CARTRIDGE FILTER SYSTEMS
OWNER'S MANUAL
Installation • Operation • Parts
Designed,
Engineered &
Manufactured
in the USA.
2200 East Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403
www.waterwayplastics.com • waterway@waterwayplastics.com
©2024 Waterway Plastics
810-0183.0724

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROCLEAN PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Waterway PROCLEAN PLUS

  • Page 1 CARTRIDGE FILTER SYSTEMS OWNER’S MANUAL Installation • Operation • Parts Designed, Engineered & Manufactured in the USA. 2200 East Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403 www.waterwayplastics.com • waterway@waterwayplastics.com ©2024 Waterway Plastics 810-0183.0724...
  • Page 2 ASSEMBLY INSTRUCTIONS FOR PROCLEAN PLUS FILTERS Position of tube in body Pre-assembled filter Pressure Gauge Tube Cartridge Body Position of cartridge and tube Install pressure gauge following “Start/Service Dial Installation Instructions” in separate bag inside fitting package.
  • Page 3 ASSEMBLY INSTRUCTIONS FOR FILTER SYSTEM WITH ONE-PIECE BASE 1. Put the base on level ground. Place pump on base. 3. Place filter inside base. DO NOT insert snap pins through (secure) 2. Remove gasket from inside trap and place in union fitting. Thread trap onto pump.
  • Page 4 ASSEMBLY INSTRUCTIONS FOR HOSE ADAPTORS 1. Wrap 4 turns of Teflon tape on 417-6141 2. Thread onto pump trap inlet. 3. Wrap 4 turns of Teflon tape on 417-6161 hose adaptor. hose adaptor. 4. Thread onto filter outlet as shown. 5.
  • Page 5: Installation

    The Waterway Cartridge Filter is designed to filter water for swimming serious injury or major property damage if ignored. pools and hot tubs only. On a new installation, we recommend: warns about hazards that can or will cause death, 1.
  • Page 6: Initial Start-Up

    Use Teflon tape, Plasto-Joint Stik® or Silastic RTV #732® on all threaded 5. Start the pump to purge air from the system and stay clear at least 10 † connections of plastic pipe and fittings. feet from the filter. DO NOT use pipe compounds on filter; it will cause the 6.
  • Page 7: System Inspection

    DISASSEMBLY: pressure gauge reading increases 10 PSI over the start-up pressure. Follow all steps in the “Disassembly” section of this manual (page 6). 1. Stop the pump. 2. Open air release valve on top of filter tank to release all pressure from NOTICE: When sanitizing your pool using PHMB (polyhexamethylene inside of tank.
  • Page 8: Troubleshooting Guide

    WINTERIZING NOTICE: Protect the filter from freezing. Allowing the filter to freeze 4. Remove the drain plugs from the trap, pump and filter. will damage it and will void the warranty. If possible, take the system 5. Gravity drain system and filter as far as possible. indoors for storage.
  • Page 9 LIMITED WARRANTY Waterway Plastics manufactures its products and equipment in accordance with very high standards of workmanship. We use the best materials available and maintain the highest quality procedures practical in the industry. For Warranty, product must be registered at time of purchase/installation...
  • Page 10 PROCLEAN PLUS REPLACEMENT PARTS PROCLEAN PLUS CARTRIDGE FILTER REPLACEMENT PARTS Item Part No. Description Item Part No. Description 550-0611 Filter Lid & Handle Assembly – 75 - 100 sq. ft. (includes #1A - 1F) 550-0260 Drain Cap w/ Gasket Assy 550-0621 Filter Lid &...
