is overheating, severe engine damage may occur. If an overheat warning appears on the instrument panel cluster and/or DIC, stop the vehicle as soon as possible. Do not increase the engine speed above normal idling speed.
Page 237: Fuel Level Low
FOLLOWING GAP This symbol appears with this message. If your vehicle has Adaptive Cruise Control (ACC), this message displays to show the follow distance that has been set. There are six follow distances to choose from. Each follow distance is shown on the DIC by displaying from one to six bars between two car symbols.
Page 238: Oil Pressure Low Stop Engine
LANE DEPARTURE SYSTEM UNAVAILABLE If your vehicle has the Lane Departure Warning (LDW) system, this message may display if the LDW system does not activate due to a temporary condition. See Lane Departure Warning (LDW) on page 3-46 for more information. LEFT REAR DOOR OPEN This symbol appears with this message.
Page 239 PARKING ASSIST OFF If your vehicle has the Ultrasonic Front and Rear Parking Assist (UFRPA) system, after the vehicle is shifted out of P (Park), this message displays to remind the driver that the UFRPA system has been turned off. Press the set/reset button to acknowledge this message and clear it from the DIC display.
Page 240: Service Air Bag
RIGHT REAR DOOR OPEN This symbol appears with this message. This message displays when the passenger side rear door is not closed completely. Make sure that the door is closed completely. SERVICE AIR BAG This message displays when there is a problem with the airbag system.
Page 241: Service Brake System
SERVICE BRAKE SYSTEM This message displays if the ignition is on to inform the driver that the brake ﬂuid level is low. Have the brake system serviced by your dealer/retailer as soon as possible. SERVICE LANE DEPARTURE SYSTEM If your vehicle has the Lane Departure Warning (LDW) system, this message may display to indicate that the LDW system is not working properly.
Page 242: Service Tire Monitor System
SERVICE STABILITRAK Your vehicle may have a vehicle stability enhancement ® system called StabiliTrak . See StabiliTrak on page 5-5. This message displays if there has been a problem detected with the StabiliTrak system. If this message comes on while you are driving, pull off the road as soon as possible and stop carefully.
Page 243: Service Vehicle Soon
SERVICE VEHICLE SOON This message displays when a non-emissions related malfunction occurs. Have your vehicle serviced by your dealer/retailer as soon as possible. SET SPD (Speed) If your vehicle has Adaptive Cruise Control (ACC), this message displays whenever the cruise control is set.
Page 244: Theft Attempted
STABILITRAK NOT READY If your vehicle has StabiliTrak, this message may display and the Traction Control System and StabiliTrak Warning Light on the instrument panel cluster may be on after ﬁrst driving the vehicle and exceeding 30 km/h (19 mph) for 30 seconds.
Page 245: Trunk Open
TRACTION CONTROL ON This message displays when the Traction Control System (TCS) is turned on. See Traction Control System (TCS) on page 5-6 for more information. TRANSMISSION HOT IDLE ENGINE Notice: If you drive your vehicle while the transmission ﬂuid is overheating and the transmission temperature warning is displayed on the instrument panel cluster and/or DIC, you can damage the transmission.
Page 246: Dic Vehicle Customization
WASHER FLUID LOW ADD FLUID This symbol appears with this message. This message displays when your vehicle is low on windshield washer ﬂuid. Reﬁll the windshield washer ﬂuid reservoir as soon as possible. See Windshield Washer Fluid on page 6-31 for more information. DIC Vehicle Customization Your vehicle has customization capabilities that allow you to program certain features to one preferred setting.
Page 247: Auto Door Lock
Press the customization button until the PRESS DISPLAY IN ENGLISH screen appears on the DIC display. Press the set/reset button once to display all DIC messages in English. DISPLAY LANGUAGE This feature allows you to select the language in which the DIC messages will appear.
Page 248: Remote Door Lock
AUTO DOOR UNLOCK This feature allows you to select whether or not to turn off the automatic door unlocking feature. It also allows you to select which doors and when the doors will automatically unlock. See Programmable Automatic Door Locks on page 3-10 for more information. Press the customization button until AUTO DOOR UNLOCK appears on the DIC display.
Page 249: Remote Door Unlock
The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC. REMOTE DOOR UNLOCK This feature allows you to select the type of feedback you will receive when unlocking the vehicle with the Remote Keyless Entry (RKE) transmitter.
Page 250: Exit Lighting
EXIT LIGHTING This feature allows you to select the amount of time you want the exterior lamps to remain on when it is dark enough outside. This happens after the key is turned from ON/RUN to LOCK/OFF. Press the customization button until EXIT LIGHTING appears on the DIC display.
Page 251: Park Tilt Mirrors
CHIME VOLUME This feature allows you to select the volume level of the chime. Press the customization button until CHIME VOLUME appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: NORMAL: The chime volume will be set to a...
Page 252 Press the customization button until EASY EXIT RECALL appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: DOOR BUTTON ONLY: No automatic seat exit recall will occur.
Page 253: Remote Start
ALL (default): The driver’s seat and the steering wheel tilt and steering column telescope features will recall, if your vehicle has this option. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC.
Page 254: Audio System(S)
FACTORY SETTINGS This feature allows you to set all of the customization features back to their factory default settings. Press the customization button until FACTORY SETTINGS appears on the DIC display. Press the set/reset button once to access the settings for this feature.
Page 255: Setting The Clock
Notice: Contact your dealer/retailer before adding any equipment. Adding audio or communication equipment could interfere with the operation of the vehicle’s engine, radio, or other systems, and could damage them. Follow federal rules covering mobile radio and telephone equipment. The vehicle has Retained Accessory Power (RAP). With RAP, the audio system can be played even after the ignition is turned off.
Page 256: Setting The Time And Date
For a Six-Disc CD Player To turn the radio clock display on or off: 1. Turn the radio on. 2. Press the MENU button until 3. Press the pushbutton located under clock and date settings appear. 4. Press the pushbutton located under the forward arrow tab until the menu for default clock and date settings appear.
Page 257: Changing The Time And Date Default Setting
For a Six-Disc CD Player This type of radio has a MENU button for setting the time and date. To set the time and date: 1. Turn the radio on. 2. Press the MENU button until 3. Press the pushbutton located under HR, MIN, MM, DD, YYYY (hour, minute, month, day, and year) displays.
Page 258: Radio(S) (Mp3)
For the Six-Disc CD Player To change the time and date default setting: 1. Change the time default setting from 12 hour to 24 hour or the date default setting from month/day/year to day/month/year, by pressing the MENU button. 2. Once displays, press the pushbutton located under until the time and date settings display...
Page 259: Playing The Radio
In rare cases, a radio station can broadcast incorrect information that causes the radio features to work improperly. If this happens, contact the radio station. Playing the Radio (Power/Volume): Press to turn the system on and off. Turn to increase or decrease the volume. Speed Compensated Volume (SCV): Radios with SCV automatically adjusts the radio volume to compensate for road and wind noise while driving.
Page 260: Finding A Station
Finding a Station BAND: Press to switch between AM, FM, or XM™. The selection displays. (Tune): Turn to select radio stations. © ¨ SEEK : Press the arrows to go to the next or to the previous station and stay there. To scan stations, press and hold either arrow for three seconds until a beep sounds.
Page 261 The number of favorites pages can be setup using the MENU button. To setup the number of favorites pages: 1. Press the MENU button to display the radio setup menu. 2. Press the pushbutton located below the FAV 1-6 label. 3.
Page 262: Adjusting The Speakers (Balance/Fade)
For the Bose ampliﬁed radio, perform the following steps to setup the equalization settings: 1. Press the knob until the DSP label displays. 2. Press the pushbutton located under the DSP label to get choices of Norm, Driv, Rear, and Surround, to display.
Page 263 • Rear: Select this screen button to adjust the audio for the rear seat passengers to receive the best possible sound quality. • ® Surround (Centerpoint ): Select this screen button ® to enable Bose Centerpoint signal processing circuitry. Centerpoint produces a full vehicle surround sound listening experience from a CD, MP3/WMA, or XM stereo digital audio source and delivers ﬁve independent audio channels from...
Page 264: Radio Message
The radio does not let you remove or add categories while the vehicle is moving faster than 5 mph (8 km/h). The CAT button also toggles between compressed and uncompressed audio when a mixed disc is present. See “Compressed Audio” later in this section. Radio Message Locked: This message displays when the ®...
Page 265 If the surface of a CD is soiled, take a soft, lint free cloth or dampen a clean, soft cloth in a mild, neutral detergent solution mixed with water, and clean it. Make sure the wiping process starts from the center to the edge.
