Marine Carbon Monoxide Alarm
CMD6-MB (Marine, Battery)
CMD6-MB-B (Marine, Battery, Black Housing)
CMD6-MBR (Marine, Battery, Interconnect, Relay)
CMD6-MBR-B (Marine, Battery, Interconnect, Relay, Black Housing)
CMD6-MD (Marine, 12/24V DC)
CMD6-MD-B (Marine, 12/24V DC, Black Housing)
CMD6-MDR (Marine, 12/24V DC, Interconnect, Relay)
CMD6-MDR-B (Marine, 12/24V DC, Interconnect, Relay, Black Housing)
Owner's Manual
&
Installation Instructions
th
Tested by ETL to UL STD 2034 Marine, 4
Edition
Read and comply with all instructions, warnings and limitations before
installing, servicing or removing this device.
1
Part Number 18160, F, 06/29/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMD6-MB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fireboy- Xintex CMD6-MB

Summary of Contents for Fireboy- Xintex CMD6-MB

  • Page 1 Marine Carbon Monoxide Alarm CMD6-MB (Marine, Battery) CMD6-MB-B (Marine, Battery, Black Housing) CMD6-MBR (Marine, Battery, Interconnect, Relay) CMD6-MBR-B (Marine, Battery, Interconnect, Relay, Black Housing) CMD6-MD (Marine, 12/24V DC) CMD6-MD-B (Marine, 12/24V DC, Black Housing) CMD6-MDR (Marine, 12/24V DC, Interconnect, Relay) CMD6-MDR-B (Marine, 12/24V DC, Interconnect, Relay, Black Housing) Owner’s Manual...

  • Page 2: Table Of Contents

    Additional copies of this manual are available at no charge by contacting the manufacturer, distributor or dealer. Fireboy-Xintex reserves the right to change features without notice. General Information Specifications Operation of Fireboy-Xintex Carbon Monoxide Alarm(s) Locating a Fireboy-Xintex Carbon Monoxide Alarm Installation Installing the Mounting Base Connecting Alarm to Mounting Base...

  • Page 3: General Information

    General Information DANGER: ACTUATION OF THIS DEVICE INDICATES THE PRESENCE OF CARBON MONOXIDE (CO) WHICH CAN BE FATAL. THE SOURCE OF THE CO MAY BE AN APPLIANCE SUCH AS A FURNACE, A WOOD BURNING STOVE, A VEHICLE, A GENERATOR, OR OTHER COMBUSTION SOURCE. EVACUATE THE PREMISES IMMEDIATELY.
  • Page 4 General Information Continued CAUTION: THERE ARE NO USER OR FIELD SERVICEABLE PARTS IN THIS PRODUCT. THE CO ALARM MUST BE RETURNED TO THE MANUFACTURER FOR ANY REPAIR OR PERFORMANCE CHECKS. THIS PRODUCT IS NOT INTENDED FOR USE IN ORDINARY OUTDOOR LOCATIONS OF FAMILY LIVING UNITS.
  • Page 5 Information on conditions which can result in transient CO situations, such as: • Excessive spillage or reverse venting of fuel burning appliances caused by outdoor ambient conditions, such as: ▪ Wind direction and/or velocity, including high gusts of wind. Heavy air in the vent pipes (cold/humid air with extended periods between cycles).
  • Page 6 General Information Continued Where Must We Guard Against Carbon Monoxide? Carbon monoxide is a by-product of combustion. CO exists wherever fuels are burned to generate power or heat. Boats may utilize propane or compressed gas for cooking and/or heating. Boats have the added hazard of an auxiliary power generator where exhaust fumes may drift into the vessel.
  • Page 7 Limitations • This carbon monoxide alarm is designed to detect carbon monoxide gas from ANY source of combustion. It is NOT designed to detect smoke, fire or any other gas. • The CO Alarm will not detect carbon monoxide that is not in the vicinity of the alarm. Carbon monoxide in other rooms or areas will not be detected.

  • Page 8: Specifications

    Specifications System Specifications (CMD6-MB & CMD6-MB-B) Operating/Storage Temperature: -40°F (-40°C) to 158°F (70°C) Alarm Points: Time Weighted Average (TWA) Alarm Horn: ≈ 85dB @3.05M Dimensions: 3.5” (89mm) x 3.5” (89mm) x 1.25” (32mm) Housing Material: Polylac PA-765(ABS-FR) System Specifications (CMD6-MBR & CMD6-MBR-B) Operating/Storage Temperature: -40°F (-40°C) to 158°F (70°C)

  • Page 9: Operation Of Fireboy-Xintex Carbon Monoxide Alarm(S)

