Summary of Contents for Cadillac 2000 DeVille

  • Page 2 2000 Cadillac Deville Owner's Manual Litho in U.S.A. © Copyright General Motors Corporation 1999 Part Number 25695353 A First Edition All Rights Reserved...
  • Page 3 Seats and Seat Controls Section Safety Belts Keys and Door Locks Section Remote Keyless Entry (RKE) System Trunk Release Automatic Transmission Parking Brake Windows Tilt Wheel Turn Signal/Multifunction Lever Windshield Wipers Cruise Control Interior and Exterior Lamps Mirrors Table of Contents Seats and Restraint Systems Air Bag Systems Child Restraints...
  • Page 4 Heating and Air Conditioning Section Setting the Radio Clock Radio/Cassette Player/CD Player Braking/Anti-lock Brakes Section Traction Control System Steering Hazard Warning Flashers Section Jump Starting Towing Your Vehicle Table of Contents (cont'd) Comfort Controls and Audio Systems Radio Theft-Deterrent Feature Steering Wheel Controls (If Equipped) Your Driving and the Road Driving Tips for Various Road Conditions...
  • Page 5 Fuel Section Checking Fluids and Lubricants Passenger Compartment Air Filter (If Equipped) Bulb Replacement Windshield Wiper Blade Replacement Scheduled Maintenance Periodic Maintenance Inspections Table of Contents (cont'd) Service and Appearance Care Tires and Wheels Appearance Care Electrical System/Fuses and Circuit Breakers Capacities and Specifications Normal Maintenance Replacement Parts Maintenance Schedule...
  • Page 6 Customer Satisfaction Procedures Section Customer Assistance Offices Roadside Assistance and Courtesy Transportation In the Index you will find an alphabetical listing of almost every subject in this manual. Section Please refer to the last page of this manual for your Table of Contents (cont'd) Customer Assistance Information Warranty Information (See Warranty Manual)

  • Page 7: For Canadian Owners Who Prefer A French Language Manual

    GENERAL MOTORS, GM and the GM Emblem, CADILLAC, the CADILLAC Crest & Wreath and the name DEVILLE are registered trademarks of General Motors Corporation. This manual includes the latest information at the time it was printed. We reserve the right to make changes in the product after that time without further notice.

  • Page 8: How To Use This Manual

    How to Use this Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. If you do this, it will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things quickly.

  • Page 9: Vehicle Damage Warnings

    Vehicle Damage Warnings Also, in this book you will find these notices: NOTICE: These mean there is something that could damage your vehicle. viii In the notice area, we tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly.

  • Page 10: Vehicle Symbols

    Vehicle Symbols These are some of the symbols you may find on your vehicle. For example, These symbols these symbols are important are used on an for you and original battery: your passengers whenever your vehicle is CAUTION driven: POSSIBLE INJURY DOOR LOCK PROTECT...

  • Page 11: Service Station Guide

    Battery a More See Section 6 Detailed Look at What's Under the Hood See Section 6 Hood Release See Section 6 Windshield Washer Fluid See Section 6 Service Station Guide Cooling System Tire Pressure See Section 5 See Section 6 Engine Oil Dipstick Remote Fuel See Section 6...

  • Page 12: Table Of Contents

    Section 1 Seats and Restraint Systems Here you’ll find information about the seats in your vehicle and how to use your safety belts properly. You can also learn about some things you should not do with air bags and safety belts. Seats and Seat Controls Safety Belts: They’re for Everyone Here Are Questions Many People Ask About...

  • Page 13: Power Seats

    Seats and Seat Controls This section tells you about the power seats adjust them, and also about the reclining front seatbacks, memory seats, lumbar adjustments and heated seats. Power Seats The power seat controls, located on the sides of the front seats, move and adjust the angle of the front seats.
  • Page 14 Four-Way Power Lumbar Control (If Equipped) If your vehicle has this feature, the driver’s and passenger’s seatback lumbar support can be adjusted four ways by moving the single switch located on the side of the seat. To increase the lumbar support, push the switch forward. To decrease the support, push the switch backward.
  • Page 15 Adaptive Seat Control (Option) The adaptive seat control is located on the outboard side of each front seat. With the ignition in ON, first use the power seat control to get the proper position. Then press the top of the control where it is marked AUTO.
  • Page 16 Memory Seat, Mirrors and Steering Wheel (Option) The controls for these features are located on the driver’s door panel, and are used to program and recall previous settings. Adjust the driver’s seat (including the lumbar adjustments), both the outside mirrors and steering wheel to a comfortable position and then press the SET button.

  • Page 17: Reclining Front Seatbacks

    Heated Seats (Option) Your vehicle may be equipped with heated front and rear seats. The control buttons are located on the armrests. The HEAT/OFF button controls the temperature settings HI, MED and LO. The other button is to choose BACK ONLY heating.
  • Page 18 But don’t have a seatback reclined if your vehicle is moving. CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this. The shoulder belt can’t do its job.

  • Page 19: Head Restraints

    Head Restraints Slide the head restraint up or down so that the top of the restraint is closest to the top of your ears. This position reduces the chance of a neck injury in a crash. On some models, the head restraints tilt forward and rear also.
  • Page 20 CAUTION: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.

  • Page 21: Why Safety Belts Work

    Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. Put someone on it. Take the simplest vehicle. Suppose it’s just a seat on wheels. 1-10...
  • Page 22 Get it up to speed. Then stop the vehicle. The rider doesn’t stop. The person keeps going until stopped by something. In a real vehicle, it could be the windshield ... 1-11...
  • Page 23 or the instrument panel ... or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense. 1-12...

  • Page 24: Here Are Questions Many People Ask About Safety Belts -- And The Answers

    Here Are Questions Many People Ask About Safety Belts and the Answers Won’t I be trapped in the vehicle after an accident if I’m wearing a safety belt? You could be whether you’re wearing a safety belt or not. But you can unbuckle a safety belt, even if you’re upside down.

  • Page 25: How To Wear Safety Belts Properly

    How to Wear Safety Belts Properly Adults This part is only for people of adult size. Be aware that there are special things to know about safety belts and children. And there are different rules for smaller children and babies. If a child will be riding in your vehicle, see the part of this manual called “Children.”...
  • Page 26 4. Push the latch plate into the buckle until it clicks. Be sure to use the correct buckle when buckling your shoulder belt. If you find that the latch plate will not go fully into the buckle, see if you are using the buckle for the center passenger position.
  • Page 27 Shoulder Belt Height Adjuster Before you begin to drive, move the shoulder belt adjuster to the height that is right for you. 1-16 To move it down, press down on the power seat recline control and move the height adjuster to the desired position.
  • Page 28 4. Now you can add a small amount of slack. Lean forward slightly, then sit back. If you’ve added more than 1 inch (25 mm) of slack, pull the shoulder belt out as you did before and start again. If you move around in the vehicle enough, or if you pull out the shoulder belt, the belt will become tight again.
  • Page 29 What’s wrong with this? The shoulder belt is too loose. It won’t give nearly as much protection this way. 1-18 CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury.
  • Page 30 What’s wrong with this? The belt is buckled in the wrong place. CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones.
  • Page 31 What’s wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. 1-20 CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
  • Page 32 What’s wrong with this? The belt is twisted across the body. CAUTION: You can be seriously injured by a twisted belt. In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.

  • Page 33: Safety Belt Use During Pregnancy

    To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.

  • Page 34: Right Front Passenger Position

    The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly.
  • Page 35 Here are the most important things to know about the air bag systems: CAUTION: You can be severely injured or killed in a crash if you aren’t wearing your safety belt have air bags. Wearing your safety belt during a crash helps reduce your chance of hitting things inside the vehicle or being ejected from it.
  • Page 36 CAUTION: Both frontal and side impact air bags inflate with great force, faster than the blink of an eye. If you’re too close to an inflating air bag, as you would be if you were leaning forward, it could seriously injure you. Safety belts help keep you in position for air bag inflation before and during a crash.

  • Page 37: How The Air Bag Systems Work

    United States There is an air bag readiness light on the instrument panel, which shows the words AIR BAG or an air bag symbol. The system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem.
  • Page 38 The right front passenger’s frontal air bag is in the instrument panel on the passenger’s side. The driver’s side impact air bag is in the side of the driver’s seatback closest to the door. 1-27...
  • Page 39 The right front passenger’s side impact air bag is in the side of the passenger’s seatback closest to the door. 1-28 The side impact air bags for the rear seat outboard passenger positions are in the sides of the rear seatback closest to the doors.
  • Page 40 CAUTION: If something is between an occupant and an air bag, the bag might not inflate properly or it might force the object into that person. The path of an inflating air bag must be kept clear. Don’t put anything between an occupant and an air bag, and don’t attach or put anything on the steering wheel hub or on or near any other air bag covering and don’t let seat covers block the...
  • Page 41 What makes an air bag inflate? In an impact of sufficient severity, the air bag sensing system detects that the vehicle is in a crash. For both frontal and side impact air bags, the sensing system triggers a release of gas from the inflator, which inflates the air bag.
  • Page 42 CAUTION: When an air bag inflates, there is dust in the air. This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in the vehicle should get out as soon as it is safe to do so. If you have breathing problems but can’t get out of the vehicle after an air bag inflates, then get fresh air by opening a window or a door.

  • Page 43: Servicing Your Air Bag-Equipped Vehicle

    NOTICE: If you damage the covering for the driver’s or the right front passenger’s air bag, or the air bag covering on the driver’s, right front passenger’s or rear seatback, the bag may not work properly. You may have to replace the air bag module in the steering wheel, both the air bag module and the instrument panel for the right front passenger’s air bag, or both the air bag module...

  • Page 44: Lap Belt

    Safety Belt Pretensioners Your vehicle has safety belt pretensioners. You’ll find them on the buckle end of the safety belts for the driver and right front passenger. They help the safety belts reduce a person’s forward movement in a moderate to severe crash in which the front of the vehicle hits something.

  • Page 45: Rear Seat Passengers

    To make the belt shorter, pull its free end as shown until the belt is snug. Buckle, position and release it the same way as the lap part of a lap shoulder belt. If the belt isn’t long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
  • Page 46 1. Pick up the latch plate and pull the belt across you. Don’t let it get twisted. The shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.
  • Page 47 3. To make the lap part tight, pull down on the buckle The lap part of the belt should be worn low and snug on end of the belt as you pull up on the shoulder part. the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones.
  • Page 48 The safety belt locks if there’s a sudden stop or a crash, or if you pull the belt very quickly out of the retractor. The rear outboard seating positions may have a shoulder belt tightness adjustment feature. You can tell if your vehicle has this feature by following the steps below.
  • Page 49 CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body. To unlatch the belt, just push the button on the buckle. 1-38...

  • Page 50: Rear Safety Belt Comfort Guides For Children And Small Adults

    Rear Safety Belt Comfort Guides for Children and Small Adults Rear shoulder belt comfort guides will provide added safety belt comfort for children who have outgrown child restraints and for small adults. When installed on a shoulder belt, the comfort guide pulls the belt away from the neck and head.
  • Page 51 2. Slide the guide under and past the belt. The elastic cord must be under the belt. Then, place the guide over the belt, and insert the two edges of the belt into the slots of the guide. 1-40 3. Be sure that the belt is not twisted and it lies flat. The elastic cord must be under the belt and the guide on top.

  • Page 52: Smaller Children And Babies

    4. Buckle, position and release the safety belt as described in “Rear Seat Passenger Positions” earlier in this section. Make sure that the shoulder belt crosses the shoulder. To remove and store the comfort guides, squeeze the belt edges together so that you can take them out from the guides.
  • Page 53 CAUTION: Smaller children and babies should always be restrained in a child or infant restraint. The instructions for the restraint will say whether it is the right type and size for your child. A very young child’s hip bones are so small that a regular belt might not stay low on the hips, as it should.
  • Page 54 CAUTION: Never hold a baby in your arms while riding in a vehicle. A baby doesn’t weigh much crash. During a crash a baby will become so heavy you can’t hold it. For example, in a crash CAUTION: (Continued) CAUTION: (Continued) at only 25 mph (40 km/h), a 12 will suddenly become a 240 your arms.