Page 266 (Tune): Turn to select tracks on the CD currently playing. © ¨ SEEK : Press the left arrow to go to the start of the current track, if more than ten seconds have played. Press the right arrow to go to the next track. If either arrow is held or pressed multiple times, the player continues moving backward or forward through the CD.
Page 267: Using The Auxiliary Input Jack
Playing an MP3/WMA CD-R or CD-RW Disc Radios with the MP3 feature are capable of playing an MP3/WMA CD-R or CD-RW disc. For more information on how to play an MP3/WMA CD-R or CD-RW disc, see Using an MP3 on page 4-102 later in this section. CD Messages DISC ERROR: If this message displays and/or the CD ejects, it could be for one of the following reasons:...
Page 268: Using An Mp3
(Power/Volume): Turn to increase or decrease the volume of the portable player. You might need to do additional volume adjustments from the portable device. BAND: Press to listen to the radio when a portable audio device is playing. The portable audio device continues playing, so you might want to stop it or power it off.
Page 269 • Make sure playlists have a .mp3 or .wpl extension (other ﬁle extensions might not work). • Minimize the length of the ﬁle, folder or playlist names. Long ﬁle, folder, or playlist names, or a combination of a large number of ﬁles and folders, or playlists can cause the player to be unable to play up to the maximum number of ﬁles, folders, playlists, or sessions.
Page 270 Order of Play Tracks recorded to the CD-R or CD-RW play in the following order: • Play begins from the ﬁrst track in the ﬁrst playlist and continues sequentially through all tracks in each playlist. When the last track of the last playlist has played, play continues from the ﬁrst track of the ﬁrst playlist.
Page 271: Playing An Mp3/Wma
Playing an MP3/WMA Insert a CD-R or CD-RW partway into the slot (Single CD Player), or press the load button and wait for the message to insert disc (Six-Disc CD Player), label side up. The player pulls it in, and the CD-R or CD-RW should begin playing.
Page 272 2. Press the pushbutton positioned under the RDM label until Randomize All Discs displays to play songs from all CDs loaded in a six-disc CD player in random order. Press the same pushbutton again to turn off random play. (Music Navigator): Use the music navigator feature to play MP3/WMA ﬁles on the CD-R or CD-RW in order by artist or album.
Page 273: Xm Radio Messages
XM Radio Messages XL (Explicit Language Channels): These channels, or any others, can be blocked at a customer’s request, by calling 1-800-852-XMXM (9696). XM Updating: The encryption code in the receiver is being updated, and no action is required. This process should take no longer than 30 seconds.
Page 274: Voice Recognition
Check Antenna: If this message does not clear within a short period of time, the receiver or antenna could have a fault. Consult with your dealer/retailer. Check XM Receivr: If this message does not clear within a short period of time, the receiver could have a fault.
Page 275: Bluetooth Controls
Bluetooth Controls Use the buttons located on the steering wheel to operate the in-vehicle Bluetooth system. See Audio Steering Wheel Controls on page 4-119 for more information. (Push To Talk): Press to answer incoming calls, to conﬁrm system information, and to start speech recognition.
Page 276 Locate the device named “General Motors” in the list on the cellular phone and follow the instructions on the cell phone to enter the four digit PIN number that was provided in Step 3. 5. The system prompts for a name for the phone. Use a name that best describes the phone.
Page 277: Storing Name Tags
Storing Name Tags The system can store up to thirty phone numbers as name tags that are shared between the Bluetooth and OnStar systems. The system uses the following commands to store and retrieve phone numbers: • Store • Digit Store •...
Page 278: Deleting Name Tags
Using the Digit Store Command The digit store command allows a phone number to be stored by entering the digits individually. 1. Press and hold for two seconds. The system responds with “Ready” followed by a tone. 2. Say “Digit Store”. The system responds with “Please say the ﬁrst digit to store”...
Page 279: Making A Call
Using the Delete Command The delete command allows speciﬁc name tags to be deleted. To use the delete command: 1. Press and hold for two seconds. The system responds with “Ready” followed by a tone. 2. Say “Delete”. The system responds with “Delete, please say the name tag”...
Page 280: Using The Dial Command
Using the Dial Command 1. Press and hold for two seconds. The system responds with “Ready” followed by a tone. 2. Say “Dial”. The system responds with “Dial using <phone name>”. “Number please” followed by a tone. 3. Say the entire number without pausing. •...
Page 281: Receiving A Call
Using the Call Command 1. Press and hold for two seconds. The system responds with “Ready” followed by a tone. 2. Say “Call”. The system responds with “Call using <phone name>. Please say the name tag” followed by a tone. 3.
Page 282: Call Waiting
Call Waiting Call waiting must be supported on the Bluetooth phone and enabled by the wireless service carrier to work. • Press to answer an incoming call when another call is active. The original call is placed on hold. • Press again to return to the original call.
Page 283: Transferring A Call
Transferring a Call Audio can be transferred between the in-vehicle Bluetooth system and the cell phone. To Transfer Audio to the Cell Phone During a call with the audio in the vehicle: 1. Press . The system responds with “Ready” followed by a tone.
Page 284: Other Information
Sending a Number During a Call 1. Press . The system responds with “Ready” followed by a tone. 2. Say “Dial”. The system responds with “Say a number to send tones” followed by a tone. 3. Say the number to send. •...
Page 285: Theft-Deterrent Feature
Theft-Deterrent Feature ® THEFTLOCK is designed to discourage theft of the vehicle’s radio by learning a portion of the Vehicle Identiﬁcation Number (VIN). The radio does not operate if it is stolen or moved to a different vehicle. Audio Steering Wheel Controls Vehicles with audio steering wheel controls could differ depending on...
Page 286: Radio Reception
Radio Reception Frequency interference and static can occur during normal radio reception if items such as cell phone chargers, vehicle convenience accessories, and external electronic devices are plugged into the accessory power outlet. If there is interference or static, unplug the item from the accessory power outlet.
Page 287: Backglass Antenna
Backglass Antenna The AM-FM antenna is integrated with the rear window defogger, located in the rear window. Make sure that the inside surface of the rear window is not scratched and that the lines on the glass are not damaged. If the inside surface is damaged, it could interfere with radio reception.
Page 288 ✍ NOTES 4-122...
Page 289: Driving Your Vehicle
Section 5 Your Driving, the Road, and the Vehicle ...5-2 Defensive Driving ...5-2 Drunk Driving ...5-2 Control of a Vehicle ...5-3 Braking ...5-3 Antilock Brake System (ABS) ...5-4 Braking in Emergencies ...5-5 ® StabiliTrak System ...5-5 Traction Control System (TCS) ...5-6 Magnetic Ride Control™...
Page 290: Your Driving, The Road, And The Vehicle
Your Driving, the Road, and the Vehicle Defensive Driving Defensive driving means “always expect the unexpected.” The ﬁrst step in driving defensively is to wear your safety belt — See Safety Belts: They Are for Everyone on page 2-12. WARNING: Assume that other road users (pedestrians, bicyclists, and other drivers) are going to be careless and make mistakes.
Page 291: Control Of A Vehicle
For persons under 21, it is against the law in every U.S. state to drink alcohol. There are good medical, psychological, and developmental reasons for these laws. The obvious way to eliminate the leading highway safety problem is for people never to drink alcohol and then drive.
Page 292: Antilock Brake System (Abs)
Keeping pace with the traffic and allowing realistic following distances eliminates a lot of unnecessary braking. That means better braking and longer brake life. If the engine ever stops while the vehicle is being driven, brake normally but do not pump the brakes. If the brakes are pumped, the pedal could get harder to push down.
Page 293: Brake Assist
Using ABS Do not pump the brakes. Just hold the brake pedal down ﬁrmly and let antilock work. The antilock pump or motor operating might be heard and the brake pedal might be felt to pulsate, but this is normal. Braking in Emergencies ABS allows the driver to steer and brake at the same time.
Page 294: Traction Control System (Tcs)
The TCS/StabiliTrak warning light on the instrument panel cluster will ﬂash when the system is operating. See Traction Control System (TCS) Warning Light ® on page 4-54 and StabiliTrak Indicator Light on page 4-54 for more information. The system may be heard or felt while it is working.
Page 295: Magnetic Ride Control
To turn the system off or on, press and release this button located in front of the shift lever. TCS automatically comes on whenever the vehicle is started. To limit wheel spin, especially in slippery road conditions, always leave the system turned on. TCS can be turned off if needed.
Page 296: Steering
Steering Power Steering If power steering assist is lost because the engine stops or the system is not functioning, the vehicle can be steered but it will take more effort. Magnetic Speed Variable Assist Steering System This system continuously adjusts the effort felt when steering at all vehicle speeds.
Page 297: Off-Road Recovery
