※ CAUTION※
1
Please do not look directly into the laser beam of barcode, or it
may do harm to your vision.
2
Touch screen is the most fragile parts, Please do not give a
direct impact on the screen or hit a scratch by sharp
objects which would make the device does not work.
3
When charging rechargeable adapter supplied to the other
dealer, Please check it if satisfy the standards of the
manufacture. Using an unsuitable adapter may occurs
electrical failure
.
4
AT870 have attained standards of lp65 , which required
waterproof and shockproof
o the product for leaking water.
5
Please do not disassemble or assemble the device or could
not get the guarantee repair
6
Please do not disassemble or assemble the device or could
not get the compensation repair
ATID Co., Ltd.
#1210, Byuksan/Gyungln Digital Valley II, #481-10,
Gasan-Dong, Gumchon-Gu, Seoul, Korea
Telephone: +82-2-544-1436
Fax: +82-2-2113-0040
http://www.atid1.com
,otherwise would bring damage t
AT-870
RF-ID
Bluetooth
(Rev. 1.2)

Advertisement

loading
Need help?

Need help?

Do you have a question about the AT-870 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Atid AT-870

  • Page 1 Please do not disassemble or assemble the device or could not get the guarantee repair Please do not disassemble or assemble the device or could not get the compensation repair ATID Co., Ltd. #1210, Byuksan/Gyungln Digital Valley II, #481-10, Gasan-Dong, Gumchon-Gu, Seoul, Korea Telephone: +82-2-544-1436 Fax: +82-2-2113-0040 http://www.atid1.com...
  • Page 2 ATID is a registered trademark of ATID Co., Ltd.. The ATID logo is a trademark of ATID . All other trademarks and trade names referred to herein are property of their respective owners. AT870 is a registered trademark of ATID Co., Ltd.. and of its wholly owned subsidiaries.
  • Page 3 ● Bluetooth Manager Reference Guide Your AT870 can optionally be built in with the Bluetooth Manager program to communicate with wireless printer. In the Bluetooth Stack Service, your AT870 only supports SPP (Serial Printer Profile) To make sure your Bluetooth device, keep these following tips in your mind. 1.1 To enable Bluetooth Bluetooth is not started by default after a clean-boot is performed.
  • Page 4 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth Printer. to start BT_Manager. Tap Start > Program > Tap BT_Manager Figure 1. Executing BT_Manager...
  • Page 5 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth SPP(ex Printer) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth exPrinter. to start BT_Manager. click open button for using BT_Manager Figure 2. Step-1 COM3,9600,Mode:1 Open Click...
  • Page 6 ● Bluetooth Manager Reference Guide 1.3 Bluetooth Printer(SPP) 연결하기 BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer. to start BT_Manager. Bluetooth device information: indicate current Bluetooth information Figure 3. Step-2 Device Information...
  • Page 7 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. After Scanning Device After the BT_Manager Scans Bluetooth SSP device, the information of scanned devise will be displayed on the screen Note: If the BT_Manager has found out the printer you want to use before the “OK”...
  • Page 8 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. Selecting Bluetooth Device From while SPP equipping which are searched must select the equipment which will use certainly Selection specified equipment information of equipment rises to hour cotton down...
  • Page 9 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. Connecting to Bluetooth Device Select one SSP equipment from scanned list. Click the Connect button to connect SSP equipment.
  • Page 10 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. Confirm the connection to Bluetooth Device If your PDA is connected to a printer, you can see the connection massage- “CONNECT xxxxxxxxx.
  • Page 11 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. ※ Mode Save Supporting two kinds of mode save way. Scan-0, Scan-1 indicates the status of whether could searching by PDA Or Bluetooth peripherals •...
  • Page 12 ● Bluetooth Manager Reference Guide 1.3 Connecting to Bluetooth Printer(SPP) BT-Manager is coded only for Hardware support to connect AT870 to a Bluetooth printer to start BT_Manager. ※ Save mode then exit program Apply(Exit) button: turn off BT_Manager while maintaining connection Power Off(Exit) button: turn off the power of BlueTooth(becomes disconnect )
  • Page 13 ● Bluetooth Manager Reference Guide 1.4 API Reference for Application Developer Your AT870 will get to be connected to a printer after the Step7. To control Bluetooth Printer with the user’s application, you should set your AT870 as COM3 and 9600bps rate. Application developer, if they need to make the program to control the Bluetooth printer, they must follow the below steps.
  • Page 14 ● Bluetooth Manager Reference Guide Ex ) .Net C# As shown in 10 figure, setting the properties of SerialPort, especially setting DtrEnable and RtsEnable value as True Figure 10. Step-1 COM3,9600,Mode:1 Open Click...
  • Page 15 ● Bluetooth Manager Reference Guide 1.5 Disconnecting Bluetooth Printer(SPP) from AT870 Use the BT_Manager to disconnect the Bluetooth printer from your AT870, when you are under the following case: • To close BT_Manager after it is connected to a printer. •If you don’t want to use the printer anymore, and stop to support power to the Bluetooth chip modulated in AT870 to save more power.
  • Page 16 ● Bluetooth Manager Reference Guide 1.5 Disconnecting Bluetooth Printer(SPP) from AT870 Tap Start > Program > Tap BT_Manager 1. Execute BT_Manager. 2. Click the Open button then searching and opening BaudRate automatically. 3. Click the DisConnect button you can connect your AT870 to Note : another printer after tapping the Figure 10.