  • Page 55: Child Restraints

    Child Restraints Every time infants and young children ride in vehicles, they should have protection provided by appropriate restraints. What are the different types of add child restraints? on child restraints are available in four basic types. When selecting a child restraint, take into consideration not only the child’s weight and size, but also whether or not the restraint will be compatible with the motor vehicle in which it will...
  • Page 56 A rear facing infant restraint (B) positions an infant to face the rear of the vehicle. Rear facing infant restraints are designed for infants of up to about 20 lbs. (9 kg) and about one year of age. This type of restraint faces the rear so that the infant’s head, neck and body can have the support they need in a frontal crash.
  • Page 57 A forward facing child restraint (C E) positions a child upright to face forward in the vehicle. These forward facing restraints are designed to help protect children who are from 20 to 40 lbs. (9 to 18 kg) and about 26 to 40 inches (66 to 102 cm) in height, or up to around four years of age.
  • Page 58 A booster seat (F) is designed for children who are about 40 to 60 lbs., or even up to 80 lbs. (18 to 27 kg, or even up to 36 kg), and about four to eight years of age. A booster seat is designed to improve the fit of the vehicle’s safety belt system.

  • Page 59: Where To Put The Restraint

    Where to Put the Restraint Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. We at General Motors therefore recommend that you put your child restraint in the rear seat. Never put a rear child restraint in the front passenger seat.

  • Page 60: Top Strap

    Top Strap In Canada, the law requires that forward restraints have a top strap, and that the strap be anchored. In the United States, some child restraints also have a top strap. If your child restraint has a top strap, it should be anchored.

  • Page 61: Securing A Child Restraint In A Rear Seat Position

    Securing a Child Restraint in a Rear Seat Position CAUTION: A child in a child restraint in the center front seat can be badly injured or killed by the right front passenger air bag if it inflates. Never secure a child restraint in the center front seat.
  • Page 62 Tilt the latch plate to adjust the belt if needed. If the shoulder belt goes in front of the child’s face or neck, put it behind the child restraint. 3. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

  • Page 63: Securing A Child Restraint In The Right Front Seat Position

    4. To tighten the belt, pull up on the shoulder belt while you push down on the child restraint. If you’re using a forward facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
  • Page 64 CAUTION: A child in a rear facing child restraint can be seriously injured or killed if the right front passenger’s air bag inflates. This is because the back of the rear facing child restraint would be very close to the inflating air bag. Always secure a rear facing child restraint in the rear seat.
  • Page 65 5. Pull the rest of the lap belt all the way out of the retractor to set the lock. 1-54 6. To tighten the belt, feed the lap belt back into the retractor while you push down on the child restraint. You may find it helpful to use your knee to push down on the child restraint as you tighten the belt.

  • Page 66: Larger Children

    Larger Children Children who have outgrown child restraints should wear the vehicle’s safety belts. If you have the choice, a child should sit next to a window so the child can wear a lap get the additional restraint a shoulder belt can provide. Accident statistics show that children are safer if they are restrained in the rear seat.
  • Page 67 1-56 CAUTION: Never do this. Here two children are wearing the same belt. The belt can’t properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time.
  • Page 68 CAUTION: Never do this. Here a child is sitting in a seat that has a shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt’s force would then be applied right on the child’s abdomen.

  • Page 69: Safety Belt Extender

    Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.

  • Page 70: Section 2 Features And Controls

    Section 2 Features and Controls Here you can learn about the many standard and optional features on your vehicle, and information on starting, shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is working properly and what to do if you have a problem.
  • Page 71 Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. If they turned the ignition to ON and moved the shift lever out of PARK (P), that would release the parking brake.
  • Page 72 Master Key There is a master key that works all of the lock cylinders (driver’s door, trunk, ignition and glove box). There is also a VALET key which only operates the driver’s door and the ignition. Both the master and VALET key have a transponder embedded into the key for security and vehicle theft deterrence.

  • Page 73: Door Locks

    Door Locks CAUTION: Unlocked doors can be dangerous. Passengers especially children open the doors and fall out. When a door is locked, the inside handle won’t open it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. This may not be so obvious: You increase the chance of being thrown out of the vehicle in a crash if the doors aren’t locked.

  • Page 74: Programmable Automatic Door Locks

    Central Door Unlocking System Your vehicle has a central door unlocking mode and a theft deterrent system. When unlocking the driver’s door, you can unlock the other doors by holding the key in the turned position for a few seconds or by quickly turning the door key twice in the lock cylinder.

  • Page 75: Rear Door Security Locks

    Rear Door Security Locks Your vehicle is equipped with rear door security locks that help prevent passengers from opening the rear doors of your vehicle from the inside. To use this lock: 1. Turn the knob on the passenger’s side rear door clockwise all the way down to the ENGAGED position.

  • Page 76: Remote Keyless Entry System

    Leaving Your Vehicle If you are leaving the vehicle, open the door, set the locks from the inside, get out and close the door. Remote Keyless Entry System With this feature, you can lock and unlock your doors or unlock your trunk from about 3 feet (1 m) up to 30 feet (9 m) away using the remote keyless entry transmitter supplied with your vehicle.

  • Page 77: Operation

    The average range of this system is about 10 feet (3 m). At times you may notice a decrease in range. This is normal for any remote keyless entry transmitter. If the transmitter does not work or if you have to stand closer to your vehicle for the transmitter to work, try this: Check the distance.

  • Page 78: Matching Transmitter(S) To Your Vehicle

    When you press this symbol to lock the doors, the parking lamps will flash once and the horn will sound. The park lamps will not flash, however, if the manual park lamps are left on. (You can also program your vehicle so the parking lamps will not flash and the horn will not sound.

  • Page 79: Battery Replacement

    Battery Replacement Under normal use, the battery in your remote keyless entry transmitter should last about two years. You can tell the battery is weak if the transmitter won’t work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it’s probably time to change the battery.
  • Page 80 3. Replace the battery. Insert the new battery as the instructions under the cover indicate. 4. Snap the transmitter back together tightly to be sure no moisture can enter. 5. Resynchronize the transmitter. See “Resynchronization” following. Resynchronization Pressing the remote keyless entry transmitter buttons numerous times (approximately 250 times) out of the vehicle’s operating range may cause the transmitter not to work.

  • Page 81: Trunk Lock Release

    Trunk CAUTION: It can be dangerous to drive with the trunk lid open because carbon monoxide (CO) gas can come into your vehicle. You can’t see or smell CO. It can cause unconsciousness and even death. If you must drive with the trunk lid open or if electrical wiring or other cable connections must pass through the seal between the body and the trunk lid:...

  • Page 82: Trunk Lid Tie Down

    Trunk Lid Tie Down CAUTION: Driving with the trunk lid open can allow dangerous CO (carbon monoxide) gas to come into your vehicle. You can’t see or smell CO. It can cause unconsciousness and even death. CAUTION: (Continued) CAUTION: (Continued) If you ever need to drive with your trunk lid open, then: Make sure all windows, the rear seat...
  • Page 83 2-14 This feature is used to secure the trunk lid if it will not close completely, such as when carrying large packages in the trunk. 1. Attach the clip end of the tie down to the “D” ring on the trunk lid (see view A). 2.

  • Page 84: Key In The Ignition

    Theft Vehicle theft is big business, especially in some cities. Although your vehicle has a number of theft features, we know that nothing we put on it can make it impossible to steal. However, there are ways you can help. Key in the Ignition If you leave your vehicle with the keys inside, it’s an easy target for joy riders or professional thieves...

  • Page 85: Theft Deterrent System

    Theft Deterrent System If the ignition is off and any door is open, the SECURITY light will flash, reminding you to activate the system. The light will also flash if the battery has been disconnected and reconnected. To arm the system, do the following: 1.

  • Page 86: Valet Lockout Switch

    Testing the Alarm 1. From inside the vehicle, roll down the window, then get out of the vehicle, keeping the door open. 2. From outside of the vehicle, with the door open, lock the vehicle using the power door lock or the remote keyless entry transmitter and close the door.
  • Page 87 PASS Your vehicle is equipped with the PASS (Personalized Automotive Security System) theft deterrent system. PASS Key III is a passive theft deterrent system. This means you don’t have to do anything different to arm or disarm the system. It works when you insert or remove the key from the ignition.
  • Page 88 It is possible for the PASS Key III decoder to learn the transponder value of a new or replacement key. Up to ten additional keys may be programmed for the vehicle. This procedure is for learning additional keys only. If all the currently programmed keys are lost or do not operate, you must see your dealer or a locksmith who can service PASS...

  • Page 89: Ignition Positions

    New Vehicle “Break In” NOTICE: Your vehicle doesn’t need an elaborate “break in.” But it will perform better in the long run if you follow these guidelines: Don’t drive at any one speed slow for the first 500 miles (805 km). Don’t make full throttle starts.
  • Page 90 With the ignition switch, you can turn the switch to four different positions. OFF (A): Before you put the key in, the ignition will be in OFF. This is the only position in which you can remove the key. This position locks the ignition, steering wheel and transaxle.

  • Page 91: Starting Your Engine

    Retained Accessory Power (RAP) The following accessories on your vehicle may be used for up to 10 minutes after the ignition key is turned from ON to OFF: Radio Power Windows Sunroof Power to these accessories will stop after 10 minutes or if any door is opened.
  • Page 92 Starting Your Northstar V8 Engine 1. Without pushing the accelerator pedal, turn your ignition key to START. When the engine starts, let go of the key. The idle speed will go down as your engine gets warm. NOTICE: Holding your key in START for longer than 15 seconds at a time will cause your battery to be drained much sooner.

  • Page 93: Engine Coolant Heater (If Equipped)

    Engine Coolant Heater (If Equipped) A. Engine Oil Dipstick Location B. Engine Coolant Heater Cord C. Transaxle Dipstick/Fluid Fill Location 2-24 In very cold weather, 0 _ F ( 18 _ C) or colder, the engine coolant heater can help. You’ll get easier starting and better fuel economy during engine warm the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle.

  • Page 94: Automatic Transaxle Operation

    CAUTION: Plugging the cord into an ungrounded outlet could cause an electrical shock. Also, the wrong kind of extension cord could overheat and cause a fire. You could be seriously injured. Plug the cord into a properly grounded three volt AC outlet. If the cord won’t reach, use a heavy duty three prong extension cord rated for...
  • Page 95 Column Shifter (Digital and Analog Cluster similar) PARK (P): This position locks the front wheels. It’s the best position to use when you start the engine because your vehicle can’t move easily. 2-26 CAUTION: It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set.
  • Page 96 Ensure the shift lever is fully in PARK (P) before starting the engine. Your vehicle has an automatic transaxle shift lock control system. You have to fully apply your regular brakes before you can shift from PARK (P) when the ignition key is in ON. If you cannot shift out of PARK (P), ease pressure on the shift lever push the shift lever all the way into PARK (P) as...
  • Page 97 NOTICE: Damage to your transaxle caused by shifting out of PARK (P) or NEUTRAL (N) with the engine racing isn’t covered by your warranty. DRIVE (D): This position is for normal driving. If you need more power for passing, and you’re: Going less than 35 mph (55 km/h), push the accelerator pedal about halfway down.

  • Page 98: Performance Shifting (Dts Only)

    SECOND (2): This position gives you more power. You can use SECOND (2) on hills. It can help control your speed as you go down steep mountain roads, but then you would also want to use your brakes off and on. NOTICE: Don’t shift into SECOND (2) unless you are going slower than 65 mph (105 km/h), or you can...

  • Page 99: Parking Brake

    Parking Brake Hold the regular brake pedal down with your right foot and push the parking brake pedal down with your left foot to set the parking brake. If the ignition is on, the BRAKE indicator light should come on. If it doesn’t, you need to have your vehicle serviced.
  • Page 100 Reach under the driver’s side of the instrument panel and pull on the manual release lever, which is located above the parking brake pedal. If the parking brake does not release, you should either drive to the nearest service station or have your vehicle towed. NOTICE: Driving with the parking brake on can cause your rear brakes to overheat.

  • Page 101: Shifting Into Park (P)

    Shifting Into PARK (P) CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
  • Page 102 Move the lever up as far as it will go. 3. With your right foot still holding the brake pedal down, set the parking brake. 4. Turn the ignition key to OFF. 5. Remove the key and take it with you. If you can leave your vehicle with the ignition key in your hand, your vehicle is in PARK (P).

  • Page 103: Torque Lock

    Leaving Your Vehicle With the Engine Running CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake firmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch fire.