An emergency like this requires close attention and a quick decision. If holding the steering wheel at the recommended 9 and 3 o’clock positions, it can be turned a full 180 degrees very quickly without removing either hand. But you have to act fast, steer quickly, and just as quickly straighten the wheel once you have avoided the object.
Page 298: Passing
Passing Passing another vehicle on a two-lane road can be dangerous. To reduce the risk of danger while passing: • Look down the road, to the sides, and to crossroads for situations that might affect a successful pass. If in doubt, wait. •...
Page 299: Driving At Night
It is important to slow down on slippery surfaces because stopping distance will be longer and vehicle control more limited. While driving on a surface with reduced traction, try your best to avoid sudden steering, acceleration, or braking, including reducing vehicle speed by shifting to a lower gear.
Page 300: Driving In Rain And On Wet Roads
Driving in Rain and on Wet Roads Rain and wet roads can reduce vehicle traction and affect your ability to stop and accelerate. Always drive slower in these types of driving conditions and avoid driving through large puddles and deep-standing or ﬂowing water. WARNING: Wet brakes can cause crashes.
Page 301: Before Leaving On A Long Trip
Before Leaving on a Long Trip To prepare your vehicle for a long trip, consider having it serviced by your dealer/retailer before departing. Things to check on your own include: • Windshield Washer Fluid: Reservoir full? Windows clean — inside and outside? •...
Page 302: Hill And Mountain Roads
Hill and Mountain Roads Driving on steep hills or through mountains is different than driving on ﬂat or rolling terrain. Tips for driving in these conditions include: • Keep the vehicle serviced and in good shape. • Check all ﬂuid levels and brakes, tires, cooling system, and transmission.
Page 303: Winter Driving
Winter Driving Driving on Snow or Ice Drive carefully when there is snow or ice between the tires and the road, creating less traction or grip. Wet ice can occur at about 0°C (32°F) when freezing rain begins to fall, resulting in even less traction. Avoid driving on wet ice or in freezing rain until roads can be treated with salt or sand.
Page 304 Blizzard Conditions Being stuck in snow can be in a serious situation. Stay with the vehicle unless there is help nearby. If possible, use the Roadside Service on page 8-7. To get help and keep everyone in the vehicle safe: •...
Page 305: If Your Vehicle Is Stuck In Sand, Mud, Ice, Or Snow
Repeat this until help arrives but only when you feel really uncomfortable from the cold. Moving about to keep warm also helps. If it takes some time for help to arrive, now and then when you run the engine, push the accelerator pedal slightly so the engine runs faster than the idle speed.
Page 306: Loading The Vehicle
Loading the Vehicle It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo, and all nonfactory-installed options. Two labels on your vehicle show how much weight it may properly carry, the Tire and Loading Information label and the Certiﬁcation label.
Page 307 The Tire and Loading Information label also shows the tire size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D). For more information on tires and inﬂation see Tires on page 6-46 and Inﬂation - Tire Pressure on page 6-54.
Page 308 Example 1 Item Description Vehicle Capacity Weight for Example 1 = Subtract Occupant Weight 150 lbs (68 kg) × 2 = Available Occupant and Cargo Weight = 5-20 Total Item 1,000 lbs (453 kg) 300 lbs (136 kg) 700 lbs (317 kg) Example 2 Description Vehicle Capacity...
Page 309 Example 3 Item Description Vehicle Capacity Weight for Example 3 = Subtract Occupant Weight 200 lbs (91 kg) × 5 = Available Cargo Weight = Refer to your vehicle’s Tire and Loading Information label for speciﬁc information about your vehicle’s capacity weight and seating positions.
Page 310 Certiﬁcation Label A vehiclespeciﬁc Certiﬁcation label is attached to the rear edge of the driver’s door. This label shows the gross weight capacity of your vehicle, called the Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel, and cargo.
Page 311 Notice Overloading the vehicle may cause damage. Repairs would not be covered by the vehicle warranty. Do not overload the vehicle. If you put things inside your vehicle, like suitcases, tools, packages, or anything else, they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they will keep going.
Page 312: Towing
Towing Towing Your Vehicle Consult your dealer/retailer or a professional towing service if the disabled vehicle must be towed. See Roadside Service on page 8-7. To tow the vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see “Recreational Vehicle Towing”...
Page 313: Dinghy Towing
Dinghy Towing Notice: If the vehicle is towed with all four wheels on the ground, the drivetrain components could be damaged. The repairs would not be covered by the vehicle warranty. Do not tow the vehicle with all four wheels on the ground. The vehicle was not designed to be towed with all four wheels on the ground.
Page 314: Towing A Trailer
Towing a Trailer The Cadillac Professional Vehicle cannot tow a trailer. WARNING: The driver can lose control when pulling a trailer if the correct equipment is not used or the vehicle is not driven properly. For example, if the trailer is too heavy, the brakes may not work well —...
Page 315: Pulling A Trailer
Pulling A Trailer Here are some important points: • There are many different laws, including speed limit restrictions, having to do with trailering. Make sure the rig will be legal, not only where you live but also where you will be driving. A good source for this information can be state or provincial police.
Page 316: Weight Of The Trailer Tongue
Maximum trailer weight is calculated assuming only the driver is in the tow vehicle and it has all the required trailering equipment. The weight of additional optional equipment, passengers and cargo in the tow vehicle must be subtracted from the maximum trailer weight. Ask your dealer/retailer for trailering information or advice, or write us at our Customer Assistance Offices.
Page 317: Driving With A Trailer
Hitches It is important to have the correct hitch equipment. Crosswinds, large trucks going by and rough roads are a few reasons why the right hitch is needed. Here are some rules to follow: • The rear bumper on the vehicle is not intended for hitches.
Page 318: Following Distance
Following Distance Stay at least twice as far behind the vehicle ahead as you would when driving the vehicle without a trailer. This can help to avoid situations that require heavy braking and sudden turns. Passing More passing distance is needed when towing a trailer. Because the rig is longer, it is necessary to go much farther beyond the passed vehicle before returning to the lane.
Page 319: Driving On Grades
Driving on Grades Notice: Do not tow on steep continuous grades exceeding 6 miles (9.6 km). Extended, higher than normal engine and transmission temperatures may result and damage the vehicle. Frequent stops are very important to allow the engine and transmission to cool.
Page 320: Engine Cooling When Trailer Towing
Leaving After Parking on a Hill 1. Apply and hold the brake pedal while you: • start the engine, • shift into a gear, and • release the parking brake. 2. Let up on the brake pedal. 3. Drive slowly until the trailer is clear of the chocks. 4.
Page 321: Service And Appearance Care
Section 6 Service ...6-3 Accessories and Modiﬁcations ...6-3 California Proposition 65 Warning ...6-4 California Perchlorate Materials Requirements ...6-4 Doing Your Own Service Work ...6-4 Adding Equipment to the Outside of the Vehicle ...6-5 Fuel ...6-5 Gasoline Octane ...6-5 Gasoline Speciﬁcations ...6-6 California Fuel ...6-6 Additives ...6-6 Fuels in Foreign Countries ...6-7...
Page 322 Section 6 Tire Chains ...6-70 If a Tire Goes Flat ...6-70 Tire Sealant and Compressor Kit ...6-71 Tire Sealant and Compressor Kit Storage ...6-79 Changing a Flat Tire ...6-80 Removing the Spare Tire and Tools ...6-81 Removing the Flat Tire and Installing the Spare Tire ...6-83 Storing a Flat or Spare Tire and Tools ...6-88 Spare Tire ...6-90...
Page 323: Service
Service For service and parts needs, visit your dealer/retailer. You will receive genuine GM parts and GM-trained and supported service people. Genuine GM parts have one of these marks: Accessories and Modiﬁcations When non-dealer/non-retailer accessories are added to the vehicle, they can affect vehicle performance and safety, including such things as airbags, braking, stability, ride and handling, emissions systems, aerodynamics, durability, and electronic systems like antilock brakes,...
Page 324: California Proposition 65 Warning
California Proposition 65 Warning Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems, many ﬂuids, and some component wear by-products contain and/or emit these chemicals.
Page 325: Adding Equipment To The Outside Of The Vehicle
Keep a record with all parts receipts and list the mileage and the date of any service work performed. See Maintenance Record on page 7-12. Adding Equipment to the Outside of the Vehicle Things added to the outside of the vehicle can affect the airﬂow around it.
Page 326: Gasoline Speciﬁcations
If this occurs, use a gasoline rated at 87 octane or higher as soon as possible. Otherwise, you could damage the engine. If heavy knocking is heard when using gasoline rated at 87 octane or higher, the engine needs service. Gasoline Speciﬁcations At a minimum, gasoline should meet ASTM speciﬁcation D 4814 in the United States or CAN/CGSB-3.5 or...
Page 327: Fuels In Foreign Countries
