  • Page 1 JPD-100S Fetal Doppler INSTRUCTION MANUAL Manual Version: 1.1 Issuing Date: 2020.11...
  • Page 2 Shenzhen Jumper Medical Equipment Co., Ltd reserves the right of final interpretation of this manual. "JUMPER" and "ANGELSOUNDS" are the registered trademarks of Shenzhen Jumper Medical Equipment Co., Ltd. Please read the User Manual carefully to make sure safe and proper use of this Fetal Doppler，Please read and fully understand the...

  • Page 3: Table Of Contents

    Table of Contents SECTION 1: INTRODUCTION..................2 1.1 OVERVIEW............................. 2 1.2 PRODUCT DESCRIPTION......................2 1.3 OPERATING PRINCIPLE......................2 SECTION 2: SAFETY GUIDANCE...................3 2.1 INDICATIONS FOR USE......................3 2.2 CONTRAINDICATIONS FOR USE....................3 2.3 NOTE FOR HOME USE........................ 3 2.4 SAFETY TERMS AND CONDITIONS..................3 2.5 SAFETY ALERT DESCRIPTIONS....................4 2.6 SYMBOL DESCRIPTIONS......................

  • Page 4: Section 1: Introduction

    Intended use The Fetal Doppler JPD-100S is a hand-held, battery powered audio Doppler device used for detecting fetal heartbeats. 1.2 PRODUCT DESCRIPTION The product is a lightweight, portable detector.

  • Page 5: Section 2: Safety Guidance

    wave reaches the fetal heart. Then it is converted into voltage. This Doppler signal is detected and demodulated from the received signal. And the Doppler frequency is consistent with the rhythm of the fetal systole and diastole. Once cardiac valves vibrate and a Doppler frequency excursion is formed.

  • Page 6: Safety Alert Descriptions

    DANGER: This alert identifies hazards that will cause serious personal injury or death. WARNING: This alert identifies hazards that may cause serious personal injury or death. CAUTION: This alert identifies hazards that may cause minor personal injury, product damage, or property damage. 2.5 SAFETY ALERT DESCRIPTIONS The following is a list of product safety alerts that appear in this section and throughout this manual.

  • Page 7: Symbol Descriptions

    WARNING: Adjacent and/or Stacked Equipment The Product should not be used adjacent to or stacked with other equipment. If adjacent or stacked use is necessary, the Product should be observed to verify normal operation in the configuration in which it will be used. CAUTION: Systems Statement Equipment connected to the product must be certified according to the respective IEC Standards (i.e.
  • Page 8 Consult instructions for use of the product and/or its accessories. Warning Information Authorized Representative in the European Community CE Mark: The Product system conforms to 0482 essential requirements of the Medical Device Directive 93/42/EEC. Date of manufacture. Manufacturer Storage Temperature Humidity Atmospheric Pressure Upward...

  • Page 9: Section 3: Using The Product

    Type B applied part IPX4 Ingress Protection. SECTION 3: USING THE PRODUCT This section provides the description for operation. 3.1 UNPACKING AND INSPECTING Every attempt is made to ensure your accurate and complete order. However, to be sure that your correct order, verifying the contents of the box against your packing slip.

  • Page 10: Setting Up The Product

    3.2 SETTING UP THE PRODUCT Controls and indicators Power On/Off/Volume Knob Working Indicator Light Headset Socket(two) Transducer Battery Compartment Cover 3.3 BUILD IN BATTERY 1. Open the battery cover. The rear panel is upturned. First, open the cover (5) of battery compartment. 2.

  • Page 11: Operate Knob And Indicator Light

    3.4 OPERATE KNOB AND INDICATOR LIGHT There has an 'Power on/off/volume knob (1)', it's easy to operate. And working indicator light (2) shows working condition. 3.4.1 POWER ON When the product is not in use, turn the 'Power on/off/volume knob (1)' to right for switching on the product.

