3-2. LED Indicators and LCD Panel
LED Indicators:
There are 4 LEDs on the front panel to show the UPS working status:
Mode LED
UPS Startup
Bypass mode
AC mode
Battery mode
CVCF mode
Battery Test
Fault
Note: ● means LED is ON, and ○ means LED is OFF.
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
14
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 11 17 AA 59 204 18

LCD panel

Bypass
●
●
○
○
○
●
○
Line Battery
●
○
●
○
●
●
○
LED
indicators
Fault
● ●
○ ○
○ ○
● ○
○ ○
● ○
○ ●