Gasolines containing oxygenates, such as ethers and ethanol, and reformulated gasolines might be available in your area. We recommend that you use these gasolines, if they comply with the speciﬁcations described earlier. However, E85 (85% ethanol) and other fuels containing more than 10% ethanol must not be used in vehicles that were not designed for those fuels.
Page 328: Filling The Tank
Filling the Tank WARNING: Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the fuel pump island. Turn off the engine when refueling.
Page 329 To remove the fuel cap, turn it slowly counterclockwise. The fuel cap has a spring in it; if the cap is released too soon, it will spring back to the right. While refueling, hang the tethered fuel cap from the hook on the fuel door.
Page 330: Filling A Portable Fuel Container
Filling a Portable Fuel Container WARNING: Never ﬁll a portable fuel container while it is in the vehicle. Static electricity discharge from the container can ignite the fuel vapor. You can be badly burned and the vehicle damaged if this occurs.
Page 331: Hood Release
Hood Release To lift the hood: 1. Pull the hood release lever with this symbol on it. It is located on the lower left side of the instrument panel. 2. Then go to the front of the vehicle and ﬁnd the secondary hood release lever, located near the center of the hood.
Page 332: Engine Compartment Overview
Engine Compartment Overview When you open the hood, here is what you will see: 4.6L L37 Engine shown, 4.6L LD8 Engine similar 6-12...
Page 333: Engine Oil
A. Underhood Fuse Block on page 6-101. B. Remote Positive (+) Terminal. See Jump Starting on page 6-36. C. Windshield Washer Fluid Reservoir. See “Adding Washer Fluid” under Windshield Washer Fluid on page 6-31. D. Engine Coolant Surge Tank and Pressure Cap. See Engine Coolant on page 6-23.
Page 334: When To Add Engine Oil
When to Add Engine Oil If the oil is below the cross-hatched area at the tip of the dipstick, add at least one quart/liter of the recommended oil. This section explains what kind of oil to use. For engine oil crankcase capacity, see Capacities and Speciﬁcations on page 6-109.
Page 335: What Kind Of Engine Oil To Use
What Kind of Engine Oil to Use Look for three things: • GM4718M This vehicle’s engine requires a special oil meeting GM Standard GM4718M. Oils meeting this standard may be identiﬁed as synthetic. However, not all synthetic oils will meet this GM standard. Use only an oil that meets GM Standard GM4718M.
Page 336: Engine Oil Life System
Engine Oil Additives / Engine Oil Flushes Do not add anything to the oil. The recommended oils with the starburst symbol that meet GM standards are all that is needed for good performance and engine protection. Engine oil system ﬂushes are not recommended and could cause engine damage not covered by the vehicle warranty.
Page 337: Engine Air Cleaner/Filter
How to Reset the Engine Oil Life System The Engine Oil Life System calculates when to change the engine oil and ﬁlter based on vehicle use. Whenever the oil is changed, reset the system so it can calculate when the next oil change is required. If a situation occurs where the oil is changed prior to a CHANGE ENGINE OIL SOON message in the Driver Information Center (DIC) being turned on, reset the system.
Page 338: How To Inspect The Engine Air Cleaner/Filter
How to Inspect the Engine Air Cleaner/Filter To inspect the air cleaner/ﬁlter, remove the ﬁlter from the vehicle and lightly shake the ﬁlter to release loose dust and dirt. If the ﬁlter remains caked with dirt, a new ﬁlter is required. To inspect or replace the ﬁlter: 1.
Page 339: Automatic Transmission Fluid
WARNING: Operating the engine with the air cleaner/ﬁlter off can cause you or others to be burned. The air cleaner not only cleans the air; it helps to stop ﬂames if the engine backﬁres. If it is not there and the engine backﬁres, you could be burned.
Page 340: How To Check Automatic Transmission Fluid
How to Check Automatic Transmission Fluid Because this operation can be a little difficult, you may choose to have this done at the dealer/retailer service department. If you do it yourself, be sure to follow all the instructions here or you could get a false reading on the dipstick. Notice: Too much or too little ﬂuid can damage your transmission.
Page 341: How To Add Automatic Transmission Fluid
3. Push it back in all the way, wait three seconds, and then pull it back out again. 4. Check both sides of the dipstick and read the lower level. The ﬂuid level must be in the cross-hatched area. 5. If the ﬂuid level is in the acceptable range, push the dipstick back in all the way and turn the handle clockwise.
Page 342: Cooling System
Cooling System The cooling system allows the engine to maintain the correct working temperature. 4.6L L37 Engine shown, 4.6L LD8 Engine similar A. Coolant Surge Tank with Pressure Cap B. Electric Engine Cooling Fans 6-22...
Page 343: Engine Coolant
WARNING: An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury. Keep hands, clothing, and tools away from any underhood electric fan. WARNING: Heater and radiator hoses, and other engine parts, can be very hot.
Page 344: What To Use
What to Use WARNING: Adding only plain water to the cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can boil before the proper coolant mixture will. The vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.
Page 345: Checking Coolant
Checking Coolant The vehicle must be on a level surface when checking the coolant level. Check to see if coolant is visible in the coolant recovery tank. If the coolant inside the coolant recovery tank is boiling, do not do anything else until it cools down. If coolant is visible but the coolant level is not at or above the FULL COLD mark, add a 50/50 mixture of clean, drinkable water and DEX-COOL...
Page 346 WARNING: Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They are under pressure, and if you turn the surge tank pressure cap — even a little — they can come out at high speed. Never turn the cap when the cooling system, including the surge tank pressure cap, is hot.
Page 347: Engine Overheating
4.6L L37 Engine shown, 4.6L LD8 Engine similar 4. With the coolant surge tank cap off, start the engine and let it run until you can feel the upper radiator hose getting hot. Watch out for the engine cooling fans. By this time, the coolant level inside the coolant surge tank may be lower.
Page 348: If Steam Is Coming From The Engine Compartment
You may decide not to lift the hood when this warning appears, but instead get service help right away. See Roadside Service on page 8-7. If you do decide to lift the hood, make sure the vehicle is parked on a level surface. Then check to see if the engine cooling fans are running.
Page 349: If No Steam Is Coming From The Engine Compartment
If No Steam Is Coming From The Engine Compartment If an engine overheat warning is displayed but no steam can be seen or heard, the problem may not be too serious. Sometimes the engine can get a little too hot when the vehicle: •...
Page 350: Power Steering Fluid
Power Steering Fluid The power steering ﬂuid reservoir is located next to the underhood fuse block on the passenger side of the vehicle. See Engine Compartment Overview on page 6-12 for more information on location. When to Check Power Steering Fluid It is not necessary to regularly check power steering ﬂuid unless you suspect there is a leak in the system or you hear an unusual noise.
Page 351: Windshield Washer Fluid
Windshield Washer Fluid What to Use When the vehicle needs windshield washer ﬂuid, be sure to read the manufacturer’s instructions before use. If the vehicle will be operating in an area where the temperature may fall below freezing, use a ﬂuid that has sufficient protection against freezing.
Page 352: Brakes
Brakes Brake Fluid The brake master cylinder reservoir is ﬁlled with DOT 3 brake ﬂuid. See Engine Compartment Overview on page 6-12 for reservoir location and access. There are only two reasons why the brake ﬂuid level in the reservoir might go down: •...
Page 353: Brake Wear
WARNING: With the wrong kind of ﬂuid in the brake hydraulic system, the brakes might not work well. This could cause a crash. Always use the proper brake ﬂuid. Notice: • Using the wrong ﬂuid can badly damage brake hydraulic system parts. For example, just a few drops of mineral-based oil, such as engine oil, in the brake hydraulic system can damage brake hydraulic system parts so badly that they...
Page 354: Battery
Properly torqued wheel nuts are necessary to help prevent brake pulsation. When tires are rotated, inspect brake pads for wear and evenly tighten wheel nuts in the proper sequence to torque speciﬁcations in Capacities and Speciﬁcations on page 6-109. Brake linings should always be replaced as complete axle sets.
Page 355 WARNING: A battery that is not properly vented can let sulfuric acid fumes into the area under the rear seat cushion. These fumes can damage the rear seat safety belt systems. You might not be able to see this damage and the safety belts might not provide the protection needed in a crash.
Page 356: Vehicle Storage
Vehicle Storage WARNING: Batteries have acid that can burn you and gas that can explode. You can be badly hurt if you are not careful. See Jump Starting on page 6-36 for tips on working around a battery without getting hurt. Infrequent Usage: Remove the black, negative (−) cable from the battery to keep the battery from running down.
Page 357 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles are not touching each other. If they are, it could cause a ground connection you do not want. You would not be able to start your vehicle and the bad grounding could damage the electrical systems.
