We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
EVERAINE 52-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
improvement needs. Thank you for choosing Home Decorators Collection!
THANK YOU
Item #1005 806 050
Model #52111
UL Model #52-LION
Advertisement
Related Manuals for Home Decorators Collection 52111
Summary of Contents for Home Decorators Collection 52111
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................13 Warranty ................3 Care and Cleaning ............. 14 Pre-Installation ..............3 Troubleshooting ..............14 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as To reduce the risk of electric shock, ensure the electricity has... -
Page 3: Warranty
Warranty The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The supplier warrants that the light kit, excluding any glass, to be free from defects in workmanship and material at the time of shipment from the factory for a period of five years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Blade attachment screws Plastic wire connector...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket (inside canopy) Light kit pan Ball/downrod assembly Light kit fitter assembly Canopy Shatter resistant bowl Decorative motor collar cover Receiver Fan-motor assembly Remote control Blade 3-pin extension wire 2-pin extension wire IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock, proper blade clearance when installing on a steep, sloped or personal injury, mount the fan to an outlet box ceiling. - Page 7 Assembly - Standard Ceiling Mount Preparation for standard mounting Routing the wires □ □ Remove the magnetic canopy bottom cover (DD) from the Route the wires exiting the top of the fan motor assembly canopy (C) by pulling it off. (E) through the decorative motor collar cover (D) and then □...
- Page 8 Assembly - Hanging the Fan Attaching the fan to the electrical Hanging the fan □ Carefully lift the fan-motor assembly (E) up to the slide-on WARNING: To reduce the risk of fire, electric shock, or other mounting bracket (A). personal injury, mount the fan to an outlet box or supporting □...
-
Page 9: Assembly
Assembly - Hanging the Fan (continued) Wiring the receiver to the household Installing the receiver wiring WARNING: To reduce the risk of fire or electric shock, WARNING: To avoid possible electrical shock, turn the remember to disconnect power. The electrical wiring must electricity off at the main fuse box before wiring. - Page 10 Assembly - Hanging the Fan (continued) Wiring the fan to the receiver Mounting the fan-motor assembly NOTE: The fan comes with 12 in. lead wires for use with the WARNING: When using the standard ball/downrod mounting, provided 6 in. ball downrod assembly (B), if you wish to use the tab in the ring at the bottom of the mounting bracket longer downrod, you can use the extension lead wire (42 in.) (M) must rest in the groove of the hanger ball.
- Page 11 Assembly - Attaching the Blades Attaching the fan blades □ To attach the blade (F) to the the fan motor assembly (E), align the two screw holes in the blade with the screw holes on the motor assembly (E) and secure the blades with blade attachment screws (AA).
- Page 12 Assembly - Attaching the Light Kit Attaching the light kit fitter assembly CAUTION: To reduce the risk of electric shock, disconnect the electrical supply circuit to the fan before installing the light kit pan. □ Remove the three screws (SS) from the light kit pan (G). □...
- Page 13 Preparing the Remote Control NOTE: The remote control has already been paired to the ceiling fan for your convenience. If you have two of the same model fans in your home, please follow the steps below to control each fan independently.
- Page 14 Operating Your Fan and Remote Control POWER ON/OFF Power Press and release the power button to turn the fan and light on or off. (fan and light on/off) NOTE: On start up your ceiling fan will oscillate back and forth. This is NORMAL OPERATION for DC ceiling fans as it goes through its calibration cycle.
-
Page 15: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 16 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
