ANI series
WaveDynamics™ Dante audio network interface
Installation Guide
The ANIxx are Dante audio network interfaces , supporting
channels. The installation of this optional interfaces allows these amplifiers to be integrated into
any DANTE enabled AV network and flawlessly transfer digital audio with any compatible product
on the market, ranging from music sources to microphone systems, mixers, and many more.
These interfaces come delivered as a complete installation kit, including all required accessories for
installation into the supporting devices.
The installation of the ANI module may only be performed by
qualified technicians.
Incorrect installation can lead to permanent damage or incorrect
functioning of the equipment.
Packaging contents
- 1x ANIxx main interface board
- 1x ANIxx ethernet connection board
- 1x ANIxx ethernet connection cable (24 cm) - VEXO
- 1x ANIxx ethernet connection cable (66 cm) - SMA/SMQ/PMQ
- 1x ANIxx Keystone ethernet connection cable
Included installation accessories:
- 2x Nylon snap-in spacer
- 1x M3 spacer
- 1x Spring washer
- 1x M3 nut
- 2x Cable tie
Table of contents
Installation guide MFA
Installation guide SMA/SMQ/PMQ
Installation guide VEXO
four (ANI44XT) networked audio
2
5
10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AUDAC WaveDynamics ANI Series
Summary of Contents for AUDAC WaveDynamics ANI Series
- Page 1 ANI series WaveDynamics™ Dante audio network interface Installation Guide The ANIxx are Dante audio network interfaces , supporting four (ANI44XT) networked audio channels. The installation of this optional interfaces allows these amplifiers to be integrated into any DANTE enabled AV network and flawlessly transfer digital audio with any compatible product on the market, ranging from music sources to microphone systems, mixers, and many more.
- Page 2 ANI series Installation Guide MFA Step 1: ATTENTION Step 2: chassis cover Make sure the amplifier is powered off Open the amplifier housing by carefully and the power inlet is disconnected removing the screws from the side panels from the mains power before the of the unit.
- Page 3 Step 4: Spacer Step 5: Keystone cover Insert the M3 spacer and both nylon snap- Remove the keystone cover at the back of in spacers into the appropriate holes in the the device by pressing the top lip down with circuit board as indicated in the image above.
- Page 4 Step 8: Cable management Step 9: Up to date Use the included cable tie’s to lock the To guarantee the correct functioning of network cable into place to avoid it moving the amplifier with the installed ANI Dante and touching the heatsinks. network audio interface, Verify that current MFA software is version 1.2.6 or higher.
- Page 5 ANI44XT Installation Guide SMA/SMQ/PMQ Step 1: ATTENTION Step 2 Make sure the amplifier is powered off Open the amplifiers’ enclosure by carefully and the power inlet is disconnected removing the screws from the top panel of from the mains power before the the device, and lifting it.
- Page 6 Step 3.2 Remove the cover plate at the ‘EXPANSION’ hole on the back of the amplifier. The ethernet connection board of the ANI shall be installed on this position. Step 3.3 Insert the ethernet connection board from the inner side of the amplifier to the ‘EXPANSION’ hole, and fix it by inserting and tightening the two supplied screws.
- Page 7 Step 4 Once the Ethernet connection PCB is correctly installed, the supplied ethernet connection cable shall be plugged to the RJ45 connection socket in the inner side of the ethernet connection board. The network cable has a length of 66cm. Step 5 Mount the ANI main interface board into the amplifier:...
- Page 8 Step 5.3 Connect the cable from the ethernet connection board to the RJ45 jack on the main interface board and position the cable as indicated in the below image. Correct positioning of the cable is important to avoid touching heating amplifier parts and to avoid obstruction of the internal air-flow of the device. The networking cable shall be fixed to the internal provided tabs using the supplied cable tie’s.
- Page 9 Step 7: Double check whether all internal wires are well connected and well positioned. After all connections are successfully made, the top cover of the amplifier can be re-fitted and fixed using the original screws. Step 8: To guarantee the correct functioning of the amplifier with the installed ANI Dante network audio interface, verify whether the current running software version fully supports this interfaces functions.
-
Page 10: Handle With Care
ANI44XT Installation Guide VEXO Step 2: Step 1: ATTENTION Open the speakers’ enclosure by carefully Make sure the speaker is powered off removing the screws from the back panel of and the power inlet is disconnected the device. Once removed, the back cover from the mains power before the can be removed. - Page 11 Step 4: Step 5.1: Remove the blind plate cover at the back Remove the latch from the Ethercon of the device by unscrewing the two screws. compatible connector on the connection board by putting a flat screwdriver underneath the clip and pulling back screwdriver and latch together.
- Page 12 Step 7: Step 8: Insert the M3 spacer and both nylon snap-in Fix the ANI into the amplifier by simply clicking spacers into the appropriate holes in the it in place using the snap-in spacers. It is circuit board as indicated in the image above. important that the main board is supported when the ANI is attached.
-
Page 13: Additional Information
Additional information Technical specifications Number of inputs ANI44XT Number of output ANI44XT Communication Protocol Audinate DANTE Network layer 3 IP protocol Sampling frequency 48 kHz Sampling bit depth 24-bit Latency 2 ~ 5 ms Connection Ethercon compatible RJ45 connector Network specification Standard 100 Mbit / 1 Gbit network Mounting Integration in amplifier/ speaker chassis... -
Page 14: Waste Electrical And Electronic Equipment (Weee)
CAUTION - SERVICING: CAUTION: ALWAYS KEEP THESE INSTRUCTIONS. NEVER This product contains no user serviceable parts. THROW THEM AWAY Refer all servicing to qualified service personnel. Do not perform any servicing ALWAYS HANDLE THIS UNIT WITH CARE (unless you are qualified to) HEED ALL WARNINGS EC DECLARATION OF CONFORMITY FOLLOW ALL INSTRUCTIONS... - Page 15 Notes...