Page 358 You will not see the battery of your vehicle under the hood. It is located under the rear passenger’s seat. You will not need to access the battery for jump starting. The remote terminals are for that purpose. WARNING: An electric fan can start up even when the engine is not running and can injure you.
Page 359 WARNING: Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running. 5. Check that the jumper cables do not have loose or missing insulation. If they do, you could get a shock.
Page 360: Headlamp Aiming
Notice: If the jumper cables are connected or removed in the wrong order, electrical shorting may occur and damage the vehicle. The repairs would not be covered by the vehicle warranty. Always connect and remove the jumper cables in the correct order, making sure that the cables do not touch each other or other metal.
Page 361 It is recommended that the vehicle is taken to your dealer/retailer for service if the headlamps need to be re-aimed. It is possible however, to re-aim the headlamps as described. Notice: To make sure the headlamps are aimed properly, read all the instructions before beginning. Failure to follow these instructions could cause damage to headlamp parts.
Page 362 4. At a wall, measure from the ground upward (A) to the recorded distance from Step 3 and mark it. 5. Draw or tape a horizontal line (B) the width of the vehicle at the wall where it was marked in Step 4. Notice: Do not cover a headlamp to improve beam cut-off when aiming.
Page 363: Bulb Replacement
9. Make sure that the light from the headlamp is positioned at the bottom edge of the horizontal tape line. The lamp on the left (A) shows the correct headlamp aim. The lamp on the right (B) shows the incorrect headlamp aim. 10.
Page 364: Windshield Wiper Blade Replacement
Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear or cracking. See Scheduled Maintenance on page 7-3 for more information on wiper blade inspection. Replacement blades come in different types and are removed in different ways. Here is how to remove the wiper blade: 1.
Page 365 To remove and replace the wiper blade element: 1. The wiper blade element has two notches at one end which are engaged by the bottom claw set of the wiper blade. At the notched end of the wiper blade, pull the wiper blade element from the wiper blade assembly.
Page 366: Tires
Tires Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your vehicle Warranty booklet for details. For additional information refer to the tire manufacturer. WARNING: •...
Page 367: Tire Sidewall Labeling
Tire Sidewall Labeling Useful information about a tire is molded into its sidewall. Passenger Car Tire Example (A) Tire Size The tire size is a combination of letters and numbers used to deﬁne a particular tire’s width, height, aspect ratio, construction type and service description.
Page 368 (E) Tire Ply Material The type of cord and number of plies in the sidewall and under the tread. (F) Uniform Tire Quality Grading (UTQG) manufacturers are required to grade tires based on three performance factors: treadwear, traction and temperature resistance. For more information see Uniform Tire Quality Grading on page 6-67.
Page 369 (B) Tire Ply Material The type of cord and number of plies in the sidewall and under the tread. (C) Tire Identiﬁcation Number (TIN) Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured. The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture.
Page 370 Light Truck Tire Example (A) Tire Size The tire size code is a combination of letters and numbers used to deﬁne a particular tire’s width, height, aspect ratio, construction type and service description. See the “Tire Size” illustration later in this section for more detail. 6-50 (B) TPC Spec (Tire Performance Criteria Speciﬁcation)
Page 371 (F) Tire Ply Material The type of cord and number of plies in the sidewall and under the tread. (G) Single Tire Maximum Load that can be carried and the maximum pressure needed to support that load when used as a single.
Page 372: Tire Terminology And Deﬁnitions
Tire Terminology and Deﬁnitions Air Pressure The amount of air inside the tire pressing outward on each square inch of the tire. Air pressure is expressed in pounds per square inch (psi) or kilopascal (kPa). Accessory Weight This means the combined weight of optional accessories.
Page 373 Load Index An assigned number ranging from 1 to 279 that corresponds to the load carrying capacity of a tire. Maximum Inﬂation Pressure pressure to which a cold tire can be inﬂated. The maximum air pressure is molded onto the sidewall. Maximum Load Rating The load rating for a tire at the maximum permissible inﬂation pressure...
Page 374: Inﬂation - Tire Pressure
Treadwear Indicators Narrow bands, sometimes called wear bars, that show across the tread of a tire when only 1/16 inch (1.6 mm) of tread remains. See When It Is Time for New Tires on page 6-64. UTQGS (Uniform Tire Quality Grading Standards) A tire information system that provides consumers with ratings for a tire’s...
Page 375 A Tire and Loading Information label is attached to the vehicle’s center pillar. This label lists your vehicle’s original equipment tires and shows the correct inﬂation pressures for your tires when they are cold. The recommended cold tire inﬂation pressure, shown on the label, is the minimum amount of air pressure needed to support your vehicle’s maximum load carrying capacity.
Page 376: High-Speed Operation
Professional Vehicle The proper inﬂation of the tires on your professional vehicle depends on the type of tires on it. • If your vehicle has P235/60R17 size tires, the cold inﬂation pressure is 41 psi (284 kPa). • If your vehicle has LT235/60R17E size tires, the cold inﬂation pressure depends on the vehicle mass and should be determined by the vehicle coach-builder.
Page 377: Tire Pressure Monitor System
If your vehicle has P235/55R17 or P245/50R18 size tires, and you will be driving at speeds of 100 mph (160 km/h) or higher, where it is legal, set the cold inﬂation pressure to the maximum inﬂation pressure shown on the tire sidewall, or 38 psi (265 kPa), whichever is lower.
Page 378: Tire Pressure Monitor Operation
Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will ﬂash for approximately one minute and then remain continuously illuminated.
Page 379: Tpms Malfunction Light And Message
At the same time a message to check the pressure in a speciﬁc tire appears on the Driver Information Center (DIC) display. The low tire pressure warning light and the DIC warning message come on at each ignition cycle until the tires are inﬂated to the correct inﬂation pressure.
Page 380: Tpms Sensor Matching Process
• The TPMS sensor matching process was started but not completed or not completed successfully after rotating the vehicle’s tires. The DIC message and TPMS malfunction light should go off once the TPMS sensor matching process is performed successfully. See “TPMS Sensor Matching Process” later in this section.
Page 381 The TPMS sensor matching process is outlined below: 1. Set the parking brake. 2. Turn the ignition switch to ON/RUN with the engine off. 3. Press the Remote Keyless Entry (RKE) transmitter’s lock and unlock buttons at the same time for approximately ﬁve seconds.
Page 382: Tire Inspection And Rotation
Tire Inspection and Rotation We recommend that you regularly inspect your vehicle’s tires, including the spare tire, for signs of wear or damage. See When It Is Time for New Tires on page 6-64 for more information. Tires should be rotated every 5,000 to 8,000 miles (8 000 to 13 000 km).
Page 383 A ﬁve-tire rotation pattern may be used for your professional vehicle, if it has a full-size spare tire and wheel assembly that matches the original equipment tires and wheels in size, type and brand. The correct ﬁve-tire rotation pattern is shown. After the tires have been rotated, adjust the front and rear inﬂation pressures as shown on the Tire and Loading Information label.
Page 384: When It Is Time For New Tires
When It Is Time for New Tires Various factors, such as maintenance, temperatures, driving speeds, vehicle loading, and road conditions inﬂuence when you need new tires. One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch...
Page 385 GM’s exclusive TPC Spec system considers over a dozen critical speciﬁcations that impact the overall performance of your vehicle, including brake system performance, ride and handling, traction control, and tire pressure monitoring performance. GM’s TPC Spec number is molded onto the tire’s sidewall near the tire size.
Page 386: Different Size Tires And Wheels
WARNING: If you use bias-ply tires on the vehicle, the wheel rim ﬂanges could develop cracks after many miles of driving. A tire and/or wheel could fail suddenly, causing a crash. Use only radial-ply tires with the wheels on the vehicle. If you must replace your vehicle’s tires with those that do not have a TPC Spec number, make sure they are the same size, load range, speed rating, and...
Page 387: Uniform Tire Quality Grading
Uniform Tire Quality Grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by treadwear, traction, and temperature performance.
Page 388: Wheel Alignment And Tire Balance
Temperature – A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speciﬁed indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 389: Used Replacement Wheels
If you need to replace any of your wheels, wheel bolts, wheel nuts, or Tire Pressure Monitor System (TPMS) sensors, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, wheel nuts, and TPMS sensors for your vehicle.
Page 390: Tire Chains
Tire Chains WARNING: Do not use tire chains. There is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension or other vehicle parts. The area damaged by the tire chains could cause you to lose control of the vehicle and you or others may be injured in a crash.
