- Page 1 ATD100N USER GUIDE ATID Co.,Ltd Ver 0.1...
-
Page 2: Table Of Contents
USING THE WINDOWS HOST DEMO APPLICATION ................10 SDK (SOFTWARE DEVELOPMENT KIT)....................11 PRODUCT WARRANTY ..........................12 ATD100N P ............................12 RODUCT ETAILS SDK D ................................12 OWNLOAD ........................12 ARRANTY AND ECHNICAL UPPORT ................................12 ERTIFICATIONS ATD100N User Guide... -
Page 3: Before The Beginning
Before the Beginning The objective of user guide is to pass the basic contents related with ATD100N`s maintenance and smooth uses. User guide inclusive of text, images, logos, product name may not be distributed, modified, displayed, reproduced (in whole or in part) without the prior written permission of ATID Co,.Ltd. -
Page 4: Key Features
Using the USB cable installed in the device, it is possible to connect to a Host device to operate and transmit data. It is possible to check the operation status of the device through the LED and buzzer. Support HID (Human Interface Device) mode. ATD100N User Guide... -
Page 5: Product Specification
Frequency Range KR / KC : 917MHz ~ 921MHz JP / TELEC : 920MHz ~ 923MHz (0.2W) Antenna Circular Antenna / 2.2 dBic User Environment Operating Temp -10°C to 50°C Storage Temp -30°C to 70°C Humidity 5~95% (non-condensing) ATD100N User Guide... -
Page 6: Configuration Of The Product
2) Status LED 2 : LED indicating the status of the product. 3) Mode Setting Switch : The operation mode of ATD100N is set according to the switch setting as shown table below. If user changes the operation mode, the setting is applied as the product reboots. -
Page 7: Usb Cable
USB cable connection. USB TYPE-A 3. UHF Antenna The antenna of ATD100N is located in the center of the product. The closer the tag is located at the center of the product, the higher the recognition rate. UHF Antenna Two types of antennas (866MHzk, 912MHz) are supported according to each country's frequency range. -
Page 8: Operation Guide
1. Serial Mode When the device is set to Serial mode, the device uses the ATID protocol to communicate with the HOST device in a command. In order to connect the host device to the device, a demo program provided by ATID or a program developed using SDK is required. -
Page 9: Hid (Human Interface Devices) Mode
3. HID (Human Interface Devices) mode When the ATD100N is set to HID mode, the device transmits the collected EPC data to the host in HEX format. In this case, open a program that can create documents (txt, docx, xlsx, etc.) and place the cursor on the program to display the collected data. -
Page 10: Using The Windows Host Demo Application
To connect ATD100N and Windows Host device, connect via USB. 2) User can install the demo app included in the SDK on the host device. For details on how to use the Windows demo application, refer to the ‘ATID Reader Demo Guide for Windows’ document included in the SDK. -
Page 11: Sdk (Software Development Kit)
SDK (Software Development Kit) In order to utilize the data transmitted to the host device, a separate program must be developed referring to the SDK provided by ATID. Platform Development Tool Development Language Windows Visual Studio .NET Framework (C#), UWP (C#) -
Page 12: Product Warranty
If you need an ATD100N SDK, please contact us or the place of purchase. Warranty and Technical Support All ATID products can be repaired free of charge for one year based on the product manufacturing date. However, in principle, any defects caused by customer carelessness in use shall be repaired even during the free repair period.