  • Page 104: Shifting Out Of Park (P)

    Shifting Out of PARK (P) Your vehicle has an automatic transaxle shift lock control system. You have to fully apply your regular brakes before you can shift from PARK (P) when the ignition is in ON. See “Automatic Transaxle” in the Index.

  • Page 105: Parking Over Things That Burn

    The console shift lock release is located on the front of the center console. To access the shift lock release hole: 1. Verify that the shift lever is in PARK (P). 2. Locate the shift lock release on the front of the center console.

  • Page 106: Engine Exhaust

    Engine Exhaust CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you can’t see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: Your exhaust system sounds strange or different. Your vehicle gets rusty underneath.

  • Page 107: Power Windows

    CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set. Your vehicle can roll. Don’t leave your vehicle when the engine is running unless you have to. If you’ve left the engine running, the vehicle can move suddenly.
  • Page 108 Express Down Window All power windows have this feature. Pressing the control rearward to the second position then releasing it, will lower a window completely. If you want to stop the window as it is lowering, press the control forward briefly. Press the control forward again to raise the window.

  • Page 109: Turn And Lane Change Signals

    Turn Signal/Multifunction Lever Turn and Lane Change Signals To signal a turn, move the lever all the way up or down. The lever returns automatically when the turn is complete. An arrow on the instrument panel will flash in the direction of the turn or lane change.

  • Page 110: Windshield Wipers

    Windshield Wipers WIPER: Turn the band on the turn signal lever to control the wipers. MIST: Turn the band toward you to“mist” and then release it for a single wiping cycle. For more cycles, hold the band on MIST longer. LO or HI: Turn the band away from you to either LO (low speed) or to HI (high speed), depending on the wiper speed you want.
  • Page 111 Rainsense Wipers (If Equipped) This moisture sensor is mounted on the passenger’s interior side of the windshield behind the rearview mirror and is used to automatically operate the wipers by monitoring the amount of moisture that is on the windshield. The Rainsense system can be activated by turning the wiper stalk to one of the five sensitivity levels indicated on the stalk.

  • Page 112: Windshield Washer

    Windshield Washer CAUTION: In freezing weather, don’t use your washer until the windshield is warmed. Otherwise the washer fluid can form ice on the windshield, blocking your vision. At the top of the turn signal/multifunction lever there is a paddle with the word PUSH on it. To spray washer fluid on the windshield, press and release this paddle.
  • Page 113 CAUTION: Cruise control can be dangerous where you can’t drive safely at a steady speed. So, don’t use your cruise control on winding roads or in heavy traffic. Cruise control can be dangerous on slippery roads. On such roads, fast changes in tire traction can cause needless wheel spinning, and you could lose control.
  • Page 114 Resuming a Set Speed Suppose you set your cruise control at a desired speed and then you apply the brake. This, of course, shuts off the cruise control. But you don’t need to reset it. Once the vehicle is traveling approximately 25 mph (40 km/h) or more, you can press RES/ACC (resume/accelerate) button to return to your desired preset speed.

  • Page 115: Exterior Lamps

    Passing Another Vehicle While Using Cruise Control Use the accelerator pedal to increase your speed. When you take your foot off the pedal, your vehicle will slow down to the cruise control speed you set earlier. Using Cruise Control on Hills How well your cruise control will work on hills depends upon your speed, load and the steepness of the hills.

  • Page 116: Daytime Running Lamps

    Parking Lamps Turn the lamp control knob clockwise to the first stop, to turn on the parking, taillamps, sidemarker lamps. If it is night, the instrument panel switch backlighting will also illuminate. Turn the control knob counterclockwise all the way back to turn the lamps and lights off. Headlamps Turn the control knob clockwise all the way to turn on the parklamps and headlamps.
  • Page 117 The DRL system will make the high come on at reduced intensity when: it is still daylight and the ignition is on, the headlamp switch is off and the transaxle is not in PARK (P). When DRL are on, only your high beam headlamps (at reduced intensity) will be on.

  • Page 118: Cornering Lamps

    Fog Lamps (If Equipped) Use the fog lamps for better vision in foggy or misty conditions. When you press the fog lamp button, a fog lamp symbol located in the instrument panel will come on to indicate that the fog lamps and the parking lamps are on.
  • Page 119 If you move the control all the way to the right, the lamps will remain on for approximately three minutes after the ignition has been turned to OFF. If you move the control so it is just on, the lamps will go off quickly when you turn the ignition switch out of OFF.

  • Page 120: Illuminated Entry

    Exterior Lighting Battery Saver If the headlamp or manual parking lamp control has been left on, the exterior lamps will turn off approximately 10 minutes after the ignition is turned to OFF. This protects draining the battery in case you have accidentally left the headlamps or parking lamps on.

  • Page 121: Reading Lamps

    Parade Dimming This feature prohibits dimming of the digital displays and backlighting during daylight hours when the key is in the ignition and the headlamps are on. This feature operates with the light sensor for the Twilight Sentinel and is fully automatic. When the light sensor reads darkness outside and the park lamps are active, the digital displays can be adjusted by turning the lamp control knob counterclockwise to dim and clockwise to...

  • Page 122: Inadvertent Power Battery Saver

    Battery Load Management The battery load management feature is designed to monitor the vehicle electrical load and determine when the battery is in a heavy discharge condition. During times of high electrical loading, the engine may idle at a higher RPM setting than normal to make sure the battery charges.
  • Page 123 When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing. Cleaning Photocells Use a cotton swab and glass cleaner to clean the photocells when necessary.
  • Page 124 Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight. Under certain circumstances, as during a long distance cross country trip, it will be necessary to adjust for compass variance.

  • Page 125: Driver's Outside Auto-Dimming Rearview Mirror

    Power Remote Control Mirror (Heated) The control on the driver’s door armrest operates both outside rearview mirrors. Press (R) on the control switch to choose the right mirror or (L) to choose the left mirror. The center switch position is for off and will not move the mirrors if touched.

  • Page 126: Storage Compartments

    Convex Outside Mirror Your passenger’s side mirror is convex. A convex mirror’s surface is curved so you can see more from the driver’s seat. CAUTION: A convex mirror can make things (like other vehicles) look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on your right.

  • Page 127: Rear Storage Door Trim Armrest

    Full Floor Console Storage (If Equipped) The full floor console has an upper and lower storage area. The lower has two removable that can hold tapes and/or CDs. There is also a removable coinholder that attaches to the side of one of the bins. The upper storage area is available for the optional cellular telephone.

  • Page 128: Ashtrays And Cigarette Lighter

    Ashtrays and Cigarette Lighter NOTICE: Don’t put papers or other flammable items into your ashtrays. Hot cigarettes or other smoking materials could ignite them, causing a damaging fire. Front Ashtray With the full center console, the ashtray is located below the climate control system.

  • Page 129: Sun Visors

    Sun Visors Swing down the primary visor to block out glare. It can also be detached from the center mount and moved to the side while the auxiliary sunshade remains to block the glare from the front. The visors also have side side slide capability.

  • Page 130: Cellular Telephone (Option)

    Cellular Telephone (Option) Your vehicle has been prewired for dealer installation of the Cadillac Communiport integrated portable cellular telephone system. The system has steering wheel telephone controls and information output through the Driver Information Center (DIC). Voice activation with remote record and hands free operation are standard features.

  • Page 131: Assist Handles

    Assist Handles A handle above each door can be used when getting out of your vehicle. Umbrella Holder The driver’s and passenger’s front seat cushion comes equipped with an umbrella holder. Gently slide the umbrella into the slot located under the front portion of the driver’s or passenger’s seat cushion.

  • Page 132: Homelink Transmitter

    To open the glass panel and sunshade, press and hold the ROOF switch rearward to the first position. The sunshade can also be opened by hand. To close the glass panel, press and hold the ROOF switch forward. As the glass panel closes, it will open slightly toward the vent to provide a better seal.

  • Page 133: Programming The Homelink Transmitter

    This device complies with RSS 210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Changes and modifications to this system by other than an authorized service facility could void authorization to use this equipment.

  • Page 134: Operating The Homelink Transmitter

    If you have trouble programming the HomeLink Transmitter, make sure that you have followed the directions exactly as described. The HomeLink Transmitter may not work with older garage door openers that do not meet current Federal Consumer Safety Standards. If you cannot program the transmitter after repeated attempts, refer to “Rolling Code Programming”...

  • Page 135: "Rolling Code" Programming

    “Rolling Code” Programming If you have not previously programmed the hand transmitter to the HomeLink Transmitter, see “Programming the HomeLink Transmitter” listed previously. If you have completed this programming already, you now need to train the garage door opener motor head unit to recognize the HomeLink Transmitter. Refer to your garage door opener owner’s manual for the proper transmitter training procedure for your garage door opener brand.

  • Page 136: Erasing Channels

    Erasing Channels To erase all three programmed channels, hold down the two outside buttons until the indicator light begins to flash (after 20 seconds). Release both buttons. Accessories Accessories for the HomeLink Transmitter are available from the manufacturer of the unit. If you would like additional information, please call 1 3515.
  • Page 137 The Instrument Panel Your Information System 2-68...
  • Page 138 The main components of the instrument panel are: A. Air Outlets B. Turn Signal/Multifunction Lever C. HVAC Steering Wheel Controls (or Cellular Telephone Controls, If Equipped) D. Cluster E. Audio Steering Wheel Controls F. Driver Information Center Control Buttons G. Electronic Climate Controls H.
  • Page 139 Digital Cluster (If Equipped) The instrument panel cluster is designed to let you know at a glance how your vehicle is running. You’ll know how fast you’re going, how much fuel you’re using and many of the other things you’ll need to know to drive safely and economically. United States version shown, Canada similar 2-70...
  • Page 140 Analog Cluster (If Equipped) United States version shown, Canada similar 2-71...

  • Page 141: Speedometer And Odometer

    Speedometer and Odometer The speedometer lets you see your speed in both miles per hour (mph) and kilometers per hour (km/h). The odometer shows how far your vehicle has been driven, in either miles (used in the United States) or kilometers (used in Canada).

  • Page 142: Tachometer (Analog Cluster Only)

    Vehicle Speed Limiter This feature prevents your vehicle from exceeding speeds that the tires are not rated for. When this happens, the engine’s fuel supply is shut off. When the vehicle speed slows, the fuel supply will come on again. Tachometer (Analog Cluster Only) This gage indicates the engine speed in revolutions...

  • Page 143: Safety Belt Reminder Light

    Warning lights come on when there may be or is a problem with one of your vehicle’s functions. As you will see in the details on the next few pages, some warning lights come on briefly when you start the engine just to let you know they’re working.

  • Page 144: Air Bag Readiness Light

    Air Bag Readiness Light There is an air bag readiness light on the instrument panel, which shows AIR BAG or the symbol of an air bag. The system checks the air bag’s electrical system for malfunctions. The light tells you if there is an electrical problem.

  • Page 145: Charging System Light

    Charging System Light When you turn the key to ON, this light will come on briefly to show that the generator and battery charging systems are working. If this light stays on, you need service and you should take your vehicle to the dealer at once. To save your battery until you get there, turn off all accessories.

  • Page 146: Anti-Lock Brake System Warning Light

    CAUTION: Your brake system may not be working properly if the brake system warning light is on. Driving with the brake system warning light on can lead to an accident. If the light is still on after you’ve pulled off the road and stopped carefully, have the vehicle towed for service.
  • Page 147 Traction Control System Warning Light United States This warning light should come on briefly as you start the engine. If the warning light doesn’t come on then, have it fixed so it will be ready to warn you if there’s a problem. If it stays on, or comes on when you’re driving, there may be a problem with your traction control system and your vehicle may need service.

  • Page 148: Engine Coolant Temperature Warning Light

    Engine Coolant Temperature Warning Light This light tells you that your engine has overheated. You should stop your vehicle and turn the engine off as soon as possible. A warning chime should also sound if this light comes on. As a check, the light should come on for a few seconds when you start your engine.