Page 391: Tire Sealant And Compressor Kit
WARNING: Lifting a vehicle and getting under it to do maintenance or repairs is dangerous without the appropriate safety equipment and training. If a jack is provided with the vehicle, it is designed only for changing a ﬂat tire. If it is used for anything else, you or others could be badly injured or killed if the vehicle slips off the jack.
Page 392 WARNING: Storing the tire sealant and compressor kit or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store the tire sealant and compressor kit in its original location.
Page 393: Tire Sealant
Read and follow all of the tire sealant and compressor kit instructions. The kit includes: A. On/Off Button B. Selector Switch (Sealant/Air or Air Only) C. Pressure Relief Button D. Pressure Gage E. Air Only Hose (Black) F. Sealant/Air Hose (Clear) G.
Page 394: Punctured Tire
Using the Tire Sealant and Compressor Kit to Temporarily Seal and Inﬂate a Punctured Tire Follow the directions closely for correct sealant usage. When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for 5 minutes.
Page 395 7. Start the vehicle. The vehicle must be running while using the air compressor. 8. Turn the selector switch (B) clockwise to the Sealant + Air position. 9. Press the on/off (A) button to turn the tire sealant and compressor kit on. The compressor will inject sealant and air into the tire.
Page 396 16. If the ﬂat tire was able to inﬂate to the recommended inﬂation pressure, remove the maximum speed label from the sealant canister and place it in a highly visible location. The label is a reminder not to exceed 55 mph (90 km/h) until the damaged tire is repaired or replaced.
Page 397: Not Punctured
Using the Tire Sealant and Compressor Kit without Sealant to Inﬂate a Tire (Not Punctured) To use the air compressor to inﬂate a tire with air only and not sealant: Always do a safety check ﬁrst. See If a Tire Goes Flat on page 6-70.
Page 398: Removal And Installation Of The Sealant Canister
10. Inﬂate the tire to the recommended inﬂation pressure using the pressure gage (D). The recommended inﬂation pressure can be found on the Tire and Loading Information label. See Inﬂation - Tire Pressure on page 6-54. The pressure gage (D) may read higher than the actual tire pressure while the compressor is on.
Page 399: Tire Sealant And Compressor Kit Storage
Tire Sealant and Compressor Kit Storage The tire sealant and compressor kit is located in the trunk. 1. Open the trunk. See Trunk on page 3-12. 2. Lift the cover. 3. Turn the retainer clockwise and remove the tire sealant and compressor kit. To store the tire sealant and compressor kit, reverse the steps.
Page 400: Changing A Flat Tire
Changing a Flat Tire If a tire goes ﬂat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning ﬂashers. See Hazard Warning Flashers on page 4-3. WARNING: Changing a tire can be dangerous. The vehicle can slip off the jack and roll over or fall on you or other people.
Page 401: Removing The Spare Tire And Tools
A. Wheel Block B. Flat Tire The following information explains how to use the jack and change a tire. Removing the Spare Tire and Tools The equipment needed is in the trunk. To access the equipment: 1. Open the trunk. See Trunk on page 3-12 for more information.
Page 402 4. Turn the wing nut to remove the retainer that holds the wrench and jack. 5. Remove the wheel wrench, jack and spare tire from the trunk. See Spare Tire on page 6-90 for more information. 6-82 The tools to be used are the jack (A) and the wheel wrench (B).
Page 403: Removing The Flat Tire And Installing The Spare Tire
Removing the Flat Tire and Installing the Spare Tire 1. Do a safety check before proceeding. See Changing a Flat Tire on page 6-80 for more information. 2. For models having aluminum wheels with a center wheel cover, use the ﬂat end of the wheel wrench to gently pry the wheel covers off.
Page 404 4. Find the jacking location from the diagram above and use the corresponding cutouts located in the plastic molding. The front location is (A) 8.5 inches (21 cm) from the rear edge of the front wheel well, and the rear location (B) is 3.5 inches (8.5 cm) from the front edge of the rear wheel well.
Page 405 5. Turn the jack handle counterclockwise to lower the jack lift head until the jack ﬁts under the vehicle. 6. Raise the jack until the metal ﬂange ﬁts ﬁrmly into the channel of the jack head. 7. Put the spare tire near you. 8.
Page 406 10. Remove any rust or dirt from the wheel bolts, mounting surfaces, and spare wheel. WARNING: Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident.
Page 407 13. Lower the vehicle by turning the jack handle counterclockwise. Lower the jack completely. WARNING: Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque speciﬁcation after replacing.
Page 408: Storing A Flat Or Spare Tire And Tools
5-Wheel Nuts 14. Tighten the wheel nuts ﬁrmly in a crisscross sequence as shown. If your vehicle is equipped with wheel nut covers, screw the nut covers on with your ﬁngers, then tighten one-quarter turn with the wheel wrench. Notice: Wheel covers will not ﬁt on your vehicle’s compact spare.
Page 409 A. Cover B. Wing Nut C. Retainer D. Jack and Wheel Wrench E. Jack Container F. Spare Tire G. Bolt 1. Open the trunk. See Trunk on page 3-12. 2. Reinstall the spare tire (F), face down, making sure to line up the wheel center hole with the bolt (G) and place it on the compartment ﬂoor.
Page 410: Spare Tire
Spare Tire Compact Spare Tire WARNING: Driving with more than one compact spare tire at a time could result in loss of braking and handling. This could lead to a crash and you or others could be injured. Use only one compact spare tire at a time.
Page 411: Appearance Care
Spare Tire This vehicle may have a spare tire, which, when new, was fully inﬂated. A spare tire may lose air over time, so check its inﬂation pressure regularly. See Inﬂation - Tire Pressure on page 6-54 and Loading the Vehicle on page 5-18 for information regarding proper tire inﬂation and loading your vehicle.
Page 412: Fabric/Carpet
Notice: Using abrasive cleaners when cleaning glass surfaces on the vehicle, could scratch the glass and/or cause damage to the rear window defogger. When cleaning the glass on the vehicle, use only a soft cloth and glass cleaner. Many cleaners contain solvents that may become concentrated in the vehicle’s breathing space.
Page 413: Leather
To clean: 1. Saturate a lint-free, clean white cloth with water or club soda. 2. Wring the cloth to remove excess moisture. 3. Start on the outside edge of the soil and gently rub toward the center. Continue cleaning, using a clean area of the cloth each time it becomes soiled.
Page 414: Instrument Panel, Vinyl, And Other Plastic Surfaces
Do not use heat to dry. Never use steam to clean leather. Never use spot lifters or spot removers on leather. It is very important to not use any commercial leather cleaners or coatings that are sold to preserve and protect leather. Not only are those products not necessary, they will permanently and adversely change the appearance and feel of the leather.
Page 415: Care Of Safety Belts
Care of Safety Belts Keep belts clean and dry. WARNING: Do not bleach or dye safety belts. It may severely weaken them. In a crash, they might not be able to provide adequate protection. Clean safety belts only with mild soap and lukewarm water. Weatherstrips Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak.
Page 416: Cleaning Exterior Lamps/Lenses
vehicle. Use of power washers exceeding 1,200 psi (8 274 kPa) can result in damage or removal of paint and decals. Cleaning Exterior Lamps/Lenses Use only lukewarm or cold water, a soft cloth and a car washing soap to clean exterior lamps and lenses. Follow instructions under Washing Your Vehicle on page 6-95.
Page 417: Windshield And Wiper Blades
Windshield and Wiper Blades Clean the outside of the windshield with glass cleaner. Clean the rubber blades using a lint free cloth or paper towel soaked with windshield washer ﬂuid or a mild detergent. Wash the windshield thoroughly when cleaning the blades. Bugs, road grime, sap, and a buildup of vehicle wash/wax treatments may cause wiper streaking.
Page 418: Tires
Notice: Driving the vehicle through an automatic car wash that has silicone carbide tire cleaning brushes, could damage the aluminum or chrome-plated wheels. The repairs would not be covered by the vehicle warranty. Never drive a vehicle that has aluminum or chrome-plated wheels through an automatic car wash that uses silicone carbide tire cleaning brushes.
Page 419: Chemical Paint Spotting
Chemical Paint Spotting Some weather and atmospheric conditions can create a chemical fallout. Airborne pollutants can fall upon and attack painted surfaces on the vehicle. This damage can take two forms: blotchy, ring-shaped discolorations, and small, irregular dark spots etched into the paint surface.
Page 420: Service Parts Identiﬁcation Label
Service Parts Identiﬁcation Label This label, on the spare tire cover, has the following information: • Vehicle Identiﬁcation Number (VIN) • Model designation • Paint information • Production options and special equipment Do not remove this label from the vehicle. Electrical System Add-On Electrical Equipment Notice: Do not add anything electrical to the...
Page 421: Power Windows And Other Power Options
Power Windows and Other Power Options Circuit breakers in the fuse block protect the power windows and other power accessories. When the current load is too heavy, the circuit breaker opens and closes, protecting the circuit until the problem is ﬁxed or goes away.
