Summary of Contents for IDEAL Hercules H14
- Page 1 Operating Instructions Air Purifier IDEAL Hercules H14 www.idealhealthstore.com...
- Page 2 EN Intended Use / Safety Instructions FR Utilisation conforme / Consignes de sécurité DE Vorwort Vielen Dank, dass Sie sich für ein Gerät aus dem Hause IDEAL entschieden haben. EN Introduction Thank you for choosing a device from IDEAL. FR Préface Nous vous remercions d'avoir opté...
- Page 3 DE Sicherheitshinweise EN Safety Instructions FR Consignes de sécurité EN Safety instructions • Keep packing material, such as plastic wrapping, away from children! (Risk of suffocation) • Please follow the safety instructions to prevent fire or electric shock. Only use the device indoors. •...
-
Page 4: Safety Instructions
Safety Instructions Caution Risk of injury due to electric shock. Always disconnect the mains plug prior to: • Carrying out maintenance work or cleaning • Moving the device • Changing the filter Danger Do not use any spray cans with flammable content near to the Air Purifier! Danger Do not use any flammable cleaning agents. -
Page 5: Product Features
Heavy-duty HEPA H1 particle filter subject to individual test and with certificate. Scope of delivery Air purifier (incl. filter) HEPA H14 particle filter Pre-filter Luftreiniger Betriebsanleitung Air Purifier Operating Instructions Purificateur Mode d´emploi IDEAL Hercules H14 www.ideal.de EN Power cable EN Printed operating instructions... -
Page 6: Unpacking And Setting Up
Unpacking and Setting up Installation guidelines for optimum performance: • Place the device at least 10 cm away from the wall. • Make sure that furniture, fabrics or other objects do not come into contact with the air intake/outlet or block them. •... - Page 7 Startup Open the door at the clamping latch Take out the pre-filter and remove protective film. Refit the pre-filter Take out the HEPA H14 particle filter and remove protective film. Refit the HEPA H14 particle filter. Note direction of flow-through (see sticker on particle filter). Close the door at the clamping latch...
- Page 8 Startup Pressing the button releases the hinged grip. When locking/unlocking the hinged grip, keep hold of it until it has clicked into place. Mobile deployment...
- Page 9 Startup Flexible operation. The air purifier can be operated without difficulty in both the upright and horizontal positions. Connect the power cable to the device first, then to the socket.
-
Page 10: Operation
Operation 1. Press On/Off switch (I). The switch lights up (green), machine is operational. Raise fan speed 2. Fan speeds selector (selection of 5 speeds). Memory function (the last selected fan speed is saved after switching off and back on again). Reduce fan speed... -
Page 11: Filter Change
EN Pre-filter and HEPA H14 particle filter change. (e.g. following a slowly flashing control light). Note: Use only original IDEAL pre-filters and IDEAL-HEPA H14 particle filters (order in www.ideal.de), see Page 15. No tools are needed to replace the pre-filters and HEPA H14 particle filters. - Page 12 Filter Change Remove the pre-filter. Fit new pre-filter (remove protective film beforehand). Remove the HEPA H14 particle filter. Fit new HEPA H14 particle filter (remove protective film beforehand). Note direction of flow-through, see arrow direction (sticker on the particle filter).
- Page 13 Filter Change Close the door at the clamping latch. Connect the power cable to the device first, then to the socket. Reset filter replacement indicator: Press the fan speeds selector for approx. 3 seconds until the filter replacement indicator goes out.
-
Page 14: Cleaning And Maintenance / Accessories
• Do not use any solvents. These could damage the surface of thedevice. • Protect the air purifier from water. Accessories EN You can acquire accessories through your dealer or at www.idealhealthstore.co. Set of IDEAL pre-filter + HEPA H14 particle filter FR Set of 5 IDEAL pre-filters... -
Page 15: Troubleshooting
Troubleshooting The air purifier won’t switch on. Is the power cable securely connected to the back of the device? Make sure that the power cable is not damaged in any way. Check both ends of the power cable. Make sure that these are plugged in and that the purifier is connected to the power supply (Page 10). -
Page 16: Technical Data
Technical Data IDEAL Hercules H14: Power supply 220-240V 50/60Hz / 100-120V 50/60Hz Power consumption 170W (220-240V) / 145W (100-120V) Air flow rate (max.) 810 m Dimensions (H × W × D) 625 × 522 × 399 mm Weight approx. -
Page 17: Terms Of Warranty
IDEAL provides a warranty for this device from the date of purchase. The terms of warranty are defined by our local representative. • If a material or design defect occurs during the warranty period, IDEAL shall repair or replace the device, or repay the purchase price, at its discretion. - Page 18 EN The company Krug + Priester has the following certifications: • Quality management system according to DIN EN ISO 9001:2015 • Environmental management system according to DIN EN ISO 14001:2015 • Energy management system according to DIN EN ISO 50001:2018...
- Page 19 Subject to technical changes. EC-declaration of conformity - Herewith we declare that 220-240V 100-120V IDENT. Nr. IDENT. Nr. IDEAL Hercules H14 Made in Germany 11732002 10732002 - complies with the following provisons applying to it 2014/35/EU Low voltage directive 2011/65/EU, 2015/863/EU...