    Operation of Fireboy-Xintex Carbon Monoxide Alarm(s) Horn Power Indicator Alarm Indicator Test/Mute Button Should a very high level of carbon monoxide exist, the CO Alarm will alarm in a few minutes. However, if small quantities of CO are present or high levels are short-lived, the micro controller will accumulate the information and determine when an alarm level has been reached.
  • Page 10 Operation of Fireboy-Xintex Carbon Monoxide Alarm(s) Continued CAUTION: THE AUDIBLE ALARM CANNOT BE CHECKED BY THE INTERNAL CIRCUITRY AND THEREFORE THE CO ALARM SHOULD BE TESTED FREQUENTLY USING THE TEST BUTTON AND VERIFYING PROPER ALARM SEQUENCES AND OPERATION. Normal The Green LED will flash once every 180 seconds (3 minutes) while in normal operation. Alarm When the CO Alarm enters alarm, the Alarm indicator begins flashing red and the horn beeps 4 times and pauses for 4-5 seconds in a repeat pattern.

  • Page 11: Locating A Fireboy-Xintex Carbon Monoxide Alarm

    Locating a Fireboy-Xintex Carbon Monoxide Alarm Because of the high risk of carbon monoxide injuries due to the nature of boats, it is recommended a carbon monoxide alarm be installed in the main cabin and in each sleeping area (ABYC A-24.7.2) of the enclosed accommodation compartment (ABYC A-24-4-5). Small craft with an open design may only require one CO Alarm for adequate protection.

  • Page 12: Installation

    Installation Installing the Mounting Base • Mounting Base should be installed vertically when installing CO Alarm on a wall. • Use appropriate length #6, Pan Head screws to secure Mounting Base. • Do not over-tighten. • Drill appropriate size hole (0.38” (9.5mm) Max) for wired models to accommodate the wires.

  • Page 13: Connecting Alarm To Mounting Base

    Installation Continued Connecting Alarm to Mounting Base • Align Mounting holes of CO Alarm with the posts on the Mounting Base. Mounting Hole Post • Feed wires through the Mounting Base and mounting surface. • Press CO Alarm against mounting surface and turn clockwise, approximately 25°. NOTE: A UNIT THAT HAS BEEN DEACTIVATED WILL NOT BE ABLE TO BE INSTALLED ONTO THE MOUNTING PLATE.

  • Page 14: Wiring Connections (Marine 12/24V Dc Units)

    Wiring Connections (Marine 12/24V DC Units) Units: CMD6-MD, CMD6-MDR, CMD6-MD-B, & CMD6-MDR-B Red and Black 18 GA wires are provided for connecting to the power source. Connect the Red wire to Power (+). Connect the Black wire to Ground (-). Units: CMD6-MDR &...

  • Page 15: Wiring Connections (Marine Battery Units)

    Wiring Connections (Marine Battery Units) Units: CMD6-MBR & CMD6-MBR-B Black and Yellow 18 GA wire is provided for connecting Interconnect-Relay Series units. Connect the wires of up to 10 units to each other. Two White 18 GA wires are provided for connecting to equipment on the vessel.

  • Page 16: Activating Fireboy-Xintex Carbon Monoxide Alarm (Battery Only Models)

    Activating Fireboy-Xintex Carbon Monoxide Alarm Hold “Test/Mute” button for 10 seconds. The Green LED will turn on. Press the “Test/Mute” button 5 times. The Green and Red LEDs will flash, and the horn will sound. The CO Alarm is now activated. The Green LED will flash once every 180 seconds. Testing Test the CO Alarms no less than once per week.

  • Page 17: In The Event Of An Alarm

    In the Event of an Alarm Operate reset/silence button Call your emergency services (fire department or 911). Immediately move to fresh air – outdoors or by an open door/window. Check that all persons are present. Do not re-enter the premises or move away from the open door/window until emergency services responders have arrived, the premises have been aired out and alarm remains in its normal condition.

  • Page 18: Repairing Fireboy-Xintex Carbon Monoxide Alarms

    Repairing Fireboy-Xintex Carbon Monoxide Alarms Fireboy-Xintex Carbon Monoxide Alarms are not field serviceable. Components must be returned to the factory for any repairs. Returning Fireboy-Xintex Carbon Monoxide Alarms No product may be returned for credit or repair without a written “Returned Material Authorization”...

  • Page 19: Year Limited Warranty

    1 Year Limited Warranty This Warranty is in lieu of all other expressed or implied Warranties Seller warrants title, materials, and workmanship on equipment, except components manufactured by others for which the Seller assigns, as permitted, the original manufacturer’s warranty. Seller’s warranty shall be for a period of (1) one year from the date of sale to the ORIGINAL CONSUMER PURCHASER, during which non-conforming equipment returned to the Seller at Buyer’s expense and risk, be repaired or replaced at the Seller’s option.