Page 422 Fuses Engine Control Module (ECM), Crank Fuel Injectors Odd Fuel Injectors Even Air Conditioning Clutch 6-102 Usage Fuses Usage Air Injection Reactor (AIR) Solenoid Oxygen Sensor Emission Device Transmission, Ignition 1...
Page 423 Fuses Usage Engine Control Module (ECM), Powertrain Control Module (PCM) Climate Control System, Instrument Panel Cluster Ignition 1 Airbag System Horn Windshield Wiper Fog Lamps Right High-Beam Headlamp Left High-Beam Headlamp Left Low-Beam Headlamp Right Low-Beam Headlamp Windshield Washer Pump Motor Left Front Cornering Lamp Right Front Cornering Lamp Air Pump (J-Case)
Page 424: Rear Underseat Fuse Block
Rear Underseat Fuse Block The rear fuse block is located under the rear seat on the driver side. The rear seat cushion must be removed to access the rear fuse block. Removing the Rear Seat Cushion Notice: If you touch the exposed wires with the metal on the seat cushion, you could cause a short that could damage the battery and or wires.
Page 425 To reinstall the rear seat cushion, do the following: WARNING: A safety belt that is not properly routed through the seat cushion or is twisted will not provide the protection needed in a crash. If the safety belt has WARNING: (Continued) WARNING: (Continued) not been routed through the seat cushion at all, it will not be there to work for the next passenger.
Page 426 Fuses Fuel Pump Left Park Lamp Run 3 - Rear Blower Right Park Lamp 6-106 Usage Fuses Usage Engine Control Module (ECM)/Transmission Control Module (TCM) Memory Module Right Park Lamp (optional)
Page 427 Fuses Usage Steering Wheel Illumination Front Heated/Cooled Seat Module Run 2 - Heated/Cooled Seats Rear Heated Seat Module RPA Module ® PASS-Key III System Unlock/Lock Module Magnetic Ride Control Not Used Sunroof Body Control Module (BCM) Dim Body Control Module (BCM) Run 1-Heated Steering Wheel Ignition Switch Driver Door Module...
Page 428 Fuses Rear Defogger (J-Case) Electronic Leveling Control Compressor (J-Case) Blower (J-Case) (optional) Blower (J-Case) (optional) Resistor Terminating Resistor Relays Front Blower (optional) Rear Defogger Electronic Leveling Control Compressor Park Lamps Fuel Pump License Plate Lamp (optional) Right Park Lamp (optional) 6-108 Usage Relays...
Page 429: Capacities And Speciﬁcations
Capacities and Speciﬁcations The following approximate capacities are given in English and metric conversions. See Recommended Fluids and Lubricants on page 7-8 for more information. Application Air Conditioning Refrigerant Cooling System Engine Oil with Filter Fuel Tank Transmission Fluid (Bottom Pan Removal) Wheel Nut Torque All capacities are approximate.
Page 430 ✍ NOTES 6-110...
Page 431 Section 7 Maintenance Schedule ...7-2 Introduction ...7-2 Scheduled Maintenance ...7-3 Owner Checks and Services ...7-6 Maintenance Schedule Recommended Fluids and Lubricants ...7-8 Maintenance Replacement Parts ...7-10 Engine Drive Belt Routing ...7-11 Maintenance Record ...7-12...
Page 432: Maintenance Schedule
Maintenance Schedule Introduction Notice: Maintenance intervals, checks, inspections, recommended ﬂuids, and lubricants are necessary to keep this vehicle in good working condition. Damage caused by failure to follow scheduled maintenance might not be covered by the vehicle warranty. Proper vehicle maintenance helps to keep the vehicle in good working condition, improves fuel economy, and reduces vehicle emissions for better air quality.
Page 433: Scheduled Maintenance
Rotation of New Tires To maintain ride, handling, and performance of the vehicle, it is important that the ﬁrst rotation service for new tires be performed when they have 8 000 to 13 000 km (5,000 to 8,000 miles). See Tire Inspection and Rotation on page 6-62.
Page 434: Additional Required Services
• Fluids visual leak check (or every 12 months, whichever occurs ﬁrst). A leak in any system must be repaired and the ﬂuid level checked. • Engine air cleaner ﬁlter inspection. See Engine Air Cleaner/Filter on page 6-17. • Brake system inspection (or every 12 months, whichever occurs ﬁrst).
Page 435 Once a Year • Starter switch check. See Owner Checks and Services on page 7-6. • Parking brake and automatic transmission P (Park) mechanism check. See Owner Checks and Services on page 7-6. • Automatic transmission shiftlock control system check. See Owner Checks and Services on page 7-6.
Page 436: Owner Checks And Services
First Engine Oil Change After Every 120 000 km/75,000 Miles • Professional Vehicle Only: Engine cooling system drain, ﬂush, and reﬁll, cooling system and cap pressure check, and cleaning of outside of radiator and air conditioning condenser (or every 5 years, whichever occurs ﬁrst).
Page 437: Ignition Transmission Lock Check
Automatic Transmission Shift Lock Control System Check WARNING: When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or others could be injured. 1. Before starting this check, be sure there is enough room around the vehicle. It should be parked on a level surface.
Page 438: Recommended Fluids And Lubricants
Parking Brake and Automatic Transmission P (Park) Mechanism Check WARNING: When you are doing this check, the vehicle could begin to move. You or others could be injured and property could be damaged. Make sure there is room in front of the vehicle in case it begins to roll. Be ready to apply the regular brake at once should the vehicle begin to move.
Page 439 Usage Fluid/Lubricant Windshield ® Optikleen Washer Solvent. Washer Chassis Lubricant (GM Part No. U.S. 12377985, in Parking Brake Canada 88901242) or lubricant Cable Guides meeting requirements of NLGI #2, Category LB or GC-LB. GM Power Steering Fluid Power Steering (GM Part No. U.S. 89021184, in System Canada 89021186).
Page 440: Maintenance Replacement Parts
Maintenance Replacement Parts Replacement parts identiﬁed below by name, part number, or speciﬁcation can be obtained from your dealer/retailer. Part Engine Air Cleaner/Filter Element Engine Oil Filter Passenger Compartment Air Filter Element Spark Plugs Wiper Blades Driver Side - 21.7 in (55.0 cm) Passenger Side - 21.7 in (55.0 cm) 7-10 GM Part Number...
Page 441: Engine Drive Belt Routing
Engine Drive Belt Routing 4.6L V8 Engines 7-11...
Page 442: Maintenance Record
Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. Retain all maintenance receipts. Maintenance Record Odometer Date Serviced By Maintenance Stamp Services Performed Reading 7-12...
Page 443 Maintenance Record (cont’d) Odometer Date Serviced By Maintenance Stamp Services Performed Reading 7-13...
Page 444 Maintenance Record (cont’d) Odometer Date Serviced By Maintenance Stamp Services Performed Reading 7-14...
Page 445: Customer Assistance Information
Section 8 Customer Assistance and Information ...8-2 Customer Satisfaction Procedure ...8-2 Online Owner Center ...8-5 Customer Assistance for Text Telephone (TTY) Users ...8-6 Customer Assistance Offices ...8-6 GM Mobility Reimbursement Program ...8-7 Roadside Service ...8-7 Scheduling Service Appointments ...8-11 Courtesy Transportation Program ...8-11 Collision Damage Repair ...8-13 Customer Assistance Information Reporting Safety Defects ...8-16...
Page 446: Customer Assistance And Information
Information Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and to Cadillac. Normally, any concerns with the sales transaction or the operation of the vehicle will be resolved by the dealer’s sales or service departments. Sometimes, however, despite the best intentions of all concerned, misunderstandings can occur.
Page 447 STEP THREE (U.S. Owners): Both General Motors and your dealer are committed to making sure you are completely satisﬁed with your new vehicle. However, if you continue to remain unsatisﬁed after following the procedure outlined in Steps One and Two, you can ﬁle with the Better Business Bureau (BBB) Auto Line Program to enforce your rights.
Page 448 STEP THREE (Canadian Owners): General Motors Participation in the Mediation/Arbitration Program In the event that you do not feel your concerns have been addressed after the following the procedure outlined in Steps One and Two. General Motors of Canada Limited wants you to be aware of its participation in a no-charge mediation/Arbitration program.
Page 449: Online Owner Center
— all in one convenient place. • Digital owner manual, warranty information, and more • Online service and maintenance records • Find Cadillac dealers for service nationwide • Exclusive privileges and offers • Recall notices for your speciﬁc vehicle • ®...
Page 450: Customer Assistance For Text Telephone (Tty) Users
Canada can dial 1-800-263-3830.) Customer Assistance Offices Cadillac encourages customers to call the toll-free number for assistance. However, if a customer wishes to write or e-mail Cadillac, the letter should be addressed to: United States — Customer Assistance Cadillac Customer Assistance Center Cadillac Motor Car Division P.O.
Page 451: Gm Mobility Reimbursement Program
Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) — Customer Assistance General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center Paseo de la Reforma # 2740 Col. Lomas de Bezares C.P. 11910, Mexico, D.F. 01-800-508-0000 Long Distance: 011-52-53 29 0 800 GM Mobility Reimbursement...
Page 452: Calling For Assistance
Roadside Assistance program at any time without notiﬁcation. Cadillac and General Motors of Canada Limited reserve the right to limit services or payment to an owner or driver if they decide the claims are made too often, or...
Page 453: Cadillac Owner Privileges
• Emergency Tow From a Public Road or Highway: Tow to the nearest Cadillac dealer for warranty service, or if the vehicle was in a crash and cannot be driven. Assistance is also given when the vehicle is stuck in the sand, mud, or snow.