  • Page 12: Using Product To Detect

    3.6 USING PRODUCT TO DETECT Locate the position of the fetus by hand touching, firstly to find out the best direction to the fetal heart. Place the faceplate of probe at the best position for detecting fetal heartbeats. Adjust the transducer to obtain an optimum audio signal ideally by angling the transducer around.

  • Page 13: Recommended Maintenance And Care

    The user must check that the equipment does not have visible evidence of damage which may affect patient’s safety or product’s capability before use .The recommended inspection interval is once per month or less. If damage is evident, replacement is recommended before use. 4.1.2 To ensure the product is always functional when required, the following maintenance shall be performed.

  • Page 14: Cleaning Product And Accessories

    Damage or cracks Contact Our Customer Service Examine Foreign substances Clean the cables as accessory described in the cables Section 5 Broken parts, cracks, Replace cable if any damage, or extreme wear, abnormalities are broken or bent connectors found. and pins, after bending and flexing the cable Examine Expired product or Product...

  • Page 15: Disinfections

    4.5.2 Before cleaning, remove all adherent soil (tissue, fluids, etc.) and wipe thoroughly with a cloth dampened with water before applying the cleaning solution. 4.5.3 When cleaning, do not immerse. Keep the exterior surface of the device clean and free from dust and dirt, clean exterior surface of the unit with a dry, soft cloth .if necessary, clean it with a soft cloth soaked in a solution of soap and wipe dry with a clean cloth immediately.

  • Page 16: Recycling The Batteries

    4.7 RECYCLING THE BATTERIES The batteries are recyclable. Remove the old battery from the Product and follow your local recycling guidelines or Refer to local regulations. WARNING: Irregular treatment of batteries may be result in hazards to health and environment. 4.8 AUTHORIZED REPAIR SERVICE The Product has no user-serviceable internal components.

  • Page 17: Section 5: Specifications And Safety

    SECTION 5: SPECIFICATIONS AND SAFETY This section presents the specifications and safety standards of the Product. 5.1 SPECIFICATIONS NOTE: The following specifications are subject to change and are only noted as a point of reference. ULTRASOUND Ultrasonic emitting frequency: 3MHz Overall sensitivity at the distances 200mm from the face of the transducer ≥90dB...

  • Page 18: Environmental Requirements

    W –4.1 in, D –4.7in, H –2.4 in, Wt: 31lbs (including battery) 5.4 ENVIRONMENTAL REQUIREMENTS OPERATING CONDITIONS Temperature: 5C to 40C Humidity: <80% RH, non-condensing Atmospheric pressure: 86kPa to 106kPa STORAGE AND SHIPPING CONDITIONS Temperature: - 20C to 55C Humidity: 10% - 93% RH, non-condensing Atmospheric pressure: 50kPa to 106kPa SECTION 6: ACCESSORIES 6.1 OVERVIEW...

  • Page 19: Appendix A: Emc Information-Guidance And Manufacture'sdeclaration

    the problems can be corrected before seeking help from your dealer or service representative. Symptom Cause Remedy  Audio volume too  Turn down the high volume  Too much gel on  Use less gel Audio scream the probe surface ...
  • Page 20 The Fetal Doppler is intended for use in the electromagnetic environment specified below. The customer or the user of the Fetal heart monitor should assure that it is used in such an environment. Emissions test Compliance The Fetal Doppler uses RF energy only for Group 1 emissions its internal function.
  • Page 21 specified below. The customer or the user of the Fetal Doppler should assure that it is used in such an environment. Immunity Compliance Electromagnetic environment – test 60601 level guidance test level Radiated 3 V/m 3 V/m Portable mobile 80 MHz communications equipment to 2,5...
  • Page 22 NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
  • Page 23 For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
  • Page 24 Shenzhen Jumper Medical Equipment Co., Ltd. Address: D Building, No. 71, Xintian Road, Fuyong Street, Baoan,Shenzhen,Guangdong,China Tel:+86-755-26696279 Fax:+86-755-26852025 E-mail: info@jumper-medical.com Website: http://www.jumper-medical.com...