  • Page 149: Malfunction Indicator Lamp

    Malfunction Indicator Lamp (Service Engine Soon Light in the United States or Check Engine Light in Canada) United States Your vehicle is equipped with a computer which monitors operation of the fuel, ignition and emission control systems. 2-80 This system is called OBD II (On Diagnostics Second Generation) and is intended to assure that emissions are at acceptable levels for the...
  • Page 150 NOTICE: Modifications made to the engine, transaxle, exhaust or fuel system of your vehicle or the replacement of the original tires with other than those of the same Tire Performance Criteria (TPC) can affect your vehicle’s emission controls and may cause the SERVICE ENGINE SOON or CHECK ENGINE light to come on.
  • Page 151 If the Light Is On Steady You may be able to correct the emission system malfunction by considering the following: Did you recently put fuel into your vehicle? If so, reinstall the fuel cap, making sure to fully install the cap. See “Filling Your Tank” in the Index. The diagnostic system can determine if the fuel cap has been left off or improperly installed.

  • Page 152: Oil Pressure Light

    Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or may begin programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. Here are some things you need to know in order to help your vehicle pass an inspection: Your vehicle will not pass this inspection if the SERVICE ENGINE SOON or CHECK ENGINE light is...

  • Page 153: Security Light

    CAUTION: Don’t keep driving if the oil pressure is low. If you do, your engine can become so hot that it catches fire. You or others could be burned. Check your oil as soon as possible and have your vehicle serviced. NOTICE: Damage to your engine from neglected oil problems can be costly and is not covered by...

  • Page 154: Cruise Control Light

    Lights On Reminder United States This light comes on as a reminder that your headlamps are on. Cruise Control Light This light comes on whenever you set your vehicle’s cruise control. Fuel Gage Canada Analog (United States) Digital Analog (Canada) The fuel gage shows approximately how much fuel is in the tank.
  • Page 155 If the fuel supply gets down to approximately three gallons (11.4 L) of fuel remaining in the tank, the FUEL LEVEL LOW message will appear on the Driver Information Center (DIC). On the digital cluster, if the fuel is less than approximately 1.2 gallons (4.7 L) the “E”...

  • Page 156: Dic Controls And Displays

    The RANGE display shows how far the computer thinks you can travel with the fuel that is in the tank. The computer does not know what driving conditions will be like for the rest of your trip, so the range is estimated based on the recent fuel economy.
  • Page 157 INFO RESET: Pressing this button will reset the MPG AVG, GAL FUEL USED, MPH AVG, TIMER, ENGINE OIL LIFE, TRANS FLUID LIFE, when each mode is individually selected. For more information about the trip odometer, see “Odometer” in the Index. ON/OFF: In feature programming mode, pressing this button turns the Memory and Personalization Features on and off and starts and stops the timer.
  • Page 158 Driver Information Center (DIC) Messages These messages will appear if there is a problem sensed in one of your vehicle’s systems. Vehicles that are first sold in Canada will have a number after each message. This number helps to identify the problem. You must then press INFO or INFO RESET to clear the display screen for further use.
  • Page 159 BATTERY VOLTAGE LOW 6: This message will appear when the electrical system is charging less than 10 volts or if the battery has been drained. If this message appears immediately after starting, it is possible that the generator can still recharge the battery. The battery should recharge while driving but may take a few hours to do so.
  • Page 160 CHECK OIL LEVEL 36: For correct operation of the low oil sensing system, your vehicle should be on a level surface. A false CHECK OIL LEVEL message may appear if the vehicle is parked on grades. The oil level sensing system does not check for actual oil level if the engine has been off for a short period of time, and the oil level is never sensed while the engine is running.
  • Page 161 ENGINE OVERHEATED, STOP ENGINE message will appear when the engine has overheated. Stop and turn the engine off immediately to avoid severe engine damage. See “Engine Overheating” in the Index. A multiple chime will also sound when this message is displayed. ENGINE POWER REDUCED 41: This message informs you that the vehicle is reducing engine power...
  • Page 162 SERVICE AC SYSTEM 14: This message appears when the electronic sensors that control the air conditioning and heating systems are no longer working. Have the climate control system serviced if you notice a drop in heating and air conditioning efficiency. SERVICE AIR BAG 83: There is a problem with the supplemental inflatable restraint (air bag) system when this...
  • Page 163 When the STABILITY SYS ENGAGED message is on, you should continue to steer in the direction you want to go. The system is designed to help you in bad weather or other difficult driving situations by making the most of whatever road conditions will permit.
  • Page 164 TOP SPEED FUEL CUT 111: This message will appear when the Powertrain Control Module (PCM) senses that the maximum speed for your vehicle has been reached. The speed of your vehicle will surge as the fuel supply is cut off. This allows your vehicle to stay in a safe tire operating range.
  • Page 165 Vehicle Programming and Personalization Features (If Equipped) If your vehicle is equipped with personalization, you can program certain features to a preferred setting for up to two people. If your vehicle does not have personalization then some of the features on your vehicle have been programmed for all drivers.
  • Page 166 Key in Recall Memory (If Equipped) To enter feature programming, follow the instructions listed previously, then press the down arrow on the INFO button one or more times until the KEY IN RECALL MEMORY prompt appears on the DIC display. To turn the feature on, press the ON/OFF button until ON appears.
  • Page 167 Lights Flash at Unlock To enter feature programming follow the instructions listed previously, then press the down arrow on the INFO button one or more times until the LIGHTS FLASH AT UNLOCK prompt appears. To turn this feature on, press the ON/OFF button until ON is displayed on the DIC.
  • Page 168 Press the INFO button one or more times until the FEATURE PROGRAMMING prompt appears on the DIC display. Press the ON/OFF button to enter FEATURE PROGRAMMING. To exit, press the INFO RESET button. Press the down arrow on the INFO button one or more times until the EXT LIGHTS AT UNLOCK prompt appears.
  • Page 169 Doors Unlock in PARK (P) To enter feature programming follow the instructions listed previously, then press the down arrow on the INFO button one or more times until the DOORS UNLOCK IN PARK prompt appears. This feature will automatically unlock all doors when the vehicle is shifted into PARK (P).
  • Page 170 Comfort Controls and Radio System Personalization These features allow both drivers to personalize their own climate control settings as well as their radio settings. For more information, see “Climate Control Personalization” and “Radio Personalization” in the Index. Continuous Variable Road Sensing Suspension (CVRSS) (If Equipped) The CVRSS automatically adjusts the ride of your vehicle.
  • Page 171 Night Vision System (Option) The Night Vision System can help you see better when you drive at night. The system works by sensing heat given off by objects in its field of view. Warmer objects, such as pedestrians, animals and other moving vehicles, will appear whiter.
  • Page 172 The Night Vision System can be operated if: The brightness control is in any position except OFF. It is dark enough outside. The headlamps or foglamps (if equipped) are on. The ignition is turned to ON. The controls are located to the left of and below the steering wheel.
  • Page 173 The Night Vision System image appears as a “heat image” that looks something like a black and white photographic negative. It appears in front of the driver just above the front edge of the hood. 2-104 Remember that the Night Vision System can only help you see objects that are warmer or colder than the surroundings.
  • Page 174 In dry, clear weather, the system can see pedestrians, animals and the direction of the road ahead. In light rain, light snow or light fog the image may not be as clear and you may not be able to see the direction of the road ahead.
  • Page 175 Navigation (Option) Navigation Display Controls The display screen is located in the center on the instrument panel. There are eight “hard” buttons and a touch sensitive screen. 2-106 Your vehicle may be equipped with a turn by turn navigation guidance system that includes a CD ROM map media covering nine regional areas throughout the contiguous United States.

  • Page 176: Ultrasonic Rear Parking Assist

    Ultrasonic Rear Parking Assist (URPA) (Option) Ultrasonic Rear Parking Assist can help you to determine how close an object is to your rear bumper within a given area, making parking easier. The URPA display is located inside the vehicle, above the rear window. It has three color that can be seen through the rearview mirror or by...
  • Page 177 A chime will sound the first time an object is detected. URPA can detect objects 3 inches (7.6 cm) and wider, and at least 10 inches (25.4 cm) tall, but it cannot detect objects that are above trunk level. In order for the rear sensors to recognize an object, it must be within operating range.

  • Page 178: Section 3 Comfort Controls And Audio Systems

    Section 3 Comfort Controls and Audio Systems In this section, you’ll find out how to operate the comfort control and audio systems offered with your vehicle. Be sure to read about the particular systems supplied with your vehicle. Comfort Controls Climate Control Panel Electronic Solar Sensor Air Conditioning...

  • Page 179: Comfort Controls

    Comfort Controls This section tells you how to make your air system work for you. With this system, you can control the heating, cooling and ventilation in your vehicle. Your vehicle also has a flow through ventilation system described later in this section.
  • Page 180 Outside Temperature Display The outside temperature is always displayed when your vehicle is running. You can change it from Fahrenheit to Celsius by pressing the ENG/MET (English/metric) button on the left side of the instrument panel cluster. The outside temperature sensor is located near the front grille.
  • Page 181 With the automatic setting, the air conditioning compressor automatically cycles when needed to cool the air. In cold weather, when the system senses the need for heat, the airflow will be directed out the floor outlets. As the interior temperature approaches a desired setting, the blower speed will decrease.
  • Page 182 DEFROST: Press this button to quickly remove fog or frost from the windshield. This setting sends most of the airflow to the windshield with only a small amount to the floor outlets. FAN SPEEDS: Press the AUTO. At this setting, the fan speed is automatically controlled.

  • Page 183: Air Conditioning

    Electronic Solar Sensor The sensor monitors the sun’s solar radiation and is located on top of the instrument panel near the windshield. The ECC panel uses this information to automatically make the necessary temperature and airflow adjustments to maintain your comfort. Air Conditioning On hot days, open the windows long enough to let hot inside air escape.

  • Page 184: Defogging And Defrosting

    Defogging and Defrosting On cool, humid days, use defog HEATER/DEFROST to keep the windshield and side windows clear. Use defrost to remove fog or ice from the windshield quickly in extremely humid or cold conditions. Press the MODE button to select DEFROST. Adjust the fan speed by pressing the fan button up or down.

  • Page 185: Rear Climate Control

    Rear Climate Control Your vehicle is equipped with a rear climate control. With this system, the rear passengers can control the temperature of the air flow for his/her own zones. The climate control has three buttons: Mode: Press this button to adjust the direction of the airflow.

  • Page 186: Ventilation System

    Ventilation System Your vehicle’s flow through ventilation system supplies outside air into the vehicle when it is moving. Outside air will also enter the vehicle when the heater or the air conditioning fan is running. The front outlets are located in the center and at each side of the instrument panel.

  • Page 187: Hvac Steering Wheel Controls

    HVAC Steering Wheel Controls Some heating and cooling controls can be adjusted at the steering wheel. Other touch controls operate some audio controls. See “Audio Steering Wheel Controls” in the Index. FAN SPEED: Press the up arrow lever to increase the fan speed and the down arrow lever to decrease fan speed.