Page 454: Services Not Included In Roadside Assistance
Cadillac Technician Roadside Service (U.S. only) Cadillac’s exceptional Roadside Service is more than an auto club or towing service. It provides every Cadillac owner in the United States with the advantage of contacting a Cadillac advisor and, where available, a Cadillac trained dealer technician who can provide on-site service.
Page 455: Scheduling Service Appointments
Scheduling Service Appointments When your vehicle requires warranty service, contact your dealer/retailer and request an appointment. By scheduling a service appointment and advising your service consultant of your transportation needs, your dealer/retailer can help minimize your inconvenience. If your vehicle cannot be scheduled into the service department immediately, keep driving it until it can be scheduled for service, unless, of course, the problem is safety-related.
Page 456: Transportation Options
Transportation Options Warranty service can generally be completed while you wait. However, if you are unable to wait, GM helps to minimize your inconvenience by providing several transportation options. Depending on the circumstances, your dealer can offer you one of the following: Shuttle Service Participating dealers can provide shuttle service to get you to your destination with minimal interruption of...
Page 457: Collision Damage Repair
Collision Damage Repair If your vehicle is involved in a collision and it is damaged, have the damage repaired by a qualiﬁed technician using the proper equipment and quality replacement parts. Poorly performed collision repairs will diminish your vehicle’s resale value, and safety performance can be compromised in subsequent collisions.
Page 458: Repair Facility
Repair Facility GM also recommends that you choose a collision repair facility that meets your needs before you ever need collision repairs. Your GM dealer/retailer may have a collision repair center with GM-trained technicians and state of the art equipment, or be able to recommend a collision repair center that has GM-trained technicians and comparable equipment.
Page 459 Give only the necessary information to police and other parties involved in the crash. For emergency towing see Roadside Service on page 8-7 Gather the following information: • Driver’s name, address, phone number • Driver’s license number • Owner’s name, address, phone number •...
Page 460: Reporting Safety Defects
Call 1-800-458-8006, or write: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 33169 Detroit, MI 48232-5169 In Canada, call 1-888-446-2000, or write: Canadian Cadillac Customer Communication Centre, CA1-163-005 General Motors of Canada Limited 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7...
Page 461: Owner Information
Service Publications Ordering Information Service Manuals Service Manuals have the diagnosis and repair information on engines, transmission, axle suspension, brakes, electrical, steering, body, etc. Service Bulletins Service Bulletins give additional technical service information needed to knowledgeably service General Motors cars and trucks. Each bulletin contains instructions to assist in the diagnosis and service of your vehicle.
Page 462: Vehicle Data Recording And Privacy
ORDER TOLL FREE: 1-800-551-4123 Monday-Friday 8:00 AM - 6:00 PM Eastern Time For Credit Card Orders Only (VISA-MasterCard-Discover), visit Helm, Inc. on the World Wide Web at: helminc.com Or you can write to: Helm, Incorporated P.O. Box 07130 Detroit, MI 48207 Prices are subject to change without notice and without incurring obligation.
Page 463: Event Data Recorders
Event Data Recorders This vehicle has an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 464: Onstar
® OnStar If the vehicle has OnStar and you subscribe to the OnStar services, please refer to the OnStar Terms and Conditions for information on data collection and use. Navigation System If your vehicle has a navigation system, use of the system may result in the storage of destinations, addresses, telephone numbers, and other trip information.
Page 465 Accessories and Modiﬁcations ... 6-3 Accessory Power ... 3-24 Accessory Power Outlets ... 4-34 Adaptive Cruise Control ... 4-15 Additives, Fuel ... 6-6 Add-On Electrical Equipment ... 6-100 Air Cleaner/Filter, Engine ... 6-17 Air Filter, Passenger Compartment ... 4-44 Airbag Adding Equipment to Your Airbag-Equipped Vehicle ...
Page 466 Audio System ... 4-88 Audio Steering Wheel Controls ... 4-119 Navigation/Radio System, see Navigation Manual ... 4-108 Radio Reception ... 4-120 Setting the Clock ... 4-89 Theft-Deterrent Feature ... 4-119 XM™ Satellite Radio Antenna System ... 4-121 Audio System(s) ... 4-92 Automatic Transmission Fluid ...
Page 467 Care of Safety Belts ... 6-95 CD, MP3 ... 4-102 Center Console Storage ... 3-55 Center Flex Storage Unit ... 3-56 Center Seat ... 2-9 Central Door Unlock System ... 3-10 Chains, Tire ... 6-70 Charging System Light ... 4-52 Check Engine Lamp ...
Page 468 Compressor Kit, Tire Sealant ... 6-71 Content Theft-Deterrent ... 3-19 Control of a Vehicle ... 5-3 Convenience Net ... 3-56 Coolant Engine ... 6-23 Engine Temperature Gage ... 4-56 Engine Temperature Warning Light ... 4-55 Cooling System ... 6-22 Cornering Lamps ... 4-30 Courtesy Lamps ...
Page 469 Driving (cont.) Hill and Mountain Roads ... 5-14 In Rain and on Wet Roads ... 5-12 Loss of Control ... 5-10 Off-Road Recovery ... 5-9 Rocking Your Vehicle to Get it Out ... 5-17 Winter ... 5-15 Driving for Better Fuel Economy ... 1-22 Dual Climate Control System ...
Page 470 Filter Engine Air Cleaner ... 6-17 Finish Damage ... 6-98 Flashers, Hazard Warning ... 4-3 Flash-to-Pass ... 4-10 Flat Tire ... 6-70 Flat Tire, Changing ... 6-80 Flat Tire, Storing ... 6-88 Floor Mats ... 3-56 Fluid Automatic Transmission ... 6-19 Power Steering ...
Page 471 Hazard Warning Flashers ... 4-3 Head Restraints ... 2-2 Headlamp Wiring ... 6-100 Headlamps Aiming ... 6-40 Bulb Replacement ... 6-43 Daytime Running Lamps (DRL) ... 4-29 Exterior Lamps ... 4-25 Flash-to-Pass ... 4-10 High Intensity Discharge (HID) Lighting ... 6-43 High/Low Beam Changer ...
Page 472 Labeling, Tire Sidewall ... 6-47 Lamps Cornering ... 4-30 Courtesy ... 4-31 Daytime Running (DRL) ... 4-29 Exterior Lighting Battery Saver ... 4-30 Footwell ... 4-32 Malfunction Indicator ... 4-57 Reading ... 4-32 Lane Departure Warning ... 3-46 Lane Departure Warning Light ... 4-55 Lap Belt ...
Page 473 Magnetic Ride Control ... 5-7 Maintenance Schedule Maintenance Record ... 7-12 Maintenance Replacement Parts ... 7-10 Owner Checks and Services ... 7-6 Recommended Fluids and Lubricants ... 7-8 Scheduled Maintenance ... 7-3 Malfunction Indicator Lamp ... 4-57 Massaging Lumbar Controls ... 2-4 Memory Seat, Mirrors, Steering Wheel Controls ...
Page 474 Outside Automatic Dimming Mirror ... 3-38 Convex Mirror ... 3-39 Heated Mirrors ... 3-39 Power Foldaway Mirrors ... 3-37 Overheated Engine Protection Operating Mode ... 6-29 Owner Checks and Services ... 7-6 Owners, Canadian ... iii Paint, Damage ... 6-98 Parade Dimming ...
Page 475 Radio Frequency Identiﬁcation (RFID) ... 8-20 Statement ... 8-20 Radio(s) ... 4-92 Radios Navigation/Radio System, see Navigation Manual ... 4-108 Reception ... 4-120 Setting the Clock ... 4-89 Theft-Deterrent ... 4-119 ™ Rainsense II Wipers ... 4-10 Reading Lamps ... 4-32 Rear Climate Control System ...
Page 476 Safety Belts Care of ... 6-95 Extender ... 2-33 How to Wear Safety Belts Properly ... 2-17 Lap Belt ... 2-32 Lap-Shoulder Belt ... 2-26 Reminders ... 4-49 Safety Belts Are for Everyone ... 2-12 Use During Pregnancy ... 2-31 Safety Defects Reporting Canadian Government ...
Page 477 Service ... 6-3 Accessories and Modiﬁcations ... 6-3 Adding Equipment to the Outside of the Vehicle ... 6-5 Doing Your Own Work ... 6-4 Engine Soon Lamp ... 4-57 Parts Identiﬁcation Label ... 6-100 Publications Ordering Information ... 8-17 Scheduling Appointments ... 8-11 Servicing Your Airbag-Equipped Vehicle ...
Page 478 Tachometer ... 4-48 Telescopic Steering Column, Power Tilt Wheel ... 4-4 Text Telephone (TTY) Users ... 8-6 Theft-Deterrent Feature ... 4-119 Theft-Deterrent Systems ... 3-18 Content Theft-Deterrent ... 3-19 ® PASS-Key III+ Electronic Immobilizer ... 3-21 ® PASS-Key III+ Electronic Immobilizer Operation ...
Page 479 Towing Recreational Vehicle ... 5-24 Towing a Trailer ... 5-26 Your Vehicle ... 5-24 Traction Control System (TCS) ... 5-6 Control System Warning Light ... 4-54 Magnetic Ride Control ... 5-7 ® StabiliTrak System ... 5-5 Transmission Fluid, Automatic ... 6-19 Transmission Operation, Automatic ...
Page 480 Warning Lights, Gages, and Indicators ... 4-46 Warnings DIC Warnings and Messages ... 4-67 Hazard Flashers ... 4-3 Safety and Symbols ... iv Wheels Alignment and Tire Balance ... 6-68 Different Size ... 6-66 Replacement ... 6-68 When It Is Time for New Tires ... 6-64 Where to Put the Child Restraint ...

Cadillac 2010 DTS Owner's Manual

Section 2 Seats and Restraint System

Seats and Restraint System

Head Restraints

Front Seats

Rear Seats

Safety Belts

Child Restraints

Airbag System

Restraint System Check

Section 3 Features and Controls

Features and Controls

Keys

Doors and Locks

Windows

Theft-Deterrent Systems

Starting and Operating Your Vehicle

Mirrors

Object Detection Systems

Universal Home Remote System

Storage Areas

Sunroof

Section 4 Instrument Panel

Instrument Panel Overview

Climate Controls

Warning Lights, Gages, and Indicators

Driver Information Center (DIC)

Audio System(S)

Section 5 Driving Your Vehicle

Driving Your Vehicle

Your Driving, the Road, and the Vehicle

Towing

Quick Links

Chapters

Related Manuals for Cadillac 2010 DTS

Summary of Contents for Cadillac 2010 DTS
