Deluxe Discharge Alarm
DU-RBH-01 (Round, Black, Horn)
DU-RCH-01 (Round, Chrome, Horn)
Owner's Manual
&
Installation Instructions
Read and comply with all instructions, warnings and limitations before
installing, servicing or removing this device.
1
Part Number 18146, D, 08/01/2018
Advertisement
Table of Contents
Related Manuals for Fireboy- Xintex DU-RBH-01
Summary of Contents for Fireboy- Xintex DU-RBH-01
- Page 1 Deluxe Discharge Alarm DU-RBH-01 (Round, Black, Horn) DU-RCH-01 (Round, Chrome, Horn) Owner’s Manual & Installation Instructions Read and comply with all instructions, warnings and limitations before installing, servicing or removing this device. Part Number 18146, D, 08/01/2018...
- Page 2 Fireboy-Xintex reserves the right to change features without notice. General Information Specifications Operation of Fireboy Deluxe Discharge Alarm(s) Installation Installing the Display Unit (DU-RBH-01/DU-RCH-01) Electrical Connections (DU-RBH-01/DU-RCH-01) Testing the DU-RBH-01/DU-RCH-01 Maintenance In the Event of an Alarm...
- Page 3 General Information The DU-RBH-01 and DU-RCH-01 Deluxe Discharge Alarms are an effective means to monitor the status of your Fireboy Pre-engineered Fire Suppression system. The Deluxe Discharge Alarms have both visual and audible indication of the Fire Suppression system’s status.
- Page 4 Part Number 18146, D, 08/01/2018...
- Page 5 Switch located on the Fire Extinguisher. The second terminal of the Pressure Switch is connected to Ground. Testing the DU-RBH-01/DU-RCH-01 The DU-RBH-01/DU-RCH-01 can be tested by disconnecting either wire connection at the Pressure Switch. When the wire is disconnected, the LED will turn off and the alarm horn will sound. Maintenance...
- Page 6 In the Event of an Alarm Immediately shutdown all engines, powered ventilation, and electrical systems. Extinguish all smoking materials. DO NOT open the engine compartment. Before inspecting for damage, allow the agent to “soak” the compartment for at least 15 minutes and wait for hot metals or fuels to cool. Have approved portable extinguishers in hand and ready for use.
- Page 7 1 Year Limited Warranty This Warranty is in lieu of all other expressed or implied Warranties Seller warrants title, materials, and workmanship on equipment, except components manufactured by others for which the Seller assigns, as permitted, the original manufacturer’s warranty. Seller’s warranty shall be for a period of (1) one year from the date of sale to the ORIGINAL CONSUMER PURCHASER, during which non-conforming equipment returned to the Seller at Buyer’s expense and risk, be repaired or replaced at the Seller’s option.