  • Page 188: Audio Systems

    Audio Systems Your audio system has been designed to operate easily and give years of listening pleasure. You will get the most enjoyment out of it if you acquaint yourself with it first. Find out what your audio system can do and how to operate all its controls, to be sure you’re getting the most out of the advanced engineering that went into it.
  • Page 189 SOURCE: Press this button to select a source. Sources include cassette and compact disc. The audio source must be loaded to play. Available loaded sources are shown on the display. If a source is being used, it will be underlined on the display. If none of the audio sources are loaded, NO SOURCE LOADED will appear on the display.
  • Page 190 Setting the Tone TONE: Press and release this button until the desired tone control (BASS or TREBLE) is found. The radio keeps separate tone settings for each band, each preset and each source. LEVEL: After selecting the desired tone control, press the plus (+) or minus ( ) symbol on this button to select the desired level.
  • Page 191 RW: Press the left arrow to rewind the tape rapidly. The radio will play while the tape rewinds. You may use your station pushbuttons to tune to another radio station while in RW mode. Press the left arrow again to return to playing speed.
  • Page 192 AM-FM Stereo with Cassette Tape and Compact Disc Player (If Equipped) Playing the Radio PWR/VOL: Press this knob lightly to turn the system on. Press the knob again to turn the system off. To increase volume, turn the knob clockwise. Turn it counterclockwise to decrease volume.
  • Page 193 PUSHBUTTONS: The six numbered pushbuttons let you return to your favorite stations. You can set up to 18 stations (six AM, six FM1 and six FM2). Just: 1. Turn the radio on. 2. Press BAND to select AM, FM1 or FM2. 3.
  • Page 194 Playing a Cassette Tape With the radio on, insert a cassette tape. The tape will begin playing as soon as it is inserted. When one side of your cassette tape is done playing, auto reverse plays the other side of your cassette tape. Cassette tapes may be loaded with the radio off but they will not start playing until the radio is on.
  • Page 195 EJECT: Press the upward triangle button to the right of the cassette tape player to remove a tape. The radio will play. Eject may be activated with the radio off and/or the ignition off. CLEAN TAPE: If this message appears on the display, the cassette tape player needs to be cleaned.
  • Page 196 FF: Press and hold the right arrow to fast forward to another part of the compact disc. Release it to return to playing speed. TUNE SEEK: When this button is pressed, it has two positions. This button works the same, whether it is pressed to the first or second position.
  • Page 197 HR or MN: Display the time with the ignition off by pressing this button. SOURCE: Press this button to select a source. Sources include cassette and compact disc. The audio source must be loaded to play. Available loaded sources are shown on the display.
  • Page 198 Using RDS Mode Your audio system is equipped with Radio Data Systems (RDS). RDS mode gives you many useful new features. When RDS is on, the radio can: seek only to stations with the types of programs you want to listen to, seek to stations with traffic announcements, receive announcements concerning local and national emergencies,...
  • Page 199 REGION: You can also use the RDS button to access the region function. When an RDS station becomes weak, this function searches for a stronger station within the same network. A network can span a great distance. One network can have stations spread across a country or continent.
  • Page 200 MSG (3): When RDS is on, if the current station has a message, MSG will appear on the display. Press the RDS SELECT button, followed by this button to see the message. If the whole message does not appear on the display, parts of the message will appear every three seconds until the message is completed.
  • Page 201 PUSHBUTTONS: The six numbered pushbuttons let you return to your favorite Program Types (PTYs). These buttons have factory PTY presets. See “Radio Data Systems (RDS) Program Type (PTY) Selections” in the Index. You can set up to 12 PTYs (six FM1 and six FM2).
  • Page 202 Setting the Tone TONE: Press and release this button until the desired tone control (BASS or TREBLE) is found. The radio keeps separate tone settings for each band, preset (except weather band presets) and source. LEVEL: After selecting the desired tone control, press the plus (+) or minus ( ) symbol on this button to select the desired level.
  • Page 203 Playing a Cassette Tape With the radio on, insert a cassette tape. The tape will begin playing as soon as it is inserted. When one side of your cassette tape is done playing, auto reverse plays the other side of your cassette tape. Cassette tapes may be loaded with the radio off but they will not start playing until the radio is on.
  • Page 204 EJECT: Press the upward triangle button to the right of the cassette tape player to remove a tape. The radio will play. Eject may be activated with the radio off and/or the ignition off. CLEAN TAPE: If this message appears on the display, the cassette tape player needs to be cleaned.
  • Page 205 RW: Press and hold the left arrow to reverse the compact disc. Release it to return to playing speed. FF: Press and hold the right arrow to fast forward to another part of the compact disc. Release it to return to playing speed.
  • Page 206 AVC: Your system has a feature called Automatic Volume Control (AVC). With AVC, your audio system monitors the noise in the vehicle. Then, AVC automatically adjusts the volume level so that it always sounds the same to you. To use AVC, press and hold the TONE button until AUTO VOLUME CONTROL OFF appears on the display.
  • Page 207 PUSHBUTTONS: The six numbered pushbuttons let you return to your favorite stations. The RDS PTY mode must be off to use this mode. You can set up to 24 stations (six AM, six FM1, six FM2 and six weather). Just: 1.
  • Page 208 RDS (1): With RDS off, press the RDS SELECT button, followed by this button to turn RDS on. The RDS display will turn on. You must have RDS on to use the new RDS functions. The RDS display will also turn on if one of the other RDS function buttons has been pressed on.
  • Page 209 TA (2): Press the RDS SELECT button, followed by this button to receive traffic announcements. The radio will turn on the TA display. TP will appear on the display if the tuned station broadcasts traffic announcements. You may also receive traffic announcements from stations in the network related to the tuned station.
  • Page 210 PTY (4): This button is used to turn on and off Program Type (PTY) seeks and scans. Press the RDS SELECT button, followed by this button. The PTY display will turn on. RDS SELECT: PTY NEWS will appear on the display for three seconds.
  • Page 211 HR or MN: Press the RDS SELECT button, followed by one of these buttons to display the time for the current station. STATION TIME IS will be displayed. If a time has not been sent to the radio, NO STATION TIME will be displayed.
  • Page 212 Using DSP Mode DSP: The Digital Signal Processing (DSP) feature is used to provide a choice of four different listening experiences: TALK, FRONT SEAT, AMBIENCE and SPACIOUS. DSP can be used while listening to the radio, the cassette tape player or the MiniDisc player. Press this button to turn DSP on.
  • Page 213 If an error occurs while trying to play a cassette tape, it could be that: The cassette tape is tight and the cassette player cannot turn the hubs of the tape. Hold the cassette tape with the open end down and try turning the right hub counterclockwise with a pencil.
  • Page 214 Your cassette tape player automatically reduces background noise. Dolby Noise Reduction is manufactured under a license from Dolby Laboratories Licensing Corporation. Dolby and the double D symbol are trademarks of Dolby Laboratories Licensing Corporation. Auto CrO allows the cassette tape player to adjust to the type of cassette tape for clearer sound for CrO cassette tapes.
  • Page 215 RDM: Press this button to hear the tracks in random, rather than sequential, order. Press RDM again to turn off random play. EJECT: Press the upward triangle button to the right of the MiniDisc player to remove a MiniDisc. The radio will play.

  • Page 216: Cd Adapter Kits

    Navigation/Radio System (Option) Navigation/Radio Display and Controls The display screen is located in the center of the instrument panel. There are eight “hard” buttons and a touch sensitive screen. Your vehicle may be equipped with an AM navigation radio system that includes digital sound processing (DSP), a Radio Data System (RDS) with program “type”...

  • Page 217: Glovebox-Mounted Cd Changer

    Glovebox-Mounted CD Changer With the compact disc changer, you can play up to 6 discs continuously. Normal size discs may be played using the trays supplied in the magazine. The smaller discs (8 cm) can be played only with specially designed trays.
  • Page 218 Close the door by sliding it all the way to the right. When the door is closed, the changer will begin checking for discs in the magazine. This will continue for up to one and a half minutes, depending on the number of discs loaded.
  • Page 219 SCAN: Press this button. You will hear the first few seconds of the first track on each disc. Press this button again to stop scanning. The CD will mute while scanning and SCAN will appear on the display. RDM: Press this button to hear the tracks in random, rather than sequential, order.

  • Page 220: Theft-Deterrent Feature

    Radio Personalization with Home and Away Feature (If Equipped) If DRIVER 1 (HOME or AWAY) PRESETS or DRIVER 2 (HOME or AWAY) PRESETS appears in the display when the radio is first turned on, your vehicle is equipped with this feature. With this feature, your vehicle will recall the latest radio settings as adjusted the last time your vehicle was operated.

  • Page 221: Audio Steering Wheel Controls

    Audio Steering Wheel Controls Some audio controls can be adjusted at the steering wheel. They include the following: VOLUME: Press the up arrow lever to increase volume and the down arrow lever to decrease volume. 3-44 SELECT: When listening to the radio, press the up or down arrow lever to tune to the next or previous preset radio station.

  • Page 222: Understanding Radio Reception

    Understanding Radio Reception The range for most AM stations is greater than for FM, especially at night. The longer range, however, can cause stations to interfere with each other. AM can pick up noise from things like storms and power lines. Try reducing the treble to reduce this noise if you ever get it.

  • Page 223: Care Of Your Cassette Tape Player

    NOTICE: Before you add any sound equipment to your vehicle like a tape player, CB radio, mobile telephone or two way radio be sure you can add what you want. If you can, it’s very important to do it properly. Added sound equipment may interfere with the operation of your vehicle’s engine, radio or other systems, and even damage them.
  • Page 224 When using a scrubbing action, non cassette, it is normal for the cassette to eject because your unit is equipped with a cut tape detection feature and a cleaning cassette may appear as a broken tape. To prevent the cleaning cassette from being ejected, use the following steps.

  • Page 225: Diversity Antenna System

    Care of Your Compact Discs Handle discs carefully. Store them in their original cases or other protective cases and away from direct sunlight and dust. If the surface of a disc is soiled, dampen a clean, soft cloth in a mild, neutral detergent solution and clean it, wiping from the center to the edge.

  • Page 226: Section 4 Your Driving And The Road

    Section 4 Your Driving and the Road Here you’ll find information about driving on different kinds of roads and in varying weather conditions. We’ve also included many other useful tips on driving. Defensive Driving Drunken Driving Control of a Vehicle Braking Steering Road Recovery...

  • Page 227: Defensive Driving

    Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads or freeways, it means “always expect the unexpected.”...

  • Page 228: Drunken Driving

    Drunken Driving Death and injury associated with drinking and driving is a national tragedy. It’s the number one contributor to the highway death toll, claiming thousands of victims every year. Alcohol affects four things that anyone needs to drive a vehicle: Judgment Muscular Coordination Vision...
  • Page 229 It’s the amount of alcohol that counts. For example, if the same person drank three double martinis (3 ounces or 90 ml of liquor each) within an hour, the person’s BAC would be close to 0.12 percent. A person who consumes food just before or during drinking will have a somewhat lower BAC level.
  • Page 230 But the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night. All drivers are impaired at BAC levels above 0.05 percent.

  • Page 231: Control Of A Vehicle

    Control of a Vehicle You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering and the accelerator. All three systems have to do their work at the places where the tires meet the road. Sometimes, as when you’re driving on snow or ice, it’s easy to ask more of those control systems than the tires and road can provide.

  • Page 232: Anti-Lock Brakes (Abs)

    Avoid needless heavy braking. Some people drive in spurts heavy acceleration followed by heavy braking rather than keeping pace with traffic. This is a mistake. Your brakes may not have time to cool between hard stops. Your brakes will wear out much faster if you do a lot of heavy braking.
  • Page 233 Here’s how anti lock works. Let’s say the road is wet. You’re driving safely. Suddenly an animal jumps out in front of you. You slam on the brakes. Here’s what happens with ABS. A computer senses that wheels are slowing down. If one of the wheels is about to stop rolling, the computer will separately work the brakes at each front wheel and at both rear wheels.

  • Page 234: Traction Control System

    Using Anti Lock Don’t pump the brakes. Just hold the brake pedal down firmly and let anti lock work for you. You may hear the anti lock pump or motor operate, and feel the brake pedal pulsate, but this is normal. Braking in Emergencies With anti lock, you can steer and brake at the same...
  • Page 235 The traction control system automatically comes on whenever you start your vehicle. To limit wheel spin, especially in slippery road conditions, you should always leave the system on. But you can turn the traction control system off if you ever need to. (You should turn the system off if your vehicle ever gets stuck in sand, mud, ice or snow.

  • Page 236: Power Steering

    Steering Power Steering If you lose power steering assist because the engine stops or the system is not functioning, you can steer but it will take much more effort. Magnasteer This system continuously adjusts the effort you feel when steering at all vehicle speeds. It provides ease when parking yet a firm, solid feel at highway speeds.

  • Page 237: Steering In Emergencies

    If you need to reduce your speed as you approach a curve, do it before you enter the curve, while your front wheels are straight ahead. Try to adjust your speed so you can “drive” through the curve. Maintain a reasonable, steady speed. Wait to accelerate until you are out of the curve, and then accelerate gently into the straightaway.

  • Page 238: Off - Road Recovery

    An emergency like this requires close attention and a quick decision. If you are holding the steering wheel at the recommended 9 and 3 o’clock positions, you can turn it a full 180 degrees very quickly without removing either hand. But you have to act fast, steer quickly, and just as quickly straighten the wheel once you have avoided the object.

  • Page 239: Passing

    Passing The driver of a vehicle about to pass another on a lane highway waits for just the right moment, accelerates, moves around the vehicle ahead, then goes back into the right lane again. A simple maneuver? Not necessarily! Passing another vehicle on a two highway is a potentially dangerous move, since the passing vehicle occupies the same lane as oncoming traffic for several seconds.

