USER'S INFORMATION
MANUAL
SINGLE PACKAGE
HEAT PUMP/GAS HEAT
MODELS: PHG4
CONTACT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Thermostats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Spark Ignition Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Circulating Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
For Your Safety, Read Before Operating . . . . . . . . . . . . 3
What To Do If You Smell Gas . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Start-Up Instructions - Heating System . . . . . . . . . . . . . . 3
SHUT-DOWN INSTRUCTION - TO TURN
OFF GAS TO APPLIANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Normal Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CONTACT INFORMATION
• Go to website at www.york.com, then click on "Contact Us" and
follow the instructions.
• Contact us by mail:
We recommend that the user read all sections of this
manual and keep the manual for future reference.
WARNING
!
FIRE OR EXPLOSION HAZARD - Failure to follow safety warnings
exactly could result in serious injury, death, or property damage.
— Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone (includ-
ing cell phone) in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Fol-
low the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to
alert against unsafe practices and hazards involving only property dam-
age.
Johnson Controls Unitary Products
TABLE OF CONTENTS
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
General Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Filter Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Outdoor Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
To Clean Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Flue Discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Cleaning Flue Passages And Heating Elements . . . . .4
Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Before Calling A Service Person: . . . . . . . . . . . . . . . . . .4
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
SOME EFFICIENCY DO'S AND DON'TS . . . . . . . . . . . . . . . . . . . .4
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1. Make sure that the furnace area is clear and free of combustible
materials, gasoline and other flammable vapors and liquids.
2. For proper operation of this furnace, air for combustion and ventila-
tion is required. Make sure that these openings are not obstructed.
3. For lighting or shutting down this furnace, refer to the lighting
instructions provided adjacent to the burners and also located in
this manual.
4. A roll-out switch is provided in the burner compartment. This switch
is a manual reset. If the furnace fails to operate, contact a qualified
service agency.
5. Should the gas supply fail to shut off or if overheating occurs, shut
off the gas valve to the furnace before shutting off the electrical sup-
ply. Then call a qualified service technician.
6. Do not use this furnace if any part has been under water. A flood-
damaged furnace is extremely dangerous. Attempts to use the fur-
nace can result in fire or explosion. A qualified service agency
should be contacted to inspect the furnace and to replace all gas
controls, control system parts, electrical parts that have been wet or
the furnace if deemed necessary.
7. Prior to each heating season inspect the flue gas vent and the
return and supply air duct and ensure that the equipment is well
supported and there are no signs of deterioration. The manufac-
turer recommends that main burner, ignition device and controls are
inspected by a qualified furnace technician before each heating
season.
This heating/cooling unit is designed for outdoor use and can be
installed anywhere from grade level to the roof. Electric air conditioning
in the summer electric heat pump heating, and gas heating in the winter
- all from a single unit.
8. Do not allow snow to accumulate near the furnace where it could
block the flue gas vent or the combustion air intake.
® ®
Johnson Controls Unitary Products
Consumer Relations
5005 York Drive
Norman, OK 73069
5132211-UUM-A-0815
