- Page 1 Syncro Matrix Fire Alarm Mimic Display Operation and Maintenance Manual Man-1121 Issue 05 June 2013 www.acornfiresecurity.com...
-
Page 2: Table Of Contents
6. Connections ....................6 7. Addressing ....................7 8. Power requirements ..................8 9. Configuration ....................9 10. Changing or adding LED positions ..............14 11. Maintenance and testing ................15 Man-1121 Syncro Matrix Mimic 05 Page 2 of 15 www.acornfiresecurity.com... -
Page 3: Introduction
Mimic panels require Loop Explorer version 4.9 or above for configuration. The modular nature of Syncro Matrix Mimic panels, allows mimics with up to 500 indicators to be realised very simply and with the ability to add, remove or change the position of indicators with no wiring necessary by a unique method of flexible light pipes. -
Page 4: Mounting
COMMON FA ULT LED.1 MA INS FAIL LED.2 BATT DIS C . LED.3 BATT LOW LED.4 EARTH FLT. LED.5 CHGR. FLT. L1 L2 L4 L3 (Unit shown here is mains powered type) Man-1121 Syncro Matrix Mimic 05 Page 4 of 15 www.acornfiresecurity.com... -
Page 5: Specifications
4. Specifications The information in the table below is for the standard range of Syncro Matrix Mimics with up to 56 LEDs in the standard 385mm X 520mm enclosure. Some details are common to all models of Syncro Matrix Mimics. -
Page 6: Connections
Syncro fire alarm control panel. Syncro Matrix mimic panels with a built in power supply require a 230V mains supply and a two wire data connection to the Syncro fire alarm control panel. The mains and data cables should be segregated by a distance of at least 50mm. -
Page 7: Addressing
7. Addressing Each of the LED driver boards in the Syncro Matrix Mimic must be allocated a unique address number between 1 and 32. These addresses must be different to any other boards or Syncro View repeater panels connected to the Syncro panel RS485 transmission line. -
Page 8: Power Requirements
SWITCH POSITIONS 8. Power requirements Versions of the Syncro Matrix Mimic without a power supply and battery back up facility, need 24V DC power from a suitable, EN54-4 approved battery backed power source. This must be sufficiently rated to provide power for the maximum number of LEDs and with batteries of a suitable size to provide power for the standby period required. -
Page 9: Configuration
“Ground floor” etc and the way in which the LEDs behave can also be selected to suit the application. Four different modes of operation can be chosen here. Man-1121 Syncro Matrix Mimic 05 Page 9 of 15 www.acornfiresecurity.com... - Page 10 To add a 16 way mimic board, highlight the control panel left hand column before double click on the “Mimic Zone” icon bottom. Man-1121 Syncro Matrix Mimic 05 Page 10 of 15 www.acornfiresecurity.com...
- Page 11 The example now shows the configuration file mimic with one 8 way board and one 16 way board so this mimic is capable of having up to 24 LEDs. Man-1121 Syncro Matrix Mimic 05 Page 11 of 15 www.acornfiresecurity.com...
- Page 12 When further 16 way mimic boards are added, these will also be allocated to zones 9 to 24 and will need to be configured to the correct zones. The simplest way to do this is to use Zone Manager in the Loop Explorer programme. Man-1121 Syncro Matrix Mimic 05 Page 12 of 15 www.acornfiresecurity.com...
- Page 13 Alternatively, the channels (LED outputs) of the mimic boards can be configured independently. To edit a channel of a mimic board, double click the board to be edited to expand the tree and reveal the individual channels. Man-1121 Syncro Matrix Mimic 05 Page 13 of 15 www.acornfiresecurity.com...
-
Page 14: Changing Or Adding Led Positions
OUTPUT PROPERTIES MUST BE UNTICKED. 10. Changing or adding LED positions The construction of Syncro Matrix Mimic panels is such that it is simple to add, remove or change the position of LED indicators without the need for special tools or wiring. -
Page 15: Maintenance And Testing
K6019 ISS 01 Fitting additional indicators Parts required for adding or changing LED positions on Syncro Matrix Mimic panels: Acrylic Drawing with or without controls. S707 – Additional 16 way LED board (RED) S715 – Additional 16 way LED board (YELLOW) S716 –...