  • Page 240: Loss Of Control

    If other cars are lined up to pass a slow vehicle, wait your turn. But take care that someone isn’t trying to pass you as you pull out to pass the slow vehicle. Remember to glance over your shoulder and check the blind spot.
  • Page 241 A cornering skid is best handled by easing your foot off the accelerator pedal. Remember: Any traction control system helps avoid only the acceleration skid. If your traction control system is off, then an acceleration skid is also best handled by easing your foot off the accelerator pedal.

  • Page 242: Driving At Night

    Driving at Night Night driving is more dangerous than day driving. One reason is that some drivers are likely to be impaired by alcohol or drugs, with night vision problems, or by fatigue. Here are some tips on night driving. Drive defensively.
  • Page 243 No one can see as well at night as in the daytime. But as we get older these differences increase. A 50 driver may require at least twice as much light to see the same thing at night as a 20 year old.

  • Page 244: Driving In Rain And On Wet Roads

    Driving in Rain and on Wet Roads Rain and wet roads can mean driving trouble. On a wet road, you can’t stop, accelerate or turn as well because your tire road traction isn’t as good as on dry roads. And, if your tires don’t have much tread left, you’ll get even less traction.
  • Page 245 4-20 Driving too fast through large water puddles or even going through some car washes can cause problems, too. The water may affect your brakes. Try to avoid puddles. But if you can’t, try to slow down before you hit them. CAUTION: Wet brakes can cause accidents.

  • Page 246: Driving Through Deep Standing Water

    Hydroplaning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you’re going fast enough. When your vehicle is hydroplaning, it has little or no contact with the road.

  • Page 247: Driving Through Flowing Water

    Driving Through Flowing Water CAUTION: Flowing or rushing water creates strong forces. If you try to drive through flowing water, as you might at a low water crossing, your vehicle can be carried away. As little as six inches of flowing water can carry away a smaller vehicle.

  • Page 248: City Driving

    City Driving One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving: Know the best way to get to where you are going.

  • Page 249: Freeway Driving

    Freeway Driving Mile for mile, freeways (also called thruways, parkways, expressways, turnpikes or superhighways) are the safest of all roads. But they have their own special rules. 4-24 The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving.

  • Page 250: Before Leaving On A Long Trip

    Of course, you’ll find experienced and able service experts in Cadillac dealerships all across North America. They’ll be ready and willing to help if you need it. Here are some things you can check before a trip:...

  • Page 251: Highway Hypnosis

    Highway Hypnosis Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy.
  • Page 252 If you drive regularly in steep country, or if you’re planning to visit there, here are some tips that can make your trips safer and more enjoyable. Keep your vehicle in good shape. Check all fluid levels and also the brakes, tires, cooling system and transaxle.

  • Page 253: Winter Driving

    As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident. You may see highway signs on mountains that warn of special problems. Examples are long grades, passing or no passing zones, a falling rocks area or winding roads.

  • Page 254: Driving On Snow Or Ice

    Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth and a couple of reflective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet or a couple of burlap bags to help provide traction.

  • Page 255: If You're Caught In A Blizzard

    Whatever the condition smooth ice, packed, blowing or loose snow drive with caution. Keep your traction control system on. It improves your ability to accelerate when driving on a slippery road. Even though your vehicle has a traction control system, you’ll want to slow down and adjust your driving to the road conditions.
  • Page 256 Tie a red cloth to your vehicle to alert police that you’ve been stopped by the snow. Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats anything you can wrap around yourself or tuck under your clothing to keep warm.

  • Page 257: Recreational Vehicle Towing

    Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged.

  • Page 258: Loading Your Vehicle

    Loading Your Vehicle Two labels on your vehicle show how much weight it may properly carry. The Tire Loading Information label found on the driver’s side center hinge pillar tells you the proper size, speed rating and recommended inflation pressures for the tires on your vehicle. It also gives you important information about the number of people that can be in your vehicle and the total weight that you can carry.

  • Page 259: Electronic Level Control

    CAUTION: Do not load your vehicle any heavier than the GVWR, or either the maximum front or rear GAWR. If you do, parts on your vehicle can break, and it can change the way your vehicle handles. These could cause you to lose control and crash.

  • Page 260: Towing A Trailer

    Towing a Trailer CAUTION: If you don’t use the correct equipment and drive properly, you can lose control when you pull a trailer. For example, if the trailer is too heavy, the brakes may not work well or even at all. You and your passengers could be seriously injured.

  • Page 261: If You Do Decide To Pull A Trailer

    If You Do Decide To Pull A Trailer If you do, here are some important points: There are many different laws, including speed limit restrictions, having to do with trailering. Make sure your rig will be legal, not only where you live but also where you’ll be driving.

  • Page 262: Weight Of The Trailer Tongue

    2,000 lbs. (900 kg). You can ask your dealer for our trailering information or advice, or you can write us at: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 436004 Pontiac, MI 48343...

  • Page 263: Total Weight On Your Vehicle's Tires

    If you’re using a weight carrying hitch, the trailer tongue (A) should weigh 10 percent of the total loaded trailer weight (B). If you have a weight hitch, the trailer tongue (A) should weigh 12 percent of the total loaded trailer weight (B). After you’ve loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper.

  • Page 264: Trailer Brakes

    Safety Chains You should always attach chains between your vehicle and your trailer. Cross the safety chains under the tongue of the trailer so that the tongue will not drop to the road if it becomes separated from the hitch. Instructions about safety chains may be provided by the hitch manufacturer or by the trailer manufacturer.

  • Page 265: Driving With A Trailer

    Driving with a Trailer Towing a trailer requires a certain amount of experience. Before setting out for the open road, you’ll want to get to know your rig. Acquaint yourself with the feel of handling and braking with the added weight of the trailer.

  • Page 266: Turn Signals When Towing A Trailer

    Making Turns NOTICE: Making very sharp turns while trailering could cause the trailer to come in contact with the vehicle. Your vehicle could be damaged. Avoid making very sharp turns while trailering. When you’re turning with a trailer, make wider turns than normal.

  • Page 267: Engine Cooling When Trailer Towing

    Parking on Hills CAUTION: You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged. But if you ever have to park your rig on a hill, here’s how to do it: 1.

  • Page 268: Section 5 Problems On The Road

    Section 5 Problems on the Road Here you’ll find what to do about some problems that can occur on the road. Hazard Warning Flashers Other Warning Devices Jump Starting Towing Your Vehicle Engine Overheating Cooling System If a Tire Goes Flat Changing a Flat Tire Compact Spare Tire If You’re Stuck: In Sand, Mud, Ice or Snow...

  • Page 269: Hazard Warning Flashers

    Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will flash on and off. The hazard warning button is located on the center of the instrument panel between the two air vents.

  • Page 270: Other Warning Devices

    Other Warning Devices If you carry reflective triangles, you can set one up at the side of the road about 300 feet (100 m) behind your vehicle. Jump Starting If you cannot start your vehicle and you are unable to remove your key from the ignition, see “Shift Lock Release”...
  • Page 271 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other. If they are, it could cause a ground connection you don’t want. You wouldn’t be able to start your vehicle and the bad grounding could damage the electrical systems.
  • Page 272 CAUTION: An electric fan can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan. 5. Lift and move the red positive (+) terminal cover away from the relay center.
  • Page 273 6. Check that the jumper cables don’t have loose or missing insulation. If they do, you could get a shock. The vehicles could also be damaged. Before you connect the cables, here are some basic things you should know. Positive (+) will go to positive (+) and negative ( ) will go to a heavy, unpainted metal engine part.
  • Page 274 9. Now connect the black negative ( the good battery’s negative ( Don’t let the other end of the negative ( anything until the next step. The other end of the negative ( ) cable doesn’t go to the dead battery. 10.

  • Page 275: Towing Your Vehicle

    A. Remote Positive (+) Terminal B. Good Battery C. Heavy, Unpainted Metal Engine Part Towing Your Vehicle CAUTION: To help avoid serious personal injury to you or others: Never let passengers ride in a vehicle that is being towed. Never tow faster than safe or posted speeds. Never tow with damaged parts not fully secured.

  • Page 276: Engine Overheating

    NOTICE: Use the proper towing equipment to avoid damage to the bumper, fascia or fog lamp areas of the vehicle. With current trends in automotive styles and design, it is essential that the correct towing equipment is used to tow a vehicle. Your vehicle can be towed with wheel lift or car carrier equipment.

  • Page 277: If Steam Is Coming From Your Engine

    If Steam Is Coming From Your Engine CAUTION: Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Just turn it off and get everyone away from the vehicle until it cools down.

  • Page 278: If No Steam Is Coming From Your Engine

    NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty. See “Overheated Engine Protection Operating Mode” in the Index. If No Steam Is Coming From Your Engine If you get an engine overheat warning but see or hear no steam, the problem may not be too serious.

  • Page 279: Cooling System

    Cooling System When you decide it’s safe to lift the hood, here’s what you’ll see: A. Coolant Surge Tank with Pressure Cap B. Electric Engine Cooling Fans 5-12 CAUTION: An electric engine cooling fan under the hood can start up even when the engine is not running and can injure you.
  • Page 280 A low coolant level should be indicated by a CHECK COOLANT LEVEL message on the Driver Information Center. If it is, you may have a leak in the radiator hoses, heater hoses, radiator, water pump or somewhere else in the cooling system. CAUTION: Heater and radiator hoses, and other engine parts, can be very hot.

  • Page 281: How To Add Coolant To The Coolant Surge Tank

    If there seems to be no leak, with the engine on, check to see if the electric engine cooling fans are running. If the engine is overheating, both fans should be running. If they aren’t, your vehicle needs service. How to Add Coolant to the Coolant Surge Tank If you haven’t found a problem yet, but the coolant level isn’t at the proper level (2.5 inches (6.4 cm) below the...
  • Page 282 CAUTION: Adding only plain water to your cooling system can be dangerous. Plain water, or some other liquid like alcohol, can boil before the proper coolant mixture will. Your vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, your engine could get too hot but you wouldn’t get the overheat warning.
  • Page 283 1. You can remove the coolant surge tank pressure cap 2. Then keep turning the cap, but now push down as when the cooling system, including the coolant you turn it. Remove the pressure cap. surge tank pressure cap and upper radiator hose, is no longer hot.
  • Page 284 3. Then fill the coolant surge tank with the proper 4. With the coolant surge tank pressure cap off, start the mixture, to the base of the filler neck. engine and let it run until you can feel the upper radiator hose getting hot.

  • Page 285: If A Tire Goes Flat

    5. Then replace the pressure cap. Be sure the arrows on the pressure cap line up like this. Start the engine and allow it to warm up. If the CHECK COOLANT LEVEL message does not appear on the Driver Information Center, coolant is at the proper fill level.

  • Page 286: Changing A Flat Tire

    Changing a Flat Tire If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning flashers. CAUTION: Changing a tire can cause an injury. The vehicle can slip off the jack and roll over you or other people.

  • Page 287: Removing The Spare Tire And Tools

    Removing the Spare Tire and Tools The equipment you’ll need is in the trunk. Instructions for changing your tires are on the inside of the tire cover located in your trunk. To gain access to the instructions, spare tire and jacking equipment, do the following: 1.
  • Page 288 3. Unscrew the wing nuts to remove the container that holds the wrench and jack. 4. Remove the wheel wrench, jack and spare tire from the trunk. See “Compact Spare Tire” later in this section for more information about the compact spare tire.

  • Page 289: Removing The Flat Tire And Installing The Spare Tire

    Removing the Wheel Cover Models with Center Wheel Cover For models having aluminum wheels with a center wheel cover, use the flat end of the wheel wrench to gently pry the wheel covers off. Be careful not to scratch the aluminum wheel edge and don’t try to remove it with your hands.
  • Page 290 2. Find the jacking location from the diagrams above and corresponding hoisting notches located in the plastic molding. The notches may be labeled “JACK” with an arrow pointing to the jacking location on the vehicle. 5-23...
  • Page 291 CAUTION: Getting under a vehicle when it is jacked up is dangerous. If the vehicle slips off the jack, you could be badly injured or killed. Never get under a vehicle when it is supported only by a jack. CAUTION: Raising your vehicle with the jack improperly positioned can damage the vehicle and even make the vehicle fall.
  • Page 292 8. Remove any rust or dirt from the wheel bolts, mounting surfaces and spare wheel. CAUTION: Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts become loose after a time. The wheel could come off and cause an accident.
  • Page 293 10. Replace the wheel nuts with the rounded end of the nuts toward the wheel. Tighten each nut by hand until the wheel is held against the hub. 11. Lower the vehicle by turning the jack handle counterclockwise. Lower the jack completely. 5-26...
  • Page 294 12. Tighten the wheel nuts firmly in a crisscross sequence as shown. If your vehicle is equipped with wheel nut covers, screw them on with your fingers, then tighten quarter turn with the wheel wrench. CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off.

