Product User's Guide
Ver. 2.0
Model : AT280
ATID Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT280 and is the answer not in the manual?

Questions and answers

Related Manuals for Atid AT280

Summary of Contents for Atid AT280

  • Page 1 Product User’s Guide Ver. 2.0 Model : AT280 ATID Co., Ltd...
  • Page 2 Disclaimer ATID is registered trade mark of ATID Co., Ltd. Si303, Si203, AT880, AT280 is registered trade mark of ATID Co., Ltd. All other trademarks and trade names referred to herein are property of their respective owners. Microsoft Windows®, Windows® 2000, Windows® CE .NET, Windows® NT, Windows®...

  • Page 3: Table Of Contents

    Table of Contents Copyright and Agreement ....................... 5 Chapter1. Caution when using ATID PDA Product ................6 1. How to use the battery correctly ....................6 2. Caution when using ATID PDA Product ..................6 Chapter2. Products compositions ....................7 1.
  • Page 4 3.3 Bixolon SPP-R200 Printer Demo ..................42 Chaptor5. Appendix ........................44 Specification with AT280 ......................44 User’s Guide...

  • Page 5: Copyright And Agreement

    Safety Information Read a nd fo llow all warnings an d c autions in t his m anual before y ou h andle a nd op erate ATID equipment. If you do not follow the safety warnings and cautions, you might be seriously injured, and the equipment and data are also might be damaged.

  • Page 6: Chapter1. Caution When Using Atid Pda Product

    If your AT280 has problem, do not try to repair or disassemble the p roduct arbitrarily, please  contact customer service center. Do n ot use y our AT280 where ha ve ele ctromagnetic wave or th e r isk ma y o ccur such a s  hospital, plane so on.

  • Page 7: Chapter2. Products Compositions

    Chapter2. Products compositions AT280 mobile computer is a small, ergonomically designed PDA, which built on the Microsoft window CE 5.0 Operating System. The PDA could equip with Barcode Scanner and so on devices as optional items. Its various function applied to Industry, Enterprise, Logistics and so on, can be used extensively in many fields.

  • Page 8: Each Part Name & Function

    2. Each Part Name & Function  MODEL : AT280 Power LED 1D/2D Scanner Window WLAN/BlueTooth LED Hand Strap Hole Touch Screen Function Button & Ear Jack UHF Connecting Port Volume Buttons Speaker Keypad Main Battery Battery Latch Reset Button...
  • Page 9 Part Descriptions 1D/2D Scanner Window Laser beam emitted through this window. Please be careful the foreign substances and (Option) preventing from the damage. Warning! Do not look at the laser beam directly. UHF Connecting Port Enable you to install a UHF 900Mhz tag reader module. Enable you to perform a Warm Reset, Press <Power>button simultaneously, enable you to Reset Button perform a Hard Reset.

  • Page 10: Chapter3. Basic Functions

    1. Power and Battery AT280 battery is composed of main battery and backup battery. A main battery supplies the power to the system and RAM which could keep save the data. A backup battery could keep save the data of RAM when the main battery discharged completely.
  • Page 11  Power off automatically The device has been powered but has not been used for a period of time, then the system will enter low-power mode (sleep mode) automatically. You could set the sleep mode time at the power management so that could save power and prolog the battery life. [Start Button] ->...

  • Page 12: Checking Battery Gauge

    1.2 Check ing Battery Gauge Note:  Battery life is largely affected from the user using method and surrounding environments. A 2200mA battery is usually needs 6 ~ 12 hours to get charged completely.  Checking Battery Gauge [Start Button] -> [Setting] -> [Control Panel] -> [Power Management] -> [Battery] ...

  • Page 13: Backup Battery

    1.3 Ba ckup Battery A backup battery could safely keep the RAM data, even the main battery discharged completely. Caution: If the main battery and the backup battery are both discharged, the RAM date will disappear. Among the running programs, the RAM data will disappear in which are using, and the system will not be restore to previous state, but rebooting system after start charging.

  • Page 14: System Reset

    2. System Reset If there is no response from the system or an application is locked up and stops responding, and when you want to upgrade the firmware, reset the system is maybe necessary. 2.1 Sof t Reset When do you need to perform Soft Reset? If there is no response for your command from the system, it calls (Hang-up).

  • Page 15: Initializing System

    2.3 In itializing System Enter [Boot Menu] and do what you want, when in the situations as below: 1. When you need to restore the original registry information, which has been changed. 2. When you need to initialize “My device” storage spaces. 3.

