Assured Wireless AW12 HPUE Manual

Hide thumbs Also See for AW12 HPUE:

Advertisement

Quick Links

Download this manual
When Staying Connected Means Saving Lives
Connecting Cradlepoint IBR1700 Router to FirstNet
with
Assured Wireless AW12 HPUE Modem
www.assured-wireless.com
v0.5

Advertisement

loading
Need help?

Need help?

Do you have a question about the AW12 HPUE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Assured Wireless AW12 HPUE

Summary of Contents for Assured Wireless AW12 HPUE

  • Page 1 When Staying Connected Means Saving Lives Connecting Cradlepoint IBR1700 Router to FirstNet with Assured Wireless AW12 HPUE Modem www.assured-wireless.com v0.5...
  • Page 2 AW12 requires 3 LTE connections - LTE, LTE Diversity, Band14 for HPUE. • IBR1700 will require WiFi antennas and GPS Antenna. • NetCloud activation. Contact Cradlepoint Support cradlepoint.com/support • PC with browser and ethernet interface to connect to IBR1700. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 3 With a and LTE antenna the internal modem will activate. A key for IBR1700 status LEDs is shown here to the right. Installed SIM Cards ©2021 Assured Wireless Corporation All rights reserved. 6/24/2021 assured-wireless.com...
  • Page 4 FirstNet IBR1700 Router + AW12 Modem AW12-EI Ethernet Injector AW12 HPUE Modem Goal: Connect CP IBR1700 Router to AW12 HPUE Modem. IBR1700 Front View IBR1700 Back panel ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 5 In photo, WAN port is far-right RJ45 port with yellow cable in red box. AW12 In photo, a rooftop antenna with three LTE leads is attached to AW12 Rooftop and WiFi antenna is attached Antenna to IBR1700. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 6 LTE connection is established. Entire Flashing Green: process may take minutes the first time to establish a LTE Connecting to FirstNet network connection. Green: Green: Connected to ATT FirstNet. Connected to FirstNet ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...

  • Page 7: Configuration Overview

    2) PC Browser to Cradlepoint IBR1700 for Config IBR1700 3) Login to IBR1700 as Admin Configuration 4) Setup IBR1700 WAN Ethernet Port Overview 5) Access FirstNet 6) Setup IBR1700 WiFi Access Point ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 8 • Username: admin • Password: Found on IBR1700 label RECOMMENDED: Change the IBR1700 password & update firmware as soon as convenient. Take photo of router labels, they may be inaccessible after installation. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 9 NOTE: When you cannot login to the IBR1700 using the default password on the label, it is possible that someone has previously changed the password. A Factory Reset will return the default pasword and clear ALL existing configuration. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 10 NetCloud Dashboard Ethernet WAN active & Connected to AW12-EI. Default is 192.168.0.x Primary LAN, configured for DHCP and NAT. WiFi 2.4GHz & 5GHz have default SSID, and are networked as Primary LAN. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 11 Security> 2) In the Advanced User Management section, select User Name [ admin ], then <Edit> 3) Enter new Password twice. [ Save ] button will highlight when two password entries match. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 12 Verify the Wireless Radio is enabled. Select SSID to edit [ IBR1700-c2f-5G ]. 2) Configuration dialogue pops up for chosen WiFi SSID 3) Enter WPA Password & press [ Save ] button. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 13 3) Next slide will modify Ethernet WAN. NOTE: Ethernet is at the top of the WAN Device Interface Profiles. This explicitly makes Ethernet WAN the highest priority WAN and this will be important for IBR1700 failover configuration. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 14 Assured Wireless recommends MTU size of 1328 bytes for video applications on LTE WAN. 1) Select <Ethernet WAN> [ Edit 2) In WAN Interface Profile dialogue set ] to 1320. 3) Press <Save> ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 15 Success! AW12 WAN Link is UP On Dashboard Ethernet WAN (AW12) is Connected. Modem/LTE (internal) in standby. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 16 WAN and is Connected. Internal side of the WAN entry, then drag them up and down. LTE modem 1200M is alive and using ATT SIM1, but it is Connected. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...

  • Page 17: Failover Mode

    Failover Mode Ethernet-Wan has failed (AW12) Modem/LTE is now Connected. ©2021 Assured Wireless Corporation All rights reserved. 6/24/2021 assured-wireless.com...
  • Page 18 This ensures that the higher priority interface has remained online for a set period of time before it becomes active. For example, in case the connection is dropping in and out. ©2021 Assured Wireless Corporation All rights reserved. 6/24/2021 assured-wireless.com...
  • Page 19 Failback to Primary WAN - AW12 Failback AW12 is back online and IBR1700 has Failback to Ethernet-WAN Connected. ©2021 Assured Wireless Corporation All rights reserved. 6/24/2021 assured-wireless.com...
  • Page 20 • Turn off Auto-Update to control Software Updates. • MTU 1328 recommended. • Configuration changes auto-save to Cradlepoint cloud service. When needed, download configuration to a PC file to protect from loss. ©2021 Assured Wireless Corporation All rights reserved. assured-wireless.com...
  • Page 21 Success! IBR1700 FirstNet HPUE Service Thank you for joining us! AW12 Product Information assured-wireless.com FirstNet Information, Products, and Services FirstNet.com...