  • Page 295: Storing The Flat Tire And Tools

    13. Don’t try to put a wheel cover on your compact spare tire. It won’t fit. Store the wheel cover and lug nut caps in the trunk until you have the flat tire repaired or replaced. NOTICE: Wheel covers won’t fit on your compact spare. If you try to put a wheel cover on your compact spare, you could damage the cover or the spare.

  • Page 296: Storing The Spare Tire And Tools

    Storing the Spare Tire and Tools CAUTION: Storing a jack, a tire or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place. The compact spare is for temporary use only.

  • Page 297: Compact Spare Tire

    Compact Spare Tire Although the compact spare tire was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated.

  • Page 298: Rocking Your Vehicle To Get It Out

    If You’re Stuck: In Sand, Mud, Ice or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you don’t want to spin your wheels too fast. The method known as “rocking” can help you get out when you’re stuck, but you must use caution.
  • Page 299 NOTES 5-32...

  • Page 300: Section 6 Service And Appearance Care

    Section 6 Service and Appearance Care Here you will find information about the care of your vehicle. This section begins with service and fuel information, and then it shows how to check important fluid and lubricant levels. There is also technical information about your vehicle, and a part devoted to its appearance care.

  • Page 301: Doing Your Own Service Work

    Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to your dealer for all your service needs. You’ll get genuine GM parts and trained and supported service people. We hope you’ll want to keep your GM vehicle all GM. Genuine GM parts have one of these marks: Doing Your Own Service Work If you want to do some of your own service work, you’ll...

  • Page 302: Adding Equipment To The Outside Of Your Vehicle

    CAUTION: You can be injured and your vehicle could be damaged if you try to do service work on a vehicle without knowing enough about it. Be sure you have sufficient knowledge, experience, the proper replacement parts and tools before you attempt any vehicle maintenance task.
  • Page 303 (See “Malfunction Indicator Lamp” in the Index.) If this occurs, return to your authorized Cadillac dealer for diagnosis to determine the cause of failure. In the event it is determined that the cause of the condition is the type of fuels used, repairs may not be covered by your warranty.

  • Page 304: Fuels In Foreign Countries

    Fuels in Foreign Countries If you plan on driving in another country outside the United States or Canada, the proper fuel may be hard to find. Never use leaded gasoline or any other fuel not recommended in the previous text on fuel. Costly repairs caused by use of improper fuel wouldn’t be covered by your warranty.
  • Page 305 The fuel door release button is located to the left of the steering wheel next to the headlamp knob. The button only works in PARK (P) or NEUTRAL (N) when the ignition key is in any position and the VALET lockout button is in the OFF position.
  • Page 306 CAUTION: If you get gasoline on yourself and then something ignites it, you could be badly burned. Gasoline can spray out on you if you open the fuel filler cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather.

  • Page 307: Checking Things Under The Hood

    Filling a Portable Fuel Container CAUTION: Never fill a portable fuel container while it is in your vehicle. Static electricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle damaged if this occurs.

  • Page 308: Hood Release

    Hood Release Pull the lever inside the vehicle to open the hood. It is located on the lower driver’s side of the instrument panel. Then go to the front of the vehicle and find the secondary hood release lever which is located under the front edge of the grille.
  • Page 309 When you open the hood, you’ll see: A. Windshield Washer Fluid Reservoir B. Underhood Junction Block C. Engine Coolant Surge Tank D. Power Steering Fluid E. Engine Oil Fill Cap 6-10 F. Engine Oil Dipstick G. Brake Master Cylinder H. Transaxle Dipstick/Fluid Fill Location I.

  • Page 310: Engine Oil

    Before closing the hood, be sure all filler caps are on properly. Then pull the hood down and close it firmly. Underhood Lamp Turn the parking lamps on to operate the underhood lamp. The underhood lamp will come on when the hood is opened.

  • Page 311: Checking Engine Oil

    Checking Engine Oil It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground. The engine oil dipstick is located behind the radiator on the driver’s side of the engine.

  • Page 312: When To Add Engine Oil

    When to Add Engine Oil If the oil is at or below the ADD line, then you’ll need to add at least one quart of oil. But you must use the right kind. This part explains what kind of oil to use. For crankcase capacity, see “Capacities and Specifications”...

  • Page 313: What Kind Of Engine Oil To Use

    What Kind of Engine Oil to Use Oils recommended for your vehicle can be identified by looking for the starburst symbol. This symbol indicates that the oil has been certified by the American Petroleum Institute (API). Do not use any oil which does not carry this starburst symbol.

  • Page 314: When To Change Engine Oil

    As shown in the chart, SAE 5W 30 is best for your vehicle. However, you can use SAE 10W to be 0 C) or above. These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils, such as SAE 20W NOTICE: Use only engine oil with the American Petroleum Institute Certified For Gasoline Engines...

  • Page 315: What To Do With Used Oil

    How to Reset the Oil Life Indicator After the oil has been changed, display the OIL LIFE message by pressing the INFO button. Then press and hold the RESET button until the display shows 100% ENGINE OIL LIFE. This resets the oil life index. The percentage of oil life remaining may be checked at any time by pressing the INFO button several times until the OIL LIFE message appears.
  • Page 316 3. Remove the air filter element and any loose debris that may be found laying in the air cleaner base. 4. Replace the air filter element. Follow these steps to reinstall the air cleaner cover to the air cleaner housing: 1.
  • Page 317 CAUTION: Operating the engine with the air cleaner/filter off can cause you or others to be burned. The air cleaner not only cleans the air, it stops flame if the engine backfires. If it isn’t there, and the engine backfires, you could be burned. Don’t drive with it off, and be careful working on the engine with the air cleaner/filter off.
  • Page 318 1. To access the passenger compartment air filter, insert the flat tip of a screwdriver into the outer edge of the cover and gently pry the cover up. 2. Then, insert the flat tip of the screwdriver behind the push pin located on the inboard side of the air filter compartment to carefully pry the pin out.

  • Page 319: Automatic Transaxle Fluid

    3. To remove the air filter, insert the flat tip of the screwdriver between the air filter and the compartment wall on the outboard side of the vehicle. Then, push in to flatten the pin holding the air filter in place. Gently remove the air filter and any loose debris that may be inside the air filter compartment.

  • Page 320: How To Check

    How to Check Because this operation can be a little difficult, you may choose to have this done at the dealership service department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.
  • Page 321 Checking the Fluid Level Prepare your vehicle as follows: Park your vehicle on a level place. Keep the engine running. With the parking brake applied, place the shift lever in PARK (P). With your foot on the brake pedal, move the shift lever through each gear range, pausing for about three seconds in each range.

  • Page 322: How To Add Fluid

    3. Check both sides of the dipstick, and read the lower level. The fluid level must be in the cross hatched area. 4. If the fluid level is in the acceptable range, push the dipstick back in all the way. Reinstall the air cleaner assembly.

  • Page 323: Engine Coolant

    How to Reset Transaxle Fluid Change Indicator After the transaxle fluid has been changed, display the transaxle FLUID LIFE message by pressing the INFO button. Then press and hold the INFO RESET button until the display shows “100”. This resets the transaxle fluid life index.

  • Page 324: What To Use

    What to Use Use a mixture of one half clean, drinkable water and half DEX COOL coolant which won’t damage aluminum parts. If you use this coolant mixture, you don’t need to add anything else. CAUTION: Adding only plain water to your cooling system can be dangerous.

  • Page 325: Checking Coolant

    Checking Coolant The surge tank is located on the passenger’s side of the engine. The cooling system is under a lot of pressure when it is hot. If the CHECK COOLANT LEVEL message appears on the Driver Information Center (DIC), you will need to add coolant.

  • Page 326: When To Check Power Steering Fluid

    Adding Coolant If you need more coolant, add the proper DEX coolant mixture at the surge tank, but only when the engine is cool. CAUTION: You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol, and it will burn if the engine parts are hot enough.

  • Page 327: Adding Washer Fluid

    How to Check Power Steering Fluid When the engine compartment is cool, wipe the cap and the top of the reservoir clean, then unscrew the cap and wipe the dipstick with a clean rag. Replace the cap and completely tighten it. Then remove the cap again and look at the fluid level on the dipstick.

  • Page 328: Brake Fluid

    NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system. Also, water doesn’t clean as well as washer fluid.
  • Page 329 There are only two reasons why the brake fluid level in the reservoir might go down. The first is that the brake fluid goes down to an acceptable level during normal brake lining wear. When new linings are put in, the fluid level goes back up.
  • Page 330 What to Add When you do need brake fluid, use only DOT fluid. Use new brake fluid from a sealed container only. Refer to “Recommended Fluids and Lubricants” in the Maintenance Schedule booklet. Always clean the brake fluid reservoir cap and the area around the cap before removing it.

  • Page 331: Brake Pedal Travel

    Brake Wear Your vehicle has four wheel disc brakes. Disc brake pads have built in wear indicators that make a high pitched warning sound when the brake pads are worn and new pads are needed. The sound may come and go or be heard all the time your vehicle is moving (except when you are pushing on the brake pedal firmly).

  • Page 332: Replacing Brake System Parts

    Replacing Brake System Parts The braking system on a vehicle is complex. Its many parts have to be of top quality and work well together if the vehicle is to have really good braking. Your vehicle was designed and tested with top quality GM brake parts.

  • Page 333: Vehicle Storage

    To be sure the vent hose (A) is properly attached, the vent hose connectors (B) must be securely reattached to the vent outlets (C) on each side of the battery, and the vent assembly grommet (D) must be secured to the floor pan (E).

  • Page 334: Bulb Replacement

    Bulb Replacement For the proper type of replacement bulb, see “Replacement Bulbs” in the Index. For any bulb changing procedure not listed in this section, contact your dealer’s service department. Halogen Bulbs CAUTION: Halogen bulbs have pressurized gas inside and can burst if you drop or scratch the bulb.
  • Page 335 2. Remove the two bolts at the top of the headlamp assembly. 3. Loosen the bolt at the bottom of the headlamp assembly to gain access to the bulb socket. 6-36 4. Firmly grasp the outboard side of the headlamp assembly with both hands and pull hard enough, so that the whole assembly opens freely.
  • Page 336 5. Remove the bulb socket dust cover and set aside. 8. Install the new bulb into the socket. Make sure that 6. Turn the headlamp housing socket counterclockwise to 9. Reinstall the headlamp housing socket back into the unlock the socket from the lamp housing.
  • Page 337 To reinstall the filler panel: 1. Place the filler panel in the correct location. 2. Reset each push pin by holding each by the outer circle while pushing up on the pin assembly from below. The center portion of the push now be above the outer circle.
  • Page 338 If your vehicle is damaged in an accident, the headlamp aim may be affected. Aim adjustment to the low beam may be necessary if it is difficult to see lane markers (for horizontal aim), or if oncoming drivers flash their high beams at you (for vertical aim).
  • Page 339 If you believe your headlamps need horizontal (left/right) adjustment, follow the horizontal aiming procedure. If you believe your headlamps need only vertical (up/down) adjustment, follow only the vertical aiming procedure. Adjustment screws can be turned with an E8 Torx socket or T15 Torx screwdriver. 6-40 Headlamp Horizontal Aiming Turn the horizontal aiming screw (A) until the...
  • Page 340 Headlamp Vertical Aiming 1. Find the aim dot on the lens of the lamps. 2. Measure the distance from the ground to the aim dot on each lamp; if left low beam, subtract two inches. Record this distance. 3. At the wall or other flat surface, measure from the floor to the recorded distance and draw a horizontal line the width of the vehicle.
  • Page 341 4. Turn on the low beam headlamps and cover the lamp not being evaluated. The ambient light should allow the beam cut off to be seen on the wall. 6-42 5. Turn the vertical aiming screw (C) until the headlamp beam is aimed to the horizontal line. It is recommended to cover the lamp that is not being evaluated to better see the beam being aimed.