  • Page 16: Using Micro Sd Card

    3. Using Micro SD Card The image as below is battery compartment of AT280, and there are 1EA SIM C ard Slot, 1EA SAM Card Slot(Option) and 1EA Micro SD Card Slot. 1 Micro SD Card Slot You can find the Micro SD Memory Card icon when executing the file explorer, after the Micro...

  • Page 17: System Settings

    4. System Settings 4.1 S etting Brightness Brightness is already set 80% at the factory, and brightness is the biggest consume part of the power, so you might need to adjust it to your actual need. [Setting Brightness] 1. [Start Button] -> [Setting] -> [Control Panel] -> [Brightness] 2.

  • Page 18: Setting Volume And Sounds

    4.3 Setting Volume and Sounds Volumes is already set 80% at the factory, and you can readjust you need volume at control panel ->”Volume and Sounds” Setting Volume and Sounds [Start Button] –> [Setting] -> [Control Panel] -> [Volume and Sounds] 4.4 Setting Data and Time [Start Button] ->...
  • Page 19 Setting Month: Setting Day: Double Click the Month or Click the day directly to set Click L/R arrow button to set day. Month. Setting Time: Setting Time Zone: Click AM/PM, Time area Click up and down arrow directly, using up and down direction to select time zone arrow button to set Time.

  • Page 20: Using Keypad

    5. Using keypad Keypad enables you to input numbers, alphabets and special symbols. And can also execute other set function with <Fun> button. 5.1 Us ing keypad If you’d like to change the current input language, can press <ALP> button as below steps: [Numeric] ->...

  • Page 21: Using Button

    5.3 Usi ng <Fun> Button Press <Fun> button and other buttons simultaneously can activate functions as below: Fun + button Descriptions Enable you t o canc el th e se lected co mmand or th e pro grams operating or <1>...

  • Page 22: Using Activesync Program

    7. Using ActiveSync Program ActiveSync p rogram cou ld synchr onize be tween th e PC and PDA de vice, so tha t ena ble you to perform program installing, copy, transition, delete and so on operations. 7.1 Installing Microsoft ActiveSync Program Download the late st ver sion of Active Sync program from Microsoft Windows CE.

  • Page 23: Connecting Pc To Pda

    7.2 Connecting PC to PDA Setting PC [Start button] -> [Programs] -> [Microsoft ActiveSync] Executing Microsoft ActiveSync program Click [File], Click [Get Connected]. Select <Allow USB connection with ActiveSync connected to PDA this desktop computer>, press OK button. User’s Guide...

  • Page 24: Transmitting Data

    Setting AT280 PDA [Start Button] -> [Setting] -> [Control Panel] -> [PC Connection] Double click PC Connection icon To check if set to connected to USB Sync cable 7.3 Transmi tting Data Connect USB cable to PC or Device. 현재 이 이미지를 표시할 수 없습니다...
  • Page 25 After ActiveSync connected, click Designate transmitting file path. Explore button. Transmit files. User’s Guide...

  • Page 26: Firmware Upgrade

    8. Firmware Upgrade [Start Button] -> [Setting] -> [Control Panel] -> [Firmware Upgrade] User’s Guide...

  • Page 27: Chapter4. Optional Module

    Chapter4. Optional Module AT280 provided variety of optional modules and in this chapter will provide you the information of each module. Optional modules as below: 1. B arcode Scanner -. 1D Laser Barcode Scanner -. 2D Imager Barcode Scanner Wireless LAN – 802.11 b/g 3.

  • Page 28: D Or 2D Barcode Scanner

    1. 1D or 2D Barcode Scanner AT280 enable to equip with a compact image engine, which could recognize all the 1D and 2D barcodes. 1.1 Scanning Barcode Press Scan Buttons to Read Start Button/Programs/Demo Barcode. Apps/Scanner/BarcodeDemo 1.2 Setting Barcode Emulator...
  • Page 29 Executing Barcode Emulator [Start Button] -> [Program] -> [Demo Apps] -> [Scanner] -> [BarcodeEmulator] Run Barcode Emulator Program Barcode Emulator Icon will be showed on the taskbar. Run WordPad Program, then Result Type click the Emulator Icon Keyboard Event: Barcode inputted one by one.
  • Page 30 Terminator Key Setup None:Not input terminal F1-F8 Key: Hardware Keypad barcode value. Gun1, Gun2: Gun Trigger CRLF: Barcode value will include an “Enter” Space: Barcode value will include a “Space” Tab: Inputting type as same as Tab Key Function. Sound: Set sound ON/OFF after scanned barcode Vibrator:...

