TABLE OF CONTENTS

Safety Instructions ................................................. 3
General Information ............................................... 3
Installation ............................................................. 4
Initial Startup ......................................................... 4
Filter Assembly & Disassembly ............................... 5
Cartridge Cleaning Procedure ................................. 6
System Inspection & Winterizing............................ 6
Troubleshooting Guide ........................................... 7
Replacement Parts List ........................................... 8
PRESSURE DROP CURVE FOR PCCF MODELS
PCCF-075
Max Flow
Flow Rate in GPM (LPM)
Filter Area in Sq. Ft. (m )
2
Max. Residential Flow Rate GPM (LPM)
Max. Public Pool Flow Rate GPM (LPM)*
Max. Operating Pressure PSI (kPa)
Max. Continuous Water Temperature °F (°C)
*NSF listing is for public pool flow rates only.
2
PCCF-175
PCCF-200
Max Flow
Max Flow
PCCF-150
Max Flow
PCCF-125
Max Flow
PCCF-100
Max Flow
Table 1 - Filter Specifications
PCCF-075
75 (6.96)
75 (284)
28 (106)
50 (345)
104° (40°)
Minimum Service Height
41 1/8"
(1044.6mm)
2" NPT Inlet
30 3/8"
(771.5mm)
Figure 1 - Filter Dimensions in Inches (mm)
Model No.
PCCF-100 PCCF-125
100 (9.2) 125 (11.6)
100 (379) 125 (473)
37 (148) 47 (177)
50 (345) 50 (345)
104° (40°) 104° (40°)
SPECIFICATIONS
Air Relief Valve
Pressure Gauge
}
PCCF-125
Medium Size
PCCF-150
}
PCCF-175
Large Size
PCCF-200
}
PCCF-075
Small Size
PCCF-100
3/4" Drain
18"
(457.2mm)
12" (304.8mm)
6 7/8" 6 1/2"
(174.6mm) (165.1mm)
PCCF-150 PCCF-175
150 (13.9) 175 (16.2)
150 (568) 150 (568)
56 (212) 65 (246)
50 (345) 50 (345)
104° (40°) 104° (40°)
ProClean Ring
2" NPT Outlet
6 5/8"
(168.3mm)
3 7/8
(98.4mm)
PCCF-200
200 (18.6)
150 (568)
75 (284)
50 (345)
104° (40°)