  • Page 342: Front Turn Signal Lamps

    Front Cornering Lamps 1. Follow Steps 1 through 5 in “Headlamps” described previously. 2. Disconnect the cornering lamp bulb by pulling the bulb out of the socket. Do not twist or turn the bulb. 3. Replace cornering lamp bulb by pushing the bulb directly into the socket.

  • Page 343: Windshield Wiper Blade Replacement

    3. Remove the turn signal lamp housing socket and replace the bulb. 6-44 Windshield Wiper Blade Replacement Windshield wiper blades should be inspected at least twice a year for wear or cracking. See “Wiper Blade Check” in the Maintenance Schedule booklet under Part B “Owner Checks and Services”...
  • Page 344 Your new vehicle comes with high a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your Cadillac Warranty booklet for details. CAUTION: Poorly maintained and improperly used tires are dangerous.

  • Page 345: Inflation -- Tire Pressure

    CAUTION: (Continued) Underinflated tires pose the same danger as overloaded tires. The resulting accident could cause serious injury. Check all tires frequently to maintain the recommended pressure. Tire pressure should be checked when your tires are cold. Overinflated tires are more likely to be cut, punctured or broken by a sudden impact such as when you hit a pothole.
  • Page 346 NOTICE: Don’t let anyone tell you that underinflation or overinflation is all right. It’s not. If your tires don’t have enough air (underinflation), you can get the following: Too much flexing Too much heat Tire overloading Bad wear Bad handling Bad fuel economy.

  • Page 347: Tire Inspection And Rotation

    Tire Inspection and Rotation Tires should be rotated every 6,000 to 8,000 miles (10 000 to 13 000 km). Any time you notice unusual wear, rotate your tires as soon as possible and check wheel alignment. Also check for damaged tires or wheels.

  • Page 348: Buying New Tires

    When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining. You need a new tire if any of the following statements are true: You can see the indicators at three or more places around the tire.

  • Page 349: Uniform Tire Quality Grading

    CAUTION: Mixing tires could cause you to lose control while driving. If you mix tires of different sizes or types (radial and bias belted tires), the vehicle may not handle properly, and you could have a crash. Using tires of different sizes may also cause damage to your vehicle.
  • Page 350 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 1/2) times as well on the government course as a tire graded 100.

  • Page 351: Wheel Replacement

    Wheel Alignment and Tire Balance The wheels on your vehicle were aligned and balanced carefully at the factory to give you the longest tire life and best overall performance. Scheduled wheel alignment and wheel balancing are not needed. However, if you notice unusual tire wear or your vehicle pulling one way or the other, the alignment may need to be reset.

  • Page 352: Tire Chains

    Used Replacement Wheels CAUTION: Putting a used wheel on your vehicle is dangerous. You can’t know how it’s been used or how far it’s been driven. It could fail suddenly and cause an accident. If you have to replace a wheel, use a new GM original equipment wheel.

  • Page 353: Appearance Care

    Appearance Care Remember, cleaning products can be hazardous. Some are toxic. Others can burst into flame if you strike a match or get them on a hot part of the vehicle. Some are dangerous if you breathe their fumes in a closed space. When you use anything from a container to clean your vehicle, be sure to follow the manufacturer’s warnings and instructions.

  • Page 354: Cleaning The Top Of The Instrument Panel

    Here are some cleaning tips: Always read the instructions on the cleaner label. Clean up stains as soon as you can Carefully scrape off any excess stain. Use a clean cloth or sponge, and change to a clean area often. A soft brush may be used if stains are stubborn.

  • Page 355: Cleaning Interior Plastic Components

    Cleaning Interior Plastic Components Use only a mild soap and water solution on a soft cloth or sponge. Commercial cleaners may affect the surface finish. Cleaning Wood Panels Use a clean cloth moistened in warm, soapy water (use mild dish washing soap). Dry the wood immediately with a clean cloth.

  • Page 356: Cleaning The Outside Of The Windshield And Wiper Blades

    Cleaning the Outside of the Windshield and Wiper Blades If the windshield is not clear after using the windshield washer, or if the wiper blade chatters when running, wax, sap or other material may be on the blade or windshield. Clean the outside of the windshield with GM Windshield Cleaner, Bon Ami Powder (non...

  • Page 357: Finish Care

    Don’t wash your vehicle in the direct rays of the sun. Use a car washing soap. Don’t use strong soaps or chemical detergents. Be sure to rinse the vehicle well, removing all soap residue completely. You can get approved cleaning products from your dealer. (See “Appearance Care and Materials”...

  • Page 358: Cleaning Tires

    Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from industrial chimneys, etc., can damage your vehicle’s finish if they remain on painted surfaces. Wash the vehicle as soon as possible. If necessary, use non abrasive cleaners that are marked safe for painted surfaces to remove foreign matter.

  • Page 359: Chemical Paint Spotting

    Although no defect in the paint job causes this, Cadillac will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km) of purchase, whichever occurs first.

  • Page 360: Gm Vehicle Care/Appearance Materials

    GM Vehicle Care/Appearance Materials PART NUMBER SIZE 994954 23 in. x 25 in. 1050172 16 oz. (0.473 L) 1050173 16 oz. (0.473 L) 1050174 16 oz. (0.473 L) 1050214 32 oz. (0.946 L) 1050427 23 oz. (0.680 L) 1052918** 8 oz. (0.237 L) 1052925 16 oz.

  • Page 361: Engine Identification

    Vehicle Identification Number (VIN) This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle. The VIN also appears on the Vehicle Certification and Service Parts labels and the certificates of title and registration.

  • Page 362: Electrical System

    Electrical System Add-On Electrical Equipment NOTICE: Don’t add anything electrical to your vehicle unless you check with your dealer first. Some electrical equipment can damage your vehicle and the damage wouldn’t be covered by your warranty. Some add on electrical equipment can keep other components from working as they should.

  • Page 363: Fuses And Circuit Breakers

    Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses and circuit breakers. This greatly reduces the chance of fires caused by electrical problems. Look at the silver colored band inside the fuse. If the band is broken or melted, replace the fuse.
  • Page 364 Minifuses Fuse Usage Assembly Line Diagnostic Link Accessory Windshield Wipers Not Used Headlamp Low Beam Left Fuse Usage Headlamp Low Beam Right Instrument Panel Powertrain Control Module Battery Headlamp High Beam Right Headlamp High Beam Left Ignition 1 Transmission Cruise Control Coil Module Injector Bank #2 Not Used...
  • Page 365 Micro Relays Relay Usage Headlamp High Beam Headlamp Low Beam Fog Lamps Daytime Running Lamps Horn Air Conditioner Clutch Mini Relays Relay Usage Not Used Accessory Not Used Starter 1 Cooling Fan Secondary Ignition 1 Cooling Fan Series/Parallel Cooling Fan Primary 6-66 Maxibreaker Circuit Breaker...

  • Page 366: Removing The Rear Seat Cushion

    Removing the Rear Seat Cushion NOTICE: The battery and main fuse boxes are located under the rear seat cushion. The battery’s ground terminal and some relay wires are exposed. To help avoid damage to the battery and wires, be careful when removing or reinstalling the seat cushion.
  • Page 367 CAUTION: A safety belt that isn’t properly routed through the seat cushion or is twisted won’t provide the protection needed in a crash. If the safety belt hasn’t been routed through the seat cushion at all, it won’t be there to work for the next passenger.
  • Page 368 Minifuses Fuse Usage Fuel Pump Heater, Ventilation and Air Conditioning Battery Memory Seat, Tilt and Telescoping Steering HVAC Blower Driver Door Module Heated Seat Left Rear Fuse Usage Power Tilt and Telescoping Steering Supplemental Inflation Restraint Not Used Lamps Park Right Fuel Tank Ventilation Solenoid Ignition 1 Interior Lamp Dimmer Module...
  • Page 369 Fuse Usage Rear HVAC Blower Ignition Switch Hazard Signal Reverse, Locks Continuous Variable Road Sensing Suspension Heating, Ventilation, Air Conditioning Ignition 3 Rear Antilock Braking System Heated Seat, Right Front Heated Seat, Right Rear Dimmer Micro Relays Relay Usage Fuel Pump Parking Lamps Ignition 1 Park Brake A...

  • Page 370: Capacities And Specifications

    MaxiFuses Fuse Usage Park Brake Rear Defog Right Rear Lumbar, Power Audio Amplifier ELC Compressor/Exhaust Cigar Lighter Not Used The spare fuses are located in numbers 70 through 74. The fuse puller is located in number 75. Replacement Bulbs Application Headlamps, Composite Lower High Beam .

  • Page 371: Normal Maintenance Replacement Parts

    Wheel Nut Torque 100 lb ft (140 N·m) Capacities Transaxle (4T80 ..Crankcase (Engine Oil with Filter Change) ... Engine Cooling System .

  • Page 372: Section 7 Customer Assistance Information

    Section 7 Customer Assistance Information Here you will find out how to contact Cadillac if you need assistance. This section also tells you how to obtain service publications and how to report any safety defects. Customer Satisfaction Procedure Customer Assistance for Text Telephone...

  • Page 373: Customer Satisfaction Procedure

    Cadillac Customer Assistance Center, 24 hours a day, by calling 1-800-458-8006. In Canada, contact GM of Canada Customer Communication Centre in Oshawa by calling 1-800-263-3777 (English) or 1-800-263-7854 (French).

  • Page 374: Customer Assistance For Text Telephone

    To assist customers who are deaf, hard of hearing, or speech impaired and who use Text Telephones (TTYs), Cadillac has TTY equipment available at its Customer Assistance Center. Any TTY user can communicate with Cadillac by dialing: 1 CMCC (2622).

  • Page 375: Customer Assistance Offices

    Customer Assistance Offices Cadillac encourages customers to call the toll-free number for assistance. If a U.S. customer wishes to write to Cadillac, the letter should be addressed to Cadillac’s Customer Assistance Center. United States Cadillac Customer Assistance Center Cadillac Motor Car Division P.O.

  • Page 376: Gm Mobility Program For Persons With Disabilities

    All TTY users call 1 3830. Roadside Service Cadillac’s exceptional Roadside Service is more than an auto club or towing service. It provides every Cadillac owner with the advantage of contacting a Cadillac 9935. advisor and, when appropriate, a Cadillac trained dealer 9935.
  • Page 377 1112, 24 hours a day, 365 days a year. This service is provided at no charge for any warranty covered situation and for a nominal charge if the Cadillac is no longer under warranty. Roadside Service is available only in the United States and Canada. Cadillac Owner Privileges...

  • Page 378: Roadside Service Availability

    Text Telephone (TTY) in the Roadside Service Center. Any customer who has access to a (TTY) or a conventional teletypewriter can communicate with Cadillac by dialing from the United States or Canada CMCC daily, 24 hours.

  • Page 379: Plan Ahead When Possible

    Transportation Options Warranty service can generally be completed while you wait. However, if you are unable to wait Cadillac helps minimize your inconvenience by providing several transportation options. Depending on the circumstances,...

  • Page 380: Additional Program Information

    Courtesy Rental Vehicle When your vehicle is unavailable due to warranty repairs, your dealer may arrange to provide you with a courtesy rental vehicle or reimburse you for a rental vehicle you obtained, at actual cost, up to a maximum of $35.00 per day supported by receipts.

  • Page 381: Warranty Information

    General Motors reserves the right to unilaterally modify, change or discontinue Courtesy Transportation at any time and to resolve all questions of claim eligibility pursuant to the terms and conditions described herein at its sole discretion. Warranty Information Your vehicle comes with a separate warranty booklet that contains detailed warranty information.

  • Page 382: Reporting Safety Defects To The Canadian Government

    In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at 1 8006, or write: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 436004 Pontiac, MI 48343...
  • Page 383 2000 CADILLAC SERVICE PUBLICATIONS ORDERING INFORMATION The following publications covering the operation and servicing of your vehicle can be purchased by filling out the Service Publication Order Form in this book and mailing it in with your check, money order, or credit card information to Helm, Incorporated (address below.)
  • Page 384 ORDER TOLL FREE (NOTE: For Credit Card Holders Only) 1-800-551-4123 (Monday-Friday 8:00 AM – 6:00 PM EST) FAX Orders Only 1-313-865-5927 PUBLICATION FORM PUBLICATION FORM NUMBER NUMBER Service Manual Car & Light Truck Transmission Unit Repair Owner’s Manual NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent.
  • Page 385 NOTES 7-14...

This manual is also suitable for:

Deville

Table of Contents