  • Page 31: Setting Barcode Symbology

    1.3 Setting Barcode Symbology AT280 enables you to set the various barcode by using barcode symbologies program. [Start Button] -> [Program] -> [Demo Apps] -> [Scanner] -> [BarcodeSetup] BarcodeSetup Program. Set Barcode Type in detail. Click Set Enable Status button...

  • Page 32: Barcode Scanning Beam Position

    2D Symbology Selection: 1D Symbology selection: 1. Initialize all the symbologies to 1. Initialize all the symbologies to factory default value. factory default value. 2. Unable read 2. Unable read symbologies. symbologies. 3. Enable read 3. Enable read symbologies. symbologies. 4.
  • Page 33 [Correct Scanning Beam Position] 1. The more small size of barcode, AT280 needs the more close to barcode. The effective scanning rang of Si303 is from 40 ~ 300mm. if failed to scan barcode, please try to adjust scan angle and distance.

  • Page 34: Using Wireless Lan

    2. Using Wireless Lan AT280 enable to equip an internal 802.11 radio module to transfer data and do wireless communication. AT280 supports TCP/IP network protocol, and communicate with a host computer directly. Connecting to Wlan [Start Button] -> [Program] -> [Demo Apps] -> [Wireless Lan] Run the Wireless LAN program.

  • Page 35: Checking Wlan Information

    Checking WLAN Information Double click WLAN icon on the taskbar Start Button/Programs/ATID to check Wlan information. App/Wireless Lan, and then select <WLAN OFF> to stop Wlan communication.  Note: The Wlan LED will changed to green and the Wlan icon on the taskbar will be lighted on ,if failed the Wlan icon will be light off User’s Guide...

  • Page 36: Using Bluetooth

    3. Using Bluetooth This User Guide is only applied to the AT280 which installed "MD6RF" module. AT280 not only supports to the SPP printer device like as AT870/AT570, but also supports Bluetooth Stack Service of Windows CE. This Chapter described how to Pairing and Disc onnecting between and Bluetooth devices, and also described basic testing method of Mobile Printer SPR-R203, which launched by Bixolon, as a sample device.
  • Page 37 Select “Bluetooth ON” item, then press OK button. C. After Bluetooth executed, the Bluetooth BTPAN1 icon will be appeared on the bottom of Windows Taskbar, and the red cross mark on it shows that you access is available and prepared to be accessed. User’s Guide...
  • Page 38 2. Blueto oth Function Closing Executing “Bluetooth” demo App from Windows CE Menu. Select “Bluetooth OFF”, then to press OK button to off the Bluetooth power. User’s Guide...

  • Page 39: Bluetooth Pairing

    3.2 Bluetooth Pairing After connecting each o ther throu gh pairing way, Bluetooth d evices cou ld do its function properly. 1. Executing Bluetooth program as below path. Start->Settings->Control Panel->Bluetooth Device Properties -> 2. Press “Scan Device” button to searching devices which could pairing. User’s Guide...
  • Page 40 3. Depending on the situ ation, maybe n eed to input password for some devices, the n co uld search devices continually. According to the devices need, some devices have to input Pin Code (password) firstly. SPP-R200 printer factory setting Pin Code is “0000”. 4.
  • Page 41 5. Double click you r device name, click “Trusted” Tab to ad d the device to the pairing items, then click “Yes” button to ending the Bluetooth Manager. -> -> You can set the Password (Authentication code) according to the each device. The Red Cross mark(X) on the Key icon will disappear if finished to registration.

  • Page 42: Bixolon Spp-R200 Printer Demo

    6. Click “Active” button to active the paired device. 7. Then, you can perform the data communication through COM2 Port. 8. After pairing and active the Bluetooth device, you can use the Device driver, S/W, and SDK, which provided from the Bluetooth device manufacturer, to perform the relevant Bluetooth function.
  • Page 43 11. Change the COM8 to COM2, then press “Open” button to testing printer. User’s Guide...

  • Page 44: Chaptor5. Appendix

    Chaptor5. Appendix Specification with AT280 Physical and Environmental Characteristics Dimension 53.5mm(L) X 146.9mm(W) X 32.2mm(H) Weight 320g Operation Temperature -10℃ ~ 50℃ Storage Temperature -30℃ ~ 60℃ Humidity Non-condensing Drop 1.5m drop to concrete Performance Characteristics Processor Marvell™ PXA320 806MHz Operating System Windows CE 5.0...
